SCUDERIA FERRARI F4000C User manual

F3000C 3-in-1
Toddler/Booster carseat
STAGE 1
STAGE 3
STAGE 2
F3000C 3-en-1
Siège d’auto pour tout-pet
/Rehausseur
ETAPE 1
ETAPE 3
ETAPE 2
Lisez aenvement et comprenez toutes les instrucons et les
mises en garde contenues dans ce manuel. Le défaut d’uliser
adéquatement ce siège d’auto accroît le risque de blessure grave ou
de décès lors d’un arrêt brusque ou d’un accident.
!MISE EN GARDE
Pour les enfants âgés d’au moins un an, capables de s’asseoir droit
sans aide et pesant de 10 à 45 kg (22 à 100 lb).
• Cerfié pour une ulisaon à bord d’un aéronef lorsqu’ulisé AVEC
un harnais.
• NON cerfié pour une ulisaon à bord d’un aéronef en mode
siège d’auto rehausseur SANS harnais.
• Respecte ou excède toutes les exigences applicables des Normes
de sécurité des véhicules automobiles du Canada 213 et 213.2.
F4000C
Highback Booster carseat
STAGE 2
STAGE 1
Carefully read and understand all instrucons and warnings
in this manual. Failure to properly use this Car Seat increases
the risk of serious injury or death in a sudden stop or crash.
!WARNING
• For children at least 3 years of age and 18 to 45 kg (40 to 100 lbs).
• Cerfied for use in motor vehicles.
• NOT cerfied for use on aircra.
• Meets or exceeds all applicable requirements of Canada Motor
Vehicle Safety Standard 213.2.
!WARNING
• For children at least 1 year of age, able to sit upright unassisted
and 10 to 45 kg (22 to 100 lbs.).
• Cerfied for use on aircra when used WITH Harness.
• NOT cerfied for use on aircra in Booster Car Seat mode
WITHOUT harness.
• Meets or exceeds all applicable requirements of Canada Motor
Vehicle Safety Standard 213 & 213.2.
F4000C
Siège d’auto rehausseur
à dossier surélevé
Lisez aenvement et comprenez toutes les instrucons et les
mises en garde contenues dans ce manuel. Le défaut d’uliser
adéquatement ce siège d’auto accroît le risque de blessure grave ou
de décès lors d’un arrêt brusque ou d’un accident.
!MISE EN GARDE
• Pour les enfants âgés d’au moins trois ans, et pesant de 18 à 45 kg
(40 à 100 lb).
• Cerfié pour une ulisaon à bord des véhicules
• NON cerfié pour une ulisaon à bord d’un aéronef.
• Respecte ou excède toutes les exigences applicables des Normes
de sécurité des véhicules automobiles du Canada 213.2.
Carefully read and understand all instrucons and warnings
in this manual. Failure to properly use this Car Seat increases
the risk of serious injury or death in a sudden stop or crash.
ETAPE 2
ETAPE 1
Carefully read and understand all instrucons and warnings
in this manual. Failure to properly use this Car Seat increases
the risk of serious injury or death in a sudden stop or crash.
!WARNING
• For children at least 4 years of age and 18 to 45 kg (40 to 100 lbs).
• Cerfied for use in motor vehicles.
• NOT cerfied for use on aircra.
• Meets or exceeds all applicable requirements of Canada Motor
Vehicle Safety Standard 213.2.
F5000C Siège d’auto rehausseur sans dossier
Lisez aenvement et comprenez toutes les instrucons et les
mises en garde contenues dans ce manuel. Le défaut d’uliser
adéquatement ce siège d’auto accroît le risque de blessure grave ou
de décès lors d’un arrêt brusque ou d’un accident.
!MISE EN GARDE
• Pour les enfants âgés d’au moins quatre ans, et pesant de 18 à 45 kg
(40 à 100 lb).
• Cerfié pour une ulisaon à bord des véhicules
• NON cerfié pour une ulisaon à bord d’un aéronef.
• Respecte ou excède toutes les exigences applicables des Normes
de sécurité des véhicules automobiles du Canada 213.2.
F5000C Backless booster Car Seat
Julien DUPUY 05-03-2013
FC7411CEN_C

