OPERATING MECHANISM
TYPE MR41E
ENGLISH
INSTRUCTION BOOK
NTI010hA
PAGE
SPECIAL ADAPTATION STUDIES
SITE OPERATIONS / ON-SITE ASSESSMENT
ASSEMBLY SUPERVISION
SPARE PARTS
TRAINING
REFURBISHMENT
ISO 9001 AND ISO 14001 CERTIFICATIONS
01 NTI010hA
THE KNOW-HOW OF SDCEM SERVICES
Operating mechanism
type MR41E
PAGE
INTRODUCTION
SAFETY AND RECOMMENDED
GLOSSARY
STORAGE AND HANDLING
CHARACTERISTICS
INSTALLATION
ADJUSTMENT
MAINTENANCE
SPARE PARTS
FAQ
02
Date: Issued by:
08/06/2016 CA NTI010hA
Operating mechanism
type MR41E
CONTENTS
03
05
06
ENGLISH
07
19
23
21
14
24
07
07
07
08
14
15
17
24
08
09
18
10
12
13
13
PAGE
PURPOSE
This Instruction Book provides assistance with site assembly and adjustment and supplies safety
and maintenance information. It refers to the drawings supplied in the contract (outline drawings,
installation drawings, wiring diagrams, etc).
To install equipment properly, the following are thus required:
- the drawings supplied in the equipment contract
- the disconnector manual
- the operating drive manual (electrical and/or manual operating mechanism)
THIS INSTRUCTION BOOK IS INTENDED FOR
Project managers.
SDCEM PRODUCT REGULATIONS
the applicable regulations in the country where they are located.
CONTACT
Your contact, if necessary, is SDCEM Services (contact details on the last page of this Instruction
Book).
As our equipment warranty is dependent on strict compliance with the information provided in this
Instruction Book, we ask you to comply with this information in all respects.
CAPTIONS
The following symbols are used in this Instruction Book :
03 NTI010hA
Danger
This warning sign indicates a hazardous situation that, if the necessary precautions are not
taken, may lead to serious injuries or material damage.
Important note
Indicates particularly important information.
i
INTRODUCTION
Foreword
Safety and recommended tools
Operating mechanism
type MR41E
PAGE
SAFETY INSTRUCTIONS
Maintenance operations must be carried out by persons possessing:
• the necessary electrical accreditation,
• knowledge of the equipment in question.
Some maintenance operations must be carried out by SDCEM technicians, who can also
provide you with assistance in assembly and adjustment of your installations. Please contact
SDCEM Services for all queries (contact details on the last page of this Instruction Book).
Electrical
accreditation :
Recognition of a person’s
ability to safely carry out
the tasks assigned to him/
her.
The accreditation
category specifies its
scope and limits
04
NTI010hA
INTRODUCTION
Foreword
Safety and recommended tools
Operating mechanism
type MR41E
The installation concerned by the operation must be de-energised prior to operation.
Electrocution, burn, explosion, finger squeezing, cut-offs (handling, operations, etc.) hazards are
present at each operation.
Only qualified persons, complying with all safety regulations, are accredited to perform such
operations.
DANGER: Electrocution, burn and explosion hazards
Safety and operation instructions, personal protective equipment, tools
and signalling
Refer to local regulations and legislation.
RECOMMENDED TOOLS (Not supplied by SDCEM)
Adjustable spanner (600 long)
Spirit level
ENGLISH
PAGE
CAPTIONS
Fixing plane
Output shaft (vertical)
Connection terminal blocks
Fixing bracket (option)
Operating mechanism earthing terminal
A
B
C
D
Cable gland plate
Ventilation device
Emergency crank-handle
S-Digit display
Position selector
F
G
05 NTI010hA
GLOSSARY
Storage / Handling / Weight
H
I
EJ
Operating mechanism
type MR41E
C
A
B
H
D
G F
E
JI
000
PAGE
06
NTI010hA
STORAGE AND HANDLING
Storage / Handling / Weight
TYPE OF EQUIPMENT TO BE STORED: INDOOR / OUTDOOR
3 types of packaging are used :
(crate with plywood walls or wooden bound case).
UNPACKING, HANDLING
Handle and unpack the equipment with care, in particular :
WEIGHT
Minimum weight for an operating mechanism is 30kg. Refer to the instructions for the
hoisting means used.
Stacking forbidden
Type of
packaging Length Indoor equipment Outdoor equipment
SEI 3 and SEI 4a
1 month - In original packaging - In original packaging
- In ventilated, dry place
1 month - Into bottom case - Into bottom case
12 months - In ventilated, dry place - Store operating mechanisms
- Supply the anti-condensation in vertical position
resistance of electrical or manual - Supply the anti-condensation
operating mechanisms resistance of electrical or manual
operating mechanisms
SEI 4c
6 months - In the original packaging and sheltered
- No specific conditions
6 months - Into bottom case
12 months - Caution: remove the plastic cover
- In ventilated, dry place
- Supply the anti-condensation resistance of electrical and manual
operating mechanisms and of switchgear cubicles.
After 12 months, consult us to adapt equipment storage conditions to equipment site.
Handling instructions
Operating mechanism
type MR41E
Without braket
With bracket
ENGLISH
PAGE
07 NTI010hA
CHARACTERISTICS
Operating mechanism
type MR41E
MECHANICAL CHARACTERISTICS
ELECTRICAL CHARACTERISTICS
10s (optional for other values)
500 Nm (2000 cycles) or 350 Nm (10000 cycles)
1000 Nm (MR41E_A) or 2000 Nm (MR41E_C) (10000 cycles)
120 turns
21 turns before closed position
IP56
In position Out of Use (optional for other positions)
Padlock, keylock in option
Option
110Vdc (std), 48 Vdc, 120Vdc, 125Vdc, 220Vdc, 110Vac
single-phase, 230Vac single-phase, 12/208Vac three-
phase, 230/400 Vca three-phase - 50Hz/60 Hz.
110Vdc (std), 48 Vdc, 120 Vdc, 125 Vdc, 220 Vdc,
110Vac single-phase, 230 Vac single-phase - 50Hz/60 Hz
230Vac (option 110Vac) - 50 Hz / 60 Hz.
Class 2
Local and distance
300W
8O/8C (option 16O/16C)
Option
POSITION SELECTOR
The position selector has 4 operating modes :
Position
selector
switch
iTo help you, an instruction plate is affixed
on each operating mechanism casing.
PAGE
08
NTI010hA
CHARACTERISTICS
OPERATING MECHANISM ROTATION DIRECTION
NOR Direction
Vertical output
NOR Direction
Right output
NOR Direction
Left output
INV Direction
Vertical output INV Direction
Right output
INV Direction
Left output
