SIIG JU-VG0311-S1 User manual

1
USB 3.0 Display Adapter
Quick Installation Guide
04-0817A
Introduction
The USB 3.0 Display Adapter allows you to connect
a monitor, LCD or projector to your desktop or
notebook PC and use it as an extended desktop or
as an additional larger/different display for your
main screen.
Key Features and Benefits
• Compliant with Universal Serial Bus 3.0
Specification
• Works with standard and wide screen
monitors
• Supports high resolutions up to 2048 x 1152
• Video streaming is supported up to 1080p
• Display modes: Primary Display, Extend,
Mirror
• Connect up to 6 USB display adapters
simultaneously

2
System Requirements
• Desktop or notebook PC with a single core
1.2 GHz CPU or faster
• An available USB 2.0/3.0 port (USB 3.0
recommended)
• Windows®
8 (32-/64-bit) / 7 (32-/64-bit) /
Vista (32-/64-bit) / XP (32-bit, SP3)
Package Contents
• USB 3.0 Display Adapter
• Driver CD
• DVI to VGA adapter (For JU-DV0311-S1
only)
• Quick installation guide
Layout
JU-DV0311-S1
Figure 1: USB 3.0 to DVI/VGA Pro - with DVI Output
DVI out
USB 3.0 connector

3
Windows Software Installation
Make sure the proper driver for your graphics
card is installed, the USB 3.0 Display Adapter is
not designed to work with Windows' Standard
VGA Graphics Adapter driver. Important: Do
not plug the USB 3.0 Display Adapter into the
computer until instructed to do so.
Figure 3: USB 3.0 to VGA Pro
Figure 2: USB 3.0 to DVI/VGA Pro - with VGA Output
JU-VG0311-S1
DVI to VGA adapter VGA out
USB 3.0 connector
VGA out

4
1. Insert the driver CD.
2. At the autoplay CD driver window, double
click Setup. Or press Windows key and R,
type D:\Setup.exe in the Run window,
then click OK. (Change D: to match your
CD/DVD-ROM drive letter)
3. Click Yes or Allow at the User Account
Control. Skip this step if not prompted.
4. Click I Accept.
5. Connect your second monitor to the USB
3.0 to Display Adapter and turn it on, then
plug the USB 3.0 Display Adapter into the
computer. (USB 3.0 recommended)
6. Restart the computer.
To Verify Windows Installation
1. Go to Device Manager to verify installation.
For Window 8 / Windows 7 / Windows XP:
Right click Computer or My Computer,
click Manage, then click Device Manager.
For Windows Vista: Right click Computer,
click Manage, click Continue, then click
Device Manager.

5
2. Double click USB Display Adapters.
For USB 3.0 to VGA Pro: USB3 VGA Adapter
should be displayed.
For USB 3.0 to DVI/VGA Pro: USB3 DVI
Adapter should be displayed.
Uninstalling the Adapter Driver
Windows 8 / Windows 7
1. For Windows 8, double click Control Panel
on desktop. For Windows 7, click Start, and
click Control Panel.
2. Click Programs, and click Programs and
Features.
3. Select DisplayLink Graphics, then click
Uninstall.
4. Click Yes, Yes, then click OK.
5. ClickYes tocompleteuninstallingthedriver.
Windows Vista
1. Click Start, and click Control Panel.
2. Click Classic View, double click Programs
and Features.

6
3. Select DisplayLink Graphics, then click
Uninstall, then click Yes.
4. Click Allow, then click Yes to complete
uninstalling the driver.
Windows XP
1. Click Start, and Control Panel.
2. Double click Add/Remove Programs.
3. Select DisplayLink Graphics, click
Remove, then click Yes.
4. ClickYes tocompleteuninstallingthedriver.
Windows Display Utility
After successful driver installation, a display
utility icon will appear in the taskbar. This
display utility allows you to quickly change the
viewing modes and resolutions. Access the utility
by clicking the icon.
Viewing Modes
Several options to change the setups of your
display:
•Screen Resolution: Displays a list of
available resolutions.

7
•Screen Rotation:
Normal - No rotation is applied to the USB
3.0 Display Adapter display.
Rotated Left - Rotates the extended or
mirrored display by 270 degrees.
Rotated Right - Rotates the extended or
mirrored display by 90 degrees.
Upside-Down - Rotates the extended or
mirrored display by 180 degrees.
•Extend to:
Right - Extends the display to the right of
the main display.
Left - Extends the display to the left of the
main display.
Above - Extends the display above of the
main display.
Below - Extends the display below the main
display.
• Extend (default): This mode extends your
desktop for easy viewing of multiple
windows. Windows will move off the
primary display from the right side and
enter the extended display from the left.

8
•Set as Main Monitor: This mode, makes
the USB 3.0 Display Adapter the main display
adapter in the system.
•Mirror: In this mode, the USB 3.0 Display
Adapter will mirror your desktop. You will
see the same image on both monitors.
•Off: This setting turns off the USB 3.0 Display
Adapter.
•Optimize for Video (not available in
Windows XP): Configures the secondary
display for optimum full screen video
performance output. Note: Text may appear
less clear.
•Fit to TV: Adjust the size of the Windows
desktop when the Windows desktop does
not completely appear on the TV.
Using Windows Display Properties (WDP)
Note: Not all of the WDP functions are
available in Windows Vista.
Instead of using the display utility, you can use
the embedded Windows Display Properties
(WDP) to change view modes and resolutions.