1.0 GeneralWarningsandInformation..............................................3
2.0  WARNINGS................................................................................7
3.0 FeaturesandBenets
3.1 Highback Booster Car Seat (Front)...........................................11
3.2 Highback Booster Car Seat (Back)............................................12
 3.3 Backless Booster Car Seat........................................................13
4.0 PreparingBoosterCarSeatforUse
 4.1 Determine the Use Mode and Prepare the
Booster Car Seat for Use With Your Child.................................14
4.2 Select a Vehicle Seating Location to
Install the Booster Car Seat.......................................................15
5.0 ProperUseCheckList.................................................................15
6.0 WeightandHeightRecommendations
6.1 Booster Car Seat Use Modes....................................................16
 6.2 Highback Booster Car Seat Use ...............................................17
 6.3 Backless Booster Car Seat Use ...............................................18
7.0 SelectingaVehicleSeatingLocation.........................................19
7.1 Overall Considerations for Selecting
a Seating Location.....................................................................20
7.2 Seating Locations to Avoid.........................................................21
8.0 BoosterCarSeatInstallationandUse......................................22
 8.1 Highback Booster Car Seat
Installation and Use...................................................................23
8.2 Backless Booster Car Seat
Installation and Use...................................................................28
TableofContents
KMC0039 112712.indd 2 11/27/12 7:25 AM

9.0 VehicleSeatBelts
9.1 Check that the Vehicle Seat Belt is Safe to Use..........................32
10.0 OperationandAdjustments
10.1Assembly and Removal of Back Support..................................35
36
37
........................38
38
39
41
42
Maintenance.........................................................
Parts......................................................................
Seat...................................
 10.2Adjusting the Head Support........................................................
 10.3 Cup Holder Attachment..............................................................
11.0 AdditionalInformation
 11.1Certi
 11.2Useful Life.................................................................................
12.0 Cleaningand
13.0 Replacement
14.0 HowtoRegisteryourBoosterCar
TableofContents
KMC0039 112712.indd 3 11/27/12 7:25 AM

The ultimate safety of your child depends on the proper and secure
installation of the Booster Car Seat in your vehicle. Proper installation
requires that you read and understand this entire manual and your
vehicle’s owner’s manual before placing your child in the Booster Car
Seat.
DONOT allow others to install or use this Booster Car Seat unless they
completely understand its proper use and installation.
- When using a Vehicle Lap/Shoulder Belt to secure your child.
Vehicle belt must be properly routed and positioned on your child
and snugly adjusted onto child.
- This Booster Car Seat IS FOR USE in passenger cars,
multi-purpose vehicles (vans and SUVs), trucks, and school buses
that have Vehicle Lap/Shoulder Belts.
- This Booster Car Seat IS NOT FOR USE on aircraft as a
Lap/Shoulder Belt is NOT available on aircrafts.
1.0GeneralWarningsandInformation
3
WARNINGTOPARENTSANDCAREGIVERS
• Properuseisrequired.Yourchild’ssafetydependsontheproper
installation and use of this Booster Car Seat. Read and understand
all information in this owner’s manual and product labels before
using this Booster Car Seat.
• Improper use of the Booster Car Seat can result in death or serious
injury from a sudden stop or crash.
KMC0039 112712.indd 4 11/27/12 7:25 AM

This Booster Car Seat is distributed in Canada by 5514 Km
Corporation. For convenience, 5514 Km Corporation is referred
to as “5514 Km” in this manual.
NEEDHELP?
Contact the Car Seat Group (a division of 5514 Km) Customer Service
by one of the following methods:
- local calls: 416-422-4515
- toll-free calls: 1-855-422-4515
- email: [email protected]
- online: www.csg-canada.com
or one of the following resources:
  • CallTransportCanada1-800-333-0371.
  • Logontohttp:
//www.tc.gc.ca/eng/roadsafety/safedrivers-childsafety-notices-
   menu-907.htm
4
1.0GeneralWarningsandInformation
KMC0039 112712.indd 5 11/27/12 7:25 AM

