Philips FC6091/01 User manual

FC6095, FC6093, FC6091

2

1
3

4


 6
 15
 25
 34
 43
 52
 61
 71
 80
 89
 98
 108
 118
 127
 135
 144

6

Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.

 Bendable crevice tool (FC6093/6091)
 Floor nozzle (FC6095 only)
 Cleaning brush
 Crevice tool
 Brush tool
 Socket for car cord (FC6093 only)
 Contact points
 Connection for telescopic stick (FC6095 only)
 Charging socket
 Charging light
 Exhaust air openings
 On/off slide
 Dust compartment release button
 Motor inlet grille
 Filter holder
 Inner HEPA lter
 Outer lter
 Dust compartment
 Nozzle release button
 Nozzle insert
 Detachable nozzle
 Nozzle & stick holder (FC6095 only)
 Wall mounting bracket
 Charger
 Adapter
 Car cord with car plug (FC6093 only)
 Telescopic stick (FC6095 only)



Read this user manual carefully before you use the appliance and save it
for future reference.

- Never suck up water or any other liquid. Never suck up ammable
substances and do not suck up ashes until they are cold.
- Never immerse the vacuum cleaner, the charger or the adapter in
water or any other liquid.

- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.
- Do not use the vacuum cleaner, the charger or the adapter if it is
damaged.
- Do not use the appliance if it is damaged in any way. Take it to an
authorised Philips service centre for repair.
- If the adapter or charger is damaged, always have it replaced with one
of the original type in order to avoid a hazard.
- FC6093 only: if the car cord or car plug is damaged, stop using the car
cord and have it replaced with one of the original type.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
- Children should be supervised to ensure that they do not play with
the appliance.

- Remove the adapter from the wall socket before you clean the
charger.
- Only charge the vacuum cleaner with the adapter and charger
supplied. During charging, the adapter feels warm to the touch. This is
normal.
- Always switch off the vacuum cleaner after use.
 7

- The voltage on the contact points in the charger is low (max. 30
volts) and therefore not dangerous.
- Never block the exhaust air openings during vacuuming.
- Make sure the appliance is switched off when you charge it.
- Always use the vacuum cleaner with the lter unit assembled.
- Always use the appliance with the nozzle insert in place.
- To avoid the risk of electric shock, be careful when you drill holes in
the wall to attach the charger, especially close to a wall socket.

- FC6095: Lc = 80 dB(A)
- FC6093: Lc = 79 dB(A)
- FC6091: Lc = 78 dB(A)

This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.


1 To attach the charger to the wall:
- Screw the wall mounting bracket to the wall with the screws supplied
with the appliance (Fig. 2).
- Place the charger on the wall mounting bracket (1) and push the
charger downwards to x it (2) (Fig. 3).
- Attach the nozzle & stick holder to the wall mounting bracket
(FC6095 only).
- Screw the nozzle & stick holder to the wall with the screws supplied
with the appliance.
2 To use the charger without attaching it to the wall:
- Place the charger on a level and horizontal surface. (Fig. 4)
3 Slide the brush tool onto the crevice tool and place them in the
charger (Fig. 5).
8

4 FC6095 only: insert the telescopic stick and the oor nozzle into
the nozzle & stick holder (‘click’) (Fig. 6).

Caution: Make sure the appliance is switched off when you charge it.
Charge the appliance for at least 18 hours before you use it for the rst
time.
Tip: If you are not going to use the appliance for a longer period of time,
remove the adapter from the wall socket to save energy.
1 Charge the appliance in one of the following two ways:
- Insert the small plug into the charger, insert the adapter into the wall
socket, and place the appliance on the charger (Fig. 7).
- Insert the small plug into the charging socket of the appliance
and insert the adapter into the wall socket (Fig. 8).
,The charging light on the appliance goes on to indicate that the
appliance is charging (Fig. 9).
Note: The charging light stays on as long as the appliance is placed on the
charger and the adapter is in the wall socket.
Note: The charging light does not give any information about the charge level
of the built-in battery pack.

1 Push the on/off slide forwards to switch on the appliance (Fig. 10).
2 Push the on/off slide backwards to switch off the
appliance. (Fig. 11)
3 Leave the adapter in the wall socket and always put the vacuum
cleaner back onto the charger after use, even if the battery pack is
still almost fully charged.
 9



This appliance comes with the following tools:
 Brush tool for cleaning delicate surfaces
 Crevice tool for cleaning hard-to-reach places
 Bendable crevice tool for cleaning at an angle (FC6093/6091 only)
1 Take the tool you want to use.
2 Attach the tool to the detachable nozzle (Fig. 12).

With the car cord, you can connect the vacuum cleaner to the cigarette
lighter socket in your car. You can use it as long as necessary without
having to recharge it.
1 Insert the small plug of the car cord into the car cord socket of the
appliance. Then insert the car plug into the cigarette lighter socket
of your car (Fig. 13).
Note: The car cord cannot be used to charge the appliance.
2 Press the button on the small plug to detach the car cord from the
appliance.
Caution: To prevent damage, do not pull the small plug out of the
appliance without pressing the button.

1 Push the telescopic stick rmly into the back of the appliance until
it locks into position (‘click’) (Fig. 14).
The telescopic stick gives you extra reach when you clean hard oors,
carpets and hard-to-reach areas.
2 Attach the oor nozzle to the detachable nozzle (Fig. 15).
The oor nozzle can be used to vacuum hard oors and carpets.
The oor nozzle is equipped with a uff collector that removes hair and
uff.
