SCOTT MILLER SM-V7000 Operational manual

SCOTT MILLER PRODUCT USER MANUAL
Page 1 | 12
Instruction Manual &
Product E-Warranty
Scott Miller Cordless Vacuum Cleaner
Model: SM-V7000

SCOTT MILLER PRODUCT USER MANUAL
Page 2 | 12
Important Safety Instructions
READ ALL INSTRUCTIONS BEFORE USE AND RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
Overview of Package Content
• 1 x Scott Miller SM-V7000 Vacuum Cleaner
• 1 x Aluminium Tube
• 1 X Charging Adaptor
• 1 x Removable Li-ion Battery
• 1 x Motorised Floor Brush
• 1 x 2-in-1 Combination Brush
• 1 x Crevice Nozzle
• Motorised Mite Brush
• 1 x Wall Mount Tool
• HEPA Filter
Important Safety Instructions
Attention:
• Use the product only as described in the instructions. Under no circumstances should
Purchasers attempt repairing the appliance themselves.
• Ensure to use only genuine accessories and replacement parts from Scott Miller.
• Do not use the vacuum for liquid, water or similar substances. Use only on dry surfaces.
• Never touch the power supply or the appliance with wet or damp hands.
• Always grasp the power supply connector instead of the cable to disconnect the
power supply from the appliance.
• Do not use the appliance with damaged cable or plug. If the power supply cable is
damaged, it must be replaced immediately with genuine power supply cable from
Scott Miller.
• This appliance is not suitable for use with inflammable and explosive substances or
chemical and volatile liquids.
• Do not use this appliance to pick up anything that is burning or smouldering, such as
cigarettes, burning matches, hot ashes etc.
• Repairs should only be carried out by a service agent or a suitable qualified person in
accordance with relevant safety regulations. Repairs or replacements of parts not
carried out by qualified personnel may lead to physical injuries.
• Ensure that the dust bin, HEPA filter and battery are properly installed before use.

SCOTT MILLER PRODUCT USER MANUAL
Page 3 | 12
• Use only genuine charger from Scott Miller to charge the appliance. Use only genuine
battery from Scott Miller. Using unauthorised accessories may cause damage to the
appliance.
• Always switch off the appliance before attempting to connect or disconnect any
accessories.
Battery Safety Instructions:
• Use only genuine battery from Scott Miller. Using unauthorised battery may cause
damage to the appliance.
• The appliance comes with a Li-ion battery. The battery indicator will keep on blinking
when the battery needs to be charged. When charging the appliance, the battery
indicator will blink continuously and stop only when it is fully charged.
• The appliance with a fully charged battery can be used for approximately 45 minutes.
Specification:
Lithium Battery
2200mAh
Voltage
22.2V
Adaptor Voltage
100 – 240V
Power
150W
Adaptor Output
27V 500mA
Service time
45 mins
Charger time
4 – 5 hr
Noise
60 - 70dB
Item Size
348 x 120 X 220 mm (machine only)
Item Weight
2.6Kg (machine only)
There are 5 functional buttons and one charging port as shown in the picture:
Aluminium Tube
Motorised Floor
Brush
Dust Mite Brush
---

SCOTT MILLER PRODUCT USER MANUAL
Page 4 | 12
Operating Instructions
Assemble the unit
Note: Before assembling the extended tube, ensure that the vacuum cleaner is not connected to the
charger.
1. Insert the battery pack into the main body as shown in the picture.
2. Connect the aluminium tube to the main body.
3. Connect the motorised floor brush.
Floor brush cleaning and maintenance
1. Pull the release button to remove the lid.
2. Remove the fluffy brush.
3. Wash the fluffy brush and air dry it.

SCOTT MILLER PRODUCT USER MANUAL
Page 5 | 12
Dust bin removal and cleaning
Method 1:
1. Press down the dust bin removal button and empty the rubbish.
Method 2:
1. Press down on the dust bin release button, take out the dust bin from the main body as shown in
the picture.
Washing the filter
1. Empty all the rubbish.
2. Remove the HEPA filter and cyclone cone and rinse it with cold water. Do this once a month.
3. Ensure that the filters are completely dry before placing it back as shown in the picture.
*Do not use the appliance without installing the HEPA filter and cyclone cone first.