1.0GeneralWarningsandInformation
5
Yourchild’ssafetydependson:
1. Choosing the correct use mode for your child. Use Highback Mode
as long as possible.
2. Choosing the best location within your vehicle for using the Booster
Car Seat. Seating positions with frontal Air Bags must be avoided
if possible.
3. Proper installation.
a. Booster Use Mode
    - RequiresproperroutingandadjustingtofVehicle
Lap/Shoulder Belt.
b Always properly position the vehicle belts on your child and
snugly adjust the vehicle belts around child.
NOTE: Not all vehicle seat belts or vehicle seats can be used with
this Booster Car Seat.
NEVER use with a Vehicle Lap Belt ONLY.
4. Proper belt adjustment.
- Properly position Vehicle Lap/Shoulder Belt on child.
- Snugly adjust belts around child.
KMC0039 112712.indd 6 11/27/12 7:25 AM

BoosterCarSeatsymbols:
This Booster Car Seat has two (2) different use modes - Highback
Booster Car Seat and Backless Booster Car Seat. In both modes, the
Booster Car Seat MUST be used with a Vehicle Lap/Shoulder Belt.
In this instruction manual, and on the Booster Car Seat labels, the
symbol below is used to indicate Booster Use Mode with a Vehicle
Lap/Shoulder Belt. NEVER use this Booster Car Seat with a Lap Belt
ONLY to secure child.
Special symbols are used throughout this manual and on the Car Seat
labels to help identify these use modes. See symbols below.
Booster Use Mode.
Vehicle Lap/Shoulder Belt
6
1.0GeneralWarningsandInformation
KMC0039 112712.indd 7 11/27/12 7:25 AM

FailuretofollowtheseinstructionsandBoosterCarSeatlabels
canresultinchildstrikingthevehicle’sinteriorduringasudden
stoporcrash.
• UsethisBoosterCarSeatonlywithchildrenwhoweigh
 between18and45kg(40and100lbs.)andwhoseheightis
 between107 (42 and145cm and57in.)andwhoarecapable
 ofsittinguprightunassisted.
• Childmustbeatleast3yearsoldand18kg(40lbs.)touse
 thisBoosterCarSeat.
• ProperinstallationandsecuringofyourchildintheBooster
 CarSeatareessentialtoensurethesafetyofyourchild.Your
 childcanbeinjuredinasuddenstoporcrashifnotproperly
 securedintheBoosterCarSeatoriftheBoosterCarSeatis
 notproperlyinstalledinthevehicle.
• UsethisBoosterCarSeatforward-facingonlywithchildfacing
 thefrontofthevehicle.
• SnuglyadjusttheVehicleLap/ShoulderBeltaroundchild.
• ProperlypositiontheVehicleLap/ShoulderBeltonchild.Lap
 BeltMUSTbelowonchild’shipsandcontactingthighsand
 ShoulderBeltMUSTbecenteredonshoulder.
7
2.0WARNINGS
KMC0039 112712.indd 8 11/27/12 7:25 AM

•UseonlytheVehicle’sLap/ShoulderBeltsystemtorestrain
 achild.
• NeveruseaLapBeltONLY tosecure
 childintheBoosterCarSeat.
• UseBackSupportaslongaspossible.
• Neverleaveyourchildunattended,even
 foramoment.
• NeverputaBoosterCarSeatinavehiclefrontseatlocation
 unlessspecicallyrecommendedinvehicle’sowner’smanual.
• NeverusethisBoosterCarSeatinavehicleseatinglocation
 thathasanActiveAirBagunlessrecommendedinthevehicle’s
 owner’smanual.Ifyourvehicleisequippedwithafront
 passengersideActiveAirBag,pleaserefertothevehicle’s
 owner’smanualforadditionalinformationaboutActiveAirBags
 andchildsafetyseatinstallation.
• Thevehiclebackseatisthesafestplaceforchildren12and
 under.
• SecurelybeltthisCarSeatinvehicle,evenwhennotoccupied.
 AnunsecuredCarSeatcaninjureotheroccupantsinacrash.
8
2.0WARNINGS
KMC0039 112712.indd 9 11/27/12 7:25 AM

