TABLE OF CONTENTS
www.SeaDooManuals.net

II
SAFETY NOTICE
This manual was primarily published to be used by watercraft technicians trained by the manufacturer
who are already familiar with all service and maintenance procedures relating to Bombardier made Sea-
Doo watercraft.
Please note that the instructions will apply only if proper hand tools and special service tools are used.
It is understood that this manual may be translated into another language. In the event of any discrepan-
cy, the English version shall prevail.
The content depicts parts and/or procedures applicable to the particular product at its time of manufac-
ture. It does not include dealer modifications, whether authorized or not by Bombardier, after manufac-
turing the product.
The use of Bombardier parts is most strongly recommended when considering replacement of any com-
ponent. Dealer and / or distributor assistance should be sought in case of doubt.
Torque wrench tightening specifications must be strictly adhered to. Locking devices (ex.: locking disk,
lock nut) must be installed or replaced with new ones, where specified. If the efficiency of a locking
device is impaired, it must be renewed.
This manual emphasizes particular information denoted by the wording and symbols;
NOTE: Indicates supplementary information needed to fully complete an instruction.
Although the mere reading of such information does not eliminate the hazard, your understanding of the
information will promote its correct use. Always use common shop safety practice.
This information relates to the preparation and use of Bombardier watercraft and has been utilized safely
and effectively by Bombardier Inc. However, Bombardier Inc. disclaims liability for all damages and/or
injuries resulting from the improper use of the contents. We strongly recommend that any services be
carried out and/or verified by a highly skilled professional technician. It is understood that certain modifi-
cations may render use of the watercraft illegal under existing federal, provincial and state regulations.
◆WARNING
Identifies an instruction which, if not followed, could cause serious personal injury including
possibility of death.
-CAUTION
Denotes an instruction which, if not followed, could severely damage watercraft components.
SAFETY NOTICE
www.SeaDooManuals.net

III
INTRODUCTION
This Shop Manual covers BOMBARDIER made
SEA-DOO®watercraft models SP 5879, SPX
5834/5661, XP 5662, GS 5621, GSI 5622, GSX
5624, GTS 5818, GTI 5641, GTX 5642 and HX
5882.
HULL IDENTIFICATION NUMBER
(H.I.N.)
SP, SPX, GTS and HX Models
It is located at right rear side of hull.
1. Hull Identification Number (H.I.N.)
XP, GS, GSI, GSX, GTI and GTX Models
It is located on floorboard at the rear of the water-
craft.
1. Hull Identification Number (H.I.N.)
All Models
The Hull Identification Number is composed of 9 digits:
ENGINE IDENTIFICATION
NUMBER (H.I.N.)
717 Engines
The Engine Identification Number is located on
the upper side of the magneto housing.
TYPICAL
1. Engine Identification Number (E.I.N.)
F01L45A
1
F07A01A
1
Z Z N 1 2 3 4 5 L 4 9 5
Model year
Serial
number*
*
A letter may also be used as a digit.
F00A0CA
Month of production
Year of production
*
A letter may also be used as a digit.
1
F01D01A
1997 BOMBARDIER WATERCRAFT SHOP MANUAL
www.SeaDooManuals.net

IV
787 Engine
The Engine Identification Number is located on
the crankcase on PTO side.
1. Engine Identification Number (E.I.N.)
ARRANGEMENT OF THIS
MANUAL
The manual is divided into 13 major sections:
01 MAINTENANCE
02 TROUBLESHOOTING
03 ENGINE
04 COOLING SYSTEM
05 FUEL SYSTEM
06 LUBRICATION SYSTEM
07 ELECTRICAL SYSTEM
08 PROPULSION SYSTEM
09 STEERING SYSTEM
10 SUSPENSION
11 HULL/BODY
12 TECHNICAL DATA
13 WIRING DIAGRAMS
Several sections are divided in various sub-sections.
There is a table of contents at the beginning of
many sections.
