Seagate MEDALIST 1080SL User manual

. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .
Medalist 1080sl
. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . .
SCSI Interface Drive
. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
Installation Guide
. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .

© 1995 Seagate Technology, Inc. All rights reserved
Publication Number: 36325-001, Rev. A, August 1995
Seagate, Seagate Technology and the Seagate logo are regis-
tered trademarks of Seagate Technology, Inc. MedalistSL, Sea-
FAX, SeaFONE, SeaBOARD and SeaTDD are trademarks of
Seagate Technology, Inc. Other product names are registered
trademarks or trademarks of their owners.
Seagate reserves the right to change, without notice, product
offerings or specifications. No part of this publication may be
reproduced in any form without written permission from Seagate
Technology, Inc.
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 1
Read before you begin... . . . . . . . . . . . . . . . . . . 3
Configuring the drive . . . . . . . . . . . . . . . . . . . . 5
Attaching cables . . . . . . . . . . . . . . . . . . . . . . 10
Mounting the drive . . . . . . . . . . . . . . . . . . . . . 11
Configuring the drive and computer . . . . . . . . . . . 12
System setup configuration . . . . . . . . . . . . . . . . 12
Low-level formatting . . . . . . . . . . . . . . . . . . . . 12
Partitioning . . . . . . . . . . . . . . . . . . . . . . . . 13
High-level formatting . . . . . . . . . . . . . . . . . . . 14
NonDOS operating systems . . . . . . . . . . . . . . . 15
Network installation . . . . . . . . . . . . . . . . . . . . 15
Basic troubleshooting . . . . . . . . . . . . . . . . . . . 16
Advanced troubleshooting . . . . . . . . . . . . . . . . 18
Technical support services . . . . . . . . . . . . . . . . 21
Storing and shipping your drive . . . . . . . . . . . . . . 24

Introduction
Thank you for choosing a Seagate drive. The purpose of this
guide is to assist you with installing your new hard drive. Its
organization outlinesthecomplete installation processfromhan-
dling the drive and drive application in Before you begin... to
offering troubleshooting suggestions and technical support infor-
mation. The topics discussed are:
•Handling your drive (see Before you begin...)
•Configuring the drive
•Attaching cables to the drive
•Mounting the drive
•Configuring the computer
•Troubleshooting
•Where to call for Seagate technical support
We hope your installation goes smoothly, but if complications
arise,alistof commonsymptomsandsolutionsisprovidedinthe
troubleshooting section. If the problem persists, contact your
dealerfirst.Yourdealerisfamiliarwith systemintegrationandthe
conflicts that arise. If you need additional help or information
about Seagate products, Seagate technicalsupport numbersare
provided.
Medalist 1080sl SCSI Installation Guide,August 1995 1

Drive features
Formatted Capacity (Mbytes) 1080.23
Total sectors 2,109,840
Cylinders 4,826
Physical heads 4
Sectors per track (average) 109
Bytes per sector 512
Spindle speed 5,376 RPM
Average seek time (msec) 12.5 msec
Cache (segmented) 128 Kbytes
Internal transfer rate (Mbits per second max) 33 MHz to
65 MHz
External transfer rate (Mbytes per second max)
Asynchronous
Synchronous 5.0 10.0
Power on to Ready 20 sec
Seek power (typical) 7.11W
Drive acoustics, Idle mode 30 dBA
2 Medalist 1080sl SCSI Installation Guide, August 1995

Read before you begin...
Note. Throughout this manual the Medalist 1080sl SCSI is
referred to by its model number, ST51080N.
Application. YourSeagate® drive is designed for IBM and IBM-
compatible personal computers, Macintosh and other systems
using the SCSI interface.
Turn off the system power before attempting any installation.
Static discharge. Observe the followingprecautions:
•Keep the drive in its static-shielded bag until you are ready to
complete theinstallation.Donotattach anycablestothedrive
while it is in its static-shielded bag.
•Handle the drive by its edges or frame, and do not touch the
I/O connector pins or the circuit board.
•Before handling any components, put on a grounded wrist
strap, or ground yourself frequently by touching the metal
chassis of a computer that is plugged into a grounded outlet.
•Use antistatic padding on all work surfaces.
•Avoid static-inducing carpeted areas.
Drive handling. The drive is extremely fragile—handle it with
care. Do not attach labels to any part of the drive.
Inspection. After you are familiar with the handling precautions
listed above, inspect the drive. If it appears to be damaged, call
your distributor or dealer immediately.
Warranty. See your authorized Seagate distributor or dealer.
Maintenance and repair. Seagate drives do notrequire mainte-
nance. The head/disc assembly is sealed; if you break the seal,
Medalist 1080sl SCSI Installation Guide,August 1995 3

