Sea-doo ISLANDIA User manual

SAFETY WARNING
Disregarding any of the safety precautions and instructions contained in
this Operator’s Guide, the Safety Videocassette and the on-product
Warning Labels could cause injuries, including the possibility of death.
The operator has the responsibility to inform passenger(s) of safety
precautions.
This Operator’s Guide and Safety Videocassette should remain with the
craft at the time of resale.
Gelcoat is a trademark of Gelcote International
Knight’s Spray-Nine is a trademark of Korkay System Ltd
The following trademarks are the property of Bombardier Inc. or its
subsidiaries:
SEA-DOO®
BOMBARDIER-ROTAX®
BOMBARDIER LUBE®
Sea-Doo Synthetic Grease
Printed in Canada (LMO-2004-005a.fmSB)
®*Trademarks of Bombardier Inc. or its subsidiaries.
©2003 Bombardier Inc. All rights reserved.
lmo2004_005a.book Page 0 Thursday, August 14, 2003 12:28 PM

1
Doin’it on your new Sea-Doo Sport Boat
Congratulations, you are now the proud owner of a Sea-Doo sport boat. Whether
you are an experienced boater or are new to the sport of boating, we ask you to
take the time to view the Videocassette provided with the craft, to read this Op-
erator’s Guide, and on-product warning/caution labels and familiarize yourself with
the contents. These manuals contain pertinent information which, if followed, will
provide you with the necessary knowledge to help you fully enjoy the pleasures
of this craft.
We strongly recommend that any craft operator complete a safety boating
course. Check with your local Coast Guard or Power and Sail Squadron in your
area for course availability. More serious boaters may want to obtain Chapman
Piloting by Elbert S. Maloney, available at most book stores.
When introducing your family or friends to the sport, be sure they fully understand
the controls and operation of the craft and the importance of courteous, respon-
sible riding.
Each operator has a responsibility to ensure the safety of his/her passenger(s)
and of other water users. Please follow all safety instructions and operate your
craft with care.
We encourage you to have an Annual Safety Inspection of your craft. Please
contact your authorized Sea-Doo dealer for further details.
Finally, we urge you to visit your authorized Sea-Doo dealer regularly for regular
and safety maintenance as well as any craft accessories you may require.
Have fun and... Bon Voyage.
Please keep this guide on board. This manual should remain with the craft
at time of resale.
lmo2004_005a.book Page 1 Thursday, August 14, 2003 12:28 PM

2
TABLE OF CONTENTS
FOREWORD ................................................................................ 7
Hazard Statements.................................................................................. 7
Advisory Statements ............................................................................... 8
SAFETY INFORMATION
SAFETY ...................................................................................... 10
Safe Boating Checklist............................................................................. 10
Safety Equipment.................................................................................... 12
Carbon Monoxide and Boating ................................................................ 17
Lanyard Stop Switch................................................................................ 20
Safe Boating Practices............................................................................. 20
Passenger Safety..................................................................................... 21
Rules of the Road.................................................................................... 21
Voluntary Inspections .............................................................................. 23
Safe Boating Courses.............................................................................. 24
Water Sports ........................................................................................... 24
VEHICLE INFORMATION
REGISTRATION NUMBER LOCATION ......................................... 28
LOCATION OF THE IMPORTANT LABELS ................................... 29
IDENTIFICATION NUMBERS ....................................................... 33
Hull .......................................................................................................... 33
Engine...................................................................................................... 33
CONTROLS, COMPONENTS AND INSTRUMENTS LOCATION .... 34
Cockpit..................................................................................................... 34
Overview ................................................................................................. 35
Front View ............................................................................................... 36
Rear View ................................................................................................ 37
CONTROLS, COMPONENTS AND INSTRUMENT FUNCTIONS.... 39
1) Safety Lanyard (engine cut-out switch)............................................. 39
2) Steering Wheel ................................................................................. 39
3) Throttle/Shifter Lever ........................................................................ 39
4) Ignition Switch .................................................................................. 41
5) 12-Volt Accessory Jack ..................................................................... 41
6) Navigation Light Switch .................................................................... 41
7) Docking Light Switch ........................................................................ 42
8) Boarding Light Switch....................................................................... 42
9) Engine Compartment Light Switch................................................... 42
10) Bilge Pump Switch............................................................................ 43
11) Bilge Air Blower Switch............................................................................. 43
12) Horn Switch ...................................................................................... 44
13) Deck Light Switch............................................................................. 44
lmo2004_005a.book Page 2 Thursday, August 14, 2003 12:28 PM

