SECO-LARM ENFORCER EV-N1506-2W4Q User manual

®
EV-N1506-2W4Q
IP Fixed Bullet Camera
Manual
Features:
1/2.7" 5MP SMARTSENS CMOS
H.265/H.264, Tri-stream IP Camera
12VDC, PoE 802.3af
True Day & Night function with ICR
mechanism
Max. 20FPS/5MP, 1440p (2592x1944)
Weather-resistant (IP66)
3DNR
ONVIF Profile S, Profile G

ENFORCER IP Fixed Bullet Camera
2 SECO-LARM U.S.A., Inc.
Dimensions:
Specifications
:
Parts List:
1x
Camera
1x
CD
3x
Mounting screws
1x
Security wrench
1x
Manual
1x
DC plug with terminal block
Type Fixed Bullet Camera
Sensor
1
/
2.7
" 5MP
SMARTSENS
CMOS
Video encoding
H.265/H.264
Megapixels
5MP
Resolution
1440p,
2592
x
1944
DNR
2DNR
N/A
3DNR
Yes
Scanning system
Progressive 1080p
# of IR LEDs
2pcs (850nm)
Lens
2.8mm
Viewing angle
131°
Minimum
illumination
0.05 Lux
F Stop
1.2
Gamma correction
Auto
S/N
R
atio
N/A
Gain control
Auto
White balance
Auto
Operating voltage
12VDC, PoE
802.3af
Current draw (IR Off)
80mA max.
IP Rating
IP66
Operating temperature
-
22°~131° F (
-
30°~55° C)
Dimensions
ø
2
13
/
16
"x
5
15
/
16
" (
ø
71
x
151
mm)
Weight
13.4
-
oz (370g)
515/16" (151mm)
ø
213/16"
(ø71mm)

ENFORCER IP Fixed Bullet Camera
SECO-LARM U.S.A., Inc. 3
Before Starting:
Overview:
Installation:
RJ45 Ethernet Jack
DC Plug with
terminal block
DC Jack
Micro
SD
Card slot
Reset button
Bottom of camera
Micro SD / Reset button
compartment
1.
Please read this manual carefully and keep it for
future reference.
2. Use the camera within given temperature and
electrical limits.
3. Do not point the camera at the sun. Heat could
damage the camera, even when not in use.
4.
Do not mount the camera in areas exposed to
radiation, strong magnetic fields, or strong
electrical signals.
5. Do not open or disassemble the camera. There
are no field-serviceable parts inside.
6. Do not drop the camera or subject it to strong
vibrations.
NOTE: For the full Web Admin manual, download from the camera’s product page on www.seco-larm.com.
1.
Run a 12VDC power supply wire and cable with
an RJ45 jack through the wall at the location
where the camera is to be mounted. The 12VDC
power supply wire is not required if using PoE.
2. Install and Execute "Device Config Tool" on a
computer connected to the same network as the
camera.
3. Press the "Search" button. This will search for IP
cameras connected to the same router on the
network. It may take several seconds to complete
.
Default IP address is 192.168.1.168.
4. Once the search is complete, click on the camera
IP or type the IP address manually using Internet
Explorer.
5. IP Address: The camera may use Dynamic or
Static IP addressing. An example of a typical static
IP setting is as follows:
IP Address: 192.168.0.10 (you can change the
last column)
Netmask: 255.255.255.0
Gateway: 192.168.0.1
DNS1/2: You can copy the PC’s network
properties. This is for an internet
environment.
6. Input "admin" for user ID and password. If this is
the user's first time logging into the camera, the
user will be prompted for a new password.
NOTE: If the password is unknown, hold the
RESET button located on the camera for
about 10 seconds and reload "Device
Config Tool".
7. In order to access the camera web interface, the
user will be prompted to download and install the
Active-X web plugin.
8. Once installed, the user will be able to view live
camera video and modify necessary
configurations.

ENFORCER IP Fixed Bullet Camera
4 SECO-LARM U.S.A., Inc.
The screen is blank.
 Check that the camera is powered up.
 Check that the power supply’s polarity is correct.
 Check that the monitor is powered up.
 Check that the video cable connecting the camera to the
monitor is connected properly.
The screen image is dim.
 Clean the lens using a soft, clean cloth.
 Check that the light source is adequate.
The screen image has poor contrast.
 Adjust the monitor’s contrast knob.
 Change the position of the camera.
The screen image flickers.
 Change the position of the camera.
The screen image is distorted.
 Change the position of the camera.
The camera case is hot.
 Check that the correct power supply is in use.
Troubleshooting:
SECO-LARM
® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Website:
www.seco
-
larm.com
Phone: [phone] | [phone] Email: [e-mail]
PICRN3
MI_EV-N1506-2W4Q_200803.docx
NOTICE: The SECO-LARM policy is one of continual development and improvement. For that reason, SECO-
LARM reserves
the right to change specifications without notice. SECO-LARM is also not responsible for misprints. All t
rademarks are the
property of SECO-LARM U.S.A., Inc. or their respective owners. Copyright © 2020 SECO-LARM U.S.A.,
Inc. All rights
reserved.
WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while
used in normal
service for three (3) years from the date of sale to the original customer. SECO-
LARM’s obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if
damage is caused by or attributed to acts of God, physical or electrical
misuse or abuse, neglect, repair or alteration, improper
or abnormal usage, or faulty installation, or if for any other reason SECO-
LARM determines that such equipment is not
operating properly as a result of causes other than defects in material and workmanship. The sole obligation of SECO-
LARM
and the purchaser’s exclusive remedy, shall be limited to the replacement or repair only, at SECO-LARM’s option.
In no event
shall SECO-LARM be liable for any special, collateral, incidental, or consequential person
al or property damage of any kind
to the purchaser or anyone else.
IMPORTANT:
Users and installers of this product are responsible for ensuring this product complies with all national, state,
and local laws and statutes related to monitoring and recording audio and video signals. SECO-LARM
will not be held
responsible for the use of this product in violation of any current laws or statutes.
FCC COMPLIANCE STATEMENT
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2)
THIS DEVICE MUST ACCEPT
ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device
is permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure
requirements
and void user’s authority to operate the device.
WARNING:
Stop using the camera if you see a malfunction such as smoke or unusual heat, as it could cause fire or
electric shock. Do not open the case of this device, as there are no user-serviceable components inside.
