Scion-Tech SC02.6040 User manual
User Manual
Version 1.1
SC02.6040
User ManualScion Tech SC02.6040
1:4 HDMI Splitter over CAT6
18G, 4K/60Hz 4:4:4, HDR
User ManualScion Tech SC02.6040
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
The manual is only for operational purposes, please contact a local dealer for maintenance assistance. The
functions described in this version were updated in July 2020. In the constant effort to improve this product, we
reserve the right to make functional or parameter changes without notice or obligation. Please refer to your local
dealer for the latest details.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric
shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend
the life of your equipment.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance
with the instructions may cause harmful interference to radio communications equipment. It has been tested and
found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a commercial installation.
Any changes or modifications not expressly approved by the manufacture would void the user’s authority to
operate the equipment.
F
E
D
E
R
A
L
C
O
M
M
U
N
I
C
A
T
I
O
N
S
C
O
M
M
I
S
S
I
O
N
-
U
S
A
-
F
User ManualScion Tech SC02.6040
Safety Precautions
●Unpack the equipment carefully and save the packaging for possible future use.
●Follow basic safety precautions to reduce the risk of fire, electric shock and personal injury.
●Do not dismantle the housing or modify the enclosure as this may result in electric shock or personal injury.
●Using parts or components not meeting the manufactures specifications may result in damage, deterioration or
malfunction of the device.
●Refer all and any servicing to the manufacturer or local dealer.
●To prevent electric shock, do not expose this device to rain, moisture or install this product near water.
●Do not place items on the product as this may result in overheating.
●Do not open or remove the housing as this may expose you to harmful voltages or electric shock.
●Ensure the product has plenty of ventilation above and below.
●Liquid spillage over or inside the product may result in electric shock and permanent damage. In the event of
spillage remove the power immediately.
●Do not pull or twist the optical cables as this may result in damage to the optical connector.
●Do not use liquid or aerosol cleaners on the product and always remove the power before cleaning.
●Remove the power if the product is going to be left for long periods without use.
●Information on disposal for scrapped devices: do not burn or mix with general household waste and please treat
the product as normal electrical waste.
User ManualScion Tech SC02.6040
CONTENTS
1.0 Introduction, Features and Package Contents--------------------------------------------------------------------- 5
1.1 Key Features------------------------------------------------------------------------------------------------ 5
1.2 Package Contents------------------------------------------------------------------------------------------ 5
2.0 Specifications---------------------------------------------------------------------------------------------------------- 6
3.0 Front Panel Description---------------------------------------------------------------------------------------------- 7
4.0 Rear Panel Description----------------------------------------------------------------------------------------------- 7
5.0 Side Panel Description----------------------------------------------------------------------------------------------- 8
6.0 Receiver Front & Rear Panel Description------------------------------------------------------------------------- 8
7.0 IR Pin Connections--------------------------------------------------------------------------------------------------- 9
8.0 Application Drawing-------------------------------------------------------------------------------------------------- 10
9.0 EDID Mode Table---------------------------------------------------------------------------------------------------- 11
10.0 Maintenance and Warranty------------------------------------------------------------------------------------------ 12
1.0 Introduction
This professional 1 in 4 out HDMI splitter over CAT6 delivers lossless 4K/60Hz video resolution up to 60m over
a single CAT6 cable. With it’s 18G high spec performance, this splitter supports 8/10/12bit colour depth, YCbCr
4:4:4 colour space, HDR, HDR+, HLG and Dolby Vision™. The splitter also supports all digital audio formats
up to LPCM 7.1 and offers de-embedded analogue and digital audio for connecting to a sound system. A looped
HDMI output is provided for connecting a local screen or stacking several splitters for larger installations.
Each receiver has an Infra-Red return path for controlling the soucre device and the receivers are powered from
the splitter over CAT6 (PoC), therefore removing the need for local PSU’s behind the screens.
The advanced EDID management ensures the splitter is compatible with all displays making this splitter quick
and easy to install.
This splitter is supplied with 4 x receivers and is ideal for the home, retail displays, education, control centres,
churches or anywhere were you have multiple displays spread over long distances.