3
14) Low-Battery Warning System Switch............................................... 44
15) Fuel Gauge/Low Oil Level Pilot Lamp and Beeper ........................... 46
16) Fountain Pump Switch...................................................................... 46
17) Main Water Pump Switch................................................................. 47
18) Tachometer....................................................................................... 47
19) Speedometer .................................................................................... 47
20) Windscreen....................................................................................... 47
21) Grab Handle(s) .................................................................................. 48
22) Rear Grab Handle(s).......................................................................... 48
23) Front/Rear Swim Platform ................................................................ 48
24) Sun Deck/Rear Seat/Engine Cover.................................................... 48
25) Front Seat(s)...................................................................................... 49
26) Bow Seat(s)....................................................................................... 50
27) Cup Holders ...................................................................................... 51
28) Deck Storage Compartment ............................................................. 51
29) Rear Storage Compartment.............................................................. 52
30) Rear Side Storage Compartment...................................................... 53
31) Glove Box.......................................................................................... 53
32) Bow and Stern Eyelet(s) ........................................................................ 53
33) Docking Lights .................................................................................. 54
34) Boarding Lights................................................................................. 54
35) Engine Compartment Light............................................................... 54
36) Navigation Lights .............................................................................. 54
37) Removable Stern Light ..................................................................... 55
38) Deck Lights....................................................................................... 56
39) Changing Room Ceiling Light............................................................ 56
40) Deck.................................................................................................. 56
41) Foot Well........................................................................................... 56
42) Fountain Jet ...................................................................................... 57
43) Wash Down Valve............................................................................. 58
44) Table ................................................................................................. 59
45) Fuel Tank Cap ................................................................................... 59
46) Fuel Tank Vent .................................................................................. 60
47) Main Oil Reservoir Cap ..................................................................... 61
48) Potable Water Tank Cap ................................................................... 61
49) Flushing Connector........................................................................... 62
50) Ventilation Ducts............................................................................... 62
51) Jet Pump Nozzle............................................................................... 62
52) Jet Pump Water Intake..................................................................... 62
53) Hydro Surge Grate System............................................................... 62
54) Reverse Gate .................................................................................... 62
55) Bilge Drain Plug(s)............................................................................. 62
56) Retractable Ladder(s)........................................................................ 63
57) Mooring Cleat(s)................................................................................ 63
58) Convenience Center ......................................................................... 64
lmo2004_005a.book Page 3 Thursday, August 14, 2003 12:28 PM

