Sealey LED130P.V2 User manual

1. ELECTRICAL SAFETY
1.1. PLUG & MAINS POWER SUPPLY
 WARNING! It is the owner’s responsibility to read, understand and
comply with the following:
You must check all electrical equipment and appliances to ensure that they are
safe before using. You must inspect power supply leads, plugs and all electrical
connections for wear and damage. You must ensure that the risk of electric
shock is minimised by the installation of appropriate safety devices. An RCCB
(Residual Current Circuit Breaker) should be incorporated in the main
distribution board. We also recommend that an RCD (Residual Current Device)
is used with all electrical products. It is particularly important to use an RCD
together with portable products that are plugged into an electrical supply not
protected by an RCCB. If in doubt consult a qualified electrician. You may
obtain a Residual Current Device by contacting your Sealey dealer. You must
also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical
appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a
year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical
appliances responsible for the safe condition of the appliance and the
safety of the appliance operator. If in any doubt about electrical
safety, contact a qualified electrician.
1.1.3. Ensure the insulation on all cables and the product itself is safe
before connecting to the power supply. See 1.1.1. & 1.1.2. above and
use a Portable Appliance Tester (PAT).
1.1.4. Ensure that cables are always protected against short circuit and
overload.
1.1.5. Regularly inspect power supply, leads, plugs and all electrical
connections for wear and damage and especially power connections
to ensure that none are loose.
1.1.6. Important: Ensure the voltage marked on the product is the same as
the electrical power supply to be used and check that plugs are fitted
with the correct capacity fuse.
A 13amp plug may require a fuse smaller than 13amps for certain
products, see recommended fuse rating listed below.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull plugs from sockets by the power cable.
1.1.9. DO NOT use worn or damaged leads, plugs or connections.
Immediately replace or have repaired by a qualified electrician.
A U.K. 3 pin 13amp plug with ASTA/BS approval is fitted. In case of
damage, cut off and fit a new plug according to the following
instructions (discard old plug safely). (UK only - see diagram).
Ensure the unit is correctly earthed via a three-pin plug. FOR
230 VOLT 13AMP PLUG SEE fig.1.
a) Connect the GREEN/YELLOW earth wire to the earth terminal
‘E’.
b) Connect the BROWN live wire to live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d) After wiring, check that there are no bare wires, that all wires
have been correctly connected, that the cable external insulation
extends beyond the cable restraint and that the restraint is tight.
1.1.10. Cable extension reels. When a cable extension reel is used it should
be fully unwound before connection. A cable reel with an RCD fitted is
recommended since any product which is plugged into the cable reel
will be protected. The section of the cores of the cable is important
and should be at least 1.5mm², but to be absolutely sure that the
capacity of the cable reel is suitable for this product and for others
that may be used in the other output sockets, we recommend the use
of 2.5mm² section cable.
RECOMMENDED 230V
FUSE RATING: 3AMP
INSTRUCTIONS FOR:
130 LED PORTABLE
FLOODLIGHT - 230V
MODEL No: LED130P.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS, AND
CAUTIONS. USE THIS PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE, OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY.
1.2. LIGHT WIRING
 WARNING! Ensure all cables are disconnected from the power
supply before attempting following.
Should you need to re-wire the cable into the lamp, proceed as
follows: Remove back cover of terminal box, located at the rear of the
lamp, to expose the connection block and wires, see fig.2. When
wired, check that the weather proofing seal is correctly located in the
back cover recess and then replace the back cover. If in any doubt
contact a qualified electrician.
1.2.1 DO NOT use worn or damaged leads, plugs or connections.
Immediately replace or have repaired by a qualified Electrician.
Ensure the unit is correctly earthed and wired according to fig.2
below.
a) Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b) Connect the BROWN live wire to live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’. After
wiring, check there are no bare wires, that all wires have been
correctly connected and that the cable clamp is tight. Also
ensure that the mains cable passes through the rubber washer
situated beneath the cable entry nut.
fig.2
1.3. GENERAL SAFETY
p WARNING! Turn off the mains power supply before servicing or
performing any maintenance.
