Sea Eagle Boats FastCat12 Quick start guide

FastCat
Instruction & Owner’s Manual
Sea Eagle Boats Inc.
19 N. Columbia Street, Suite 1
Port Jefferson, NY 11777
1-800-748-8066
January 2021

1
Sea Eagle Warranty
All Sea Eagle products come standard with a 3 year warranty against manufacturing defects The warranty begins the date that
your product is delivered.
Warranty does not cover damage from use, neglect, or abuse such as but not limited to abrasions, punctures and tears.
See complete warranty details at SeaEagle.com/Warranty.
If you receive a damaged item, please call the shipping carrier to report the issue. Do not return damaged merchandise until it has
been inspected by the carrier. Sea Eagle will be notied by the carrier when they have completed their inspection and if
necessary, Sea Eagle will arrange for the repair or replacement of damaged merchandise.
Decals, Stickers & Registration
Always contact your state boating authorities for information on boating registration and regulations. Most states require you to
register your boat if you are using a motor. *The Sea Eagle FastCat is rated for use with up to a 6 hp motor.
Upon registration it may be required to provide the Manufacturer’s Statement of Origin. Purchases made through an authorized
dealer or reseller may require for you to contact them directly in order to obtain this. You may be charged your own state sales tax
if you were not charged sales tax at the time of purchase.
Registered boats generally require for the registration number to be applied to the boat. We do not recommend the use of decals
or stickers as they tend to crack and peel over time with the repeated inflation and deflation of your Sea Eagle. Instead we suggest
applying these numbers to a small piece of hard plastic or marine plywood and hanging it from your boat like a license plate if
permitted by your state. Another method is to apply the numbers to the hull using either PVC based paint or permanent marker.
Contact Us
Unlike many other companies today we pride ourselves on answering the phone and helping you with any concerns, questions
or special ordering needs that you may have! Feel free to give us a call at 1-800-748-8066 and we will be happy to talk with you!
Our business hours are Monday to Friday from 9AM to 5PM, EST.
Sea Eagle Boats Inc.
19 N. Columbia Street, Suite 1
Port Jefferson, NY 11777
1-800-748-8066
[email protected]
Congratulations on purchasing a Sea Eagle!
With over 50 years of experience in designing, selling and using these quality
inflatables, we’re confident that you are going to love your Sea Eagle and
we’re ready to proudly stand behind them.

