X24 SATA Product Manual
512E*Models Self-
Encrypting
512E*Models Instant
Secure Erase
ST24000NM001H ST24000NM002H
ST20000NM001H ST20000NM002H
ST16000NM001H ST16000NM002H
ST12000NM001H ST12000NM002H
ST10000NM021H

© 2022 Seagate Technology LLC. All rights reserved.
Publication number: 205194300, Rev. A (Draft 1) 3August 2023
Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Raid Rebuild and
SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS
logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.All other trademarks or registered trademarks are
the property of their respective owners. No part of this publication may be reproduced in any form without written permission of Seagate Technology LLC.
Call 877-PUB-TEK1 (877-782-8351) to request permission.
When referring to drive capacity, one gigabyte, or GB, equals one billion bytes and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use
a different standard of measurement and report a lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be
available for data storage. Actual quantities will vary based on various factors, including file size, file format, features and application software. Actual data rates may vary
depending on operating environment and other factors. The export or re-export of hardware or software containing encryption may be regulated by the U.S. Department of
Commerce, Bureau of Industry and Security (for more information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to
Document Revision History
Revision Date Pages affected and Description of changes
Rev. A (Draft 1) 08/06/2023 Initial draft. Model Numbers, spec, Mech drawings, wave forms, commands, logpgs, etc

Seagate Exos X22 SATA Product Manual, Rev. A (Draft 1) 2
Contents
Seagate® Technology Support Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.0 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 About the Serial ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Specification summary tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.1 Fast Format - logical sector size conversion. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.2 LBA mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.3 Recording and interface technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.5 .Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5.1 Power consumption. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.5.2 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.5.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.5.4 Extended Power Conditions - PowerChoice™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.6 Environmental limits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6.1 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6.2 Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6.3 Effective Altitude (sea level) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6.4 Shock and Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.7 Acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.7.1 Test for Prominent Discrete Tones (PDTs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.8 Electromagnetic immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.9 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.9.1 Annualized Failure Rate (AFR) and Mean Time Between Failures (MTBF) . . . . . . . . . . . . . 24
2.10 HDD and SSD Regulatory Compliance and Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.10.1 Regulatory Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.11 Corrosive environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.12 Reference documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.13 Product warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.13.1 Shipping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Seagate Exos X22 SATA Product Manual, Rev. A (Draft 1) 3
Contents
2.13.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.13.3 Product repair and return information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.0 Configuring and mounting the drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.1 Handling and static-discharge precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2 Configuring the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.3 Serial ATA cables and connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.4 Drive mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.4.1 Mechanical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.0 About self-encrypting drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.1 Data encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2 Controlled access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2.1 Admin SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2.2 Locking SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.2.3 Default password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3 Random number generator (RNG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.4 Drive locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.5 Data bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.6 Cryptographic erase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.7 Authenticated firmware download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.8 Power requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.9 Supported commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.10 RevertSP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.10.1 ATA Security Erase Unit Command on SED SATA drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.10.2 Sanitize Device - CRYPTO SCRAMBLE EXT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5.0 Serial ATA (SATA) interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.1 Hot-Plug compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.2 Serial ATA device plug connector pin definitions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.3 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.3.1 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.3.2 Identify Device Data log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.3.3 Device Statistics log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Seagate Exos X22 SATA Product Manual, Rev. A (Draft 1) 4
Contents
5.3.4 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5.3.5 S.M.A.R.T. commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Seagate Exos X22 SATA Product Manual, Rev. A (Draft 1) 5
For Seagate Product Support, visit: www.seagate.com/support
For Seagate Compliance, Safety, and Disposal, visit: www.seagate.com/support
For Firmware Download and Tools Download for Secure Erase, visit: www.seagate.com/support/downloads/
For information regarding online support and services, visit: www.seagate.com/contacts/
For information regarding Warranty Support, visit: www.seagate.com/support/warranty-and-replacements/
For information regarding data recovery services, visit: www.seagate.com/services-software/recover/resources/
For Seagate OEM and Distribution partner and Seagate reseller portal, visit: www.seagate.com/partners
Seagate® Technology Support Services