you voidthe warranty. Seagate customer service centers are the
only facilitiesauthorized to repairSeagate drives. Seagate does
not sanction any third-party repair facilities.
Shipping. Keep your original box and packing materials for
transporting or shipping your drive. The box has a
Seagate
Approved Package
label. Shipping a drive in a nonapproved
container voids the warranty. Call your authorized Seagate dis-
tributor to purchase additional boxes.
Radio and television interference. This product complies with
ClassBlimitsforradionoiseemissionsfromcomputerequipment
as set out in the radio interference regulations of the Canadian
Department of Communications.
Le présent appareil numérique néémet pas de bruits radioélec-
triques depassant les limites applicable aux appareils numéri-
ques de Classe B prescrites dans le règlement sur le brouillage
radioélectrique edicté par le Ministère des Communications du
Canada.
Sicherheitsanleitung
1. Das Gerrät ist ein Einbaugerät, das für eine maximale Umge-
bungstemperatur von 55°C vorgesehen ist.
2. Zur Befestigung des Laufwerks werden 4 Schrauben 6-32
UNC-2Abenötigt.BeiseitlicherBefestigungdarfdiemaximale
Länge der Schrauben imChassis nicht mehr als 5,08 mm und
bei Befestigung an der Unterseite nicht mehr als 5,08 mm
betragen.
4 Medalist 1080sl SCSI Installation Guide, August 1995

3. Als Versorgungsspannugen werden benötigt:
+5V æ 5% 0,65A
+12V æ 5% 0,45A (1,9A fur ca. 10 Sek. fur æ 10%)
4. Die Versorgungsspannung mub SELV entsprechen.
5. Alle Arbeiten auf dem Festplatte dürfen nur von Ausgebilde-
tem Servicepersonal durchgeführt werden. Bitte schaffen Sie
Festplatteetiketten nicht weg.
6. Der Einbau des Drives mub den Anforderungen gemäb DIN
IEC 950V DC 0805/05.90 entsprechen.
Configuring the drive
Required materials:
2-mm jumper connector (supplied as spare jumpers)
Your Seagate drive is configured for operation using the options
jumper block (J8) shown in Figure 1 on page 6. The settings for
theavailableconfigurations areshowninFigure2onpage7.The
options jumper block (J8) allows you to:
•Set the SCSI ID
•Connect a remote LED
•Enable or disable parity
•Enable or disable the drive’s terminator
•Select the termination power source
SCSI ID settings. Each device on the SCSI bus must be as-
signed a unique SCSI ID. The drive uses pin-pairs1 and 2, 3 and
4, and 5 and 6 on the options jumperblock (J8) forassigning the
ID. The chart in Figure 2 shows you how to place the jumpers to
Medalist 1080sl SCSI Installation Guide, August 1995 5

J3. Standard
power connector
1234
J1. Interface
connector
J8. Options jumper block
+5V
+5V return
+12V return
+12V
Circuit
board
J1 pin 1
J8 pin 1
Figure 1. Connector and jumper block locations
6 Medalist 1080sl SCSI Installation Guide, August 1995

SCSI ID 0
SCSI ID 1
SCSI ID 2
SCSI ID 3 (default)
SCSI ID 4
SCSI ID 5
Note.
1. All other pins
are reserved. Do
not use them.
2. Jumpers on
pins 28 and 30
and 32 and 34
are spares; these
pins do not
require jumpers.
SCSI ID 6
SCSI ID 7
Remote LED 
connection
Reserved 
Do not use
Remote start
Enable parity (default)
Disable terminator
(default is enable)
Power to drive
terminator only
Power from bus, drive
terminator disabled
Power to drive
terminator and to
SCSI bus (default)
Power to SCSI
bus only
J8. Options jumper block Circuit board
side up.
11
12
9
10
7
8
5
6
3
4
13
14
1
2
15
16
17
18
19
20
21
22
33
34
31
32
29
30
27
28
25
26
23
24
Spares
Figure 2. Options jumper settings
Medalist 1080sl SCSI Installation Guide, August 1995 7

