seasmart AWM60 User manual

Awning post side mount kit.
| P. 01 |
CAUTION. Read all instructions carefully before installing and using this product.
AWNING POST SUPPORT: AWM60, AWM60A, AWM80, AWM80A, AWM100, AWM100A.
1. REQUIRED FOR INSTALLATION.
Installation instruction
Threadlocker
Non acidic degreaser
Anti-corrosion lubricant
Template Hole saw
Polyurethane marine sealant
rev. 07-2021
Wrenches Drill
(only for external installation)
Screwdriver and countersunk
screws Ø 5,5 mm
(only for external installation)

| P. 02 |
Installation instruction
1. TEMPLATE.
Mark the holes, and use a hole saw to cut hole for the socket of the
mounting bracket.
Type T min T max A min
AWM60 10 mm 44 mm 250 mmØ 32 mm
AWM80 / AWM100 10 mm 44 mm 300 mmØ 32 mm
AWM60A 250 mmØ 32 mm
min 50 mm A
T
Awning post side mount kit.
rev. 07-2021
AWM80A / AWM100A 300 mmØ 32 mm

| P. 03 |
Installation instruction
AWM60 / AWM80 / AWM100
Type
40 mm 30 mm
2.1 INTERNAL INSTALLATION
Carefully clean the base of the socket with a non-acid degreasing agent.
Then apply a small bead of marine sealant. Apply some anti-corrosion
lubricant into the drilled hole, and some thread locker to the thread.
Insert the socket inside the hole, and tighten the nut with the wrench.
Remove the excess of marine sealant on the top.
Awning post side mount kit.
rev. 07-2021

| P. 04 |
Installation instruction
2.2 EXTERNAL INSTALLATION (ONLY FOR AWM60A, AWM80A, AWM100A)
Carefully clean the base of the socket with a non-acid degreasing agent.
Then apply a small bead of marine sealant. Apply some anti-corrosion
lubricant into the drilled hole. Use eight Ø5.5 self-tapping countersunk
screws to fix the two PB20AX to the wall.
Remove the excess of marine sealant on the top.
Awning post side mount kit.
rev. 07-2021

| P. 05 |rev. 01-2021
BP20AX
52 mm
64,5 mm