2
SAFETY
In a manual of this type it is impossible to give adequate space to the topic of water safety. For further information on boating
safety, visit USCGBoating.org or enroll in a water safety course given by a local provider.
As a safety reminder, each Sea Eagle has a safety summary we call Boating Safety Basics printed on it. Please follow these
suggestions and use good boating safety practices. In addition to the basics, we suggest you have a reasonable swimming ability
and know that it is safer to go boating with a buddy. If you go alone, tell someone your float plan as described below. When
possible, plan your trip so you go upwind on the way out and downwind on the way back.
Boating Safety Tips
• Always wear a USCG approved PFD (life vest) at all times while on the water.
• Be aware of your local boating rules and regulations and abide by them accordingly.
• Check inflation levels each time before you go out and inflate your boat for a full 24 hours before undertaking long trips.
• DO NOT allow children to use your Sea Eagle unsupervised.
• DO NOT consume alcohol while boating or operating a boat while under the influence of alcohol or drugs.
• DO NOT drag your Sea Eagle over pavement or gravel if it can be avoided.
• DO NOT exceed the certified maximum capacities of this boat under any circumstance.
• DO NOT go boating alone.
• DO NOT use compressors, CO2or compressed air for inflation, only use Sea Eagle recommended pumps.
• DO NOT use your Sea Eagle Boat as a personal flotation device as they are not rated for that use.
• DO NOT sleep inside of your Sea Eagle while on the water.
• Bring a fully charged cell phone or other emergency contact device in a waterproof bag.
• Always tell someone of your boating plans.
Safety Equipment & Important Safety Items
Water conditions will determine the type of safety equipment needed. At a minimum have a PFD (personal flotation device) and a
whistle for each passenger. PDFs are required by law In most places.
Drinking Water & Snacks: Boating is a physical activity that can deplete your reserves. Have enough water and snacks to prevent
dehydration and loss of stamina. Bring enough water for all passengers. Know the warning signs of dehydration and heat sickness
such as dizziness and shaking.
Extra Clothes/Layers: Avoid deadly hypothermia. Water conducts heat faster than air, so go prepared with weather proof
clothing especially if the water is cold. Use a “dry bag” to store extra clothing inside so they’re not damp when needed. Wear a
wetsuit or drysuit when warranted.
First Aid-Kit: Contents of the kit may vary depending on your preferences but be sure to include items that match the hazards
you are likely to encounter. A waterproof container is recommended.
Manual Pump/Repair Kit: Although our boats are both durable and rugged, it may be possible that you need to make a repair
while on the water in which case you’ll need the repair kit and a manual pump to re-inflate the boat. If this is your first repair, you
may also want to bring this instruction manual with you.
Sun/Rain Protection: A hat can protect both your face and head from the rain or sun. Sunscreen will help prevent serious
damage to your skin from the sun and the sun’s reflection from the water. Reapply sunscreen as needed.
Whistle: Having a whistle readily available to you in case of emergency is a great way to attract the attention of others if
assistance is needed.
Float Plan: Similar to a pilot’s Flight Plan, consider having a Float Plan (www.floatplancentral.org). Always tell someone where
you are going to be boating and what time you plan to return. Keep a cell phone in a waterproof container that will float if it falls
in the water.

3
Boating is challenging and inherently dangerous. Follow safe boating practices. Be physically t enough to meet the challenges,
prepared for any weather conditions that might be anticipated, and follow the safety basics. Protect all personal items in a
waterproof bag. Secure all accessories to the boat. The FastCat is large and stable for a boat. Keep weight (such as batteries, mo-
tors and gear) close to the center as possible to minimize tippiness.
SAFETY
Motor Safety and Reboarding
Danger: Spinning propellers and carbon monoxide produced by gas engines can cause serious injury or death.
• Do not approach a running motor from the water.
• If you or your passenger falls overboard, do not attempt to reboard in the motor mount area.
• Turn engine o at a safe distance when approaching a swimmer in the water.
• Install propeller guard on gas motors
If the motor is equipped with an engine safety cuto (kill) switch, the driver must attach the cable to themselves, either around
the thigh or wrist, or to clothing (preferably a life jacket). In addition:
• Test regularly to ensure that the engine stops when the kill cord is pulled from the switch.
• Make sure that the kill cord is in good condition.
• Always attach the kill cord securely to the driver, ideally before the engine is started, but certainly before the boat is put in
gear.
• Stop the engine before transferring the kill cord to another driver.
• Wireless kill switches are available and each passenger can wear one.
Safety Training
Completion of an approved boating safety course is recommended for all operators of powered boats, and is required for junior
operators in many jurisdictions.
Battery Features and Safety for Trolling Motors
• Positive (+) red wire connects to positive (+) battery terminal. Black wire to negative terminal (-).
• To determine a battery’s charge life, divide the amp hour rating by the motor amperage. For example, a battery rated at 60
Ah connected to a 30 amp motor will last approximately two hours at full speed. Note: this number will vary depending on
conditions.
• Running the battery all the way down will shorten its life. Not more than 85% discharge is recommended. Multiply the above
by 0.85 to get best run time.
• Charge battery after each use. Lead acid batteries like to be kept charged.
• Exposure to excessive heat will shorten battery life.
• Cold Cranking Amps (CCA) and starting power are not a consideration for trolling.
• 12v automobile, lawn tractor and motorcycle batteries can be used but are not designed for deep discharge and will wear out
more quickly.
• A battery box like the Minn Kota Power Center is recommended, especially around aluminum paddle shafts which could
cause an electrical short. It has a built-in circuit breaker. It will keep bare skin and clothes protected if any acid leaks from the
battery.
• A circuit breaker or fuse is required by the Coast Guard. Check the trolling motor manual for the size circuit interrupter need-
ed. Circuit interrupters are intended to protect against reverse polarity, shorts, and will protect the motor from overheating if
the propeller gets bound up with weeds, anchor line or shing line.
• In the event the motor wires are placed on the wrong terminals, reversing the polarity, the wires heat up and can melt the
insulation and cut through the boat.
• A 12v battery charger will be needed. Chargers are widely available and prices range widely. Inexpensive chargers are usually
sucient.
• Choose gel cell over wet cell. Gel will be less likely to leak acid if the case seal is broken.
• Lithium or AGM batteries can be a good choice even if they are more expensive. They are generally lighter, discharge evenly
for longer run times, and charge evenly for a longer life.
• For some operators, two small batteries are better than one large, heavy one. A small backup battery can be helpful too.
More technical and safety information is available from battery and motor manufacturer’s, boating organizations and publications.

