ST11200 Family Install Guide
ST11200 Family:
Installation Guide
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
ST11200N/ND/NC
ST1980N
ST1950N
ST1830N

ST11200 Family Install Guide
Contents
Introduction ........................................................ 1
Electromagneticinterference ............................ 1
Before you begin ................................................ 3
Installation overview ................................ 8
Product Repair.................................................... 10
Shipping................................................... 11
Product Repair and Return Information ... 12
Technical Support Services ..................... 13
Drive specifications............................................ 15
Initial set-up information.................................... 19
Drive configuration............................................. 24
Drive installation................................................. 32
© 1993 Seagate Technology, Inc. All rights reserved
Publication Number: 77738480, Rev. D.
Seagate®,SeagateTechnology® andtheSeagatelogo
areregisteredtrademarksofSeagateTechnology,Inc.
SeaFAXTM, SeaFONETM, SeaBOARDTM are trade-
marks of Seagate Technology, Inc. Other product
names are registered trademarks or trademarks of
their own.
No part of this publication may be reproduced in any
formwithoutwrittenpermissionfromSeagateTechnol-
ogy, Inc.

ST11200 Family Install Guide 1
Introduction
Beforeattemptinganyinstallation,pleasereadthrough
all applicable sections of this document, including all
warnings and cautions.
Warning. This equipment generates, uses, and can
radiate radio frequency energy and if not
installedinaccordancewiththese instruc-
tions,maycauseinterferencetoradiocom-
munications.
Electromagnetic interference (EMI) con-
siderations
The drive(s) described herein, as delivered, are de-
signed for system integration and installation into a
suitable enclosure prior to use. As such, the drive(s)
described herein are supplied as a sub-assembly and
arenotsubjecttoSubpartJofPart15oftheFCCRules
and Regulations nor the Radio Interference Regula-
tionsoftheCanadianDepartmentofCommunications.
However,theunithasbeentestedusingpropershield-
ing and grounding and found to be compliant with the
ClassAlimitsoftheFCCRulesandtheRegulationsof
the Canadian Department of Communications.

ST11200 Family Install Guide2
The physical design characteristics of the drive(s)
described herein, serve to minimize EMI radiation
when installed in an enclosure that provides reason-
able shielding. As such, the drive(s) are capable of
meeting the Class B limits of the FCC Rules and the
RegulationsoftheCanadianDepartmentofCommuni-
cations.
Note. It is the end users' responsibility to assure that
the drive(s)describedhereinmeettheappropri-
ateEMIrequirementsoftheirsystem.ShieldedI/
O cables may be required if the enclosure does
notprovideadequateshielding.IfI/Ocablesare
externaltotheenclosure,shieldedcablesshould
beused, withtheshields groundedtothe enclo-
sure and to the host controller.

ST11200 Family Install Guide 3
Before you begin
Verify that the system is switched off and discon-
nected from main power before any installation is
attempted.
Protect yourself, the drive, and your valuable pro-
grams and data by reading the following cautions
and warnings.
•Donotunpackdrivefromits staticshieldedbag until
you are ready to install it in the system.
•Always handle the drive by the frame or casting.
•Do not touch printed circuit board (PCB) or the I/O
connector pins.
•Never apply pressure to the PCB or to the drive top
cover.
•Donottamperwithsealedtop cover.Doingso voids
yourwarranty.Thedrivecontainsnouserservicable
components. See Product Repair section for more
information.
•Visually inspect the shipping container for any obvi-
ous damage.