SCOTT MILLER PRODUCT USER MANUAL
Page 6 | 12
Using the vacuum
1. Press the on/off button to start the Vacuum.
2. Press the Low/High Speed Control to alternate between Low Speed Mode and High Speed mode.
CAUTION: The suction inlet must be open and free of any obstructions at all times. Otherwise, the motor
may be overheated and could be damaged.
Note: it is recommended to clean or replace filter frequently. The cyclone system should be cleaned every
three (3) to six (6) months depending on the usage to ensure optimum performance of the vacuum cleaner.
The power brush rolling bar should be checked from time to time to avoid blockage. In the event of faulty
operation, such as the power brush rolling bar is blocked by hair, or the main vacuum motor inlet is jammed,
or the battery is overheated etc., the system may be cut off to protect the motor of the product. Use the
charger to reactivate the vacuum cleaner and if problem persists, send it to a qualified service agent for
repair or maintenance.

SCOTT MILLER PRODUCT USER MANUAL
Page 7 | 12
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE REASON
POSSIBLE SOLUTION
Vacuum cleaner does
not work
1. Battery not charged up properly.
2. Dead battery (battery would not
hold charge).
3. Connector between the unit and
the charger is dirty.
4. No power in electrical outlet
supplying transformer.
5. Charger is plugged in.
6. System is cut off.
1. Charge unit.
2. Contact customer service or dispose the
unit appropriately.
3. Wipe and clean dirt from connector.
4. Check fuse or breaker, replace faulty
fuse/reset breaker.
5. Unplug charger.
6. Activate the system with the charger.
Power floor brush
does not work
1. Rolling brush is blocked with
debris or string etc.
2. Belt is broken.
3. Vacuum cleaner is not connected
properly.
1. Remove debris from rolling brush. If
there is string or thread coiled around,
cut gently with scissors.
2. Contact customer service for assistance.
3. Connect the vacuum cleaner properly.
Vacuum cleaner
cannot pick-up dust;
suction power
become weak
1. Dust container is full.
2. HEPA filter needs cleaning or
replacement.
3. Unit needs recharging.
1. Empty dust container
2. Remove dust filter assembly and check
for obstructing object(s) in suction inlet
and remove. Clean or replace dust filter
assembly.
3. Charge unit.
Dust leak from
vacuum cleaner
1. Dust container is full.
2. Dust filter is not installed
correctly.
3. Puncture/hole in dust filter
1. Empty dust container
2. Review the dust filter assembly and
follow installation instructions carefully.
3. Replace dust filter assembly.
Battery cannot be
charged
Battery has reached the end of its service
life.
Contact customer service for assistance.
Strange noise when
the operation
Check if the floor brush and dust filter are
blocked by dust or debris; check if dust
container is full.
Stop using the appliance right away; clean the
dust filter assembly, floor brush, and empty the
dust container. If problem persists, contact
customer service for assistance.

SCOTT MILLER PRODUCT USER MANUAL
Page 8 | 12
Important
Ensure that dust filter is completely air dried before replacing it back into the vacuum cleaner.
Warning
Remove floor brush from the unit before cleaning it.
WARNING:
Correct Disposal of this product
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health due to
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They can take back this product for
safe disposal.

