Sealey LED170 User manual

INSTRUCTIONS FOR
RECHARGEABLE FOLD FLAT FLOODLIGHT
10W/20W SMD LED LITHIUM-ION
MODEL NO’S: LED170 & LED171
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
USE ONLY THE SUPPLIED MAINS CHARGER PLUG FOR CONNECTING FLOODLIGHT TO THE MAINS POWER
SUPPLY.
WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions:
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices. An RCCB (Residual
Current Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD (Residual
Current Device) is used with all electrical products, particularly portable equipment which is plugged into an electrical
supply not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2. The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
 thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.
1.1.3. You must ensure that you:
9Inspect the charger plug, cable and connector for wear and damage to ensure items are safe before connecting to the mains power
supply. If worn or damaged DO NOT use.
9Check cables are always protected against short circuit and overload.
▲Important: Check that the voltage marked on the charger plug is the same as the power supply to be used.
9Uncoil the cable between charger and the floodlight.
8888 DO NOT pull the charger plug from the mains socket by the lead.
8888 DO NOT use any other type of charger with this product.
8888 DO NOT place the connector into any area of the floodlight except the correct jack inlet socket.
8888 DO NOT try to take the charger plug apart.
8888 DO NOT use the charger plug to charge or power any other electrical item.
8888 DO NOT get the charger wet, or use in wet, damp conditions (for indoor use only).
888 WARNING!8NEVER substitute a standard 13Amp 3 pin plug, or any other type of plug, for the charger plug.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire: ,
8888 DO NOT attempt to open, disassemble, modify or service the battery.
9Ensure the charger is switched off and disconnected from the floodlight before attempting to open the lamp unit.
8888 DO NOT expose to temperatures above 60°C (140°F).
8DO NOT crush, puncture, short external contacts or dispose of in fire or water.
8988 Replace only with the battery designated for this product.
9Dispose of the old batteries in accordance with local authority battery regulations. DO NOT dispose of with regular refuse.
9If the electrolyte in the cells contacts the skin, wash thoroughly with soap and water.
9If the electrolyte in the cells gets into the eyes, rinse thoroughly with cool water and seek immediate medical attention.
1.3. GENERAL SAFETY
9Ensure the floodlight is correctly charged before initial use.
8888 DO NOT cover or block the lens during use.
8888 DO NOT turn the floodlight on when it is being re-charged.
8888 DO NOT shine directly into your, other person’s or animal’s eyes.
8888 DO NOT allow children to use the floodlight.
8888 DO NOT handle or move the floodlight whilst it is being charged.
8888 DO NOT use the floodlight if you suspect that the battery or the spotlight casing is damaged.
8888 DO NOT immerse the floodlight in water.
9Ensure replacement batteries are genuine Sealey batteries of the same rating.
8988 Ensure the floodlight is unplugged and allowed to cool before attempting any cleaning or replacement.
9When not in use store the floodlight in a safe, dry, childproof location.
LED170, LED171 | Issue:1 27/04/17
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual

2. INTRODUCTION
Innovative swivel function enables floodlight to rotate 360° and fold flat. Floodlight houses 20 (LED170) or 36 (LED171) super bright SMD LEDs
providing up to 1200 lumen output with 110° spread of light. High quality 2.6Ah (LED170) or 5.2Ah (LED171) Lithium-ion battery for longer life and a
much slower discharge than traditional Ni-MH batteries. Supplied with mains charger.
3. SPECIFICATIONs
Model no:......................................................................LED170
Battery: .......................................................... 7.4V 2.6Ah Li-ion
LED quantity:................................................................20 SMD
Power: ............................................................................... 10W
Lumen output (high/low):..........................................600/300lm
Operating time (high/low): .......................................... 2.2/4.4hr
Charging time: .................................................................. 4.5hr
IP rating: ............................................................................ IP44
Thebatteryttedtothislampisconsideredtobeaconsumableitemanditsabilitytoacceptachargewillreduceovertime. 
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
 Ifthebatteryisnotproperlychargedbeforerstuse,orregularlyconditioned,itscapacitywilldiminish.Underthesecircumstances
we will not replace the battery regardless of whether it is less than one year old.
Note: The lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without
another charge.
4. OPERATION
WARNING! Ensure that you read, and fully understand the safety instructions before use.
Charging
4.3.1. Chargethebatterybeforeuse.Onlyusethechargersuppliedwiththeoodlight.
▲IMPORTANT: Ensuretheoodlightisturned‘Off’whilstcharging.Failuretodosowilldamagethecharger.
4.3.2. Insertthechargerjackplugintothesocketonthebackoftheoodlight.
4.3.3. The RED led indicates that it is charging. When the battery is fully charged the light will turn off.
4.3.4. Whenthebatterygoesat,chargethebatteryassoonaspossible.Batterylifewillbeaffectedifitisleftdischargedforalongtime.
4.1. Operation
4.1.1. Press the On/Off button on the back to turn on. Select 50% or 100% as required.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
Web
LED170, LED171 | Issue:1 27/04/17
Original Language Version
© Jack Sealey Limited
Model no:......................................................................LED171
Battery: .......................................................... 7.4V 5.2Ah Li-ion
LED quantity:................................................................36 SMD
Power: ............................................................................... 20W
Lumen output (high/low):........................................1200/600lm
Operating time (high/low): .......................................... 2.2/4.4hr
Charging time: .................................................................. 4.5hr
IP rating: ............................................................................ IP44
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
Battery Removal
 Undo4screwsonbackofoodlampandremovefrontpanel.Usegreatcaresoastonotdamagethebattery.Cutwires
one at a time, carefully remove the battery. Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey
 Ltdarerequiredtoinformpotentialpurchasersofproductscontainingbatteries(asdenedwithintheseregulations),that
they are registered with Valpak’s registered compliance scheme. Jack Sealey Ltd’s Batteries Producer Registration
Number (BPRN) is BPRN00705.