ST11200 Family Install Guide4
•Inspectdriveforpossibleshippingdamage.Allclaims
of this type should be filed promptly with the trans-
porterinvolved.Saveoriginalpackingmaterialstobe
used when reshipping.
•Verifyallpartslistedonshippingbillarereceivedwith
the equipment. Discrepencies or damage should be
reported to the shipping company.
Caution. The circuit assemblies and components
contained in this equipment can be de-
graded or destroyed by Electrostatic Over-
stress (EOS) or by Electrostatic Discharge
(ESD).
Static electrical charges can accumulate
quicklyonpersonnel,clothingandsynthetic
materials. The electrostatic fields due to
these charges when brought in close prox-
imity to susceptable circuit assemblies and
components,canresultindegradedreliabil-
ity or immediate failure of the affected com-
ponent or assembly.
•When transporting or shipping a drive or system,
please ensure that they are correctly packed in
original Seagate approved (or equivalent) container
and shipped via an air-ride carrier experienced in
handling computer equipment.

ST11200 Family Install Guide 5
To insure optimum reliable equipment op-
eration, it is required that technical support
personnel discharge themselves by wear-
ing a grounding strap around the wrist and
be connected to a grounding terminal while
workinginthevicinityof,andwhilehandling
EOS/ESD susceptible assemblies/parts. If
unavailable, ground yourself frequently by
touching the metal chassis of the system
beforehandlinganycomponents(thishelps
onlyifthesystemisconnectedtoaground).
Avoid static-inducing carpeted areas.

ST11200 Family Install Guide6
Safety instructions
1. The disc drive(s) are to be installed in a customer
suppliedenclosurewherethesurroundingairdoes
not exceed 50oC.
2. Four (4) 6-32 UNC-2A screws are required for
installation. Maximum screw length into side of
drive is 0.15 inches (3.81 mm). Maximum screw
length into bottom is 0.20 in. (5.08 mm).
3. Thepower requirementsareshown in Section1.0
ProductInformation.
4. The power supply must satisfy the safety require-
ments for SELV (Safety Extra Low Voltage) cir-
cuits.
5. Service is to be provided by trained Seagate ser-
vice personnel.
6. The incorporation of the disc drives listed in this
guide into a customer enclosure must meet the
appropriate safety requirements of the country in
which it is used (e.g. UL 1950, CAN/CSA-C22.2
No.950-M89,DINVDE0805/05.90andEN60950:
1988 (IEC 950).

ST11200 Family Install Guide 7
Sicherheitsanleitung
1. DäsGerätisteinEinbaugerät,vorgesehenfüreine
maximale Umgebungstemperatur von 50oC.
2. Zur Befestigung der Drive werden 4 Schrauben
benötigt (6-32 UNC-2A). Die maximale Länge der
Schrauben in der unteren Seite des Chassis darf
nicht mehr als 0.20 in (5.08 mm) betragen, die in
der oberen 0.15 in (3.81 mm).
3. Die Versorgungsspannungen werden im Kapitel
1.0 (Produkt Information) gezeigt.
4. Die Versorgungsspannung muss SELV entspre-
chen.
5. AlleArbeitendürfennurvonausgebildetemSeagate
Service-Personal durchgefürhrt werden.
6. Der Einbau des Drives muss den Anforderungen
gemässDINVDE0805/05.90oderEN60950:1988
(IEC 950).

ST11200 Family Install Guide
8
Installation Overview
Installation of the drive can be divided into distinct
phases as outlined below. Some of these may not be
applicableto yourparticularinstallation requirements.
Refer to the individual drive installation sections for
specific information on your drive model.
•Driveconfiguration: Theusermustselectwhichof
the drive features are appropriate to enable for
installationin theirsystem. Thisis doneby installing
orremovingof theuser configurationjumpersfound
onthe drivePCB. "NC"models areprobably config-
ured by the host over the 80 pin interface.
•Mechanical installation: After setting up the drive
configuration the drive must be mechanically in-
stalled into the host system and the power and I/
O cables attached. Previously mentioned precau-
tions should be observed
•SCSI drives should not be defined in the CMOS:
The SCSI Host adapter has its own BIOS to handle
the Input/output procedures. The CMOS setting for
SCSI drive is either drive type zero, or the "no drive
installed"option.