assign ID values0 through 7. Be sure that the ID you choose is
not used by another device on the SCSI bus.
YourSeagate driveis shippedby the factory configuredas SCSI
ID 3—jumpers are attached to pins 3 and 4 and pin 5 and 6. You
must reconfigure the SCSIID if another device is assigned SCSI
ID 3 or if you are making the drive the bootable drive. The
bootable drive must be Drive C. It must be assigned the ID
number your SCSIadapterrecognizes as the first positionon the
bus. Usually, this is SCSI ID 0 (refer to your SCSI host adapter
documentation).
If installing your new drive puts more than two drives on the bus,
your SCSI adapter may require thatyou install a device driver or
that you reconfigure its onboard BIOS. Refer to your SCSI
adapter’s user guide for instructions on how to install the third
drive.If a device driver isrequired, it will beprovided bythe SCSI
adapter manufacturer.
Remote LED. You can connect a remote LED to the drive using
pins 9 and 10 on jumper block J8. Connect the LED ground wire
(usually the black wire) to pin 9.
Remote start. This setting causes the drive to wait for a specific
commandfromthehostbeforeitstartsorstopsthespindlemotor.
Parityenable.Parityisamethodthatissometimesusedforerror
detection. The drive is shippedwith parity enabled.
Terminators. The drive is designed with single-ended drivers
andreceiversandmustbeusedwithotherSCSIdevicesthatuse
single-ended drivers and receivers. These systems require that
terminators be used at both ends of the SCSI bus to ensure the
integrity of the signal. The drive has built-in terminators that can
be enabled or disabled as required. It is shipped with the termi-
8 Medalist 1080sl SCSI Installation Guide, August 1995

nators enabled. If you are positioningthe drive at the end of the
cable, you must enable the drive’s internal terminators or attach
an external terminator to the endof the cable.Terminatorson the
devices between the bus ends must be disabled or removed.
•Toenablethedrive’sterminators, leavethepin-pair19 and20
on jumper block J8 open.
•To disable the terminators, place a jumper on pins 19 and 20
of jumper block J8.
Terminator power. The terminators must have a 5 volt power
source to be active. In general, the device that provides the
terminator also provides power for its terminator. Power for the
terminator may also be supplied through the SCSI cable (this is
usually done for external terminators). The Seagate drive pro-
vides settings for four implementations of terminator power:
•Terminator power to the drive terminator and the SCSI bus—
install jumpers on pins 21 and23 andon pins22 and 24of J8.
This is the default.
•Terminator power to the drive terminators only—install a
jumper on pins 23 and 24 of J8.
•Terminator power from another device to the bus and the
drive’s terminator disabled—install a jumper on pins 21 and
23 of J8.
•Terminator power to the bus only and the drive terminator
disabled—install a jumper on pins 22 and 24 of J8.
Medalist 1080sl SCSI Installation Guide, August 1995 9

Attaching cables
Required materials:
A four-conductor power-supply cable
A fifty-conductor, nonshielded interface cable with a 50-pin, fe-
male connector attached for each SCSI device that is to be
connected to the SCSI bus. The maximum cable length for
asynchronous operation is 19.5 feet (6 meters). The maximum
cable length for synchronous operation is 9.75 feet (3 meters).
Figure 1 on page 6 shows connectorand jumper block locations.
1. Turn off the system power and put on a grounded wrist
strap before proceeding.
2. Attach the 50-pin SCSI interface cable. Pin 1 on the drive
mustalignwithpin1oftheotherSCSIdevicesattachedtothe
bus. Use the edge-stripe on the cable to denote pin 1. Pin 1
on the drive is located next to the four-pin power connector.
2. ConnectingaremoteLED.(Optional)ConnectaremoteLED
to pins 9 and 10 of jumper block J8. Pin 9 is ground.
3. Attach an available power cable to the drive.
10 Medalist 1080sl SCSI Installation Guide, August 1995

Mounting the drive
Required materials:
•Four 6-32 UNC-2A screws (not included)
The drive fits in the standard 3.5-inch bay and can be mounted
in any orientation. Position the drive so that the cables are not
strainedorcrimped.Secureitwithfourmountingscrewsnotmore
than 6 full turns (0.20 inches) into the drive frame (see Figure 3).
Caution. To prevent drive mounting-hole damage, use only the
type of screws specified.
Figure 3. Mounting hole locations
Medalist 1080sl SCSI Installation Guide, August 1995 11