4
CONSTRUCTION & WORKING PRESSURE
Working Pressure:
In this instruction manual, we use the term “working pressure” to describe ination pressure in pounds per square inch
(PSI). By this we mean, the air pressure needed to make a boat rigid enough for use. All three chambers of the
FastCat12 are drop-stitch material with a maximum pressure of 15 psi (1 bar). The recommended working pressure is
10 to 14 psi. How much pressure is needed can depend on how much weight is in the boat and environmental factors
such as wave height.
When using the manual pump, the air pressure a person can force into the boat is related to how much the person
weighs. For example, a 150 lb. individual may nd it dicult to put more than 12 psi into the boat and impossible to
reach 15 psi, but will nd the boat to be rigid enough for use at 12 psi. Additional pressure may not improve
performance nor will it make the boat more buoyant.
Caution: Do not use the FastCat12 below 7 psi. Below this pressure the boat will be too exible.
Danger: Over pressurization could lead to catastrophic failure and sudden release of compressed air. Serious
injury to persons nearby could result. Maximum recommended pressure is 15 psi (1 bar). DO NOT use air compressors
that are designed for other uses such as tire ination. They can easily over-inate & cause harm to you and your Sea
Eagle that uses much lower pressure.
As air is compressed it heats up and expands. Warm air occupies more volume than cool air. If the water is cold, warm
air in the boat will shrink and some rigidity will be lost. Allow a few minutes for the boat to cool o in the water, and if
needed, top it o with enough pump strokes to bring it back up to pressure. The boat could also appear to lose
pressure overnight if the nighttime temperature drops signicantly below the daytime temperature.
Air pressure within the boat may increase on a very hot day. It is best to keep the boat in the water to dissipate heat,
but the boat should be able to accept the additional pressure without failure. Refer to the care section of this manual
for protection and storage information.
The FastCat12 holds a lot of air! Inating with the manual pump is hard work and takes approximately 20 minutes with
breaks to inate the boat. The exercise from inating the boat may be valuable, but often boating time is limited and
it is better to get out on the water as quickly as possible. An electric pump is recommended for achieving that goal. If
the FastCat12 is to inated once a season or kept on inated on a trailer, a hand pump may be sucient to maintain
working pressure.
Caution: Inating the boat manually is physically demanding. Pace yourself. If you feel uncomfortable, stop and
rest, do not proceed if you are having a health issue.
Drop Stitch Construction:
The boat is made of drop-stitch material. Dozens of threads per square inch hold the top and bottom layers together
and keep the at-boat shape. Without drop stitch, inatables are tube shaped.

