Scott Edge Reinforcer User manual

Copy No.:
Instruction Manual
Model No. : Scott Edge Reinforcer.................
Year of Manufacture : 2006.......
Manufactured by :..........
Document Number : R99999--2........
Issue : 1.....................
Date of Issue : July 2006..............

ISSUE NOTE
This is Issue 1; Date of Issue: July 2006
Copyright 2006

Table of Contents
III
Scott Edge Reinforcer
TABLE OF CONTENTS
1 INTRODUCTION & SAFETY 1--1...........................................................
1.1 Introduction 1--3....................................................................
1.1.1 Scott Edge Reinforcer Machine Specifications and Utility Requirements 1--4..............
1.2 General Safety Guidelines 1--5.......................................................
1.3 Safety Features 1--6.................................................................
1.3.1 Emergency Stop 1--6.............................................................
1.3.2 Stop and Safe 1--6...............................................................
1.3.3 Main Power Switch 1--6...........................................................
1.3.4 Guards and Covers 1--7...........................................................
1.4 Warnings, Cautions & Notes 1--8.....................................................
1.4.1 Warnings 1--8....................................................................
1.4.2 Cautions 1--8....................................................................
1.4.3 Notes 1--8.......................................................................
1.5 On Machine Warnings 1--9...........................................................
1.5.1 Hazards 1--9....................................................................
1.6 Safety Procedures 1--10..............................................................
1.6.1 Appropriate Dress 1--10............................................................
1.6.2 Keep Area Clean 1--10.............................................................
1.6.3 Grease and Oil 1--10..............................................................
1.6.4 Manual Usage 1--10...............................................................
2 INSTALLATION 2--1......................................................................
2.1 Installation Requirements 2--3........................................................
2.2 Pre-Installation Requirements 2--4....................................................
2.3 Uncrating & Placement 2--5..........................................................
2.3.1 Main Machine 2--5................................................................
2.3.2 Install Discharge Paper Tray 2--5...................................................
2.3.3 Start--Up & Tools Kit 2--5..........................................................
2.4 Electrical Connection 2--5...........................................................
2.4.1 Electrical Connections 2--5........................................................
3 OPERATION 3--1.........................................................................
3.1 GENERAL INFORMATION 3--3........................................................
3.1.1 Before Operating the Machine 3--3.................................................
3.2 Operating Controls and Indicators Descriptions 3--5...................................
3.2.1 Operator’s Control Panel Layout 3--5................................................
3.2.2 Machine Stopping Device 3--5.....................................................
3.2.3 Additional Machine Controls 3--8...................................................
3.2.4 Brake and Clutch Controllers 3--8...................................................
3.3 Set Up Machine for Production 3--9...................................................
3.3.1 Set Heat Controller For Running Heat Seal Tapes 3--9.................................
3.3.2 Threading Mylar Into Machine 3--9..................................................