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 6
www.seagate.com Introduction
1.0 Introduction
This manual describes the functional, mechanical and interface specifications for the following:
Seagate® Exos® X24 SATA drive models.
These drives provide the following key features:
• 7200 RPM spindle speed.
• Fluid Dynamic Bearing motor
• Tri Stage Actuator
• 512MB Cache buffer
• Full-track multiple-sector transfer without local processor intervention.
• High instantaneous (burst) data-transfer rates (up to 600MB per second).
• Native Command Queuing with command ordering to increase performance in demanding applications.
• PowerChoice™ for selectable power savings
• Perpendicular recording technology provides the drives with increased areal density.
• SeaTools™ diagnostic software performs a drive self-test that eliminates unnecessary drive returns.
• State-of-the-art cache and on-the-fly error-correction algorithms.Support for S.M.A.R.T. drive monitoring and reporting.
• Supports latching SATA cables and connectors.
• T13 Fast Format conversion (see Section 2.2.1)
• Top Cover Attached motor for excellent vibration tolerance
• Worldwide Name (WWN) capability uniquely identifies the drive.
NOTE Seagate recommends validating the configuration with the selected HBA/RAID
controller manufacturer to ensure use of full capacity is supported.
NOTE The Self-Encrypting Drive models indicated on the cover of this product manual have
provisions for “Security of Data at Rest” based on the standards defined by the Trusted
Computing Group (see www.trustedcomputinggroup.org).
512E ISE as Base Models
SED ISE
ST24000NM001H
ST20000NM001H
ST16000NM001H
ST12000NM001H
ST24000NM002H
ST20000NM002H
ST16000NM002H
ST12000NM002H
ST10000NM021H

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 7
www.seagate.com Introduction
1.1 About the Serial ATA interface
The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages
include:
• Easy installation and configuration with true plug-and-play connectivity.
It is not necessary to set any jumpers or other configuration options.
• Thinner and more flexible cabling for improved enclosure airflow and ease of installation.
• Scalability to higher performance levels.
In addition, Serial ATA makes the transition from parallel ATA easy by providing legacy software support. Serial ATA was
designed to allow users to install a Serial ATA host adapter and Serial ATA disk drive in the current system and expect all
of the existing applications to work as normal.
The Serial ATA interface connects each disk drive in a point-to-point configuration with the Serial ATA host adapter. There
is no master/slave relationship with Serial ATA devices like there is with parallel ATA. If two drives are attached on one
Serial ATA host adapter, the host operating system views the two devices as if they were both “masters” on two separate
ports. This essentially means both drives behave as if they are Device 0 (master) devices.
NOTE The host adapter may, optionally, emulate a master/slave environment to host
software where two devices on separate Serial ATA ports are represented to host
software as a Device 0 (master) and Device 1 (slave) accessed at the same set of host
bus addresses. A host adapter that emulates a master/slave environment manages
two sets of shadow registers. This is not a typical Serial ATA environment.
The Serial ATA host adapter and drive share the function of emulating parallel ATA device behavior to provide backward
compatibility with existing host systems and software. The Command and Control Block registers, PIO and DMA data
transfers, resets, and interrupts are all emulated.
The Serial ATA host adapter contains a set of registers that shadow the contents of the traditional device registers, referred
to as the Shadow Register Block. All Serial ATA devices behave like Device 0 devices. For additional information about
how Serial ATA emulates parallel ATA, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. The
specification can be downloaded from www.serialata.org.