F01D87A 1
1997 BOMBARDIER WATERCRAFT SHOP MANUAL
www.SeaDooManuals.net

V
Section 03 ENGINE
Sub-Section 04 (MAGNETO SYSTEM)
MAGNETO SYSTEM
717 Engine
03-04-1
F01D4WS
12 11
5 N•m
(44 lbf•in)
13 9 N•m
(80 lbf•in)
Loctite
242
4
68Loctite
242
7
6 N•m
(53 lbf•in)
Loctite
242
6 N•m
(53 lbf•in)
9
Loctite
242
5
6 N•m
(53 lbf•in)
3
14
Loctite
242
4
Loctite
648
10
15
145 N•m
(107 lbf•ft)
Anti-seize
lubricant 2
9 N•m
(80 lbf•in)
1
Page heading
indicates section
and sub-section
detailed.
Tightening torque nearby fastener.
In this case, nut must be torqued to
145 N•m (107 lbf•ft).
Exploded view assits
you in identifying
parts and related
positions.
TYPICAL PAGE
F01A09S
Illustration number
for publishing
process.
Sub-section title
indicates
beginning of the
sub-section.
Dotted box
contains parts of
a particular
model or an
exploded view.
Page numbering system:
03: ENGINE section
04: MAGNETO SYSTEM sub-section
1: First page of this sub-section
Italic sub-tiltle
above exploded
view indicate
pertaining models.
Drop represents a
liquid product to be
applied to a surface.
In this case Loctite
242 to screw
threads.
Bold face number
indicates special
procedure
concerning this part.
Pay attention to torque specifi-
cations. Some of these are in
lbf•in instead of lbf•ft. Use appro-
priate torque wrench.
CAUTION
▼
1997 BOMBARDIER WATERCRAFT SHOP MANUAL
www.SeaDooManuals.net

VI
1
2
Section 06 FUEL SYSTEM
Sub-Section 03 (CARBURETORS)
06-03-4
Step : Install pump gauge tester to pulse nipple
Step : Pump tester until it reaches the desired pressure
1. Fuel outlet nipple
2. Fuel inlet nipple
A. 28 kPa (4 PSI)
3, Diaphragm
XP Model Only
CARBURETOR REMOVAL
Inspect parts for corrosion dammage (shaft, butterfly,
spring screw, check valve housing, etc.).
PUMP DIAPHRAGM LEAK TEST
TYPICAL
To remove carburetors from engine, proceed as fol-
lows:
Remove air vent tube support.
Unlock retaining slides holding air intake silencer base.
Remove air intake silencer base from watercraft.
Remove screws holding flame arrester base support
to cylinder head cover.
Unscrew base retaining screws then remove base from
carburetors and move to front of watercraft.
Turn the valve to OFF position.
NOTE: For fuel line removal, use pliers (P/N 295
000 054).
Disconnect pulse line from fuel pump.
Disconnect fuel fuel supply line from fuel pump.
Disconnect fuel return line.
Disconnect oil injection pump cable, throttle cable and
choke cable.
Remove screws no. 6 and lock washers no. 7 retaining
carburetors.
All Others Models
Remove 4 bolts no. 8 and lock washers no. 12 from
rotary valve cover then move carburetors and rotary
valve cover on top of engine.
NOTE: When removing rotary valve cover , pay
attention that the rotary valve stay in place, other-wise
it must be timed.
Remove carburetors from intake manifold.
Disconnect fuel bypass line between carburetors (twin
carburetors).
Remove carburetor(s) from rotary valve cover.
DISASSEMBLY AND INSPECTION
Using a suitable pump gauge tester, perform the fol-
lowing test proceeding as follows:
- Install pump gauge tester (P/N 295 000 083) on pulse
nipple.
- Pump tester until it reaches 28 kPa (4 PSI).
Diaphragm must stand pressure for 10 seconds. If
pressure drops, replace diaphragm.
TYPICAL PAGE
Sub-title with part
number(s) from exploded
view followed by part
name(s).
