Installation Manual
SchwankAir 3200-Recessed Series
SchwankAir
The curtains shown herein are licensed to bear the AMCA Seal. The ratings shown are based on tests and
procedures performed in accordance with AMCA Publication 211 and AMCA Publication 311 and comply
with the requirements of the AMCA Certied Ratings Program. The AMCA Certied Ratings Seal applies to
airow rate, average outlet velocity, outlet velocity uniformity, velocity projection and power rating at free
delivery only.

schwankgroup.com/schwankair
Technical Specication
1. Highest airow at 3 fan speed.
2. Values shown are for total sound power levels for Installation Type A: free inlet, free outlet.
3. The Sound power level ratings shown are in decibels, referred to 10-12 watts, calculated per AMCA
Standard 301.
4. FLA: total amperage for motor and heat.
5. Applicable at water temperature 140/104F, air temperature, in +64F.
Above table is valid for 208V/1ph/60Hz. Also approved for 230V/1ph/60Hz. Product performance for
230V/1ph/60Hz will differ from stated data.
Protection class for units with electrical heating: [TE] IP20.
Protection class for units without electric heating and units with water heating: [TW] IP21.
1Ambient, no heat - [IP21]
Model Output
[MBH]
Airow*1
[CFM]
Sound power*2
[dB[A]]
Sound Pressure
[dB[A]]
Motor
power [W]
Voltage
motor [V]
Amperage
motor [A]
Weight [lb]
AC-TA36-23-R 0 950 72 54 127 208V~ 0.8 64
AC-TA60-23-R 0 1350 73 55 148 208V~ 0.9 87
AC-TA72-23-R 0 1900 74 56 254 208V~ 1.5 121
3Electrical heat - [IP20]
Model Output
[kW]
Airow*1
[CFM]
Sound
power*2
[dB[A]]
Sound
Pressure
[dB[A]]
FLA [full load
amperage]*3
[A]
Motor
power
[W]
Amperage
motor
[A]
Voltage [V]
Amperage
[A] [heat]
Weight
[lb]
AC-TE36-20-R 4/7 950 72 54 21 127 0.8 208V3~/20 68
AC-TE60-20-R 7/10 1350 73 55 29 148 0.9 208V3~/28 91
AC-TE72-20-R 8/13 1900 74 56 39 254 1.5 208V3~/36 130
AC-TE36-48-R 5/8 950 72 54 11 127 0.8 480V3~/10 68
AC-TE60-48-R 8/12 1350 73 55 16 148 0.9 480V3~/15 91
AC-TE72-48-R 10/16 1900 74 56 21 254 1.5 480V3~/20 130
AC-TE36-60-R 5/8 950 72 54 9 127 0.8 600V3~/8 68
AC-TE60-60-R 8/12 1350 73 55 13 148 0.9 600V3~/12 91
AC-TE72-60-R 10/16 1900 74 56 17 254 1.5 600V3~/16 130
Model Output*4
[MBH]
Airow*1
[CFM]
Sound
power*2
[dB[A]]
Sound
Pressure
[dB[A]]
Motor
power
[W]
Voltage
motor
[V]
Amperage
motor
[A]
Water
volume
[US gal]
Weight
[lb]
AC-TW36-23-R 27 750 72 54 127 208V~ 0.8 0.34 65
AC-TW60-23-R 48 1200 73 55 148 208V~ 0.9 0.55 90
AC-TW72-23-R 65 1500 74 56 254 208V~ 1.5 0.71 123
2Water heat - [IP21]
The air curtains shown herein are licensed to bear the AMCA Seal. The ratings shown are based on tests
and procedures performed in accordance with AMCA Publication 211 and AMCA Publication 311 and
comply with the requirements of the AMCA Certied Ratings Program. The AMCA Certied Ratings Seal
applies to airow rate, average outlet velocity, outlet velocity uniformity, velocity projection and power
rating at free delivery only.

