USER MANUAL
Please read and keep these instrucons
HARD CANOPY
SE-HC
AUGUST 2019



scooterxtras.com.au
SCOOTER XTRAS owns the copyright to the Hard Canopy user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of Scooter Xtras.
SCOOTER XTRAS strives to provide the highest quality products possible.
Products are subject to change without noce.
© Copyright SCOOTER XTRAS 2019
SCOOTER XTRAS is part of FOR-DE Group Pty Ltd



scooterxtras.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. ASSEMBLY - UNPACK and INSPECT SUPPLIED PARTS
4. ASSEMBLY - BAG / WALKER CARRIER LOCATION
5. ASSEMBLY - FRONT MOUNT KIT LOCATION
6. ASSEMBLY - FRONT MOUNT KIT LOCATION (Connued)
7. ASSEMBLY - LOWER WINDSCREEN LOCATION
8. ASSEMBLY - CANOPY PRE-ASSEMBLY
9. ASSEMBLY - CANOPY ON SCOOTER
10. USAGE GUIDELINES - DO’s + DON’Ts
11. PRODUCT CARE - INSPECTIONS / CLEANING
12. WARRANTY
13. SCOOTER XTRAS OPTIONAL EXTRAS
14. SCOOTER XTRAS WEATHER CURTAINS
15. SCOOTER XTRAS PRODUCT RANGE
16. NOTES

scooterxtras.com.au
INTRODUCTION
Thank you for purchasing this quality SCOOTER XTRAS product.
If you have any issues or quesons about the Hard Canopy
please contact your supplier or Scooter Xtras direct:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance to these guidelines.
Failure to follow these guidelines may result in damage to the product and injury
to the user. It is the responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate healthcare
professional if unsure of the correct product usage for their unique circumstances.
Only use your Hard Canopy for the purpose for which it is intended, which is as a
wind and sun shelter soluon - it is not designed to be a rain shelter soluon as
mobility scooters should not be operated in the rain.
IMPORTANT NOTE
This equipment MUST be assembled
by competent people. We recommend
that 2 people install the hard canopy
onto the mobility scooter.
Tools required (not supplied) for assembly:
- 4mm Allen Key
- 10mm Spanner
- Rubber Mallet
Using a mobility scooter ed with
a Hard Canopy in strong winds and
adverse weather can seriously
compromise your safety and may
damage the mobility scooter beyond
repair.
1.

scooterxtras.com.au
PRODUCT OVERVIEW
FEATURES
- Provides excellent wind + sun protecon
- Clear polycarbonate windscreens
- Lightweight metal framework
- Used in conjuncon with SE-BC: Bag Carrier
- Accessory mount brackets
(for rear vision mirrors / bole - mobile phone holders)
- Easily removable for servicing
- Retro able to certain Shoprider mobility scooters
Oponal Extras (Contact your supplier or Scooter Xtras direct)
- Retro able Clear PVC side + rear enclosure curtains
SPECIFICATIONS (All dimensions shown are nominal)
Overall Dimensions:
Length: 1300mm
Width: 720mm
Height: 1400mm
Product Weight:
8kg
IMPORTANT NOTE:
Hard Canopy can only be ed to the following Mobility Scooters:
SHOPRIDER ROCKY 4 (Mount Kit 1 required)
SHOPRIDER ROCKY 6 (Mount Kit 1 required)
SHOPRIDER ALLROUNDER (Mount Kit 2 required)
SHOPRIDER 889SL (Mount Kit 2 required)
SE-BC: Bag + Walking Scker Carrier or SE-WWC: Wheelie Walker Carrier is required
to t Hard Canopy to any mobility scooter.
Please contact SCOOTER XTRAS if you would like any further informaon
on your Hard Canopy.
2.

scooterxtras.com.au
ASSEMBLY- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
PARTS:
IMPORTANT NOTE
Check the product for any visible damage. If you see any damage or suspect a fault,
DO NOT USE YOUR PRODUCT and contact your supplier for support.
3.
Not included but required to t Hard Canopy to any mobility scooter:
SE-BC: Bag + Walking Scker Carrier or SE-WWC: Wheelie Walker Carrier / Relevant Mount Kit
1 x Canopy
1 x Upper Windscreen
1 x Rear Frame
1 x Lower Windscreen
2 x Short Bolt
2 x Long Bolt
4 x Bolt Cover 12 x Saddle Washer
*Fasteners not shown to scale
4 x Nut
MOUNT KIT 1
Suitable for:
SHOPRIDER ROCKY 4
SHOPRIDER ROCKY 6
MOUNT KIT 2
Suitable for
SHOPRIDER ALLROUNDER
SHOPRIDER 889SL