SCOTT MILLER PRODUCT USER MANUAL
Page 9 | 12
PRODUCT E-WARRANTY | SM-V7000
WARRANTY COVERAGE AND WARRANTY COVERAGE TIME PERIODS
The SCOTT MILLER (S) PTE. LTD. (“SCOTT MILLER SG”) warranty covers the repair and replacements on
certain parts of this vacuum cleaner and the cost of workmanship of the parts for a period of twelve (12)
months from the date of purchase. This limited warranty covers substantial defects in materials and
workmanship of the Vacuum Cleaner, provided that the Vacuum Cleaner is operated and maintained
properly and in conformity with the user’s manual. The warranty period becomes effective from the date
of purchase. This limited warranty applies only to the first purchaser of the products. It is not transferable.
WHAT SCOTT MILLER SG WILL DO TO CORRECT PROBLEMS This warranty covers only the repair and/or
replacement of the Vacuum Cleaner’s motor. In the event that a substantial defect in material and/or
workmanship, attributable to SCOTT MILLER SG, is found to exist during the warranty coverage period
specifically in the Vacuum Cleaner’s motor only, it will be repaired or replaced at SCOTT MILLER SG’s
discretion, without imposing any charges for the parts and/or workmanship to repair the Vacuum Cleaner’s
motor, in accordance with the terms, conditions and limitations of this limited warranty. The cost of labour
to repair or replace at any time after the warranty coverage detailed above is the sole responsibility of the
purchaser and is to be borne by the purchaser. SCOTT MILLER SG’s obligation to repair or replace defective
materials or workmanship is the sole obligation of SCOTT MILLER SG under this limited warranty, provided
that and terms and conditions of this limited warranty are fulfilled. SCOTT MILLER SG reserves the right to
use new or remanufactured parts of similar standard to complete any work, and to make parts and design
changes from time to time without providing prior notice. SCOTT MILLER SG reserves the right to make
changes in the design and/or material of its products without incurring any obligation to incorporate such
changes in any previously manufactured product. SCOTT MILLER SG makes no warranty as to the future
performance of this product. In addition, the purchaser’s obligation to notify SCOTT MILLER SG, or one of
its authorised independent dealers, of a claimed defect does not modify any obligation placed on the
purchaser to contact SCOTT MILLER SG directly when attempting to pursue remedies under laws of
Singapore.
LIMITATIONS, EXCLUSIONS AND DISCLAIMER OF IMPLIED WARRANTIES Any implied warranty that is
found to arise by way of law, including any implied warranty of merchantability or any implied warranty of
fitness, is limited in duration and scope of coverage of this limited warranty. SCOTT MILLER SG disclaims
any express or implied warranty, including any implied warranty of fitness or merchantability, on items
excluded from the coverage under this warranty as set forth. SCOTT MILLER SG makes no warranty of any
nature beyond that contained in this limited warranty. No one has the authority to enlarge, amend or
modify this limited warranty, and SCOTT MILLER SG does not authorise anyone to create any other
obligation for it regarding this product. SCOTT MILLER SG is not responsible for any representation, promise
or warranty made by any independent dealer or other person beyond what is expressly stated in this
limited warranty. Any selling or servicing dealer is not an authorised SCOTT MILLER SG’s agent, but an
independent entity.

SCOTT MILLER PRODUCT USER MANUAL
Page 10 | 12
SCOTT MILLER SG SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES THAT MAY
RESULT FROM THE BREACH OF THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTY. THIS EXCLUSION
OF CONSEQUENTIAL AND INCIDENTAL DAMAGES SHALL BE INDEPENDENT OF ANY FAILURE OF THE
ESSENTIAL PURPOSE OF ANY WARRANTY, AND THIS EXCLUSION SHALL SURVIVE ANY DETERMINATION
THAT THIS LIMITED WARRANTY OR ANY IMPLIED WARRANTY HAS FAILED OF ITS ESSENTIAL PURPOSE.
This warranty does not cover, and in no event shall result in SCOTT MILLER SG being liable for towing
charges, travel, lodging, or any other expenses incurred due to the loss of use of the product or by any
other reasons that may be raised.
HOW TO GET SERVICE To obtain warranty service, the purchaser shall: 1. Notify an authorised service
centre with regards to the claimed defect attributable to SCOTT MILLER SG, within the warranty coverage
period designated above; 2. Provide the notification mentioned in (1) above, within ten (10) days when
the owner discovered, or should have discovered, the claimed defect; 3. Promptly schedule an
appointment with and take the product to an authorised service centre for servicing; 4. Pay any
transportation costs and all expenses associated with obtaining the warranty service. Since SCOTT MILLER
SG does not control the scheduling of service work at the independent dealerships you may contact SCOTT
MILLER SG, by email at [e-mail]. If two (2) or more service attempts have
been made to correct any covered defect that you believe impairs the value, use or safety of the product,
or if it has taken longer than thirty (30) days for repairs to be completed, you must, to the extent permitted
by law, notify SCOTT MILLER SG directly, in writing, to the above email address, on the unsuccessful repair(s)
of the alleged defect(s) so that SCOTT MILLER SG can then be directly involved in providing service pursuant
to the terms of this limited warranty.
WHAT IS NOT COVERED This Limited Warranty does not cover any of the following: defects in materials,
components or parts of the product not attributable to SCOTT MILLER SG, any material, component or part
of the product that is warranted by another entity (Note: the written warranty provided by the
manufacturer of the material, component or part is the direct responsibility of the manufacturer); items
that are added or changed after the product leaves SCOTT MILLER SG’s possession; additional items
installed at any dealership, or other place of business, or by any other party, other than SCOTT MILLER SG;
normal wear, tear, usage, maintenance, service, periodic adjustments, the effects of condensation or
moisture from condensation; mould or any damage caused by mould; imperfections that do not affect the
product for its intended purpose; items that are working as designed but that you are unhappy with;
problems related to mis-operation, misuse, mishandling, neglect or abuse, including failure to maintain the
product in accordance with the user manual, or other routine maintenance such as inspections, lubricating,
adjustments, tightening of screws, sealing, wheel alignments or rotating tires; damage due to accident or
collision, including any acts of weather or damage or corrosion due to the environment; theft, vandalism,
fire, act of God or other intervening acts not attributable to SCOTT MILLER SG; damage resulting from
defacing, scratches, dents, or chips on any interior or exterior surface of the products, including
overloading or alteration of the product, or any of its components or parts. Defects and/or damage to
interior and exterior surfaces and other appearance items may occur at the factory or when the product is
in transit. These items are usually detected and corrected at the factory or by SCOTT MILLER SG or a dealer
prior to delivery to the purchaser. You must inspect the product for this type of damage when you receive
it upon delivery. Upon discovery of any defect or damage, you must immediately notify the dealer, or SCOTT
MILLER SG at the time of delivery to have these defects covered by this limited warranty and to have work