Table of Contents
IV Scott Edge Reinforcer
3.3.3 Adjusting Tape Position On Paper 3--12..............................................
3.3.4 Adjusting Delivery Tray 3--12........................................................
3.3.5 Adjusting Cut--Off Guide Finger 3--13................................................
3.3.6 Testing the Cut Off Guide Finger 3--14...............................................
3.3.7 Feeding Machine By Hand 3--15.....................................................
3.3.8 To Remove the Table 3--16.........................................................
3.3.9 Adjusting Automatic Brake On Reel Holder 3--19.......................................
3.3.10 Adjustment Of Brake & Clutch Potentiometers 3--19....................................
3.3.11 Changing From Heavy Stocks To Light Weight Paper Stocks 3--20.......................
3.3.12 Tips For Feeding Lightweight Stocks 3--22............................................
3.3.13 Adjustment of the Trip Switch 3--23..................................................
3.4 Using Self--Adhesive Tape 3--24.......................................................
3.4.1 Recommended Uses For Pressure Sensitive Tape 3--24................................
3.4.2 When to use Pressure Sensitive Polyester Tape instead of Heat Seal Polyester Tape 3--24..
3.4.3 Installing Self--Adhesive Drum Assembly 3--24........................................
3.4.4 Adjustment For “Tracking” 3--27.....................................................
3.4.5 Machine Cleaning 3--29............................................................
4 MAINTENANCE 4--1......................................................................
4.1 Spare Parts 4--3.................................................................
4.1.1 Machine Lubrication 4--4..........................................................
4.1.2 Installing New Trip Switch 4--6.....................................................
4.1.3 Replacing Cut--Off Knives 4--8.....................................................
4.1.4 Removing & Installing the Upper and Lower Cut--Off Knife Assembly 4--9................
4.1.5 Packaging Instructions For Returning Assemblies to Factory for Repairs 4--12.............
4.1.6 Instructions for Installing the Two Cut--off Assemblies 4--12..............................
5 PARTS 5-1..............................................................................
5.1 Base Assembly 5-4.....................................................................
5.2 Base Assembly 5-6.....................................................................
5.3 Feed Plate & Paper Guide Assembly 5-8...................................................
5.4 Gear Belt Idler Assembly 5-10.............................................................
5.5 Main Drive Shaft Assembly 5-12...........................................................
5.6 Motor Assembly 5-14.....................................................................
5.7 Belt Assembly 5-16......................................................................
5.8 Cover Assembly 5-18....................................................................
5.9 Front Roller Belt Assembly 5-20...........................................................
5.10 Tension Arm Assembly 5-22.............................................................
5.11 Support Mounting Assembly 5-24..........................................................
5.12 Electric Motor Assembly 5-26............................................................
5.13 Conveyor Belt Assembly 5-28............................................................
5.14 Pivot Shaft Assembly 5-30...............................................................
5.15 Bearing Housing & Lower Appling Shaft Assembly 5-32......................................
5.16 Slip Ring & Brush Assembly 5-34..........................................................
5.17 Upper & Lower Knife Holder Assembly 5-36................................................
5.18 Housing Assembly 5-38.................................................................
5.19 Sprocket Mounting Assembly 5-40........................................................
5.20 Plastic Mounting Hub Assembly 5-42......................................................
5.21 Roller Mounting Block Assembly 5-44.....................................................

Table of Contents
V
Scott Edge Reinforcer
5.22 Pressure Sensitive Tape Assembly 5-46...................................................
5.23 Leg Extension Assembly 5-48...........................................................
5.24 Rail & Leg Assembly 5-50...............................................................
5.25 Leg Extension Assembly 5-52...........................................................
6 SCHEMATICS 6-1........................................................................

1 Introduction & Safety
1--1
Edge Reinforcer Issue 1
1 INTRODUCTION & SAFETY
Edge Reinforcer Issue 1

1 Introduction & Safety
1--2 Edge Reinforcer Issue 1

1 Introduction & Safety
1--3
Edge Reinforcer Issue 1
1.1 Introduction
The Scott Edge Reinforcer machine lays reinforcing tape within the outside edges of the sheet at the rate
of up to 3,000 sheets per hour.
Fig. 1-1. Edge Reinforcer
Fig. 1-2. Machine Rear View

1 Introduction & Safety
1--4 Edge Reinforcer Issue 1
1.1.1 Scott Edge Reinforcer Machine Specifications and Utility Requirements
Model Scott Edge Reinforcert
Speed Up to 3,000 sheets per hour.
Sheet Size 431.8 mm (17”) WIDTH x ANY LENGTH MAXIMUM
88.9 mm x 203.2mm (3--1/2” WIDTH x 8”) LENGTH MINIMUM
Paper 32lb. Bond to 17 Point Board
Plastic Length 203.2 mm (8”) MINIMUM
ANY LENGTH MAXIMUM
Plastic 14.3 mm -- 19mm (9/16” -- 3/4”)
Motor FEED: 1/3 HP
DRIVE: 1/6HP
Electrical Requirements 15 AMPS, 120 VAC SINGLE PHASE, 60HZ (50HZ Option Available)
Decibel Rating 90 DB
Dimensions L -- 1320.8 MM (52”)
W -- 812.8 MM (32”)
H -- 1422 MM (56”)
Shipping Weight Approximately 152kg (335 lbs)
Warranty One year against defects in parts and workmanship. Labor Not Included.