''TYPICAL'' mention
indicates a general
view which does not
represent full detail.
Sub-sub-title in this
case indicates that
particular procedure
for XP is finished, so
from this point, all
others models are
concerned.
Title in italic indicates a
particular procedure
concerning a model.
Service tool to be
used to perform a
certain procedure.
Title indicates main
procedure to be
carried-out.
F01A0AS
Sub-sub-title in
capital indicates a
particular testing,
adjustment or
repair procedure.
Illustration
always follows
text it is
pertained to.
Numbers in a frame
are used to give a
sequence to be
perfomed.
Numbers are used
for desciption of
components.
Letters are used for
any measures.
F01F0XB
A
2
1
1 2
Bold numbers in the
text refer to the parts
shown in the exploded
view at the beginning
of the sub-section.
1997 BOMBARDIER WATERCRAFT SHOP MANUAL
www.SeaDooManuals.net

VII
GENERAL INFORMATION
The use of RIGHT and LEFT indications in the text,
always refers to driving position (when sitting on
watercraft).
1. Left (port)
2. Right (starboard)
The information and component/system descrip-
tions contained in this manual are correct at time
of publication. Bombardier Inc. however, main-
tains a policy of continuous improvement of its
products without imposing upon itself any obliga-
tion to install them on products previously manu-
factured.
Bombardier Inc. reserves the right at any time to
discontinue or change specifications, designs,
features, models or equipment without incurring
obligation.
This
Shop Manual
uses technical terms which
may be different from the ones of the
Parts Cata-
logs
.
When ordering parts always refer to the specif-
ic model
Parts Catalogs
.
ILLUSTRATIONS AND
PROCEDURES
The illustrations show the typical construction of
the different assemblies and, in all cases, may not
reproduce the full detail or exact shape of the
parts shown, however, they represent parts
which have the same or a similar function.
As many of the procedures in this manual are in-
terrelated, we suggest, that before undertaking
any task, you read and thoroughly understand the
entire section or sub-section in which the proce-
dure is contained.
A number of procedures throughout the book re-
quire the use of special tools. Before undertaking
any procedure, be sure that you have on hand all
the tools required, or approved equivalents.
Technical Publications
Bombardier Inc.
Valcourt (Quebec), Canada
F01L45B
12
-CAUTION
These watercraft are designed with parts di-
mensioned in both the metric and the impe-
rial systems. When replacing fasteners,
make sure to use only those recommended
by Bombardier.
1997 BOMBARDIER WATERCRAFT SHOP MANUAL
www.SeaDooManuals.net

01-01-1
Section 01 MAINTENANCE
Sub-Section 01 (TABLE OF CONTENTS)
TABLE OF CONTENTS
PERIODIC INSPECTION CHART............................................................................................ 01-02-1
FLUSHING AND LUBRICATION............................................................................................ 01-03-1
GENERAL ........................................................................................................................... 01-03-1
PROCEDURE ...................................................................................................................... 01-03-1
WATER-FLOODED ENGINE................................................................................................... 01-04-1
GENERAL ........................................................................................................................... 01-04-1
PROCEDURE ...................................................................................................................... 01-04-1
STORAGE............................................................................................................................... 01-05-1
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 02 (PERIODIC INSPECTION CHART)
01-02-1
PERIODIC INSPECTION CHART 0
NOTE: Servicing period is given in hours. Shaded area shows the maintenance frequency.
➀Every 10 hours in salt water use.
➁These items have to be initially checked after 25 hours. Thereafter, servicing to be made as specified
in this chart.
➂Daily flushing in salt water or foul water use.