scooterxtras.com.au
4.
ASSEMBLY- BAG / WALKER CARRIER LOCATION
Before the Hard Canopy can be ed to a mobility scooter...
SE-BC: Bag + Walking Sck Carrier or SE-WWC: Wheelie Walker Carrier
must rst be ed. Assemble the carrier as required and then t to scooter.
Ensure the carrier is fully located into
the mount tube under the seat.
Lock the carrier in posion
by ghtening both bolts
unl the carrier is
rmly held in place. Carrier
to be
ed
Fully insert
Carrier
prior to
fastening
in place
Note:
Carrier shown as basic frame
for illustraon purposes
Ensure BOTH
Bolts are to be
ghtened prior
to ng Hard
Canopy

scooterxtras.com.au
5.
ASSEMBLY- FRONT MOUNT KIT LOCATION
Before the Hard Canopy can be ed to a mobility scooter, a front mount kit needs to be
ed. Please ensure you have been supplied with the correct mount kit for your mobility
scooter model:
SHOPRIDER ROCKY 4 (Mount Kit 1 required)
SHOPRIDER ROCKY 6 (Mount Kit 1 required)
SHOPRIDER ALLROUNDER (Mount Kit 2 required)
SHOPRIDER 889SL (Mount Kit 2 required)
Insert the outrigger into the mount tube located above the front tyres of the scooter and
underneath the cover. The uprights on ends of mounts to be posioned just o the cover
- ready to accept the front mount tube.
Mount Kit 1
Mount Kit 2
Secondary tube(s) on
outriggers sit on top of
sheet bracket
Outrigger
Outrigger

scooterxtras.com.au
6.
ASSEMBLY- FRONT MOUNT KIT LOCATION (Connued)
Once the outriggers have been ed to the scooter, the front mount tube can be located:
(refer to sequence stated and shown below):
1. Reposion the outriggers to line
up with front mount tube.
2. Locate the tube onto the uprights.
3. Feed the bolt cover and saddle
washer onto the short bolt,
4. Pass the short bolt through
the hole in the front mount
tube and the upright,
5. Feed saddle washer onto bolt
and screw on nut to hold
all in place.
6. Using an Allen Key and
Spanner, ghten fastener
assembly.
(Close lid on bolt cover)
Repeat process for other xing.
Mount Kit 1 shown
for illustraon purposes
Front Mount Tube
Short Bolt
Bolt Cover
Saddle Washer
Saddle Washer
Nut

scooterxtras.com.au
7.
ASSEMBLY- LOWER WINDSCREEN LOCATION
The lower windscreen fastens
onto the front mount tube
(refer to sequence stated and shown below):
1. Feed the bolt cover and saddle washer
onto the long bolt,
2. Pass the long bolt through the hole
in the lower windscreen frame,
3. Feed 2 x saddle washers onto the bolt
(back to back),
4. Pass the bolt through the hole in the
front mount tube,
5. Feed saddle washer onto bolt and
screw on nut to hold all in place.
6. Using an Allen Key and Spanner,
ghten fastener assembly.
(Close lid on bolt cover)
Repeat process for other xing.
Long Bolt
Bolt Cover
Saddle Washer
Saddle Washer
Saddle Washer
Saddle Washer
Long Bolt
Assembled
Lower Windscreen

scooterxtras.com.au
8.
ASSEMBLY- CANOPY PRE ASSEMBLY
The Canopy, Upper Windscreen and Rear frame require pre-assembly prior to ng
(refer to sequence stated and shown below):
1. Posion Canopy upside down - lay in box to protect cover from scratching,
2. Locate Upper Windscreen into frame on inside of Canopy,
3. Locate Rear Frame into frame on inside of canopy.
If required:
Using a rubber mallet - lightly tap
the Upper Windscreen / Rear Frame
down unl fully located.
Canopy
Upper Windscreen
Rear Frame

scooterxtras.com.au
ASSEMBLY- CANOPY ON SCOOTER
The pre-assembled canopy with upper windscreen
and rear frame ed can now be ed onto
the mobility scooter.
(refer to sequence stated and shown below):
IMPORTANT NOTE:
2 people are required to t the
pre-assembled canopy to the scooter.
1. Turn the pre-assembled canopy over
and oer up to the scooter,
2. Line up the frame on the upper
windscreen with the lower
windscreen frame,
3. Line up the rear frame with the
bag carrier frame,
4. At the same me - locate the canopy
onto the various mounng frames,
5. Flex the windscreens to clear the cross
tube during locaon onto lower
windscreen.
If required:
Using a rubber mallet - lightly tap
the Upper Windscreen / Rear Frame
down unl fully located.
9.