5
OPERATING YOUR SEA EAGLE
BEFORE & DURING USE: Avoid damage. Do not drag your Sea Eagle over abrasive surfaces like asphalt parking lots, or concrete
boat ramp, whether the boat is in its bag or inflated. Carry or wheel your Sea Eagle from the car to the setup point, and then to the
water when assembled.
Rocks and sticks usually will not damage a Sea Eagle but be alert for partially hidden or submerged hazards like metal signs,
shopping carts, and other debris especially during periods of low water. Be careful of docks and pilings which may have exposed
nails, screws, and marine life such as barnacles and oysters.
FISH SPINES: Many species of fish have sharp spines than can cause small punctures in the FastCat. Do not allow fighting fish to
bump the boat. Use a net to lift fish out of water when possible.
PADDLING: Most of the power should come from your torso. Your arms contribute, but too much reliance on your arms will
cause you to tire quickly. For good balance, keep your head up and eyes focused on the horizon. Start paddling gently and
smoothly. As the boat picks up speed it will maintain a truer heading. If you dig in hard at first you will create more yaw. Course
corrections can be made by easing up or bearing down on one side or the other. Gentle turns can be made by sweeping water
behind the boat. Braking will allow you to maneuver sharp bends in a stream, for example, but kills forward speed.
In a crosswind, paddle more on the downwind (leeward) side of the boat to keep on a straight course. Paddling on the upwind
side will cause the boat to turn down wind.
SELF BAILING: The FastCat12 is designed to be self draining. Water coming over the bow or sides will drain under the transom.
Capacity Ratings and Dimensions:
Persons: 2 Persons
Total Weight Capacity: 1200 lbs
Maximum Engine Rating: 6 HP, Short Shaft Recommended
Chambers: 4
Length: 12’
Boat Weight: 104lbs
Width: 4’ 8”
The FastCat12 has four oatation chambers; two side chambers and two oor chambers. The boat will stay aoat and can be
paddled or motored when loaded to capacity with the main chamber deated.
WARNING: This product can expose you to chemicals including DEHP (Di(2-ethylhexyl)phthalate), which is known to the
state of California to cause Cancer, Birth Defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
Warning Labels:
WARNING
ROTATING PROPELLER MAY CAUSE
SERIOUS INJURY OR DEATH.
SHUT OFF ENGINE WHEN NEAR
PERSONS IN THE WATER
DANGER
Carbon Monoxide (CO) gas can
cause brain damage or death.
Engine exhaust contains odorless
and colorless Carbon Monoxide gas.
Carbon Monoxide gas will be around
the back of the boat when engine
is running.
Move to fresh air, if you feel nausea,
headache, dizziness or drowsiness.
CO-Label.indd 1 27-09-2013 AM 02:29:29
WARNING
ROTATING PROPELLER MAY CAUSE
SERIOUS INJURY OR DEATH.
SHUT OFF ENGINE WHEN NEAR
PERSONS IN THE WATER
DANGER
Carbon Monoxide (CO) gas can
cause brain damage or death.
Engine exhaust contains odorless
and colorless Carbon Monoxide gas.
Carbon Monoxide gas will be around
the back of the boat when engine
is running.
Move to fresh air, if you feel nausea,
headache, dizziness or drowsiness.
CO-Label.indd 1 27-09-2013 AM 02:29:29
Safety Instructions/Boating Safety Basics are glued to the oor near the transom.
Invasive Species Control: If the boat is to be used in multiple waterways, fully drain the boat, rinse and dry between uses. Flush
the channel between the side chambers and oor chamber with a disinfectant such as a mild bleach solution. Call or check web-
site for local sh and wildlife authority for more information on how to prevent the spread of invasive plants and animals. Your Sea
Eagle is resistant to most stains and most chemicals.