DESCRIPTION
FREQUENCY
Every
10 hours Every 25 hours Every 50 hours
Every 100
hours or
seasonally
Lubrication/corrosion protection of metallic components ➀
Engine ignition timing
Spark plug replacement
Throttle/choke cables, inspection/lubrication ➀
Flame arrester inspection
Carburetor adjustment including choke/throttle cable adjustments and linkage
RAVE valve cleaning (787 engine)
Water flow regulator valve inspection (787 engine)
Oil injection pump adjustment
Fuel filter and oil filter inspection
Fuel filter and oil filter replacement
Engine head bolts, retorque
Steering system inspection
Reverse system/reverse cable adjustment (if applicable)
Variable trim system (if applicable)
Fastener tightening (flame arrester support, carburetor(s), engine mount, exhaust
system, etc).
Muffler, battery and reservoir fastening devices
Fuel/oil lines, check valve and hose inspection, fuel system pressurization
Fuel/vent line pressure relief valve inspection
Inspect/clean engine drain hose ➀
Water tank trap drain inspection (GTS)
Bailer pick up inspection
Battery condition
Electrical connections (starter, battery, etc.)
Monitoring beeper
Impeller shaft reservoir oil level/oil condition Replace
Impeller condition and impeller/wear ring clearance ➁
Drive shaft boot/spline condition (both ends) ➁
PTO flywheel and mid bearing (HX/XP models only) lubrication
Water intake grate condition ➁
Hull condition
Cooling system flushing ➂
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 03 (FLUSHING AND LUBRICATION)
01-03-1
FLUSHING AND LUBRICATION 0
GENERAL
Flushing the cooling system with fresh water is
essential to neutralize corroding effects of salt or
other chemical products present in water. It will
help to clean up sand, salt, shells or other particles
in water jackets (engine, exhaust manifold, tuned
pipe) and/or hoses.
Flushing and engine lubrication should be per-
formed when the watercraft is not expected to be
used further the same day or when the watercraft
is stored for any extended time.
PROCEDURE
Clean jet pump by spraying water in its inlet and
outlet and then spray BOMBARDIER LUBE lubri-
cant.
SP, SPX and GTS Models
Remove seat to allow access of cooling system.
XP Model
Remove rear access cover.
SP, SPX, GTS and XP Models
Remove dust cap from fitting spigot and attach
coupler hose (P/N 295 500 258). Make sure cou-
pler hose is properly locked to fitting spigot.
Install a hose pincher on water outlet hose.
TYPICAL
1. Coupler hose
2. Fitting spigot
3. Hose pincher
Attach other end of coupler hose to a garden hose.
GS Series, GTI and GTX Models
Connect a garden hose to the water outlet located
at the rear of the watercraft.
-CAUTION
Failure to flush cooling system, when neces-
sary, will severely damage engine and/or ex-
haust system. Never flush a hot engine.
Make sure engine operates during entire
procedure.
◆WARNING
Perform this operation in a well ventilated
area. Do not touch any electrical parts or jet
pump area when engine is running.
◆WARNING
Always remove safety lanyard cap from
switch to prevent accidental engine starting
before cleaning the jet pump area. Engine
must not be running for this operation.
-CAUTION
This prevents water from exiting through
outlet socket. Remove hose pincher after
flushing operation.
-CAUTION
Do not open water tap yet.
F01E1EA
1
2
3
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 03 (FLUSHING AND LUBRICATION)
01-03-2
1. Water outlet
NOTE: A quick hose connector can be used to
ease garden hose installation.
1. Quick hose connector
1. Garden hose installed
All Models
Start the engine then immediately open the water
tap.
Run the engine about 3 minutes at a fast idle
around 3500 RPM.
Pull plug from air intake silencer cover.
1. Air intake silencer cover
2. Pull plug
Spray BOMBARDIER LUBE lubricant through air
intake silencer cover keeping engine at fast idle.
1. Spray Bombardier Lube
NOTE: Lubrication of engine should be done at
least for one minute.
F06E01A
1
F00E01A
1
F07E01A
1
-CAUTION
Always start the engine before opening the
water tap. Open water tap immediately after
engine is started to prevent overheating.
F01F25B
1
2
F00M01A
1
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 03 (FLUSHING AND LUBRICATION)
01-03-3
After approximately half a minute, close fuel valve
to run engine out of fuel while lubricating.