Page 5
User ManualScion Tech SC02.6040
1.2 Package contents
1. 1 x Main Unit (SC02.6040)
2. 1 x IR Emitters
3. 4 x Receivers
4. 4 x IR Senders cables
5. 1 x Power Adaptor 12V/2.5A
6. User Manual
1.1 Key Features
●18G, 1:4 HDMI Splitter over CAT6
●HDMI 2.0, HDCP 2.2
●Up to 60m Distance over CAT6/6a/7
●4K/60Hz, YCbCr 4:4:4, HDR, HDR10+
●LPCM 7.1, Dolby True HD, DTS-HD
Key Features
●Looped HDMI output
●Return IR Path for Source Control
●Extracts analogue and digital audio
●Advanced EDID Management
●PoC (Power over Cable)
Page 6
User ManualScion Tech SC02.6040
Connections
Main Unit (Splitter)
HDMI Input: 1 x HDMI Type A, 19-Pin Female
CAT6/6a/7 Output: 4 x RJ45 Data socket
Looped HDMI Output: 1 x HDMI Type A, 19-Pin Female
Digital Audio Output: 1 x Coax RCA Phono
Analogue L/R Audio Output: 1 x 3.5mm Stereo Jack Socket
Infra-Red Output: 1 x 3.5mm Jack Socket
RS232 Service: 1 x Micro USB
Power: 1 x DC Jack
Receiver
CAT6/6a/7 Input: 1 x RJ45 Data Socket
HDMI Output: 1 x HDMI Type A, 19-Pin Female
Infra-Red Input: 1 x 3.5mm Jack Socket
RS232 Service: 1 x Micro USB
Power: 1 x DC Jack (not required when used with SC02.6040)
Signal
Signal Input: HDMI
Standards: HDMI 2.0b, HDCP 1.x and 2.2
Bandwidth: 18Gbps
Video Resolutions: 4K/60Hz, 4:4:4
Colour Space: RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0, HDR, HDR 10+, HLG, Dolby Vision
Colour Depth: 8/10/12-bit
HDMI Audio: LPCM 7.1, Dolby Atmos™, Dolby True HD™, Dolby Digital™ Plus, DTS: X™, DTS-HD™
Master Audio™ pass through
Digital Audio: PCM 2.0, Dolby Digital / Plus, DTS 2.0/5.1
L/R Stereo Audio: PCM 2.0CH
Infra-Red: Wide Bandwidth, Frequency 30KHz to 56KHz (940nm)
Cable Lengths
HDMI Input/Output Cable: 4K/60Hz 4:4:4@3m, 4K/60Hz 4:2:0@5m, 1080p/60Hz@15m
CAT5e/6/7 Distance: 4K/60Hz 4:4:4@35m, 4K/30Hz@50m, 1080p/60Hz@60m
Power Adaptor
Input: 100~240V AC 50/60Hz
Output: DC 12V/2.5A
Consumption: 14 Watts
Environment
Operating Temperature: -0° to 40°C
Storage Temperature: -20° to 60°C
Operating Humidity: 20 to 90% RH (no condensation)
Dimensions: Splitter (W) 210 x (D) 100 x ( H) 25, Receiver (W) 61 x (D) 88 x ( H) 18
Weight: Splitter 620g, Receiver 155g
Colour: Black
ESD: Human Body - +/-8kV, (air gap discharge) & +/-4kV (contact discharge)
Safety and Emissions: CE, FCC, UL, RoHS
2.0 Specifications
3.0 Front Panel Description
User ManualScion Tech SC02.6040
Number Name Function / Description
1 Power Switch Powers the splitter on and off.
2 Power LED Illuminates red when powered ON.
3 IN LED The LED illuminates green when a HDMI source in connected.
4 Loop LED The LED illuminates green when a HDMI device in connected.
5 Out 1 ~ 4
When the output is connected to a powered device the LED illuminates green.
Page 7
ON
OFF
TM
HIGH-DEFINITION MULTIMEDIA INTERFACE
IN LOOP 1 2 3 4 OUT
18Gbps HDMI 1:4 Splitter over CAT6
Scion Tech Ltd
SC02.6040
1 2 3 4 5
4.0 Rear Panel Description
L/R
COAX
1
IN LOOP OUT 2 3 4
CAT OUTHDMI INAUDIO OUT
IR OUT
DC 12V
1 2 3 4 5 67
Number Name Function / Description
1Audio Out
(Coax, L/R) Analogue and digital audio outputs for connection to amplifiers or speakers.
2 HDMI Ports IN: HDMI input, connect to source device. Loop: output, connect to local
screen, splitter or other device.