1 Introduction & Safety
1--5
Edge Reinforcer Issue 1
1.2 General Safety Guidelines
Providing a safe working environment for operating your machine is the responsibility of the user. The
suggested precautions, material safety data and other suggestions that follow do not have preference over
the user’s own plant practices, regulations or safety committee recommendations.
Personal injury and equipment damage can be avoided by the continued adherence to the safety features
provided with this machine and in keeping with the necessary governmental requirements. The guarding
and interlocking safety switches have been installed on the machine for the operator’s safety. These items
should be maintained in good working order by the user.
It is assumed that the user’s safety department has established a safety program that is in keeping with a
complete analysis of industrial hazards. Before installing and operating or performing maintenance and
clean--up procedures on the machine, it is suggested that the safety program be reviewed to ensure that it
covers the possible hazards that might occur with the operation of this machine.
Due consideration must be given to those hazards which arise from the presence of electrical power, high
temperature, and cleaning materials used in the operational areas of the machine. Proper installation and
care of protective devices and over--pressure protective equipment should be considered an essential part of
any safety program.
Special lock--out features are to prevent the possibility of applying power to the equipment at any time when
maintenance work is in progress.
In general, personnel should be guided by all basic rules of safety associated with the equipment and the
process. It should be further understood that information contained in this manual does not relieve operating
and maintenance personnel of the responsibility of exercising normal good judgment in operating and care of
the machine and its attendant equipment.

1 Introduction & Safety
1--6 Edge Reinforcer Issue 1
1.3 Safety Features
E--STOP
Fig. 1-3. Know Where Emergency Stop Button
is Located
These safety features are to be used in conjunction
with the installation, operation and maintenance
instructions contained in this manual.
1.3.1 Emergency Stop
Stops machine drive immediately. This pushbutton
must be manually pulled out to reset.
STOP
Fig. 1-4. Know How to Stop Machine & Set Key
Switch to SAFE
1.3.2 Stop and Safe
The machine operator, clean--up and maintenance
personnel MUST be shown how to stop the
machine and place the SWITCH on the operator’s
CONTROL PANEL in the OFF mode whenever
machine is accessed or clean--up operations are
performed.
Fig. 1-5. Turn Machine Off Before Making
Adjustments
1.3.3 Main Power Switch
If machine is to be shut down for adjustments or
repairs, turn the power supply to the machine off.

1 Introduction & Safety
1--7
Edge Reinforcer Issue 1
Fig. 1-6. Guards Must Be In Place to Run
Machine
1.3.4 Guards and Covers
All safety guards, protective screens and covers
MUST be in place and securely fastened before
operating the machine.

1 Introduction & Safety
1--8 Edge Reinforcer Issue 1
1.4 Warnings, Cautions & Notes
In order to emphasize certain areas in the interest of personal safety and a properly operated and maintained
machine, you will encounter the words WARNING,CAUTION, and NOTE throughout this manual.
WARNING!
Fig. 1-7. Warnings Indicate Personal Danger
1.4.1 Warnings
AN OPERATING PROCEDURE,
PRACTICE, ETC. WHICH IF NOT
CORRECTLY FOLLOWED, COULD
RESULT IN PERSONAL INJURY OR
LOSS OF LIFE.
WARNING!
CAUTION!
Fig. 1-8. Cautions Indicate Potential Damage to
Equipment
1.4.2 Cautions
AN OPERATING PROCEDURE,
PRACTICE, ETC. WHICH, IF NOT
STRICTLY OBSERVED, COULD RESULT
IN DAMAGE TO OR DESTRUCTION OF
EQUIPMENT.
CAUTION!
Note !
Fig. 1-9. Notes Indicate Essential Information
1.4.3 Notes
An Operating Procedure, Condition,
etc. Which is Essential To Highlight.
Note !

1 Introduction & Safety
1--9
Edge Reinforcer Issue 1
1.5 On Machine Warnings
Fig. 1-10. Burn Hazard --- Heat Rollers
1.5.1 Hazards
Observe Hazard signs. There is burn hazard sign
on top of the heat roller unit.
Fig. 1-11. Voltage Warning
There is a hazardous voltage warning on the main
electrical cabinet.