schwankgroup.com/schwankair
Model Nozzle
width x depth [in]
Max Velocity
at nozzle [fpm]
Outlet Velocity
[fpm]
Outlet Velocity
Uniformity [%]
AC-TA36-23-R 38.2X2.8 2159 1870 78
AC-TE36-20[48][60]-R 38.2X2.8 2159 1870 78
AC-TW36-23-R 38.2X2.8 2159 1870 78
AC-TA60-23-R 58.5X2.8 2018 1850 83
AC-TE60-20[48][60]-R 58.5X2.8 2018 1850 83
AC-TW60-23-R 58.5X2.8 2018 1850 83
AC-TA72-23-R 78.7x2.8 2159 1870 78
AC-TE72-20[48][60]-R 78.7x2.8 2159 1870 78
AC-TW72-23-R 78.7x2.8 2159 1870 78
Model Fan
Speed
Airow
[CFM]
Output
[MBH]
Return water
temp. [°F]
Water ow
[GPM]
Pressure
drop [kPa]
Output*2
[MBH]
Outlet air
temp. [°F]
Water
ow [GPM]
Pressure
drop [kPa]
AC-TW36-23-R max 750 30.0 95 0.79 2.4 48.1 115 2.70 23.7
AC-TW60-23-R max 1200 51.9 91 1.27 8.5 83.6 115 4.75 92.3
AC-TW72-23-R max 1500 62.1 90 1.43 4.9 104.1 117 5.87 60.7
Technical Specication
Model Fan
Speed
Airow
[CFM]
Output
[MBH]
Return water
temp. [°F]
Water ow
[GPM]
Pressure
drop [kPa]
Output*2
[MBH]
Outlet air
temp. [°F]
Water ow
[GPM]
Pressure
drop [kPa]
AC-TW36-23-R max 750 30.0 109 1.90 14.0 28.0 93 1.56 9.2
AC-TW60-23-R max 1200 51.9 108 3.17 48.5 49.1 93 2.70 37.2
AC-TW72-23-R max 1500 62.1 106 3.64 27.5 61.1 95 3.49 24.1
1. Recommended outlet air temperature for good comfort and optimized output.
2. Nominal output at given supply and return water temperature.
Supply water temperature: 176 °F
Room temperature: +64 °F
Outlet air temperature: +95 °F*1
Water temperature: 176/140 °F
Room temperature: +64 °F
Supply water temperature: 140 °F
Room temperature: +64 °F
Outlet air temperature: +95 °F*1
Water temperature: 140/104 °F
Room temperature: +64 °F

schwankgroup.com/schwankair
The introduction pages consist mainly of pictures.
For translation of the English texts used, see the respective language pages.
EN
Les pages de présentation contiennent principalement des images.
Pour la traduction des textes en anglais, consultez la page correspondante à
la langue souhaitée.
FR

schwankgroup.com/schwankair
ø
ø
A / B / C
D / E / F
G
G
J
L
N
M
HH
KI
3.3 ft: 4 x M8
4.9 ft: 4 x M8
6.6 ft: 6 x M8
Ref [inch] Model
A43.12 AC-TA36-23-R
AC-TE36-20[48][60]-R
AC-TW36-23-R
B63.52 AC-TA60-23-R
AC-TE60-20[48][60]-R
AC-TW60-23-R
C83.12 AC-TA72-23-R
AC-TE72-20[48][60]-R
AC-TW72-23-R
D41.12 AC-TA36-23-R
AC-TE36-20[48][60]-R
AC-TW36-23-R
E61.52 AC-TA60-23-R
AC-TE60-20[48][60]-R
AC-TW60-23-R
Ref [inch] Model
F81.12 AC-TA72-23-R
AC-TE72-20[48][60]-R
AC-TW72-23-R
G1.16 All Models
H3.6 All Models
I2.04 All Models
J5.4 All Models
K2.8 All Models
L19 All Models
M10.24 All Models
N21 All Models
All Models
Dimensions

schwankgroup.com/schwankair
244
134
933 805
156
525
66
805 / 1315
157
All 72" Recessed Models
All 36" & 60" Recessed Models
Front view
Side view
A / B
C
E
J
I
GH
F
D
Mounting on threaded bars outside the unit
Ref [inch] Model
A32.20 AC-TA36-23-R
AC-TE36-20[48][60]-R
AC-TW36-23-R
B52.60 AC-TA60-23-R
AC-TE60-20[48][60]-R
AC-TW60-23-R
C2.64 All Models
Ref [inch] Model
D6.28 All Models
E37.32 All Models
F32.2 All Models
G5.36 All Models
H6.24 All Models
I21 All Models
J9.76 All Models