ST11200 Family Install Guide 9
•Low-level formatting: After the drive has been
properly configured for the system, it does not need
to be low-level formatted, as this has been done by
the factory and does not require this step during
installation. (The low-level format writes the sector
boundariesandtrackinformationtothedrive).Defect
managementinformationisreadfromthedrivebythe
host system when required in the installation proce-
dure. If an installed drive is low-level formatted, all
user data stored on the drive will be lost.
Note. SeagateTechnologyassumes noliability for
lost user data.
•Partitioning and high level formatting: A drive
canbesub-dividedinto"partitions"whichbehaveas
individualdriveswithinthesystem.Seeyoursystem
documentation. Present day drive installation pro-
grams have menus that lead you through these
installationprocedures.

ST11200 Family Install Guide10
Product repair information
Service requirements
The special facilities required for the manufacture of
these drives generally prohibit repair in the field. If
problemsoccurduringinstallation,pleasecontactyour
supplier for assistance. Do not attempt to dissas-
semble or repair. Drives should be sent to the repair
depotthroughthepurchasesource,ifpossible.Please
observe the following cautions.
Caution.
•Handle drive with care. Do not drop or bump hard.
•Never remove the cover of these disc drives. Serv-
icingitems inthe sealedHDA(heads, media,actua-
tor,etc.)requirespecial facilities.The drivecontains
no user purchasable parts or PCBs.
•Opening the sealed HDA voids the drive warranty.
•Applyingasolderingdevicetothecomponentsonthe
PCB voids the drive warranty.

ST11200 Family Install Guide 11
Shipping: When transporting or shipping a drive, a
Seagateapprovedcontainermustbeused.Keepyour
original box. They are easily identified by the Seagate
Approved Package label. Shipping a drive in a non-
approved container voids the drive warranty.
Seagate repair centers may refuse receipt of compo-
nents improperly packaged or obviously damaged in
transit.ContactyourAuthorizedSeagateDistributorto
purchaseadditionalboxes.Seagaterecommendsship-
ping by an air-ride carrier experienced in handling
computerequipment.
• Place drive on a flat, static dissapative surface and
handle with extreme care. Always follow all EOS/
ESD precautions to avoid damage to the electrical
assemblies.

ST11200 Family Install Guide12
Product repair and return information
Seagate customer service centers are the only facili-
ties authorized to service Seagate drives. Seagate
does not sanction any third-party repair facilities. Any
unauthorizedrepair ortampering withthe factory-seal
voids the warranty.
Warranty:Contactyour SeagateAuthorized Distribu-
tor, Dealer or other purchase source for warranty
information.
If the drive is no longer under warranty contact pur-
chasesourceforrepairinformationorrefertonumbers
listed in the following paragraph .

ST11200 Family Install Guide
Technical support services
Please contact your dealer for technical support and
installation troubleshooting. Product Technical Sup-
port is available for all Seagate products by calling the
SeaFAX, SeaFONE or SeaBOARD services. These
are toll calls.
SeaFAX:408/438-2620
You can use a Touch-Tone telephone to access
Seagate's automated FAX delivery system and select
technicalsupportinformationbyreturnFAX.Thisserv-
ice is available 24 hours a day, 7 days a week.
SeaFONE:408/438-8222
The enhanced phone system provides recorded tech-
nical information on selected Seagate products while
you are on hold. Technical suppport specialists are
availabletoanswerquestionsfrom8:00AMto5:00PM
PST, Monday through Friday. Recordings are acces-
sible 24 hours a day, 7 days a week.
13

ST11200 Family Install Guide14
SeaBOARD:
TheSeagateTechnicalSupportBulletinBoardSystem
(BBS) is available 24 hours a day, 7 days a week. A
modemisrequiredtoaccessthisservice.Thecommu-
nications software must be set for eight data bits, no
parity and one stop bit (8N1).
With this service you can access:
•Specifications and jumper configurations for all
Seagate products.
•Reprints of Seagate documentation.
•Adirectoryofinformationandhelpfulutilitiesthatyou
can download to your own computer.
BBS Modem Maxmum
Location Number Baud Rate
United States 408-438-8771 9600
England 44-62-847-8011 9600
Germany 49-89-140-9331 2400
Singapore 65-227-2217 9600
Australia 61-2-756-2359 9600
Note: These are toll calls

