Sealey Led112 User manual

LED EXTRA SLIM FLOODLIGHT WITH WALL

BRACKET

MODEL NO: LED112, LED113, LED114, LED115

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these

instructions, and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY

1.1. ELECTRICAL

WARNING! It is the user’s responsibility to read, understand and comply with the following:

WARNING! THIS PRODUCT MUST BE INSTALLED BY A QUALIFIED ELECTRICIAN.

9You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads

and all electrical connections for wear and damage.

9You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices. An RCCB (Residual Current

Circuit Breaker) should be incorporated in the main distribution board.

9You must also read and understand the following instructions concerning electrical safety.

9 Ensurethelightisconnectedtoanappropriateelectricalon/o󰀨switch.

9Ensure the insulation on all cables and the product itself is safe before connecting to the mains power supply.

9Ensure that cables are always protected against short circuit and overload.

9Regularly inspect power supply, leads and all electrical connections for wear and damage, especially power connections, to ensure

that none are loose.

9Ensure the voltage marked on the product is the same as the electrical power supply to be used.

8DO NOT pull power cable once installed.

8DO NOTusewornordamagedleads,orconnections.ImmediatelyreplaceorhaverepairedbyaqualiedElectrician.

9 Ensuretheunitiscorrectlyearthedandwiredaccordingtothefollowing.(Installationshouldbeundertakenbyaqualiedelectrician)

a) Connect the green/yellow earth wire to the earth terminal ‘E’.

b) Connect the brown live wire to live terminal ‘L’.

c) Connect the blue neutral wire to the neutral terminal ‘N’.

9After wiring, check there are no bare wires, that all wires have been correctly connected and that the wire restraint is tight.

1.2. GENERAL SAFETY

WARNING!Turno󰀨themainspowersupplybeforeservicingorperforminganymaintenance.

9 Maintainthelightingoodcondition(Repairsmustonlybeundertakenbyaqualiedelectrician).

9Replace or repair damaged parts. Use genuine parts only, non authorised parts may be dangerous and will invalidate the warranty.

9Ensure the light is installed correctly in accordance with these instructions.

9Only install the light on a vertical surface.

8DO NOTxthelightonanyhorizontalsurfacei.e.ceiling,oroverhang.

9 IdeallytheInstallationshouldbeawayfromammableorcombustiblematerialssuchaswood,cloth,paperetc.

▲DANGER! DO NOT direct the light into a persons eyes. This unit has a very intensive light output, which if incorrectly used could

cause eye damage.

8DO NOT install the light where it is likely to be knocked or hit.

8DO NOT install in bathrooms, shower rooms, sauna or such locations.

8DO NOTinstallnearanexhaustoutlet.i.e.Boilerue,dryeroutlet,etc.

8DO NOTusethelightwithoutthefrontglassshieldtted.

2. INTRODUCTION

Mountedindie-castpowdercoatedaluminiumextraslimhousingwithwallbracket.SMDLEDtechnologyallowsultra-brightilluminationwhilst

still keeping costs lower than traditional halogen tubes. Even spread of light across a 110° angle. Supplied with power cable only and suitable

for outdoor mounting.

3. SPECIFICATION

Model No:...............................................LED112................................ LED113 ................................. LED114 ................................LED115

Colour Temperature:....3000K, 4000K and 6000K.... 3000K, 4000K and 6000K ..... 3000K, 4000K and 6000K ......3000k, 4000k and 6000k

IP Rating: ..................................................... IP65......................................IP65 .......................................IP65 ..................................... IP65

LED Qty:..................................................12 SMD................................ 54 SMD ................................. 69 SMD ................................80 SMD

Lumen Output:..........................................1700lm................................. 4500lm .................................. 5600lm .................................8500lm

Nett Weight: ..............................................0.28kg.................................. 0.58kg ................................... 0.75kg ....................................1.3kg

PIR Motion Sensor: .........................................No........................................ No ......................................... No ........................................ No

Power:.......................................................... 20W......................................50W .......................................70W ................................... 100W

Supply: ........................................................ 230V.....................................230V ......................................230V .................................... 230V

LED112, LED113, LED114, LED115 Issue 1 29/03/19

Original Language Version

Refer to

instructions

4. ASSEMBLY

WARNING! DO NOT connect unit to the mains power supply before installation.

4.1. Installation

4.1.1. Givecarefulconsiderationtothepositionofunittoensureyouobtainmaximumbenetfromthe 

lighting range, and that an appropriate electrical power source can be provided.

4.1.2. Anapproximateappropriatemountingheightfromthegroundis2.5m.Seeg.1.

4.1.3. ThisLEDoodlightdevelopsminimalheatandisnotsubjecttothesamemountingrestrictionsthat

 applytohalogenlampsthatbecometoohottotouch.Wedohoweverrecommendthattheoodlight

 shouldnotbeplacedincrampedorrestrictivepositionsandshouldbexedatthefollowingminimum

 distancesbetweenthelightandanysurface/object.Seeg.2.

 ●500mmminimumbetweenthetopofthelightandanyoverheadsurface,orobjects,i.e.ceilings,

overhangs.

 ●200mmbetweensidesoflightandwall/surfaces

 ●2metresminimumbetweenthefrontofthelightandanyobjecttobeilluminated.

 Fixthelighttoaverticalsurfacewithappropriatexings.

 Ensurethelampisconnectedtothemainsbyaqualiedelectrician.

5. MAINTENANCE

5.1.  Cleanthecasingexternally(nottheglass)withamoistcloth.

8DO NOT use solvents or abrasives to clean the light.

5.2. Avoid touching the glass shield as handling may reduce its serviceable life and cause the glass to crack. If necessary clean the

glass shield with alcohol and a soft cloth. Undo the single screw without removing it to clean internally.

8DO NOT use the light without the glass shield.

8DO NOT use the light without the weather seals intact.

g.1

g.2