Disconnect the garden hose.
SP, SPX, GTS and XP Models
Unlock and remove coupler hose. Reinstall dust
cap over fitting spigot.
Remove hose pincher from water outlet hose.
All Models
Wipe up any residual water from the engine.
Remove spark plug cables and connect them on
the grounding device.
SP, GTS AND HX MODELS
1. Spark plug cables on grounding device
SPX, GS, GSI, GSX, GTI AND GTX MODELS
1. Spark plug cables on grounding device
XP MODEL
1. Grounding device
Remove both spark plugs and spray BOMBAR-
DIER LUBE lubricant into each cylinder.
Crank the engine a few turns to distribute the oil
onto cylinder wall.
Apply anti-seize lubricant on spark plug threads
then reinstall them.
Reinstall plug on air intake silencer cover.
-CAUTION
When engine begins to run irregularly, im-
mediately close the water tap to stop water
flow before engine dies.
-CAUTION
If used, remove the quick hose connector
from watercraft.
F01H64A
1
F00H0DA
1
F00H0AA
1
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 03 (FLUSHING AND LUBRICATION)
01-03-4
NOTE: Engine fogging should be done with
BOMBARDIER LUBE lubricant whenever the wa-
tercraft is to be stored for a few days or a long
period.
-CAUTION
Never leave rags or tools in the engine com-
partment or in the bilge.
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 04 (WATER-FLOODED ENGINE)
01-04-1
WATER-FLOODED ENGINE 0
GENERAL
If engine is water-flooded, it must be serviced
within a few hours after the event. Otherwise en-
gine will have to be overhauled.
PROCEDURE
Check fuel and oil reservoirs for water contamina-
tion. If necessary, siphon and refill with fresh flu-
ids.
Turn fuel valve to OFF position then drain fuel filter
bowl. Refer to FUEL SYSTEM 05-02.
Drain bilge if water is present.
Remove spark plug cables and connect them on
the grounding device.
SP, GTS and HX Models
1. Spark plug cables on grounding device
SPX, GS, GSI, GSX, GTI and GTX
1. Spark plug cables on grounding device
XP Model
1. Grounding device
All Models
Remove spark plugs and dry them with a clean
cloth. A contact cleaner spray can be used. It may
be preferable to replace spark plugs. Do NOT in-
stall spark plugs on engine.
Crank engine to drain crankcase.
-CAUTION
A water-flooded engine must be properly lu-
bricated, operated then lubricated again,
otherwise parts will be seriously damaged.
◆WARNING
Never crank engine with spark plugs re-
moved unless spark plug cables are con-
nected to the grounding device.
F01H64A
1
-CAUTION
Be careful when cranking engine, water will
spray out from spark plug holes.
F00H0DA
1
F00H0AA
1
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 04 (WATER-FLOODED ENGINE)
01-04-2
Spray BOMBARDIER LUBE lubricant (P/N 293
600 016) into spark plug holes.
Crank engine again.
Reinstall spark plugs and spark plug cables.
SPX, GSX, GTX and XP Models
On the 787 engine, remove the drain plug of the
counterbalance shaft located on the PTO side of
the lower crankcase.
Drain completely the crankcase oil of the counter-
balance shaft. Reinstall drain plug.
Remove the filling plug located on the upper
crankcase.
Add 30 mL (1 oz) of SAE 30 motor oil.
Reinstall filling plug.
All Models
Turn fuel valve to ON position.
Start engine; It may be necessary to use the
choke. If engine does not start, repeat previous
steps as necessary.
NOTE: If engine does not start after several at-
tempts, check ignition system for spark occur-
rence. Refer to ELECTRICAL SYSTEM 07-02.
Check crankshaft if needed, it may be misaligned
or deflected. Refer to ENGINE 03-06.
After engine has started, spray BOMBARDIER
LUBE lubricant through air intake silencer while
engine is running.