schwankgroup.com/schwankair
Fig. 1b. Mounting on threaded bars outside the unit.
Fig. 1a: Mounting brackets on delivery.
For 72" Models
Mounting on threaded bars outside the unit

schwankgroup.com/schwankair
Fig. 2a: Mounting brackets on delivery.
Top view
All 36" & 60" Models
124
392
E/A: 932
W: 848
E/A: 851
W: 935
121
124
850 / 1360
54
88
All 72" Models
A / B
E
G
F
H
C
IJ
K
Mounting on threaded bars inside the unit
Ref [inch] Model
A34.00 AC-TA36-23-R
AC-TE36-20[48][60]-R
AC-TW36-23-R
B54.4 AC-TA60-23-R
AC-TE60-20[48][60]-R
AC-TW60-23-R
C2.16 All Models
D4.96 All Models
E34.04 AC-TA72-23-R
AC-TE72-20[48][60]-R
Ref [inch] Model
F37.28 AC-TA72-23-R
AC-TE72-20[48][60]-R
G37.4 All Models
H33.92 All Models
I4.84 All Models
J4.96 All Models
K15.68 All Models
L3.52 All Models
Side view
J
I

schwankgroup.com/schwankair
Fig. 2c. Location of the mounting brackets on the inside of the unit.
Fig. 2d. In order to mount the brackets, remove the service hatch, outlet grille and covering plates.
For 72" Models
Fig. 2b. Mounting on threaded bars inside the unit.
Mounting on threaded bars inside the unit
36" 4x
60" 4x
72" 6x

schwankgroup.com/schwankair
Fig. 3a: Snap xings
2.
1.
1.
2.
90°
Service hatch
Fig. 3b: Open the unit.
Fig. 4: Terminal box and control panel inside unit.

schwankgroup.com/schwankair
Accessories
JC-0754-15/20 - Threaded Rods for Ceiling Mount [3.3ft]
JC-0706-15/20 - V Shaped Ceiling Brackets for Wire
Suspension or Vibration Dampeners
JC-0709-15/20 - Vibration Dampeners
JC-0752-XX
Water Heated Plumbing Kit
Nipple
JC-0754-15/20 JC-0706-15/20JC-0709-15/20
JC-0752-XX - 3/4 Plumbing Kit for Water Heated Models
Kit includes:
• Valve kit: TAC, pressure independent regulation
and adjustment valve + shut off valve
• Nipple connection for valve, female thread [x2]
• Actuator ON/OFF 230V
• Bypass valve

schwankgroup.com/schwankair
5A x 3
N H1H2
N
1
On Off
F1 F2 F3
on/off 2
N
LPE N L
PE
~
6 5 4 2 31 ALPE N
SENSOR
208V1~
0 -10V
Only water
N L
1L EP
L2
L3
N
L
1L EP
3L 2L
Blue Yellow
Red
White
M
~
M
~~ ~
Left motor Right motor
6 5 4 2 31 ALPE N
Red / +10 V
Yellow / 0-10
Blue / GND
White / Tach
0 - 10V
DOOR
AFTER
WATER
5A
16A
EP 2L1L
Only 72” version
L1
L2
L3
L3
L1
L2
Over heat
cut-out
°C
N H1H2
N
1
On Off
F1 F2 F3
2
N
L
0 - 10V
DOOR
AFTER
WATER
PE N L
PE
~
C1
L1
L2
L3
L3
L1
L2
C2
L3
L2
L1
a1
a2
b2
c2
c1
b1
L3
L2
L1
a1
a2
b2
c2
c1
b1
°C
Over heat
cut-out
L1
L2
L3
L3
L1
L2
C3
L1
L2
L3
L3
L1
L2
C4
L3
L2
L1
a1
a2
b2
c2
c1
b1
L3
L2
L1
a1
a2
b2
c2
c1
b1
208V3~
0 -10V
6 5 4 2 31 ALPE N
M
~
M
~~ ~
Left motor Right motor
65 4 2 31 ALPE N
Blue
Yellow
Red
White
Red / +10 V
Yellow / 0-10
Blue / GND
White / Tach
Only 72” version
5A x 3
5A
16A
on/off
SENSOR
1L EP
L2
L3
Wiring Diagram - SchwankAir 3200 Recessed
Ambient & Hot Water