Configuring the drive and computer
Once the drive is physically installed, the drive and computer
must be configured to work with each other. This involves parti-
tioning and formatting thedrive and may require aspecial device
driveror installation softwaredependingonthe operating system
you are using and your SCSI adapter. Refer to your SCSI
adapter’s documentation for specific information on how to con-
figure your drive.
This guide describes a typicalconfiguration for a PC using DOS
and one or two SCSIdrives only.
System setup configuration
Required materials:
•A bootable diskette with the Format and FDISK command
IfyouarereplacingtheATA(IDE)driveordrivesinyourcomputer
with SCSI, you must reset the drive-type configuration listed in
System Setup to
Not Installed .
1. Turn the computer on.
2. Enter the System Setup routine. (Refer to your computer’s
user guide. System Setup may be called Setup, BIOS Setup
or CMOS Setup.)
3. Find the hard disc configuration in the System Setup screen.
4. Change the drive-type status to
Not Installed .
5. Save the changes and exit System Setup.
Low-level formatting
Yourdrive was low-level formatted atthefactory to512 bytes per
sector.Youdonot needtolow-levelformatitagain.Ifyouchoose
12 Medalist 1080sl SCSI Installation Guide, August 1995

to low-level formatthe drive, usethe format routine supplied with
your SCSI adapter. Refer to the SCSI adapter’s documentation
for instructions on how to low-level format the drive.
Partitioning
Youmustpartitionthedriveintooneormorelogical drivesbefore
you can use it.
Caution. Partitioningor formatting a drive atany level erases all
dataon it. Make a backup copy ofyour existingfiles on
another drive before you repartition or reformat. Sea-
gate assumes no liability if you erase your data.
To partition the drive:
1. Insert a bootable diskette into Drive A. Turn the computeron.
2. After the computer has completed booting, remove the boot
diskette from Drive A. Insert a diskette that has the FDISK
utility into Drive A and type fdisk. Press ENTER.
Note. Ifyouhavetwoormoredrives inyoursystem,themenu
displays five options. Option five allows you to select
thedriveyouwanttopartition. Makesure youselectthe
correct drive.
3. Select
createDOSpartitionorlogicalDOSdrive .PressENTER.
4. Select
create primary DOS partition . Use the maximum avail-
able size for your primary partition and make the partition
active for Drive C. This puts the entire drive on one partition
andallows you toload the DOSboot informationon thedrive.
Press ENTER for each subsequent selection.
After all of the appropriate selections are made, the computer
restarts itself. You must place a bootable diskette into Drive A.
Medalist 1080sl SCSI Installation Guide, August 1995 13

High-level formatting
High-level formatting verifies the information written by the low-
levelformatandbuildsthefileallocationtable(FAT)usedbyDOS
to access files on the drive. If you put more than onepartition on
thedrive, you must high-level format each partition.Referto your
DOS reference guide for instructions. Use the DOS FORMAT
utility to high-level format the drive as follows:
1. Type the followingcommand at the DOS prompt:
format
drive: /v /s
drive : designates the drive you are formatting. If you are
formatting the boot drive or if your system contains only one
drive, type c:.To format a second drive, type d:.
/v tellsthe computer to create a volume label for the partition
after it is formatted. Labeling can prevent someone from
accidentally deleting the partition and losing your data.
/s tells thecomputer to copy the necessary systemfiles to the
drive to make it bootable.
2. When the computer prompts you for a volume label, you can
assign a name to the drive volume of up to eleven characters
or leave it blank. Press ENTER.
14 Medalist 1080sl SCSI Installation Guide, August 1995