3Ensure the light is installed correctly in accordance with these
instructions.
If you use an extension lead the cable must be fully unwound from
the drum.
DANGER! DO NOT direct the light into a person’s eyes. All models
have a very intense light output which, if incorrectly used, could
cause eye damage.
DO NOT use the light without the front glass shield. Avoid touching the
glass shield as handling may reduce its serviceable life and cause the
glass to crack.
DO NOT use the light without the weather seals intact.
DO NOT use the light without the front glass shield.
fig.1
Original Language Version LED130P.V2 Issue: 1 - 13/02/13
©Jack Sealey Limited 2013

Original Language Version
DO NOT use the light near flammable, combustible or explosive liquids,
solids, gases or equipment.
Maintain the light in good condition. Repairs must only be undertaken
by a qualified electrician (use an authorised service agent).
Keep a minimum distance of 1 metre from the front of light to the
surface which is to be illuminated.
Locate the light in an adequate area for its function, keep area clean
and tidy and free from unrelated materials.
When not in use, switch off the light and disconnect from the power
supply. Ensure that the unit is cool and dry and then store in a safe, dry,
childproof area.
DO NOT install the light where it is likely to be knocked or hit.
DO NOT install in bathrooms, shower rooms, sauna or such locations.
3. INSTALLATION & USE
2. INTRODUCTION & SPECIFICATION
Portable floodlight in die-cast aluminium housing with tubular steel framed
stand. Features 130 super bright LED's, which have a longer working life than
traditional halogen bulbs. Suitable for lighting workshops, garages and other
environments where light is limited. Weatherproof design supplied with mains
cable and BS approved plug.
Power ..................... 8W
Supply....................230V
Lumen Output.............585lm
3.1. ASSEMBLY
3.1.1 Slide the high end of the stand into the black clamp as indicated in fig.3
and fig.4. Align the threaded insert in the stand with the hole in the black
clamp and screw in the fixing knob ensuring that the contoured washer
on the threaded part fits the curvature of the clamp. Adjust the angle of
the floodlight as required and tighten the knob to grip the stand.
3.2. USE OF LIGHT.
p WARNING! Ensure the mains power supply is off prior to using the
floodlight.
3.2.1. Position the floodlight in the area that requires illumination.
3.2.2. This LED floodlight develops minimal heat and is not subject to the
same restrictions that apply to halogen lamps that become too hot to
touch. We do however recommend that the floodlight should not be
placed in cramped or restrictive situations and recommend the following
minimum distances between the light and any surface/object.
 ●500mmminimumbetweenthetopofthelightandanyoverhead
surface, or objects.
 ●200mmbetweensidesoflightandendorsidewalls,surfacesor
objects.
 ●1metreminimumbetweenthefrontofthelightandanyobjecttobe
illuminated.
WARNING! Ensure the light is disconnected from the mains
power supply when not in use.
3.3. MAINTENANCE.
 ●Cleanthelightwithadry,dust-freecloth.DO NOT use solvents or
abrasives to clean the light.
 ●Ifnecessarycleantheglasswithalcoholandasoftcloth.
 ●DO NOT use the light without the glass shield.
 ●Althoughweatherproof,thelightmustnotbestoredwet.Shouldthe
unit become wet, unplug from mains and wipe dry before storing.
 ●DO NOT use the light without the weather seal intact.
 ●Repairsmustonlybeundertakenbyaqualifiedelectrician.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
LED130P.V2 Issue: 1 - 13/02/13
fig.3
fig.4
©Jack Sealey Limited 2013
Knob
Insert and slide stand tube into clamp. Align tapped
hole in stand with hole in clamp, secure with knob.
Clamp
Stand
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which
is compatible with the environment.
WEEE Regulations.
Dispose of this product at the end of its working life in compliance
with the EU Directive on Waste Electrical and Electronic Equipment.
When the product is no longer required, it must be disposed of in an
environmentally protective way. Contact your local solid waste authority
for recycling information.