3 CAT Out Connect to CAT6/6a/7 with Scion receiver on other end.
4 Green LED Illuminates green when a receiver is connected.
5 Amber LED Illuminates when a signal is detected between splitter and receiver.
6 IR Out Connect the IR emitter.
7 Power Connect the 12V power adaptor.
5.0 Side Panel Description
Page 8
User ManualScion Tech SC02.6040
12345
ON
1
0
12
Service
EDID
Number Name Function / Description
1 EDID Use to set the EDID (please see EDID table for details)
2 Service Use for firmware updates and RS232 control.
6.0 Receiver Front and Rear Panel Description
HDMI OUT CAT IN SERVICE IR IN DC IN
1 2
34
5 6 7
Number Name Function / Description
1 HDMI Out HDMI output, connect to display or sink device.
2 CAT IN Connect to CAT6/6a/7 cable.
3 Power LED Illuminates green when powered.
4 Signal LED Illuminates amber when a receiving HDMI signal.
5 Service Used for firmware update only.
6 IR In Connect the IR receiver.
7 Power Connect the 12V power adaptor (not required when used with splitter)
7.0 IR Pin Connections
User ManualScion Tech SC02.6040
Page 9
IR RECEIVER / SENDER IR BLASTER / EMITTER
IR BLASTER / EMITTER SIGNAL
POWER
NOT CONNECTED
IR SIGNAL
POWER
GROUND
8.0 Application Drawing
Page 10
User ManualScion Tech SC02.6040
Speakers
Local Display
IR Out
Display Satellite Receiver
IR Remote Control
Multi Room Audio
Ceiling Speakers
CAT5e/6
Receiver
L/R
COAX
1
IN LOOP OUT 2 3 4
CAT OUTHDMI INAUDIO OUT
IR OUT
DC 12V
Satellite Receiver
9.0 EDID Table
User ManualScion Tech SC02.6040
Page 11
EDID MODE EDID DESCRIPTION
11111 1080P, Stereo Audio 2.0
11110 1080P, Dolby/DTS 5.1
11101 1080P, HD Audio 7.1
11100 1080i, Stereo Audio 2.0
11011 1080i, Dolby/DTS 5.1
11010 1080i, HD Audio 7.1
11001 1080P 3D, Stereo Audio 2.0
11000 1080P 3D, Dolby/DTS 5.1
10111 1080P 3D, HD Audio 7.1
10110 4K2K30Hz_444, Stereo Audio 2.0
10101 4K2K30Hz_444, Dolby/DTS 5.1
10100 4K2K30Hz_444, HD Audio 7.1
10011 4K2K60Hz_420, Stereo Audio 2.0
10010 4K2K60Hz_420, Dolby/DTS 5.1
10001 4K2K60Hz_420, HD Audio 7.1
10000 4K2K60Hz_444, Stereo Audio 2.0
01111 4K2K60Hz_444, Dolby/DTS 5.1
01110 4K2K60Hz_444, HD Audio 7.1
01101 4K2K60Hz_444, Stereo Audio 2.0 HDR
01100 4K2K60Hz_444, Dolby/DTS 5.1 HDR
01011 4K2K60Hz_444, HD Audio 7.1 HDR
01010 COPY_FROM_LOOP OUT
01001 COPY_FROM_CAT OUT1
01000 COPY_FROM_CAT OUT2
00111 COPY_FROM_CAT OUT3
00110 COPY_FROM_CAT OUT4
00101 1080p, Stereo Audio 2.0
00100 1080p, Stereo Audio 2.0
00011 1080p, Stereo Audio 2.0
00010 1080p, Stereo Audio 2.0
00001 1080p, Stereo Audio 2.0
00000 PC Control Mode
Page 12
10.0 Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices.
Servicing
Damage requiring service: This product should be serviced by a qualified service engineer if:
●The DC power cord or AC adaptor has been damaged.
●Objects or liquids have entered the housings.
●The product has been exposed to rain.
●The product has stopped working or shows signs of significant change in operating performance or function.
●The unit has been dropped or severely damaged externally.
Servicing personnel: Do not attempt to service the product beyond that described in these instructions. Refer all
other servicing to authorised serving personnel.
Replacement parts: When parts need replacing ensure the service engineer uses parts specified by the manufacture
or parts that have the same characteristics as the original parts. Unauthorised substitutes may result in fire, electric
shock or other hazards.
Safety check: After a repair or service, ask the engineer to perform safety checks to confirm the product is in
proper working condition.
Warranty
If your product does not work properly because of a defect in materials or workmanship, our Company (referred to
as "the warrantor" ) will , for the length of the period indicated as below, (Parts and labour 2 years) which starts
with the date of original purchase ("Limited Warranty period"), at its option either (a) repair your product with new
or refurbished parts, or (b) replace it with a new of a refurbished product. The decision to repair or replace will be
made by the warrantor.
During the "Labour" Limited Warranty period there will be no charge for labour. During the "Parts" warranty
period, there will be no charge for parts. You must mail-in your product during the warranty period. This Limited
Warranty is extended only to the original purchaser and only covers product purchased as new. A purchase receipt
or other proof of original purchase date is required for Limited Warranty service.
Returning a Product
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the original carton.
Include a letter detailing the complaint and provide a day time phone number and/or email address where you can
be reached.
User ManualScion Tech SC38.MX88
Page 13
Limited warranty limits and exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT
COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages
which occurred in shipment, or failures which are caused by products not supplied by warrantor, or failures which
result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up
adjustments, maladjustment of consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service centre or other authorized service engineer, or
damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY
COVERAGE".THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an
installed unit if applicable, travel to and from the service, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration only).
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR
RESPONSIBILITY. This returns policy does not affect your legal rights. Details of your legal rights are available
from Trading Standards or Citizens Advice Consumer Service.
Scion Tech Limited
Thatcham, Berkshire, United Kingdom
User ManualScion Tech SC02.6040
Table of contents
Other Scion-Tech Media Converter manuals