scooterxtras.com.au
10.
USAGE GUIDELINES - DO’s + DON’TS
Please follow these guidelines to get the opmal benet from your Hard Canopy.
Failure to follow these guidelines may result in damage to the Hard Canopy, mobility
scooter and put the user at risk.
Please ensure all the parts of the hard canopy have been ed as instructed and all
fasteners have been ghtened suciently.
IMPORTANT NOTE !
Using a mobility scooter ed with a Hard Canopy in STRONG WINDS
and adverse weather can seriously compromise your safety and
may damage the mobility scooter beyond repair.
Only use your Hard Canopy for the purpose
for which it is intended, which is as a
wind and sun shelter soluon.
The Hard Canopy is not designed to be a
rain shelter soluon as mobility scooters
should not be operated in the rain.
The user should not use the Hard Canopy
to assist them with geng on and o
the mobility scooter. The Hard Canopy
has not been designed to be used as
a assisve support structure.

scooterxtras.com.au
11.
PRODUCT CARE - INSPECTIONS / CLEANING
INSPECTIONS
We suggest that you check your Hard Canopy visually periodically for signs of damage or
wear prior to use. Overall check that no components are loose or worn.
Withdraw the Hard Canopy immediately if you suspect damage or any
other fault. If in any doubt, please do not issue or use, but immediately
contact your supplier for service support.
IMPORTANT NOTE
Do not t any parts or accessories to your Hard Canopy that are manufactured by
another company. To do so will void your warranty and may seriously compromise
your safety.
CLEANING
Clean the Hard Canopy using a non-abrasive cleaner or mild detergent with a so cloth.
Abrasive cleaners or abrasive cleaning pads could damage
the Hard Canopy and should not be used.

scooterxtras.com.au
12.
WARRANTY
Your Scooter Xtras SE-HC: HARD CANOPY is covered by a 12 Month Warranty
from the date of purchase.
If the product has any manufacturing faults during this period contact the place of
purchase for assessment. Failures as a result of ACCIDENTAL MISUSE, MODIFICATION
OR WEAR AND TEAR ARE NOT COVERED BY THIS WARRANTY.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entled to a replacement part for a major failure and for
compensaon for any other reasonably foreseeable loss or damage. You are entled
to have the goods repaired or replaced if the goods fail to be of acceptable quality
and failure does not amount to major failure.
If you have any issues or quesons about your Hard Canopy
please contact your supplier or SCOOTER XTRAS direct on:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga
Western Australia 6090
Please keep this User Manual
in a safe place for future reference.

scooterxtras.com.au
SCOOTER XTRAS - HARD CANOPY OPTIONAL EXTRAS
SCOOTER XTRAS oer various opons that can be ed to the accessory mount brackets
located on the windscreen cross tube on the hard canopy:
TE-MPUL: Le Rear Vision Mirror
TE-MPUR: Right Rear Vision Mirror
SE-020: Mobility Bole Holder
SE-022: Mobility Phone Holder
13.
LEFT Rear Vision Mirror
(TE-MPUL)RIGHT Rear Vision Mirror
(TE-MPUR)
Mobility PHONE Holder
(SE-022)
Mobility BOTTLE Holder
(SE-020)

scooterxtras.com.au
SCOOTER XTRAS - HARD CANOPY WEATHER CURTAINS
The Hard Canopy is designed to take side and rear clear plasc weather curtains.
For more details please contact your supplier or SCOOTER XTRAS direct on:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga
Western Australia 6090
14.

scooterxtras.com.au
SCOOTER XTRAS - PRODUCT RANGE
SCOOTER XTRAS oer a comprehensive range of products including:
SE-BC: Bag and Walking Sck Carrier
SE-SD: Deluxe Sun Canopy
SE-S: Sun Canopy
SE- WWB: Wheelie Walker Carrier
SE-SFWC: Side Folding Walker Carrier
SE-WFC: Walking Frame Carrier
SE-WSH: Walking Sck Holder
TE-O: Flag Holder
SCOOTER XTRAS stock a large range of Spare Parts for all SCOOTER XTRAS products.
Please contact SCOOTER XTRAS for further informaon:
T: [phone]
F: [phone]
E: [e-mail]
A: 1 Business Way, Malaga Western Australia 6090
W: www.scooterxtras.com.au
15.

scooterxtras.com.au
NOTES
16.

scooterxtras.com.au
DISTRIBUTOR:
Proudly Australian Owned and Operated