• ThisBoosterCarSeatisdesignedandtestedtoaccommodate
 achildofaspecicrangeofWEIGHTandHEIGHT.Usingthe
 BoosterCarSeatforachildwhoseweightorheightisoutside
 oftheselimitswillincreasetheriskofdeathorseriousinjuryin
 theeventofacrash(seeSection6.0ofthismanualforWEIGHT
 andHEIGHTlimitsforthisBoosterCarSeat).
• DONOTdressyourchildinbulkyclothingorothergarments
 thatwillhindervehiclebeltsbeingsnuglyadjustedaroundyour
 child.
• Notallvehicleseatbeltsorseatinglocationscanbeusedwith
 thisBoosterCarSeat.Readvehicle’sowner’smanualand
 “VehicleSeatBelts”sectioninthismanual.
• Somevehiclesdonothaveanysafelocationtousethis
 BoosterCarSeat.Pleaserefertoboththismanualandyour
 vehicle’sowner’smanualforcompleteinformationforproper,
 safeuseofthisBoosterCarSeat.
• ThisBoosterCarSeatiscertiedforuseinmotorvehiclesand
NOTcertiedforuseonaircraft.DONOTusethisBoosterCar
 Seatinthehome,onboatsorothernon-certiedapplications.
• DONOTuseaccessoriesorpartsotherthanthosespecically
 providedforthismodel.Useofaccessoriesorpartsfromother
 manufacturerscouldaltertheperformanceandsafetyofthe
 BoosterCarSeat.
9
2.0WARNINGS
KMC0039 112712.indd 10 11/27/12 7:25 AM

10
• TheBoosterCarSeatmaybecomeveryhotifleftindirect
 sunlight.Yourchildmaysufferburnsfromhotcomponents.
 AlwayschecktheBoosterCarSeatforhotsurfacesthatmay
 comeintocontactwithyourchildbeforeplacingyourchildin
 theBoosterCarSeat.WesuggestthatyoucovertheBooster
 CarSeatwithablanketortowelifitwillbesubjecttodirect
 sunlightwhileyouareawayfromthevehicle.
• ThisBoosterCarSeatisconstructedofplasticthatcandeform
 overtimeifleftwithanyobjectintheseatwhilestored.DONOT
 leaveheavyobjectsintheBoosterCarSeatwhilenotinuse.
 DONOTstoretheseatinthetrunkofyourBoosterwithheavy
 objectsonitorwithpressureontheBoosterCarSeatfromthe
 trunklid.
• DiscontinueuseoftheBoosterCarSeat10yearsfromthe
 dateofmanufactureprintedonthelabelonthebottomofthe
 SeatBase.
• DONOTuseBoosterCarSeatifithasbeeninacrash,itmust
 bereplaced.Acrashcancauseunseendamageandusingit
 againcouldresultinseriousinjuryordeath.
• DONOTuseBoosterCarSeatifitisdamagedorismissing
 parts.
NoBoosterCarSeatcanguaranteeprotectionfrominjuryinevery
situation,butproperusehelpsreducetheriskofseriousinjury
ordeath.
2.0WARNINGS
KMC0039 112712.indd 11 11/27/12 7:25 AM

3.1HighbackBoosterCarSeat(Front)
Seat Base
Armrest
Booster
Shoulder
Belt Guide
11
Seat Base
Pad
Head Support
Pad
Owner’s
Manual
Owner’s Manual
Storage Pocket
(stored under pad)
Armrest
Cup Holder
Can be mounted
on either side
of seat base.
Head Support
Booster Shoulder
Belt Guide
Back Support
Pad
3.0FeaturesandBenets
KMC0039 112712.indd 12 11/27/12 7:25 AM