schwankgroup.com/schwankair
L1
L2
L3
L3
L1
L2
Over heat
cut-out
°C
N H1H2
N
1
On
Off
F1 F2 F3
2
N
L
0 - 10V
DOOR
AFTER
WATER
PE N L
PE
~
C1
L1
L2
L3
L3
L1
L2
C2
L3
L2
L1
a1
a2
b2
c2
c1
b1
L3
L2
L1
a1
a2
b2
c2
c1
b1
°C
Over heat
cut-out
L1
L2
L3
L3
L1
L2
C3
L1
L2
L3
L3
L1
L2
C4
L3
L2
L1
a1
a2
b2
c2
c1
b1
L3
L2
L1
a1
a2
b2
c2
c1
b1
208V3~
0 -10V
6 5 4 2 31 ALPE N
M
~
M
~~ ~
Left motor Right motor
6542 31 A
LPE N
Blue
Yellow
Red
White
Red / +10 V
Yellow / 0-10
Blue / GND
White / Tach
Only 72” version
5A x 3
5A
16A
on/off
SENSOR
1L EP
L2
L3
Wiring Diagram - SchwankAir 3200 Recessed
Electric Heated 208V

schwankgroup.com/schwankair
Transformer 600V /480V - 230V
L1
L2
L3
Over heat cut-out
°C
N H1H2
N
1
On
Off
F1 F2 F3
2
N
L
0 - 10V DOOR
A FTE R
WATER
PE N L
PE
~
C1
L1
L2
L3
C2
°C
Over heat cut-out
L1
L2
L3
C3
L1
L2
L3
C4
0 -10V
1L EP
3L 2L
6 5 4 2 31 ALPE N
M
~
M
~~ ~
Left motor Right motor
6 5 4 2 31 ALPE N
Blue
Yellow
Red
White
Red / +10 V
Yellow / 0-10
Blue / GND
White / Tach
Only 72” version
5A x 3
5A
16A
on/off
S E NSOR
600V3~/480V3~
2 x 10AFUSE
Wiring Diagram - SchwankAir 3200 Recessed
Electric Heated 480V/600V

SchwankAir 3200R Series - Ambient
Item Description Part # Model #
115 3200 Air Curtain Lock Pin [Recessed] JC-0543-XX AC-TA36-23-R
AC-TA60-23-R
AC-TA72-23-R
110 3200 Air Curtain Lock Pin [Recessed] JC-0543-XX AC-TA36-23-R
AC-TA60-23-R
AC-TA72-23-R
105 3200 Air Curtain Lock Pin [Recessed] JC-0543-XX AC-TA36-23-R
AC-TA60-23-R
AC-TA72-23-R
100 3200 Air Curtain Inspection Casing 36” [Recessed] JC-0577-10 AC-TA36-23-R
3200 Air Curtain Inspection Casing 60” [Recessed] JC-0577-15 AC-TA60-23-R
3200 Air Curtain Inspection Casing 72” [Recessed] JC-0577-20 AC-TA72-23-R
95 3200 Air Curtain Front Cover 36” [Recessed] JC-0545-10 AC-TA36-23-R
3200 Air Curtain Front Cover 60” [Recessed] JC-0545-15 AC-TA60-23-R
3200 Air Curtain Front Cover 72” [Recessed] JC-0545-20 AC-TA72-23-R
65 3200 Air Curtain PCB. JC-0507-XX AC-TA36-23-R
AC-TA60-23-R
AC-TA72-23-R
Replacement parts list