6
FastCat| SETUP: TOOLS FOR 1 TIME ASSEMBLY
Tools for One-Time
Assembly
A #2 Phillips head
screwdriver or drill with
#2 Phillips head bit and a
7/16” wrench or
adjustable wrench are
needed for attaching the
rod holder bases and the
swivel seats to their
aluminum benches.
Inflate:
Press and turn the stem
counterclockwise so it can
pop UP. When the stem is
up, the valve is closed and
will hold air.
Deflate:
To let air escape for
deflation, press and turn
the stem clockwise until
locked open.
Screw the hose onto the
pump.
Begin In the double action
mode for fast fill.
Switch to single action
when handle becomes too
hard to lift.
FastCat | ASSEMBLY & INFLATION
With valve stem in the up
position, insert adapter,
push down firmly and twist
clockwise.
Locate an area large
enough to safely unfold
the FastCat. Check that the
area is free of hazards that
could injure you or damage
the boat.
Using the Double Action
Hand Pump:
The pump hose has a
Recessed Valve Adapter
at one end. When ready
to inflate the boat, push
adapter firmly into valve
and twist clockwise to lock
in.
If hose untwists itself from
the valve, twist once
counterclockwise and re-
insert.
Using the Recessed
Valves:
Remove the cap to access
the valve stem.
Note: Maximum pressure is
15 psi (pounds per square
inch), working pressure is
10-14 psi.
Using the Double Action
Hand Pump:
In the double action mode
the pump inflates on the
up and down strokes. In
the single action mode,
the handle comes up more
easily, allowing the user
to push hard on the down
stroke.

7
FastCat | ASSEMBLY & INFLATION
Start with floor grommets.
Adjust transom board to
align the holes.
Transom Attachment
Hardware
4 - M8 x 100 Hex Head Screws
4 - 1” Flat Washers
4 - Threaded Knobs
Look through the
grommet hole to check
alignment with hole in
transom. Pull or push
bottom of side chamber
until holes line up.
A wrench is
recommended for
holding the bolt heads
while tightening the
threaded knob.
Insert screws with washer
through the side chamber
grommets and transom
holes
Motor Mount Transom Board
Insert transom board into
motor mount grommets.
Plate with ring faces f
orward.
WARNING:
Air compressors that are
designed for other uses
like tire inflation (usually
over 30 psi) can easily
over-inflate and cause
harm to your Sea Eagle
that uses a much lower
pressure. For this reason,
we recommend using only
Sea Eagle manual or
electric pumps.
Seat Bench Installation
FastCat12 can take two
aluminum crossbenches.
Each bench can take one
seat release and swivel
seat.
Pressure gauge will not
register until chamber
begins to get pressurized.
Pump until working
pressure of between 14
and 15 PSI is reached. Do
not exceed 15 PSI (1 bar).
Inner numbers in red show
pressure in PSI.

8
FastCat | ASSEMBLY & INFLATION
Lay one end of bench over
the screws, so screws come
up through the holes in
bench.
Locate seat hold down D-rings
which are attached to sides of
boat. Insert M6 x 50 screw with
washer through each ring and
fold ring flat with bolt
pointing upward.
D-rings must be folded
towards each other.
Partially thread bench
knobs onto bolts. Leave
theses loose until bolts are
inserted through
opposite end of bench.
Push bench down against
boat with one hand and
tighten each knob.
Place one washer and one
nut on each screw. Tighten
screw with #2 philips head
screwdriver and a 7/16” or
adjustable wrench. Screw
must engage the nylon
insert in the locking nut.
Locate the hardware for
the seat mount:
4 - 1 ¼” Phil Flat screws
4 - 1” flat washers
4 - Nylock nuts
Insert screws through the
holes in the seat mount.
Place seat mount over the
holes in the crossbench.
Slide seat onto seat release.
When seat is fully pushed
into seat release, the
locking mechanism will
pop down with a click.
Locate aluminum cross
bench(es), quick
disconnect seat mount (s),
seat(s) and hardware.
Hardware per bench
4 - M6 x 50 screws
4 - 5/16” x 1¼”washers
4 - knobs