Head Support
Adjustment
Button
12
3.0FeaturesandBenets
3.2HighbackBoosterCarSeat(Back)
Head Support
Back
Support
Seat
Base
KMC0039 112712.indd 13 11/27/12 7:25 AM

13
3.3 BacklessBoosterCarSeat
(WITHOUTBackSupport)
3.0FeaturesandBenets
KMC0039 112712.indd 14 11/27/12 7:25 AM
Backless Booster Car Seat
Seat Base
Pad
Owner’s
Manual
Owner’s Manual
Storage Pocket
(stored under pad)
Cup Holder
Can be mounted
on either side
of seat base.
Seat Base
Armrest
Armrest
Vehicle Shoulder
Belt Guide
Backless Booster Car Seat
11/26/12 3:02 PM
Vehicle Shoulder Belt Positioner

ThestepstopreparetheBoosterCarSeatforusewithyourchild
areoutlinedbelowanddescribedindetailinthisowner’smanual.
4.1DeterminetheUseModeandPreparetheBooster
 CarSeatforusewithyourChild
HighbackBoosterCarSeat
atleast3yearsold,“18to45kg”(40to100lbs.),
 and107to127cm(42to50inches)tall(see
 WeightandHeightRecommendations”section).
- For Highback Mode assemble the Back Support
(see “Assembly and Removal of Back Support”
section).
- Adjust Head Support for your child (see
“Adjusting the Head Support” section).
BacklessBoosterCarSeat
atleast4yearsold,“18to45kg”(40to100lbs.),
 andatleast107cm(42inches)tall(see“Weight
 andHeightRecommendations”section).
- Remove Back Support (see “Assembly
and Removal of Back Support” section).
14
4.0PreparingBoosterCarSeatforUse
KMC0039 112712.indd 15 11/27/12 7:25 AM

4.2SelectaVehicleSeatingLocation
 toInstalltheBoosterCarSeat
 • Selectavehicleseatinglocation
with a Lap/Shoulder Belt.
 • Neveruseavehicleseatinglocation
with a Lap Belt ONLY.
BoosterCarSeat
√Lap and Shoulder Belts are snugly adjusted around child.
√ LapBeltislowandatonhipsandcontactingthighs.
√Shoulder Belt is centered on shoulder.
√Child is sitting up, not slouching down under Vehicle Lap Belt.
√Shoulder belt is not under arm or behind back of child.
√Top of child’s ears are below top of Back Support, vehicle seat
back, or headrest.
√Shoulder belt slides freely in inner slot of Booster Shoulder Belt
Guide.
4.0PreparingBoosterCarSeatforUse
15
Lap Belt ONLY
5.0ProperUseCheckList
KMC0039 112712.indd 16 11/27/12 7:25 AM

16
6.0WeightandHeightRecommendations
WARNING!
   DEATHorSERIOUSINJURYcanoccur:
 •FAILURETOUSECHILDRESTRAINTINAMANNER
  APPROPRIATEFORYOURCHILD’SSIZEMAYINCREASE
  THERISKOFSERIOUSINJURYORDEATH.
This child restraint is designed for use only by children who are at least
3 years old, can sit upright unassisted, who weigh between 18 and 45
kg(40and100lbs.)andwhoseheightisbetween107and145cm
(42and57inches).
6.1BoosterCarSeatUseModes
This Booster Car Seat has two different use modes for the weight and
height ranges listed above and depends on the size of your child. Be
sure you are using the child restraint in the correct mode and with the
correctfeaturesforyourchildasidentiedinthisowner’smanual.
1. HighbackBoosterCarSeat
  atleast3yearsoldand18-45kg(40-100lbs.)
   •UseHighbackBoosterwithBackSupportaslongas
possible before changing to Backless Booster Mode.
2. BacklessBoosterCarSeat (WITHOUTBackSupport)
  atleast4yearsoldand18-45kg(40-100lbs.)
KMC0039 112712.indd 17 11/27/12 7:25 AM