1 Introduction & Safety
1--10 Edge Reinforcer Issue 1
1.6 Safety Procedures
Fig. 1-12. Wear Proper Clothing
1.6.1 Appropriate Dress
Personnel working in the machine operation area
must remove jewelry and neckties. Personnel
must wear clothing appropriate for the work area.
Fig. 1-13. Keep Work Area Clean and Neat
1.6.2 Keep Area Clean
Loose materials, tools and equipment, not
essential to the operation of the machine, must be
removed from the machine work area.
Fig. 1-14. Clean Up Oil and Grease Spills
1.6.3 Grease and Oil
Clean up all oil and grease spills around the
machine work area.
Fig. 1-15. Read Manuals First
1.6.4 Manual Usage
Read and understand the instructions in the
manual before operating, adjusting or servicing
machine.

2 Installation
2--1
Edge Reinforcer Issue 1
2 INSTALLATION
Edge Reinforcer Issue 1

2 Installation
2--2 Edge Reinforcer Issue 1

2 Installation
2--3
Edge Reinforcer Issue 1
2.1 Installation Requirements
Fig. 2-1. Scott Edge Reinforcer on Shipping Skid
All procedures in this section provide advance planning and site preparation data for installation of the Scott
Edge Reinforcer. Environmental requirements, unpacking instructions, electrical and physical specifications
are included. This information should be used as a reference during the development of site preparation
plans before you install your machine.
If any questions arise while performing any of the following procedures, contact:
Note ! A forklift is required to lift the machine off the shipping skid and place it on the floor.

2 Installation
2--4 Edge Reinforcer Issue 1
2.2 Pre-Installation Requirements
The environmental requirements of the Scott Edge Reinforcer must be considered well in advance of the
actual installation. Providing a well suited operating environment will help ensure a trouble free installation
process. Consideration should be given to the following items:
●Power, location and rating of power connections.
●Floor strength
●Level floor
●Adequate space must be provided around all four sides of the machine to permit normal operation and
maintenance procedures. The figure shows the minimum space required.
3
12
3’ (914mm) 3’ (914mm)
3’ (914mm)
3’ (914mm)
Fig. 2-2. Scott Edge Reinforcer Space Requirements
●Space should be allocated near the paper tray for a small table that can be used for small jobs, samples,
etc.
●Provide plenty of space In front of the machine so large jobs can be easily moved in and out with skids or
carts.

2 Installation
2--5
Edge Reinforcer Issue 1
2.3 Uncrating & Placement
The machine will arrive in one crate. Inspect the external condition of the crates for visible signs of damage
before opening. If damage is noticeable, notify the carrier and Scott Equipment before proceeding with the
installation.
To assist in the ease of installation, the machine is disassembled prior to shipping and requires some minor
assembly before the machine is operational.
2.3.1 Main Machine
Step: 1. Remove metal banding straps from cardboard surrounding shipping crates.
CAUTION!EXTREME CAUTION MUST BE EXERCISED WHEN MOVING MACHINE TO INSTALLATION
LOCATION TO PREVENT DAMAGE.
Step: 2. Use a fork lift to place the main machine shipping skid near the designated floor area of operation.
Step: 3. Remove lag screws holding machine to shipping skid.
Step: 4. Raise main machine with fork lift, remove shipping skid assembly from under machine.
Step: 5. Lower main machine to floor.
Step: 6. Remove all protective wrapping from machine.
Step: 7. Remove front and rear covers and place them aside so they won’t be damaged.
Fig. 2-3. Discharge Paper Tray
2.3.2 Install Discharge Paper Tray
The discharge paper tray is shipped uninstalled.
2.3.3 Start--Up & Tools Kit
The machine is shipped a variety of tools and parts required to set the machine up for production. Unpack
box and lay all parts from kit on table top to inventory against the included packing list.
2.4 Electrical Connection
2.4.1 Electrical Connections
The machine requires 110V 15 Amp Service.
Electricity to the machine is delivered through “United States” style plug.
Note ! Electrical cords going to machine should be routed overhead and be of sufficient height to
allow personnel to travel around entire machine without interference.