1. Spray Bombardier Lube
Run engine until it reaches its normal operating
temperature.
-CAUTION
To avoid starting motor overheating, the
cranking period should not exceed 5-10 sec-
onds and a rest period of 30 seconds should
be observed between cranking cycles.
-CAUTION
Engine must be cooled using the flush kit.
F00M01A
1
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 05 (STORAGE)
01-05-1
STORAGE 0
Engine Draining
Check engine drain hose. Make sure there is no
sand or other particles in it and that it is not ob-
structed so that water can leave the engine. Clean
hose and fitting as necessary.
All Models Except XP and HX
TYPICAL
1. Engine drain hose
2. Exhaust outlet
XP and HX Models
TYPICAL
1. Engine drain hose
Fuel System
Sea-Doo Fuel Stabilizer (P/N 413 408 600) should
be added in fuel tank to prevent fuel deterioration
and carburetor gumming. Follow manufacturer’s
instructions for proper use.
NOTE: Fuel stabilizer should be added prior en-
gine lubrication to ensure carburetor protection
against varnish deposit.
Always turn the fuel valve to OFF position when
storing the watercraft.
Cooling System Flushing and Engine
Internal Lubrication
Cooling system has to be flushed with fresh wa-
ter to prevent salt, sand or dirt accumulation
which will clog water passages.
Engine must be lubricated to prevent corrosion on
internal parts.
For proper procedure, refer to MAINTENANCE
01-03.
-CAUTION
Water in engine drain hose must be free to
flow out, otherwise water could be trapped
in engine. Should water freeze in engine, se-
vere damage will occur. Check engine drain
hose for obstructions.
2
F02E02A
1
◆WARNING
Fuel is flammable and explosive under cer-
tain conditions. Always work in a well venti-
lated area.
F05J04A
1
www.SeaDooManuals.net

Section 01 MAINTENANCE
Sub-Section 05 (STORAGE)
01-05-2
Propulsion System
Lubricant in impeller shaft reservoir should be
drained. Reservoir should be cleaned and refilled
with SEA-DOO synthetic 75W90 GL5 polyolester
oil. Refer to PROPULSION SYSTEM 08-02.
All Models Except XP and HX
Lubricate PTO flywheel at grease fitting with syn-
thetic grease (P/N 293 550 010).
1. Grease PTO flywheel
XP and HX Models
Lubricate mid bearing of drive system at seal car-
rier grease fitting with synthetic grease.
1. Grease fitting
Battery
For battery removal, cleaning and storage, refer to
ELECTRICAL 07-03.
Watercraft Cleaning
Clean the bilge with hot water and mild detergent
or with bilge cleaner. Rinse thoroughly. Lift front
end of watercraft to completely drain bilge. If any
repairs are needed to body or to the hull, touch up
paint and Gelcote®repair kit are available. Re-
place damaged labels/decals.
Wash the body with soap and water solution (only
use mild detergent). Rinse thoroughly with fresh
water. Remove marine organisms from the hull.
Apply a nonabrasive wax.
If the watercraft is to be stored outside, cover it
with an opaque tarpaulin to prevent sun rays and
grime from affecting the plastic components, wa-
tercraft finish as well as preventing dust accumu-
lation.
-CAUTION
Use only SEA-DOO jet pump oil or equiva-
lent synthetic gear oil, otherwise component
life span could be reduced. Do not mix oil
brands or types.
-CAUTION
Do not lubricate excessively. Immediately
stop when a slight movement is noticed on
rubber boot.
-CAUTION
Never leave any clothing, tool or other ob-
jects near PTO flywheel and drive shaft.
F01I0BA
1
-CAUTION
Never clean apparent fiberglass and plastic
parts with strong detergent, degreasing
agent, paint thinner, acetone, etc.
-CAUTION
The watercraft must never be Ieft in water
for storage. Never leave the watercraft
stored in direct sunlight.
F05I09A
1
www.SeaDooManuals.net