schwankgroup.com/schwankair
40 3200 Air Curtain Impellor-R 36” & 72” [Surface & Recessed] JC-0502-10 AC-TA36-23-R
3200 Air Curtain Impellor-R 60” [Surface & Recessed] JC-0502-15 AC-TA60-23-R
35 3200 Air Curtain Impellor-L 60” & 72” [Surface & Recessed] JC-0502-20 AC-TA72-23-R
30 3200 Air Curtain EC Motor Left 72” JC-0503-20 AC-TA72-23-R
25 3200 Air Curtain EC Motor Right 36” JC-0503-10 AC-TA36-23-R
3200 Air Curtain EC Motor 60” JC-0503-15 AC-TA60-23-R
15 3200 Air Curtain Nozzle Grill 36” JC-0504-10 AC-TA36-23-R
3200 Air Curtain Nozzle Grill 60” JC-0504-15 AC-TA60-23-R
3200 Air Curtain Nozzle Grill 72” JC-0504-20 AC-TA72-23-R
10 3200 Air Curtain Nozzle Bracket JC-0505-XX AC-TA36-23-R
AC-TA60-23-R
AC-TA72-23-R
5 3200 Air Curtain Nozzle Bracket Holder JC-0573-XX AC-TA36-23-R
AC-TA60-23-R
AC-TA72-23-R

SchwankAir 3200R Series - Electric
schwankgroup.com/schwankair
Item Description Part # Model #
115 3200 Air Curtain Lock Pin [Recessed] JC-0543-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
Replacement parts list

110 3200 Air Curtain Lock Pin [Recessed] JC-0543-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
105 3200 Air Curtain Lock Pin [Recessed] JC-0543-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
100 3200 Air Curtain Inspection Casing 36” [Recessed] JC-0577-10 AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
3200 Air Curtain Inspection Casing 60” [Recessed] JC-0577-15 AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
3200 Air Curtain Inspection Casing 72” [Recessed] JC-0577-20 AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
95 3200 Air Curtain Front Cover 36” [Recessed] JC-0545-10 AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
3200 Air Curtain Front Cover 60” [Recessed] JC-0545-15 AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
3200 Air Curtain Front Cover 72” [Recessed] JC-0545-20 AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
50 3200 Air Curtain Transformer JC-0521-XX 3200 Air Curtain Transformer
65 3200 Air Curtain PCB. JC-0507-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R

AC-TE72-48-R
AC-TE72-60-R
60 Air Curtain Thermal Cut-Off Electric Heated JC-0529-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
55 3200 Air Curtain Heating Rod - 208V 36” Back JC-0560-XX AC-TE36-20-R
3200 Air Curtain Heating Rod - 208V 36” Front JC-0526-XX AC-TE36-48-R
3200 Air Curtain Heating Rod - 208V 60” Front JC-0527-XX AC-TE36-60-R
3200 Air Curtain Heating Rod - 208V 60” Back JC-0528-XX AC-TE60-20-R
3200 Air Curtain Heating Rod - 347V 36” Back JC-0522-XX AC-TE60-48-R
3200 Air Curtain Heating Rod - 347V 36” Front JC-0523-XX AC-TE60-60-R
3200 Air Curtain Heating Rod - 347V 60” Back JC-0524-XX AC-TE72-20-R
3200 Air Curtain Heating Rod - 347V 60” Front JC-0525-XX AC-TE72-48-R
50 3200 Air Curtain Transformer JC-0521-XX AC-TE72-60-R
40 3200 Air Curtain Impellor-R 36” & 72” [Surface & Recessed] JC-0502-10 AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
40 3200 Air Curtain Impellor-R 60” [Surface & Recessed] JC-0502-15 AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
40 3200 Air Curtain Impellor-L 60” & 72” [Surface & Recessed] JC-0502-20 AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
30 3200 Air Curtain EC Motor Left 72” JC-0503-20 AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
20 3200 Air Curtain EC Motor Right 36” JC-0503-10 AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
20 3200 Air Curtain EC Motor 60” JC-0503-15 AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
15 3200 Air Curtain Nozzle Grill 36” JC-0504-10 AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
15 3200 Air Curtain Nozzle Grill 60” JC-0504-15 AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R

15 3200 Air Curtain Nozzle Grill 72” JC-0504-20 AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
10 3200 Air Curtain Nozzle Bracket JC-0505-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
5 3200 Air Curtain Nozzle Bracket Holder JC-0573-XX AC-TE36-20-R
AC-TE36-48-R
AC-TE36-60-R
AC-TE60-20-R
AC-TE60-48-R
AC-TE60-60-R
AC-TE72-20-R
AC-TE72-48-R
AC-TE72-60-R
schwankgroup.com/schwankair