SCOTT MILLER PRODUCT USER MANUAL
Page 11 | 12
performed on these particular defects at no cost to you as provided by this limited warranty.
EVENTS DISCHARGING SCOTT MILLER SG FROM OBLIGATION UNDER WARRANTY The following shall
completely discharge SCOTT MILLER SG from any express or implied warranty obligation to repair or
replace anything and void this warranty: misuse, neglect, collision, accidents, failure to provide routine
maintenance (See User Manual), unauthorised alteration, acts of nature, damage from weather or the
environment, theft, vandalism, tampering, fire, explosions and overloading the product.
LEGAL REMEDIES Any actions to enforce any portion of this limited warranty, or any implied warranty, must
commence within six (6) months after expiration of the warranty coverage period designated above or the
action will be barred because of the passage of time. Any performance of repairs shall not suspend this
limitation period from expiring. Any performance of repairs after the warranty coverage period has expired,
or performance of repairs regarding anything excluded from the coverage under this limited warranty shall
be considered “goodwill” repairs, and will not alter the terms of this limited warranty, or extend the
warranty coverage period or the filing limitation period in this paragraph. In addition, since it is reasonable
to expect that the product will need some service during the warranty period; this warranty does not
extend to future performance. It only sets forth what SCOTT MILLER SG will do and does not guarantee
anything about the product for any time period. Nothing in this warranty, or any action of SCOTT MILLER
SG, or any agent of SCOTT MILLER SG, shall be interpreted as an extension of any warranty period or the
filing limitation period in this paragraph.
WARRANTY REGISTRATION AND MISCELLANEOUS Your warranty registration records should be
completed through our website at https://scottmillerappliances.com/warranty-registration or delivered to
the appropriate companies. The registration of warranty must be completed within twelve (12) months
from the date of purchase. The SCOTT MILLER SG warranty will not be registered unless this warranty
registration is completed and received by SCOTT MILLER SG. SCOTT MILLER SG agrees to repair or replace
any of its factory installed parts found to have substantial defects within the warranty period designated
above provided that the repair is authorised by SCOTT MILLER SG and carried out by an authorised service
centre (a SCOTT MILLER SG labour schedule determines the cost allowance of repairs). SCOTT MILLER SG
will not honour any warranty claim for repairs or replacement of parts unless the claim is submitted with
the appropriate documentation, and the work is completed by an independent, factory authorised service
centre. The appropriate documentations can be submitted in the form of writing to SCOTT MILLER SG.
Appropriate documentations for any previous warranty claimed and/or repairs or replacement provided
by SCOTT MILLER SG shall be provided for the subsequent warranty claim within the warranty period.
SCOTT MILLER SG will not honour any warranty claim for repairs or replacement of parts if the repair or
replacement had been carried out by any entity other than SCOTT MILLER SG’s authorised service centre,
the warranty herein shall be void and all the repair or replacement cost shall be borne by the purchaser.
SCOTT MILLER SG reserves the right to designate where any warranty work can be performed. SCOTT
MILLER SG also reserves the right to examine any defective workmanship or part prior to giving any
authorisation for warranty work. SCOTT MILLER SG’s return authorisation procedure must be adhered to
for the processing of any warranty claims.

SCOTT MILLER PRODUCT USER MANUAL
Page 12 | 12
Innovation for Next
Generation Living