4
59) Changing Room with Toilet............................................................... 65
60) Portable Toilet ................................................................................... 65
61) Fuses ................................................................................................ 66
62) Radio/CD Player ................................................................................ 66
63) Speaker(s) ......................................................................................... 67
64) Transom Doors ................................................................................. 67
65) Fire Port ............................................................................................ 67
66) Shower.............................................................................................. 67
67) Water Bypass System ...................................................................... 68
68) Main Battery Cut-Off Switch............................................................. 69
69) Water Sport Towing Attachments .................................................... 69
70) Bimini Top ......................................................................................... 70
FUEL, WATER AND LUBRICATION ............................................. 71
Fueling Procedure.................................................................................... 71
Recommended Fuel ................................................................................ 71
Recommended Oil................................................................................... 72
Main Oil Reservoir Level ......................................................................... 72
Engine Mounted Oil Reservoir Level....................................................... 72
Potable Water Tank ................................................................................. 72
BREAK-IN PERIOD ...................................................................... 73
Engine...................................................................................................... 73
10-Hour Inspection .................................................................................. 73
PRE-OPERATION CHECKS .......................................................... 74
Safety Lanyard and Ignition Switch ......................................................... 75
Hull .......................................................................................................... 75
Jet Pump Water Intake............................................................................ 75
Inlet Grate................................................................................................ 75
Bilge......................................................................................................... 75
Battery..................................................................................................... 75
Fuel Tank/Potable Water Tank/Oil Reservoir ........................................... 75
Engine Compartment .............................................................................. 75
Steering System...................................................................................... 75
Throttle System ....................................................................................... 76
Shifter System......................................................................................... 76
Storage Compartment Covers................................................................. 76
OPERATING INSTRUCTIONS ...................................................... 77
Launching/Loading................................................................................... 77
Trailering.................................................................................................. 77
Principle of Operation.............................................................................. 77
Boarding from a Dock.............................................................................. 79
Boarding from the Water......................................................................... 80
Starting .................................................................................................... 80
Rough Water or Poor Visibility Operation................................................ 80
Crossing Waves....................................................................................... 81
lmo2004_005a.book Page 4 Thursday, August 14, 2003 12:28 PM

5
Stopping/Docking .................................................................................... 81
Beaching.................................................................................................. 81
Shutting Off the Engine........................................................................... 81
POST-OPERATION CARE ............................................................ 82
General Care............................................................................................ 82
Additional Care for Foul Water or Salt Water .......................................... 82
SPECIAL PROCEDURE ................................................................ 83
Engine Overheating................................................................................. 83
Potable Water System Disinfection ........................................................ 83
Jet Pump Water Intake and Impeller Cleaning........................................ 84
Capsized Boat.......................................................................................... 84
Submerged Boat ..................................................................................... 84
Low-Charge Battery Condition ................................................................ 84
MAINTENANCE .......................................................................... 85
Emission Component Maintenance ........................................................ 85
Engine Emissions Information................................................................. 85
Lubrication............................................................................................... 86
Periodic Inspection .................................................................................. 87
Throttle Cable.......................................................................................... 87
Fuel and Oil Filters................................................................................... 87
Potable Water Filter................................................................................. 87
Steering/Jet Pump Nozzle Adjustment ................................................... 87
Reverse Gate........................................................................................... 88
Deck Drain(s)........................................................................................... 88
Fuses....................................................................................................... 88
Bilge Air Blower....................................................................................... 88
Navigation Light Bulb Replacement ........................................................ 89
General Inspection and Cleaning............................................................. 91
STORAGE AND PRESEASON PREPARATION ............................. 92
Storage.................................................................................................... 92
Preseason Preparation ............................................................................ 93
PERIODIC INSPECTION CHART .................................................. 94
SPECIFICATIONS ........................................................................ 96
SI METRIC INFORMATION GUIDE............................................... 100
WARRANTY INFORMATION
BOMBARDIER LIMITED WARRANTY FOR MODEL YEAR 2004
SEA-DOO®SPORT BOATS SOLD IN THE UNITED STATES AND
CANADA .................................................................................... 102
lmo2004_005a.book Page 5 Thursday, August 14, 2003 12:28 PM

6
CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT
FOR MODEL YEAR 2004 SEA-DOO®SPORT BOATS
EQUIPPED WITH A ROTAX®ENGINE(S) ..................................... 106
Your Emission Control Warranty Rights and Obligations ........................ 107
Manufacturer’s Limited Warranty Coverage ........................................... 107
Owner’s Warranty Responsibilities ......................................................... 109
BOMBARDIER INTERNATIONAL LIMITED WARRANTY
FOR MODEL YEAR 2004 SEA-DOO®SPORT BOATS ................... 110
WEB SITES.................................................................................. 114
LIST OF DISTRIBUTORS ............................................................. 116
DECLARATION CE OF CONFORMITY.......................................... 117
Homologation and Certification ............................................................... 118
Operator’s Guide Confirmation of Receipt .............................................. 119
PRIVACY INFORMATION ............................................................ 121
CHANGE OF ADDRESS............................................................... 123
lmo2004_005a.book Page 6 Thursday, August 14, 2003 12:28 PM