9
Following the instructions below to access the
WDP functions:
Position the mouse anywhere on the Windows
Desktop,
For Windows 8 / Windows 7: Right click and select
Screen Resolution.
For Windows Vista: Right click and select
Personalize, then click Display Settings.
For Windows XP: Right click then select Properties.
WDP allows you to rotate, duplicate or extend
screens as well as modify screen resolution.
•Display: Use the drop down list to select a
display to be configured.
•Resolution: Use the drop down list and
user the slider to choose a resolution.
•Orientation:
Landscape - Sets the display to landscape
view.
Portrait - Sets the display to portrait mode.
Landscape (flipped) - Setsthe display to upside
down landscape mode.

10
Portrait (flipped) - Sets the display to upside
down landscape mode.
•Multiple displays:
Duplicates these displays - Reproduces the
main display on the second display.
Extend these displays - Extends the main
display onto the secondary display.
Show Desktop only on 1 - The desktop appears
onthedisplay marked 1. The display marked
2 becomes blank.
Show Desktop only on 2 - The desktop appears
onthedisplay marked 2. The display marked
1 becomes blank.
•Make this my main display: When you
check the box, it will make your USB 3.0
Display Adapter the main display adapter
in the system. Make sure the secondary
monitor is selected before choosing this
option.
• Display Positions: To move the position of
a display, click and hold the display you
wish to move then drag it to the desired
position. (As Figure 4 in the next page.)

11
The display will be highlighted with a blue
border while you are moving the display to
its new position.
Windows Shortcut
Press Windows key and P to bring up the menu
and choose a desirable mode. (Available in
Window 8 and Windows 7 only)
Figure 4: WDP functions
Figure 5: Shortcut
* The image may vary under different OS. However, the functions are the same.
Select a display
and drag to a
preferred position.

12
Video Playback in Extended Mode
If the video or DVD playback quality is poor or
low performance in the extended mode, please
playback on the primary monitor instead of the
add-on monitors.
Frequently Asked Questions
Q1: Why won't my DVD player work when I
move it over to the extended display?
A1: Some DVD playback software packages do
not support playing on a second display
adapter.
Q2: How come my open window will not move
over to the extended display?
A2: Restore down the open window before
moving it over the the extended display,
also make sure the open window is moved
completely over onto the extended display.
Q3: There are lines running horizontally up
and down my screen or the screen is
distorted.

13
A3: This is due to a low or unsupported refresh
rate setting. You can change this in Display
Properties/Settings/Advanced/Monitor.
Noted not to select the USB 3.0 Display
Adapter and not set the refresh rate higher
than what yourmonitor can support.
Q4: Why my mouse can't return to the primary
monitor when removing the adapter while
in extended mode?
A4: In some cases, when removing the adapter
while in extended mode, the desktop will
still be paired to be add-on monitor(s) and
the mouse cursor may not return to the
primary monitor. If this happens, connect
the addon monitor(s) and adapter again or
keep moving the mouse.

14
Q5: Why can't I make the USB 3.0 Display
Adapter the primary display?
A5: Some video cards ship their product with a
utility that prevents other video cards from
being set as the primary video card. Check
the bottom right hand corner of the taskbar
for the utility. Disable the utility before
switching the USB 3.0 Display Adapter to be
the primary display.

15
Technical Support and Warranty
QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at
www.siig.com and click Support. Our online support database is updated daily with
new drivers and solutions. Answers to your questions could be just a few clicks away.
You can also submit questions online and a technical support analyst will promptly
respond.
SIIG offers a 5-year manufacturer warranty with this product. This warranty covers the
original purchaser and guarantees the product to be free of any defects in materials or
workmanship for five (5) years from the date of purchase of the product.
SIIG will, at our discretion, repair or replace (with an identical product or product
having similar features and functionality) the product if defective in materials or
workmanship. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. Please see our web site for more warranty details.
If you encounter any problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the product to the store
where you purchased from.
B) If your purchase has passed the store's return policy period, please follow the steps
below to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, clickSupport, thenREQUEST A PRODUCT REPLACEMENT
to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request
will be processed, if the product is determined to be defective, an RMA number will
be issued.
Step 2: After obtaining an RMA number, ship the product.
• Properly pack the product for shipping. All accessories that came with the
original package must be included.
• Clearly write your RMA number on the top of the returned package. SIIG will
refuse to accept any shipping package, and will not be responsible for a product
returned without an RMA number posted on the outside of the shipping
carton.
• You are responsible for the cost of shipping to SIIG. Ship the product to the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
• SIIG will ship the repaired or replaced product via Ground in the U.S. and
International Economy outside of the U.S. at no cost to the customer.

PRODUCT NAME
USB 3.0 Display Adapter
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
Phone: [phone]
USB 3.0 Display Adapter is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered
trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft
Corporation. All other names used in this publication are for identification only and may be
trademarks of their respective owners.
September, 2012 Copyright © 2012 by SIIG, Inc. All rights reserved.
About SIIG, Inc.
Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity
solutions (including Serial ATA and Ultra ATA Controllers, FireWire, USB,
and legacy I/O adapters) that bridge the connection between Desktop/
Notebooksystems andexternal peripherals. SIIGcontinues togrow byadding
A/V and Digital Signage connectivity solutions to our extensive portfolio.
SIIGproducts offercomprehensiveuser manuals,many user-friendlyfeatures,
and are backed by an extensive manufacturer warranty. High quality control
standards are evident by the overall ease of installation and compatibility of
our products, as well as one of the lowest defective return rates in the industry.
SIIG products can be found in computer retail stores, mail order catalogs,
throughmajor distributors, system integrators, andVARs inthe Americasand
the UK, and through e-commerce sites.