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 8
www.seagate.com Drive specifications
2.0 Drive specifications
Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For
convenience, the phrases the drive and this drive are used throughout this manual to indicate the Exos X24 SATA drive
models
2.1 Specification summary tables
The specifications listed in the following tables are for quick reference. For details on specification measurement or
definition, see the appropriate section of this manual.
Table 1 Drive specifications summary
Drive specification ST24000NM001H
ST24000NM002H
ST20000NM001H
ST20000NM002H
Formatted (512 bytes/sector)* 24TB 20TB
Guaranteed sectors (see Section 2.2)
Heads 20 18
Disk 10 9
Bytes per logical sector 537
Bytes per physical sector 4096
Recording density, KBPI (Kb/in max) 2552
Track density, KTPI (ktracks/in avg.) 512
Areal density, (Gb/in2 avg) 1260
Spindle speed (RPM) 7200
Internal data transfer rate (Mb/s max) 2951
Max Sustained transfer rate OD (MiB/s 272 (285 MB/s max)
Sustained transfer rate OD (MiB/s 259 (272 MB/s max)
I/O data-transfer rate (MB/s max) 600
ATA data-transfer modes supported PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6
Cache buffer 256MB (262,144KB)
Weight: (maximum) 685g (1.510 lb)
Average latency 4.16ms
Power-on to ready (sec) (typ/max) 25/30
Standby to ready (sec) (typ/max) 25/30
Startup current (typical) 12V (peak) 2.6A
2.0A (optional configuration through Smart Command Transport)
Voltage tolerance (including noise) 5V ± 5%
12V ± 10%
Operating temperature 10 to 60°C (Drive Reported Temperature)
Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections 2.6.1 and 2.13)

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 9
www.seagate.com Drive specifications
*One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary
depending on operating environment and formatting.
*See Section 2.9, "Reliability" for rated MTBF device operating condition requirements.
Temperature gradient (°C per hour max) 20°C (operating)
20°C (non-operating)
Relative humidity* 5% to 95% (operating)
5% to 95% (non-operating)
Relative humidity gradient 20% per hour max
Altitude, operating –304.8 m to 3,048 m
(–1000 ft to 10,000+ ft)
Altitude, nonoperating
(below mean sea level, max)
–304.8 m to 12,192 m
(–1000 ft to 40,000+ ft)
Operational Shock (2 ms) 40 Gs
Non-Operational Shock (2 ms) 200 Gs
Linear Random Operating Vibration 5–500 Hz: 0.70 Grms
Random Rotary Operating Vibration 20–1500Hz: 12.5 rads/s²
Linear Random Non-Operating Vibration 2–500 Hz: 2.27 Grms
Drive acoustics, sound power (bels)
Idle 2.8 (typical)
3.0 (max)
During periods of drive idle, some offline activity may occur according to the
SMART specification, which may increase acoustic and power to operational levels.
Performance seek 3.2 (typical)
3.4 (max)
Nonrecoverable read errors 1 sector per 1015 bits read
Annualized Failure Rate (AFR)* 0.35% based on 8760 POH
Maximum Rated Workload* Maximum rate of <550TB/year
Workloads exceeding the annualized rate may degrade the drive MTBF and impact product
reliability. The Annualized Workload Rate is in units of TB per year, or TB per 8760 power
on hours. Workload Rate = TB transferred * (8760 / recorded power on hours).
Warranty To determine the warranty for a specific drive, use a web browser to access the following
web page: www.seagate.com/support/warranty-and-replacements/.
From this page, click on the “Is my Drive under Warranty” link. The following are required to
be provided: the drive serial number, model number (or part number) and country of
purchase.The system will display the warranty information for the drive.
Load-unload cycles 600,000
Supports Hotplug operation per
Serial ATA Revision 3.3 specification
Yes
Drive specification ST24000NM001H
ST24000NM002H
ST20000NM001H
ST20000NM002H

