Sealey IR20T User manual

TROLLEY (FOR HEATER - IR20)
MODEL NO: IR20T
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETYi
9Before each use, check that there is no damage to the trolley and that all fixings and wheels are firmly attached.
8DO NOT use this item for any purpose other than that it is intended for.
9Replace or repair damaged parts. Use only recommended parts. Other parts may be dangerous and will invalidate the
warranty.
2. INTRODUCTION
Optional trolley for Model No. IR20.
3. SPECIFICATION
Model No: .................................................................... IR20T
Size (H x W x D): ......................................350 x 515 x 80mm
Nett weight:................................................................. 3.48kg
4. CONTENTS
5. ASSEMBLY
5.1.  TROLLEYANDHANDLE(g.1,g.2)
5.1.1. Followingg.1,assemblethecomponentsasshown.
5.1.2. Followingg.2,assemblethehandle(ItemB)asshown.
5.2. MOUNTING HEATER (g.2)
5.2.1. Clear out the four screw holes in the heater case that align with the
handle and trolley.
5.2.2. UsexingsG,H,andItomountthehandleandtrolleyoneitherside
 oftheangeontheheaterbody.
IR20T Issue 1 21/03/19
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
ITEM DESCRIPTION QUANTITY
A Wheel frame (2 sides + 1 end part) 3 pieces total
B Handle (2 sides + 1 end part) 3 pieces total
C Axle 1
D Wheel 2
E Spacer 2
F Domed wheel nut M12 2
GHexheadboltM4x50long 4
H Coned washer M4 8
I Locknut M4 4
J FlangeheadboltM5x25long 4
K Locknut M5 4
fig.1fig.2