7
FOREWORD
This Operator’s Guide has been pre-
pared to acquaint the owner/operator
or passenger of this sport boat with
the various sport boat controls, main-
tenance and safe riding instructions. It
is indispensable for the proper use of
the product, and should be kept in a
waterproof bag in the sport boat at all
times. Make sure you read and under-
stand the content of this document.
For any questions pertaining to the
warranty and its application, please
consult an authorized Sea-Doo sport
boat dealer.
Hazard Statements
As you read your Owners Manual and
this supplement, please note the haz-
ard warnings which alert you to safety
precautions related to unsafe condi-
tions or operating procedures.
This guide uses the following symbols
to emphasize particular information.

The safety alert symbol is recognized
around the world. In this manual, it
means read this information carefully!
Be sure you understand the conse-
quences of the hazards and how to
avoid them. Failure to follow the rec-
ommendations in a hazard communi-
cation statement may result in proper-
ty damage, personal injury, or death.
People often refer to a hazard state-
ment as a warning in a general sense.
This manual uses three kinds of “warn-
ings”depending on the likely effect of
a hazard (minor injury, severe injury,
death).
CAUTION: This signal word indicates
a potentially hazardous situation
which, if not avoided, may result in
minor or moderate personal injury or
property damage. It may also be used
to alert against unsafe practices.
NOTE: Indicates supplementary infor-
mation needed to fully complete an in-
struction relating to equipment opera-
tion and/or maintenance procedures.
Although the mere reading of such in-
formation does not eliminate the haz-
ard, the understanding and application
of the information will promote correct
and safe use of the sport boat.
The warnings in this supplement do not
and cannot address every conceivable
situation. Always use common sense!
If a procedure, method, tool, or part is
not specifically recommended, you
must satisfy yourself that it is safe for
you and others and that your boat will
not be damaged or made unsafe as a
result of your decision.
WARNING
Identifies a potentially or immi-
nently hazardous situation which,
if not avoided, COULD result in se-
rious personal injuries including
the possibility of death or substan-
tial property damage.
lmo2004_005a.book Page 7 Thursday, August 14, 2003 12:28 PM

8
Advisory Statements
Advisory statements alert you to con-
ditions that affect equipment opera-
tion, maintenance, and servicing prac-
tices.
An IMPORTANT statement indicates a
procedure intended to prevent dam-
age to equipment or associated com-
ponents.
The information and components/
system descriptions contained in this
supplement are correct at the time of
publication. Bombardier Motor Corpo-
ration of America (Bombardier) howev-
er, maintains a policy of continuous im-
provement of its products without
imposing upon itself any obligation to
install them on products previously
manufactured.
Because of our ongoing commitment
to product quality and innovation,
Bombardier reserves the right at any
time to discontinue or change specifica-
tions, designs, features, models or
equipment without incurring obligation.
The illustrations in this document show
the typical construction of the different
assemblies and may not reproduce the
full detail or exact shape of the parts.
However, they represent parts that
have the same or similar function.
It is understood that this guide may be
translated into another language. In
the event of any discrepancy, the En-
glish version shall prevail.
Specifications are given in the SI metric
system with the SAE U.S. equivalent in
parenthesis. Where precise accuracy
is not required, some conversions are
rounded off for easier use.
A Shop Manual can be obtained for
complete service, maintenance and
more repair information.
lmo2004_005a.book Page 8 Thursday, August 14, 2003 12:28 PM