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 10
www.seagate.com Drive specifications
Table 2 Drive specifications summary
Drive specification ST16000NM001H
ST16000NM002H
ST12000NM001H
ST12000NM002H
ST10000NM021H
Formatted (512 bytes/sector)* 16TB 12TB 10
Guaranteed sectors (see Section 2.2)
Heads 15 or 14 10
Disk 8 or 7 5
Bytes per logical sector 512
Bytes per physical sector 4096
Recording density, KBPI (Kb/in
max)
2552
Track density, KTPI (ktracks/in
avg.)
537
Areal density, (Gb/in2 avg) 1260
Spindle speed (RPM) 7200
Internal data transfer rate (Mb/s
max)
2951
Max Sustained data transfer rate
OD (MiB/s max)
247(260 MB/s max) 237 (249MB/s)
Sustained Rate OD (MiB/s 236 (248 MB/s max) 226 (236MB/s
I/O data-transfer rate (MB/s max) 600
ATA data-transfer modes sup-
ported
PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–6
Cache buffer 512MB (524,288KB)
Weight: (maximum) 670g (1.47lb) 655g (1.44 lb)
Average latency 4.16ms
Power-on to ready (sec) (typ/max) 25/30
Standby to ready (sec) (typ/max) 25/30
Startup current (typical) 12V
(peak)
2.6A
2.0A (optional configuration through Smart Command Transport)
Voltage tolerance (including
noise)
5V ± 5%
12V ± 10%
Operating temperature 10C Ambient° to 60°C Drive Reported Temperature
Non-Operating temperature –40° to 70°C (Ambient Temperature, see sections 2.6.1 and 2.13)
Temperature gradient (°C per
hour max)
20°C (operating)
20°C (non-operating)
Relative humidity* 5% to 95% (operating)
5% to 95% (non-operating)
Relative humidity gradient 20% per hour max
Altitude, operating –304.8 m to 3,048 m
(–1000 ft to 10,000+ ft)

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 11
www.seagate.com Drive specifications
*One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary
depending on operating environment and formatting.
*See Section 2.9, "Reliability" for rated MTBF device operating condition requirements.
Altitude, non-operating
(below mean sea level, max)
–304.8 m to 12,192 m
(–1000 ft to 40,000+ ft)
Operational Shock (2 ms) 40 Gs
Non-Operational Shock (2 ms) 200 Gs
Linear Random Operating Vibra-
tion
5–500 Hz: 0.70 Grms
Random Rotary Operating Vibra-
tion
20–1500Hz: 12.5 rads/s²
Linear Random Non-Operating
Vibration
2–500 Hz: 2.27 Grms
Drive acoustics, sound power
(bels)
Idle 2.8 (typical)
3.0 (max)
During periods of drive idle, some offline activity may occur according to the
SMART specification, which may increase acoustic and power to operational levels.
Performance seek 3.2 (typical)
3.4 (max)
Nonrecoverable read errors 1 sector per 1015 bits read
Annualized Failure Rate (AFR)* 0.35% based on 8760 POH
Maximum Rated Workload* Maximum rate of <550TB/year
Workloads exceeding the annualized rate may degrade the drive MTBF and impact product reliability.
The Annualized Workload Rate is in units of TB per year, or TB per 8760 power on hours. Workload
Rate = TB transferred * (8760 / recorded power on hours).
Warranty To determine the warranty for a specific drive, use a web browser to access the following web page:
www.seagate.com/support/warranty-and-replacements/.
From this page, click on the “Is my Drive under Warranty” link. The following are required to be pro-
vided: the drive serial number, model number (or part number) and country of purchase.The system will
display the warranty information for the drive.
Load-unload cycles 600,000
Supports Hotplug operation per
Serial ATA Revision 3.3 specifica-
tion
Yes
Drive specification ST16000NM001H
ST16000NM002H
ST12000NM001H
ST12000NM002H
ST10000NM021H