9
FastCat | ASSEMBLY & INFLATION
To move the FastCat
manually, use the included
66” paddle. When not in
use, stow paddle on floor.
To remove seat, lift the
locking tab and slide seat
out.
To swivel the seat, pull
locking bar forward then
turn the seat.
The FastCat12 has a large
D-ring located under the
front chamber. The D-ring
can be used as an
attachment point for a
trailer winch or to hook up
to a mooring.
Warning: It is not
recommended to tow the
boat with this ring except at
low speed situations.
Canopy (OPTIONAL)
Canopy kit includes two
curved bars, two side rods,
canvas, two black knobs
and two short (35mm)
screws. Additional
hardware may be included
that is not for use on the
FastCat.
Layout canvas upside
down (shiny side up).
Slide one curved bar into
the canvas sleeve with
locking holes up.
Slide the second bar into
the other sleeve with
locking holes facing down.
Motor (OPTIONAL)
Clamp electric motor or
up to a 6hp gas motor to
motor mount. Turn clamp
screws until tight.
Warning: Check
motor clamp screws
frequently, tighten if
needed.

10
FastCat | ASSEMBLY & INFLATION
Fold the canvas in half so
the shiny side is facing out
and the bars are lying on
top of each other.
Insert the side rods into the
curved bars until the
locking pins engage
through the holes.
Place the canopy on the
back of the boat with the
short bars up.
Use the short screw and
the knob to secure the rods
to the black canopy pads
on the boat.
Attach the rear clips to the
small D-rings behind
transom. Attach front straps
behind the front carry
handles. Adjust and tighten
straps by sliding the
buckles.
Canopy can be folded
towards the back of the
boat. Some rod holders
may have to be turned for
the canopy to clear them.
Scotty® Deck Mounts
(OPTIONAL):
Attach deck mounts with
7/8” phil cap screws
provided to the pad
mounts near the transom.
Screws are located in
Orange Repair Kit.
Arrow points inboard.
Don’t stab the pad!
Use only ¼ - 20 x 7/8” screws
provided in the orange repair
kit. Longer screws, pointed
screws, etc., will puncture the
air chamber.
Puncturing the air chamber in
this manner is not covered under
the warranty.
Caution: Puncture
hazard: do not thread screws
into base without the Scotty
Deck Mount.
To install a Scotty accessory
in the mount, push stem into
base until it clicks in.
Shown here is the Scotty®
Baitcaster Rod Holder.
Anchor Lock mount does not
have button, it works by lining
up a groove in the stem with a
raised key in the base. Lift
partially and turn Anchor Lock
to swing anchor overboard.
Large knob on side of Rod
Holder is for adjusting rod
angle.

11
FastCat | ASSEMBLY & INFLATION
FastCat | DEFLATION
Remove transom,
crossbenches, rod holders,
and canopy. Rod holder
bases remain in place.
Place the boat bag under
front of boat. Place bag so
bottom panel is even with
front end of boat and bag
is 6 - 8” off center. Push air
out.
To deflate, push down on
the valve stem and quarter
turn it to the right. The
stem will stay in the down
position, allowing the air
to escape.
Caution: Air escapes
with force, do not place
face directly over valve.
Attach Scotty rod mounts
to the aluminum
crossbenches with #6 x 1”
truss head screws.
This one-time installation
is easier done with a power
drill with #2 phillips head
tip. Leave the screws loose
until the last hole then
tighten all the screws.
As boat deflates push it to
one side. Push it so that it is
even more off center of the
bag. Push more air out.
FastCat | DEFLATION
Fold one side onto the
other so it falls centered on
the bag. Push more air out.
Lift the back end of the
boat so it folds between rod
holder base and crossbench
D-rings. Push more air out.
Lift the last section onto
the front. Push remaining
air out.
Pull the bag end flaps
onto bag and run the staps
thorough both metal rings.
Then run the strap between
the rings and pull tight.