ST11200 Family Install Guide 15
Drive specifications
Product
Information ST11200N/NC ST11200ND
Interface [7] SCSI-2 Fast SCSI-2 Fast
Cache Type Multi-segmented, 256 Kb
Capacity MB
Unformatted 1248 1248
Formatted [1] 1054 1054
Cylinders 1872 1872
Heads 15 15
Sectors/track 74 (avg.) 74 (avg.)
Recording method RLL (1,7) RLL (1,7)
Rev/min 411 5411
Seek time (ms typ.)[2]
Average Read 12.0 12.0
Write 12.7 12.7
Operating environment
Ambient temp. [4] ------ 5oC to 50oC-----
HDA max temp. [3] -----------60oC----------
Power requirements (Versorgungsspannungen)
+12 V+/-5% (Max [6] 1.0 A 1.0 A
(Max Start) [5] 2.0 A 2.0 A
+5 V +/-5% (Max) [6] 0.8 A 1.0 A
(Max Start) 0.8 A 0.9 A
Power Idle (Typ) 9.0 W 10 W
Oper. (Typ) 11.0 W 12 W

ST11200 Family Install Guide
16
Product
Information ST1980N
Interface [7] SCSI-2 Fast
Cache Type Multi-segmented, 256 Kb
Capacity MB
Unformatted 1021
Formatted [8] 860
Cylinders 1730
Heads 13
Sectors/track 74 (avg.)
Recording method RLL (1,7)
Rev/min 5411
Seek time (ms typ.)[2]
Average Read 11.7
Write 12.5
Operating environment
Ambient temp. [4] ------5oC to 50oC------
HDA max temp. [3] -----------60oC----------
Power requirements (Versorgungsspannungen)
+12 V+/-5% (Max [6] 1.0 A
(Max Start) [5] 2.0 A
+5 V +/-5% (Max) [6] 0.8 A
(Max Start) 0.8 A
Power Idle (Typ) 9.0 W
Oper. (Typ) 11.0 W

ST11200 Family Install Guide
Product
Information ST1830N ST1950N
Interface [7] SCSI-2 Fast SCSI-2 Fast
Cache Type Multi-segmented, 256 Kb
Capacity MB
Unformatted 834 953
Formatted [8] 702 803
Cylinders 1325 1575
Heads 13 13
Sectors/track 74 (avg.) 74 (avg.)
Recording method RLL (1,7) RLL (1,7)
Rev/min 5411 5411
Seek time (ms typ.)[2]
Average Read TBD TBD
Write TBD TBD
Operating environment
Ambient temp. [4] ------5oC to 50oC------
HDA max temp. [3] -----------60oC----------
Power requirements (Versorgungsspannungen)
+12 V+/-5% (Max [6] 1.0 A 1.0 A
(Max Start) [5] 2.0 A 2.0 A
+5 V +/-5% (Max) [6] 0.8 A 0.8 A
(Max Start) 0.8 A 0.8 A
Power Idle (Typ) 9.0 W 9.0 W
Oper. (Typ) 11.0 W 11.0 W
17

ST11200 Family Install Guide
18
Notes.
[1] Standardunits arefactoryformattedwith512data
bytes per sector with twelve spare sectors per
cylinderand2cylindersatinnertracksreservedfor
spares in addition to capacity listed.
[2] Includes on-board controller overhead.
[3] Maximum measured at any location on top cover.
[4] For best reliability keep below 35oC (95oF).
[5] -10% regulation for a maximum of 10 seconds at
powerup.(-10%Regelungfür10Sekundenmax).
[6] Measured with an average reading DC ammeter.
Instantaneous +12 V current peaks will exceed
these values.
[7] CanbecommandedtooperateaccordingtoSCSI-
1 protocol.
[8] 512databytespersectorwithonesparesectorper
track, two spare cylinders at inner tracks.