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 12
www.seagate.com Drive specifications
2.2 Formatted capacity
*One GB equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary
depending on operating environment and formatting.
NOTE LBA Counts for drive capacities greater than 8TB are calculated based upon the SFF-
8447 standard publication. ftp://ftp.seagate.com/sff/SFF-8447.PDF
2.2.1 Fast Format - logical sector size conversion
• Drive supports either 512E or 4KN logical sector size formats
• SET SECTOR CONFIGURATION EXT (B2h) command (ACS-4 Standard) quickly converts between 512 and 4096 byte logical
sector size formats
• The selected sector size change occurs immediately upon command completion
• Default shipping format is 512E
• COMMAND CHECK field value is taken from the DESCRIPTOR CHECK field in the descriptor specified by the SECTOR CON-
FIGURATION DESCRIPTOR INDEX field
ST models Formatted
capacity*
Guaranteed
sectors
Bytes per
logical sector
Guaranteed
sectors
Bytes per
logical sector
ST24000NM001H, and
ST24000NM002H
24TB 46,875,541,504 512
(Default)
5,859,442,688 4096
(see Section 2.2.1)
ST20000NM001H, and
ST20000NM002H
20TB 39,063,650,304 4,882,956,288
ST16000NM000H,
ST16000NM001H, and
ST16000NM002H
16TB 31,251,759,104 3,906,469,888
ST12000NM001H, and
ST12000NM002H
12TB 23,437,770,752 2,929,721,344
ST10000NM021H 10TB 19,532,873,728 2,441,609,216
Table 3 SET SECTOR CONFIGURATION EXT command inputs
Field Description
FEATURE COMMAND CHECK field
COUNT Bit Description
15 : 3 Reserved
2:0 SECTOR CONFIGURATION DESCRIPTOR INDEX field
LBA Reserved
DEVICE Bit Description
7 Obsolete
6 N/A
5 Obsolete
4 Transport Dependent
3:0 Reserved
COMMAND 7:0 B2h

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 13
www.seagate.com Drive specifications
• SECTOR CONFIGURATION DESCRIPTOR INDEX field specifies the Sector Configuration descriptor in the Set Sector Configu-
ration log page
Sector Configuration log (Log Address 2Fh)
The Sector Configuration log contains Sector Configuration descriptors. The Sector Configuration descriptors describe
sector configurations. The sector configuration is specified using the SET SECTOR CONFIGURATION EXT command.
2.2.2 LBA mode
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the
number of guaranteed sectors as defined above.
See Section 5.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-bit
addressing support of drives with capacities over 137GB.
Table 4 Sector Configuration descriptors page format (log page 00h)
Offset Type Description
0...15 Bytes Sector Configuration descriptor 0
16...31 Bytes Sector Configuration descriptor 1
... ... ...
112...127 Bytes Sector Configuration descriptor 7
128...511 Bytes Reserved
Table 5 Sector Configuration descriptors format
Offset Type Description
0 Byte Sector Configuration descriptor flags
Bit Description
7 DESCRIPTOR VALID bit
6:0 Reserved
1 Byte LOGICAL TO PHYSICAL SECTOR RELATIONSHIP SETTING field
2...3 Word DESCRIPTOR CHECK field
4...7 DWord LOGICAL SECTOR SIZE SETTING field
8...15 Bytes Reserved

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 14
www.seagate.com Drive specifications
2.3 Recording and interface technology
2.4 Start/stop times
Power-on to ready time is based on typical operating conditions, default full current spin-up profile, and clean shutdown
prior to measurement. To ensure a clean shutdown a Flush Cache, Standby, or Standby Immediate command must be
completed before removal of interface power.
NOTE An unexpected power loss event, spin up at cold or hot temperature extremes
may cause the drive to exceed the typical and max time to ready by 5 seconds.
Extended time to ready is dependent on cache state and environmental
conditions prior to the unexpected power loss and during the subsequent power
on
Interface Serial ATA (SATA)
Recording method Perpendicular
Recording density, KBPI (Kb/in max) 2552
Track density, KTPI (ktracks/in avg) 537
Areal density (Gb/in2 avg) 1260
Spindle speed (RPM) (± 0.2%) 7200
Internal data transfer rate (Mb/s max) 2951
Sustained data transfer rate, 24/20/16/12 &10TB(MiB/s max) 272 / 262 / 247 / 237 max
I/O data-transfer rate (MB/s max) 600 (Ultra DMA mode 5)
Power-on to Ready (sec) (typ/max) 25/30
Standby to Ready (sec) (typ/max) 25/30
Ready to spindle stop (sec) (max) 20

