INSTRUCTIONS FOR
UNDERSEAL GUN WITH CANISTER & EXTENSION
PROBE
MODEL NO: SG19.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Disconnect the gun from the air supply before changing accessories, servicing or performing any maintenance.
9Wear eye protection, a mask, protective clothing and gloves.
9Locate the gun in an adequate working area for its function, keep area clean and tidy and free from unrelated materials, and ensure
there is adequate lighting.
9 Useinawellventilatedareaawayfromsourcesofignition.Ensureunderseal/rustproonguidmanufacturer’sinstructionsare 
carefully followed.
9Maintain the gun in good condition. Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be
dangerous and will invalidate the warranty.
9Keep the gun clean and rinse out nozzle, quick-release coupling and suction pipes with suitable solvent after use.
WARNING! if gun components become blocked there is a danger of excessive pressure building up in unit causing the canister to
burst.
9 Removeillttingclothing.Removeties,watches,rings,andotherloosejewellery,andcontainlonghair.
9Keep children and unauthorised persons away from the working area.
9When not in use ensure the air supply is turned off and the gun is disconnected. Avoid unintentional starting.
8DO NOT place attachments close to your face (especially eyes, ears, etc) and do not point hose at other persons or animals.
8DO NOT carry by the air hose, or yank the hose or the gun from the air supply.
8DO NOTusethegunforanypurposeotherthanforwhichitisdesignedanddonotllwithanyotheruidorliquid.
8DO NOT operate the gun if damaged.
8DO NOT direct air from the air hose at yourself or others..
9When not in use disconnect from the air supply and store in a safe, dry, child proof area.
2. INTRODUCTION
Suitableformostbrandsofwaxrustinhibitor.suppliedwithnozzleforsurfaceapplicationand910mmexibleprobeforcavities.
3. SPECIFICATION
Model no: .................................................................SG19.V2
Recommended air pressure: ...................87-145psi (6-10bar)
Air consumption without extension:........................... 13.4cfm
Air consumption with extension:.................................. 6.4cfm
Air inlet size:..............................................................1/4”BSP
Optional rigid probe:.................................................... SG191
SG19.V2 | Issue:3 (L) 05/09/17
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear eye
protection
Wear a mask Wear
protective
gloves
Wear
protective
clothing
fig.1 fig.2 fig.3

4. OPERATION
4.1.  Followtheinstructionsoftherustpreventativeuid/undersealcarefully.Ensurethatthecontainerisshakenbeforeuse.
4.2. Preparing Gun for use.
4.2.1. Pourtherustpreventativeintothecanister(g.3)andsecurelyscrewtheguntopontocanister.
4.2.2. Attachtheendofthegunhandletothecompressedairsystem(g4).
4.2.3. Aimthenozzleofthegunintoasafeareaanddepresstheguntrigger(g.5A)tocheckandadjustthegunnozzletotherequired
 suctionandspreadaccordingtotheviscosityoftheuidinthecontainerorcanister(g.5B).
4.3. Extension probes.
4.3.1. TheSG19issuppliedwithanextensionprobe(g.2)whichmayonlybeusedwiththinuids.Theexibleprobeisforsprayingthin
 uidsintocavities,betweenpanelsandinsidedoorsetc.
 Note:Probeisonlysuitableforusewiththinuids.
4.3.2. For spraying “hard-to-reach” areas, the SG19 may be used with the optional SG191 long reach extension probe.
4.3.3. Totprobereleasethelockingnutonthetriggernozzle(g.6C)andremovethenozzle(D),retainingitinasafeplace.
4.3.4. Chosetheappropriateextensionnozzle,andinsertthesprungbrasspick-upintotheendofthetriggerhoseoutlet(g.7E)andsecure
 withthelockingnut(g.7G).
5. MAINTENANCE
WARNING! Ensure you remove the gun from the air supply before attempting any maintenance.
5.1.  Itisveryimportanttokeepthegunandcomponentscleantoensurefreepassageofuidsinuse.
5.2. After use clean all items especially probes with a suitable solvent and allow to dry before storage.
WARNING! DO NOT use any component that has become blocked as this may build up excessive air pressure and cause canister to
explode.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Parts support is available for this product. To obtain a parts listing and/or diagram, please log on to
www.sealey.co.uk, email [e-mail] or telephone [phone]
