Scotsman NWH Series Installation guide

NW(H) SERIES
DICE & HALFDICE
CUBERS
TECHNICAL SERVICE TRAINING
Welcome to another Scotsman Technical Service Presentation that
cover all NW models
REV. 03/2018
Full Cube –12 gr Half Cube –6 gr

NW(H) 308
Max. Ice production = 147 Kg/24h*
Max. Storage Bin Capacity
- NB 193 = 129 Kg
* 21/10°C = Air & Water Inlet Temperature

NW(H) 508
Max. Ice production = 215 Kg/24h*
Max. Storage Bin Capacity
- NB 193 = 129 Kg
* 21/10°C = Air & Water Inlet Temperature

NW(H) 458
Max. Ice production = 200 Kg/24h*
Max. Storage Bin Capacity
NB 393 = 178 Kg
NB 530 = 243 Kg
* 21/10°C = Air & Water Inlet
Temperature

NW(H) 608
Max. Ice production = 280 Kg/24h*
Max. Storage Bin Capacity
NB 393 = 178 Kg
NB 530 = 243 Kg
* 21/10°C = Air & Water Inlet
Temperature

NW(H) 1008
Max. Ice production = 456 Kg/24h*
Max. Storage Bin Capacity
NB 530 = 243 Kg
NB 948 = 406 Kg
* 21/10°C = Air & Water Inlet
Temperature

TOPICS
On the next slides are shown the following steps by steps
procedures:
•UNPACKING
•INSTALLATION
•START UP AND OPERATIONAL CHECKS
•OPERATING PRINCIPLES and COMPONENTS
•MAINTENANCE
•SERVICE ANALYSIS

UNPACKING

The machines are supplied
in a carton box secured by
two plastic strips to a
wooden base. Check first
the outside conditions of
carton box and wooden
base then cut the two
plastic strips, remove the
tape and then the carton
box.

Visually inspect the exterior of the
machine, then remove the front and
both side panels, unscrews the two
sides screws that secure the machine
to the wooden base

Remove the water
inlet and outlet
hoses, the red
adhesive tapes and
the air baffle
deflector
NW308 and 508
are equipped with
a top grid

Remove the front
plastic deflector
and take out the
second red
adhesive tape
securing the ice
thickness sensor

The Modular NW machines require for
the installation the use of a companion
storage bin to store the ice produced.
Storage bins required:
•NB193 with NW 308 - NW 508
•NB 393/530 with NW 458 - NW 608
•NB 530/948 with NW 1008

Unpack the storage
bin and visually
inspect the exterior
then remove from
the inside the
carton box
containing the legs
as well as the drain
hose and the plastic
scoop

INSTALLATION

Install the four
legs and their
adjusting leveling
nuts on the
bottom base as
well as the water
drain tube

... install on top of the
same the ice machine
and secure it with the
two sides screws.

On air cooled version
unloose a little bit the
screws securing the air
cooled condenser to the
unit frame, then install the
metal plate (air baffle) on
the back side of the
machine
NW 458-608-1008

The installation of the
metal plate (air
separator) grants also
a minimum distance
between the back side
of the machine and the
wall so to assure a
correct and adequate
ventilation minimize the
possible recycling of hot
air through the rear panel
TOP VIEW
MINIMUM
DISTANCE
NW 458-608-1008
COLD AIR
HOT AIR
HOT AIR

Adequate space
must left for
proper water and
electrical
connections on the
rear side of the
machine and a
minimum
clearance of 15 cm
on right side for
best routing air.
Min. space 15 cm
NW 458-608-1008