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 15
www.seagate.com Drive specifications
2.5 .Power specifications
The drive receives DC power (+5V or +12V) through a native SATA power connector. See Figure 3 on page 27 .
2.5.1 Power consumption
Power requirements for the drives are listed in Table 7. Typical power measurements are based on an average of drives
tested, under nominal conditions, using 5.0V and 12.0V input voltage at 35°C ambient temperature
.
Table 6 DC power requirements (24/20TB models)
Workload Mode 6.0Gb mode
Voltage +5V +12V Watts
Regulation ± 5% ± 10% Total
Avg Idle Current * 0.315 0.387 6.220
Advanced Idle Current *
Idle_A 0.315 0.39 6.25
Idle_B 0.246 0.22 3.89
Idle_C 0.246 0.141 2.91
Standby 0.198 0.009 1.09
Maximum Start Current
DC (peak DC) 0.849 2.035
AC (Peak DC) 0.96 2.36
Delayed motor start (max) DC 0.467 0.812
Operating current (random read 4K16Q):
Typical DC 0.373 0.584 8.88
Maximum DC 0.381 0.593 9.02
Maximum DC (peak) 0.963 1.868
Operating current (random write 4K16Q)
Typical DC 0.421 0.414 7.07
Maximum DC 0.427 0.42 7.18
Maximum DC (peak) 1.006 1.818
Operating current (sequential read 64K16Q)
Typical DC 0.742 0.374 8.18
Maximum DC 0.751 0.38 8.29
Maximum DC (peak) 1.093 1.786
Operating current (sequential write 64K16Q)
Typical DC 0.82 0.371 8.53
Maximum DC 0.831 0.377 8.66
Maximum DC (peak) 1.034 1.519

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 16
www.seagate.com Drive specifications
Note: During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification,
which may increase acoustic and power to operational levels
Table 7 DC power requirements (16TB models)
Workload Mode 6.0Gb mode
Voltage +5V +12V Watts
Regulation ± 5% ± 10% Total
Avg Idle Current * 0.298 0.340 5.570
Advanced Idle Current *
Idle_A 0.341 0.322 5.59
Idle_B 0.264 0.201 3.75
Idle_C 0.246 0.132 2.82
Standby 0.199 0.009 0.95
Maximum Start Current
DC (peak DC) 0.922 2.091
AC (Peak DC) 1.100 2.40
Delayed motor start (max) DC 0.563 0.812
Operating current (random read 4K16Q):
Typical DC 0.400 0.529 8.37
Maximum DC 0.406 0.536 8.49
Maximum DC (peak) 1.035 2.086
Operating current (random write 4K16Q)
Typical DC 0.455 0.360 6.61
Maximum DC 0.463 0.367 6.74
Maximum DC (peak) 1.065 1.82
Operating current (sequential read 64K16Q)
Typical DC 0.799 0.318 7.83
Maximum DC 0.81 0.323 7.95
Maximum DC (peak) 1.059 1.829
Operating current (sequential write 64K16Q)
Typical DC 0.909 0.315 8.36
Maximum DC 0.924 0.321 8.50
Maximum DC (peak) 1.124 1.648