NonDOS operating systems
Ifyouareinstallingthedriveinasystemthatisusinganoperating
system other than DOS, you may need a device driver or instal-
lation software. The device driver is provided by your SCSI
adapter manufacturer and is operating-system specific. It is pro-
videdonadiskettethatcomeswiththeadapter.RefertotheSCSI
adapter’s documentation for instructions on how to install the
device driver. If you do not have a device driverfor the operating
system you want to install, contact the SCSI adapter manufac-
turer.
Installation software may be required to install the drive in some
systems. There are many reputable third-party installation soft-
ware packages available. Consult your dealer to determine the
best package for your needs.
Some operating systems require that you low-level format the
drive. A low-level format routine is usually supplied on the SCSI
adapter. Refer to your SCSI adapter’s documentation for instruc-
tions on using the low-level format routine.
Network installation
If you are installing the drive in a network environment, you may
need to configure your SCSI host adapter for network operation.
Refer to your SCSIadapter’s userguide forassistance preparing
the SCSI adapter and installing the drive.
If youhave trouble installing the drive with the network software,
try installing it with DOS to ensure that the drive is working
correctly.
Medalist 1080sl SCSI Installation Guide, August 1995 15

Basic troubleshooting
Warning. Alwaysturnoff thesystembefore changingjumpers or
unplugging cables and cards.
If yourdrive does notrespond or function properly whenyouturn
the power on following the hardware installation, perform these
basic checks:
•Check all cards. Make sure all cards are seated securely in
their slots on the motherboard.
•Check all cables. Make sure all cables are securely con-
nected. Adamaged ribboncableor connector strainrelief can
cause the SCSIbus to fail.
Verify that the pins 1 of eachdeviceon the cable are aligned.
Use the edge-stripe on the cable to denote pin 1.
Caution. Improperly aligning or reverse-plugging pin 1of one
device with the other devices on the cable can
damage that device or other devices.
•Check the SCSI ID. Make sure the drive’s SCSI ID does not
conflict with that of another device.
•Check theterminatorconfiguration. Ifthedriveisattheend
of the bus and external termination is not used, the drive’s
terminatormustbeenabled.Disableorremoveterminationon
all devices between the drive and thedevice at the other end
of the bus.
If the drive is not the last device on the bus or if external
terminationisused,besuretoremovethejumperthatenables
the drive’s termination.
16 Medalist 1080sl SCSI Installation Guide, August 1995

Make sure that the drive is running. Listen carefully for the
drivemotorspinning.Also,thedrive-activityLEDflasheswhen
the power is turned on. If the LED stays on after power-on,
make sure the interface cable is properly connected and that
no other device on the bus is using the same SCSI ID.
•Verify your host adapter configuration. Make sure the
address configurations your host adapter is using do not
conflict with the addresses other devices in your system use.
Refer to your host adapter’s user guide for assistance. Many
host adapters have a diagnostic utility that can help you
determine whether such conflicts exist.
Verify that the drive works when your host adapter is set with
the factory-default configuration. Refer to your host adapter’s
user guide for assistance determining the factory-default set-
tings.
•Check the CMOS drive type. If you have an AT system, the
CMOSdrive-typeparameter valuesmust be settozeroor
Not
Installed
in AT systems.
•Check the power supply specifications. The output of your
power supply may not meet the requirements of the new
devices you are installing. If you are not sure whether your
power supply meets your needs, consult your dealer.
•Check for viruses.
Before you load new software, scan the
diskette for viruses.
•Isolate the drive. If there is more than one drive in your
system, configure and install the drive for single drive opera-
tion. If you are installing the drive in a network, verify that the
drive works with DOS.
Medalist 1080sl SCSI Installation Guide, August 1995 17

Advanced troubleshooting
If you have performed the preceding basic checks but the prob-
lem has not been solved, follow these guidelines for analyzing
specific cases:
The system does not recognize the presence of the drive or
system error message, “No Drives Found,” appears.
•Check all cables. Make sure they are properly connected and
thatthepins1 are aligned.Makesurethecableis notcrimped
or damaged.
•Check all cards for proper seating.
•Check your host adapter’s BIOS memory address setting.
Makesurethatitdoesnotconflictwithanotherdevicethatsets
a BIOS memory address.
•Check the drive type in AT systems. The drive type must be
set to Not Installed or all of the drive-type parameters set to
zero.
•Check theDriveCpartitionwiththeFDISKutility.Thepartition
must be active.
•Check the bus termination. The bus must be terminated at
both ends. Disable or remove all terminators between the
termination at the ends of the bus.
•Check the terminator power source jumper settings.
•Check the power-supply specifications.
•Reboot and make sure the drive comes up to rotating speed.
(It may be difficult to hear the discs spin.) If the drive’s disc
does not spin, check all drive cables.
18 Medalist 1080sl SCSI Installation Guide, August 1995
