SECOMP Roline 12.03.3220 User manual

Datenblatt - Fiche technique - Data sheet
12.03.3220
ROLINE Typ C - DisplayPort Adapter, v1.2, ST/BU
ROLINE Adaptateur Type C - DisplayPort, v1.2, M/F
ROLINE Type C - DisplayPort Adapter, v1.2, M/F

Item no.: 12.03.3220
ROLINE USB 3.1 Cable Adapter, C – DisplayPort, M/F
Aluminum, silver
Features:
Support DisplayPort Video output 4K*2K@60Hz resolution
Aluminum Housing in silver color
No driver needed
USB 3.1 Type-C interface supports plug and play, hot swap
Easy to carry and use
With 10cm Cable in white color
Connector: USB 3.1 Type-C Male*1 (input) + DisplayPort 1.2v Female*1 (output)
Operating Temperature: 0℃~45℃
Storage Temperature: -20℃~ 70℃
Operating Humidity: 10% ~ 85 % RH (no condensation)
System requirements: Windows, MAC OS X, Google Chrome

USB 3.1 Type-C™to Displayport
1.2v Socket Converter
User Manual

USB 3.1 Type-C™to Display port 1.2v Socket converter
Contents
1.0 INTRODUCTION.............................................. 1
2.0 FEATURES ..................................................... 1
3.0 SPECIFICATIONS............................................ 1
4.0 PACKAGE CONTENTS....................................... 2
5.0 OPERATION ...................................................2
6.0 CONNECTION DIAGRAM .................................. 2

USB 3.1 Type-C™to Display port 1.2v Socket converter
1
USB 3.1 Type-C™to Display port 1.2v Socket
converter
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or using
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This is a USB 3.1Type C™ to Display port 1.2v Socket, designed for connecting
display port monitor to host computer, the host computer can easily connect to
the Display port monitor .Connecting the monitor with a Display port cable
which is contacted with Display socket of this converter It can work on Mac
book or Google new Chromebook Pixel or Asus Zen AiO and other USB
3.1Type C™ supported devices.
2.0 FEATURES
Support USB 3.1Type C™ Video output 4K*2K@60hz resolution
NO driver needed
ABS Housing Provide white，black two colors
Aluminium Housing Provide gold，silver，grey space，three colors
Slim Type ABS Housing Provide white，black two colors
With 10cm Cable
USB 3.1Type C™ interfaces support plug and play, hot swap
Easy to carry and use
3.0 SPECIFICATIONS
Item No.:
ABS Housing 716106 716106S
ABS Slim Type 716146 716146S
Aluminium Housing 716146V 716146D 716146X
Size(L*W*H)
ABS Housing 200*45*15.2mm
ABS Slim Type housing 200*25*11.5mm
Aluminium Housing 200*23.4*11mm
Input/Output Connector
Input port USB 3.1Type C™ Male*1
Output port Display port 1.2v Socket
Warranty

USB 3.1 Type-C™to Display port 1.2v Socket converter
2
Limited Warranty 1 Year
Environmental
Operating Temperature 0℃~45℃
Operating Humidity 10% ~ 85 % RH (no condensation)
Storage Temperature -20℃~ 70℃
Storage Humidity 5% ~ 90 % RH (no condensation)
System requirements Windows, MAC OSX, Google
Chrome
Regulatory Approvals
FCC CE Certification
RoHS 2.0 & REACH Compliant
Accessories Adapter
User Manual English Version
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the shipping carton:
Main unit x1
User Manual x1
5.0 OPERATION
1) Connect the Display port 1.2v Socket to Monitor
2）Connect the USB 3.1Type C™ male port of this product to computer
6.0 CONNECTION DIAGRAM