12
FastCat | DEFLATION
Pull the side flaps onto bag
and secure the staps.
Secure the bag with the
straps. Run straps through
both rings, and back
through first ring.
FastCat | CLEANING & PROTECTING
Dry after each use to avoid mold. While washing or
rinsing: close the valve and twist the cap on so water
cannot not enter the chamber. Sea Eagles can be cleaned
very effectively with general purpose cleaning products and a
scrub brush. Towel dry.
Protection from the Sun and Heat
Avoid leaving the boat in direct sunlight when ashore.
Temperatures on a beach, dock, davit, etc. can get very high,
which could affect the vinyl or glue. Excessive exposure to sun
and heat can cause your Sea Eagle to become sticky or cause
the glue to fail.
Treat the boat with a UV protectant such as 303 Aerospace
Protectant. Generally, protectants are a thin film of oil, which
will help keep your Sea Eagle clean. Avoid applying protectant
on the EVA pad or places where foot traction is needed.
Treated boat will repel sand, water scum and tar stains.
FastCat | STORAGE
If you’re planning to leave your Sea Eagle outside, keep it raised
off the ground and covered so it is not exposed to sunlight,
rain, leaves, berries, bird droppings, etc.
Storage Tips: “The best way to store a Sea Eagle is folded up in it’s
bag”. - Cecil Hoge, Jr., Sea Eagle President
• Check for water in the chambers. Water will leak out of open
valves when it is rolled up.
• Water left inside can leak out and cause a lot of mold. Dry
thoroughly to prevent mold.
• Rodent-proof the storage area. Mice, squirrels and other small
rodents can do a lot of damage.
• Avoid excess heat. Do not store in direct sunlight, in an attic or
a metal shed.
• In temperatures below freezing, do not drop, strike or
unroll until it is brought to room temperature.
• It can be stored inflated. If hung, support it along its length.
• After storage, inspect for loose items, damage and leaks.
Avoid excess heat. Do not store in direct sunlight, in an attic or
a metal shed.
If your Sea Eagle has lost pressure, it does not necessarily mean
it is leaking. If it is inflated during the heat of the day and the
temperature drops during the night it will be softer in the
morning. If launching in very cold water, the air inside may
contract and cause a loss of pressure. Add more air to restore
to full pressure. If temperature is not a factor and your boat is
losing air pressure, it’s time to look for a leak.
Step #1. LOOK
Visually inspect the boat close up and if necessary, flip it over
and closely check the outside. Any large leaks when your boat
looses a considerable amount of air should be clearly visible.
Step #3. TIGHTEN
Check the tightness of the one-way recessed valves as well and
if necessary, tighten them with the valve wrench included in
the repair kit canister.
FastCat | TROUBLE SHOOTING
Step #2. LISTEN
If you have a rough idea of where your leak is but can’t see it,
you may want to try listening for it as you may be able to hear
the air escaping and pinpoint the leak.

13
Step #4. SOAPY WATER TEST
You’ll need a bucket and liquid dish washing soap. Fill the
bucket with clear water, and add a good squirt of soap (couple
of tablespoons) to the water. Inflate the leaking chamber to full
pressure. Spread lots of soapy water on the leaking chamber
with a hand towel or large sponge. Don’t assume the leak is
coming from the valve or seams. The leak may produce
bubbles, make hissing or sputtering noises, or spray water.
Spray bottles are not effective at locating many leaks.
FastCat | TROUBLE SHOOTING
FastCat| REPAIRS
Even though Sea Eagles are very rugged and tough, you may
still experience the occasional puncture. Fortunately most
repairs are fairly easy and only take a few minutes. For
extensive repairs, please contact us directly to provide you
with further assistance. The best way to do this is to e-mail us a
digital photo of the area in question along with your hull
identification number to [email protected].
You can also call us directly at 1-800-748-8066 ex. 314 and
ask to speak with Technical Support for further assistance or a
quote for having your boat mailed to our facilities for our
professional repair services.
Sea Eagle repair fees start at $75.00 and does not include
return shipping charges. Please note that Sea Eagle does not
service any other brand other than our own. All items sent to
our repair facilities must have prior authorization in the form of
a Return Authorization Number.
Repair Kit
All Sea Eagles come
standard with a repair
kit which includes PVC
patches and PVC glue.
Repair kits also include a
valve wrench.
PVC Based Glue
To patch your Sea Eagle,
use an adhesive for PVC
boats.
Plumber’s cement, epoxy,
Flex Seal, water-poofing
sprays and Gorilla Glue do
not work.
Pinholes
Deflate the boat and
thoroughly clean and dry
the area that is to be
repaired.
For small punctures less
than 1/8” apply a small drop
of glue and allow 24 hours
to cure.
FastCat| REPAIRS
Patching
The most common
repairs are a puncture or
small cut. A penny size
patch is sufficient for
repairs of this type.
Trace the outline of a
penny on the patch
material and on the boat.
If a larger patch is needed,
use a larger item as a
template.

