Seat Comfort Systems SCS6MSS User manual

Seat Comfort Systems 6 Motor Massage System
THE UNIVERSAL MASSAGE SYSTEM has been designed to be installed in a minimal amount of time with readily available tools. The
unique design allows installation into 90% of existing seat designs. The Massage System has a dual LED switch which designates
Manual and Automatic settings.
Before You Start:
Check and determine that the massage motors will fit under the seat trim covers in the desired areas. Seat Massage Motors should
never be installed into foam where an occupant detection sensor is present on the surface of the foam cushion.
WARNING: The installation instructions have been carefully compiled through actual vehicle installations and to the best of
our ability is accurate. However, we do not warrant the accuracy of this information against changes in vehicle design, the use
or misuse of this information or typographical errors. It is the responsibility of the installer to verify the proper wire
attachments prior to and after the installation of the Seat Massage System to assure proper operation. We do not accept any
responsibility for damage to the vehicle or injury to its occupants caused by the use of this information. Improper installation
and/or connection to the incorrect wires could cause Seat Heater System or vehicle malfunction, component damage and/or
personal injury for you and/or your passengers.
GENERAL ADVICE:
The Seat Massager is to be installed under the seat cover. Always check the motor placement on the seat prior to beginning
any work. Make sure there are no vertical tie-down seams or any obstacles that would not allow the motors to be installed.
Check for Occupant Detection System in the seat prior to installing, the massager cannot be installed over or under an
Occupant Detection System.
The installer is liable for any damage due to improper installation.
All steps explained in this manual are to be followed with great care. Installation has to be performed by qualified personnel
only. Improper installation will void the limited warranty and may cause physical damage to equipment or people.
The massage system has to be connected to fused 12 volt accessory power. It is necessary that the system is capable of
driving up to 5 Amps continuous current.
The wire harness has to be fitted to the seat in a way that the full range of movement of the seat is possible.
Cars fitted with side airbags have to be treated according to the manufacturers fitting manuals. The massage system is only to
be attached to the middle of the seat back foam. The connections of the side airbag(s) have to be handled thoroughly and
should never be connected to any kind of power supply during the fitting process.
36 MONTH/36,000 MILE LIMITED WARRANTY
Seat Comfort Systems warrants to the original retail purchaser of this product that should this product or any part thereof,
under normal use and conditions, be proven to have defective material or workmanship within 36 months or 36,000 miles of the
original purchase, such defect(s) will be repaired or replaced without charge for the parts. This warranty does not apply to
batteries or normal wear and tear associated with the Product.
To obtain repair or replacement with the terms of this Warranty, the product is to be returned with a dated bill
of sale, description of defect to the installing dealer and/or retailer.
This Warranty does not cover costs incurred for the removal or reinstallation of the product, and/or related
components, and/or damage to the vehicle's electrical system or components.
This Warranty does not apply to any product or part thereof which in the opinion of the Company has been damaged
through alteration, improper installation, misuse, neglect, accident, or customer abuse.
No person or representative is authorized to assume for the Company any liability other than expressed herein in
connection with the sale of this product.
THE EXTENT OF THE COMPANYS LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR
REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S LIABILITY EXCEED THE PURCHASE
PRICE PAID BY THE PURCHASER FOR THE PRODUCT.
SCS6MSS

Seat Comfort Systems 6 Motor Massage System
Seat massagers should never
be installed into foam where an
occupant detection sensor is
present on the surface of the
foam cushion.
The installer is liable for any
damage due to improper fitting
or not following these
instructions.
Seat massage motors are to be
installed on the seat foam only.
Installation has to be
performed by qualified
personal only. Improper
installation will void the
warranty and may cause
physical damage to equipment
or people.
Dismantling the seat
Disconnect and isolate the
battery negative (ground) cable
and wait five minutes for the
system to discharge.
Dismantle the seat that will be
fitted with the heating pads. In
most cases striping the seat
cover is easier with the seat out
of the car.
Remove all seat covers in the
area you are planning to fit the
massage system and wire
harness.
Removing The Seat Cover
Separate cushion and back
from each other by removing
the covers and unscrewing the
connecting screws. It is
advised to put the seat on a
dedicated worktable for the
following steps.
Remove the cover of both seat
and back. To do so remove and
dispose all upholstery clips.
Unhook all other connections
using a suitable screwdriver.
Make sure that there are no
loose metal parts left on the
foam like hog rings.
Massage Motor Placement
Lay the massage motors on the
seat and determine the
placement of the motors.
Suggested placement are
locations that will be under the
muscle structure of the user.
Avoid the shoulder blade area
and the belt line area.
Placement locations are “lower
back” (above or below belt
line), middle back and upper
back (below/between shoulder
blades).
Using a marker, trace out the
motor outline, making sure the
motors locations are
symmetrical.
Cutting Foam Pockets
Using a blade or knife, cut the
pocket for the massage motor.
Cut on the inside of the
marked line, 1” deep. Grab the
foam at the top cut and gently
pull back while cutting the
foam at the 1” deep base. Try
to cut evenly so the pocket is
flat..
Motor Installation
Cut a slit on the top of the
pocket and then slide the
massage motor in from the
back of the foam back. Make
sure the motor wire colors are
the same. Using spray glue,
spray into the foam cavity and
then place the motor in the
cavity. Gently pull the wire
from the back of the seat back
and secure the motor into the
cavity.
Foam
motor
glue
Wire harness and switch
While running the wire harness
you have to pay attention, that
the wire cannot be cut,
crimped or damaged in any
other way. The wire harness is
to be attached to the seat frame
securely.
Plug the open connector of the
motor harness to the controller
and attach the controller to the
seat frame.
Run the switch wire harness to
the center console or side seat
shield. Drill a 25mm hole in
the panel, Pull the connecting
wire through and then plug in
the switch and push the switch
into the panel (please push on
the outer bezel of the switch).
Electrical connection and
function test
Black to Ground
Red to accessory power
White to accessory power
*Connect to a switched source
capable of driving 5 Amps
continuous current.
Power Connection
Connect the red wire to
fused 12 volt power.
Connect the black wire to
ground.
Connect the white wire to
accessory power. If you
are not using accessory
power, join the white and
red wire together. (The
white wire is a signal wire
input).
Route the wire harness
from the seat along the door
sill plate to the fuse box as
shown below.
Massage Operation
M –Manual Mode
Press once for low intensity
Press again for increased
intensity
Press third time for maximum
intensity
Press to turn off.
A –Automatic Mode
There are 8 rhythm modes
that are cycled.
Press once for low intensity
Press again for increased
intensity
Press third time for maximum
intensity
Press to turn off.
Upper
Middle
Lower
A
M