6.2HighbackBoosterCarSeatUse
(WITHBackSupport)
 ChildMUSTmeetallofthefollowingrequirements
 tousetheHighbackBoosterCarSeatmode:
 • Childmustbeatleast3years
of age and
 • Child’sweightisbetween
  18and45kg(40and
  100lbs.)and
 • Child’sheightisbetween
  107and127cm(42and
  50in.).
Pediatricians recommend using a Highback Booster Car Seat as
long as possible before changing to a Backless Booster Car Seat.
The Highback Booster Car Seat should be used until the child’s
 shouldersdonottcomfortablyunderthesidewingsoftheHead
Support.
Parents are advised that the Back Support and Head Support of the
Highback Booster Car Seat provide incremental crash protection
in frontal and side impact crashes. Removing the Back Support
and Head Support earlier than necessary also removes the
incremental crash protection.
6.0WeightandHeightRecommendations
17
KMC0039 112712.indd 18 11/27/12 7:25 AM

6.3BacklessBoosterCarSeatUse
(WITHOUTBackSupport)
 ChildMUSTmeetallofthefollowingrequirements
 tousetheBacklessBoosterCarSeatmode:
 • Childmustbeatleast4years
of age and
 • Child’sweightisbetween18
  and45kg(40and100lbs.)and
 • Child’sheightisbetween107
  and145cm(42and57in.)and
 • Topofchild’searsmustbe
below top of vehicle seat back
or vehicle headrest.
Use Highback Booster Car Seat as
long as possible before changing to
Backless Booster.
Pediatricians recommend using a Backless Booster Car Seat until
 thechildreachesastandingheightof145cm(57in.)before
changing to secure the child with a vehicle seat belt, without a
Booster Car Seat.
6.0WeightandHeightRecommendations
WARNING!
DEATHorSERIOUSINJURYcanoccur:
• TOAVOIDINJURIESFROMWHIPLASH,TOPOF
 CHILD’SEARSMUSTBEBELOWTOPEDGEOF
 VEHICLESEATBACKORVEHICLEHEADREST.
18
KMC0039 112712.indd 19 11/27/12 7:25 AM

Not every seating location within a vehicle may be safe for use
of this Booster Car Seat. In fact, some vehicles have no seating
location that is safe for the installation of a Booster Car Seat.
Improper placement of this Booster Car Seat within a vehicle will
increase the risk of death or serious injury in a sudden stop or
crash.
See “Vehicle Seat Belts” section for more information on vehicle
seat belts.
Please follow the instructions in this manual and in your vehicle
owner’s manual carefully to ensure proper location and installation
of this Car Seat. If you are uncertain about the proper location of
the Car Seat within the vehicle, call the Car Seat Group (a division
of 5514 Km Corporation) at 1-855-422-4515 or log onto
www.csg-canada.com for assistance before using this seat. You
may also contact your vehicle manufacturer directly or through
their dealer.
19
WARNING!
 •Therearemanydifferenttypesofvehicles,vehicleseatbelt
  systems,orotheroccupantrestraintsystemsinusetoday.
  Accordingly,thismanualcanonlygiveguidelinesforproper
  useoftheVehicleLap/ShoulderBeltinyourvehicle.In
  additiontothismanual,youmustalsoreadandunderstand
  thevehicle’sowner’smanual,whichshouldaddressuseof
  BoosterCarSeats.Ifyourvehicle’sowner’smanualdoesnot
  addresstheinstallationofBoosterCarSeats,pleasecontact
  yourlocalvehicledealer,orthevehicle’smanufacturerto
  obtainthisinformationbeforeusingthisBoosterCarSeat.
7.0SelectingaVehicleSeatingLocation
KMC0039 112712.indd 20 11/27/12 7:25 AM