14
Cut patch along the outline
with scissors.
Pro Tip: Trace the outline
of the penny on masking
tape and cut with a utility
knife. Apply tape to the
boat instead of tracing on
the boat.
FastCat| REPAIRS
Apply glue to the patch
and boat. Allow to dry 15
minutes. Glue must be dry
to the touch. If glue layer
is thin, apply second coat,
allow to dry 15 minutes.
Apply patch to the boat.
Smooth with finger or a
smoothing tool such as a
spoon, handle of a utility
knife, or screwdriver. For
best results, heat patch
with a hair dryer 10-20
seconds and smooth with
tool.
Patching Tips:
• The chamber must be deflated or the air will force a path
through the glue.
• Keep the patch size to a minimum, the bigger the patch,
the harder it is to seal. The most common repair failures
occur because the patch is too big.
• For repairs larger than a puncture, overlap the damage area
by about ½” on each side.
• Do not apply the patch while the glue is wet.
• Covering a leaking patch with another patch rarely fixes
the problem. To remove a patch, heat it with a hair dryer and
peel it off.
• For field repairs, allow at least an hour to cure. Other
repairs, allow to cure overnight.
• Patches can be removed by heating with a hairdryer.
• Never use a heat gun on your boat.
• Clamps and weights are not needed.
For a demonstration of good patching technique, please view
the How to Repair video on the instruction page of our web
site. There is a link at the bottom of every page at
SeaEagle.com or type “instructions” into the search box.
Contact Us
Unlike many other companies today we pride ourselves on
answering the phone and helping you with any concerns,
questions or special ordering needs that you may have!
Feel free to give us a call at 1-800-748-8066 and we will be
happy to talk with you! Our business hours are Monday to
Friday from 9AM to 5PM, EST.
Sea Eagle Boats Inc.
19 N. Columbia Street, Suite 1
Port Jefferson NY 11777
1-800-748-8066
[email protected]

15
FastCat| OPTIONAL ACCESSORIES
Sea Eagle oers a large
array of accessories for
your FastCat.
Personal Flotation
Devices (OPTIONAL)
U.S.C.G. approved. Life
jackets, paddling vest, PFD
Belts available in various
sizes.
Dry Bag
(OPTIONAL)
5 liter bag keeps phone,
keys, snacks and more dry.
See-me Safety Light
(OPTIONAL)
Coast Guard approved LED
personal safety light emits
a 360° light visible up to
3.4 miles. It also attaches to
a PFD!
EZ Cart Heavy Duty
(OPTIONAL)
Transport your Boat from
your car to the water and
back with ease. Quickly
assembles & disassembles.
303 Protectant
(OPTIONAL)
Extends the life of your Sea
Eagle. Simply spray on
every 30-45 days to
improve resistance to UV,
chemical & other types of
harmful exposure.
BTP Turbo Electric
Pump (OPTIONAL)
These electric pumps
come with a nylon
shoulder carry bag, 12V
DC power cord, hose and
pre-attached recessed
valve adapter.