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 17
www.seagate.com Drive specifications
Table 8 DC power requirements (12TB and 10TB models)
Workload Mode 6.0Gb mode
Voltage +5V +12V Watts
Regulation ± 5% ± 10% Total
Avg Idle Current * 0.363 0.298 5.4
Advanced Idle Current *
Idle_A 0.354 0.295 6.5
Idle_B 0.275 0.20 3.78
Idle_C 0.259 0.131 2.88
Standby 0.21 0.011 1.18
Maximum Start Current
DC (peak DC) 0.918 2.098
AC (Peak DC) 1.08 2.40
Delayed motor start (max) DC 0.607 0.812
Operating current (random read 4K16Q):
Typical DC 0.42 0.496 8.10
Maximum DC 0.426 0.5 8.15
Maximum DC (peak) 1.02 1.836
Operating current (random write 4K16Q)
Typical DC 0.477 0.330 6.35
Maximum DC 0.485 0.333 6.47
Maximum DC (peak) 1.115 1.769
Operating current (sequential read 64K16Q)
Typical DC 0.826 0.292 7.65
Maximum DC 0.841 0.296 7.79
Maximum DC (peak) 1.074 0.557
Operating current (sequential write 64K16Q)
Typical DC 0.931 0.288 8.12
Maximum DC 0.938 0.293 8.23
Maximum DC (peak) 1.124 1.582

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 18
www.seagate.com Drive specifications
2.5.1.1 Typical current profiles
Figure 1. Typical 5V and 12V startup and operation current profiles
2.5.2 Conducted noise
Noise is specified as a periodic and random distribution of frequencies covering a band from DC to 10 MHz. Maximum
allowed noise values given below are peak-to-peak measurements and apply at the drive power connector.
2.5.3 Voltage tolerance
Voltage tolerance (including noise):
5V ± 5%12V ± 10%
+5v = 250 mV pp from 100 Hz to 20 MHz.
+12v = 800 mV pp from 100 Hz to 8 KHz.
450 mV pp from 8 KHz to 20 KHz.
250 mV pp from 20 KHz to 5 MHz.

Seagate Exos X24 SATA Product Manual, Rev. A (Draft 1) 19
www.seagate.com Drive specifications
2.5.4 Extended Power Conditions - PowerChoice™
Utilizing the load/unload architecture a programmable power management interface is provided to tailor systems for
reduced power consumption and performance requirements.
The table below lists the supported power conditions available in PowerChoice. Power conditions are ordered from highest
power consumption (and shortest recovery time) to lowest power consumption (and longest recovery time) as follows:
Idle_a power >= Idle_b power >= Idle_c power >= Standby_z power. The further users go down in the table, the more
power savings is actualized. For example, Idle_b results in greater power savings than the Idle_a power condition. Standby
results in the greatest power savings.
Each power condition has a set of current, saved and default settings. Default settings are not modifiable. Default and
saved settings persist across power-on resets. The current settings do not persist across power-on resets. At the time of
manufacture, the default, saved and current settings are in the Power Conditions log match.
PowerChoice is invoked using one of two methods
• Automatic power transitions which are triggered by expiration of individual power condition timers. These timer values may be
customized and enabled using the Extended Power Conditions (EPC) feature set using the standardized Set Features command
interface.
• Immediate host commanded power transitions may be initiated using an EPC Set Features "Go to Power Condition" subcom-
mand to enter any supported power condition. Legacy power commands Standby Immediate and Idle Immediate also provide a
method to directly transition the drive into supported power conditions.
PowerChoice exits power saving states under the following conditions
• Any command which requires the drive to enter the PM0: Active state (media access)
• Power on reset
PowerChoice provides the following reporting methods for tracking purposes
Check Power Mode Command
• Reports the current power state of the drive
Identify Device Command
• EPC Feature set supported flag
• EPC Feature enabled flag is set if at least one Idle power condition timer is enabled
Power Condition Log reports the following for each power condition
• Nominal recovery time from the power condition to active
• If the power condition is Supported, Changeable, and Savable
• Default enabled state, and timer value
• Saved enabled state, and timer value
• Current enabled state, and timer value
Power Condition Name Power Condition ID Description
Idle_a 81H Reduced electronics
Idle_b 82H Heads unloaded. Disks spinning at full RPM
Idle_c 83H Heads unloaded. Disks spinning at reduced RPM
Standby_z 00H Heads unloaded. Motor stopped (disks not spinning)
