Security Camera King HDIR7907VF User manual

Wire ports
Thank you for purchasing this HD CCTV Camera. Please read these
instructions carefully for a thorough understanding of how the cameras op-
erates.
1.Operating requirements
1.1 Before using the camera ,please read this manual carefully and keep it
safely for later use.
1.2 Installation should be proceed by professional service and follow manu-
facturer’s instructions, do not dismantle without authorization.
1.3 In order to prevent sensor ,do not expose lens to intense light source in
long time.
1.4 Do not touch sensor directly. Please covers the dustproof cover when
the camera is not being used.
1.5 Please use a dry soft cloth to clean the camera. If dirt difficult to clean,
use detergent with water and wipe dry the camera.
1.6 Do not install camera under air conditioning’s air gate ,or else lens blur
with condensation of moisture.
1.7 Please ensure that all electric power sources are turned off when not
open , installation ,clean, etc operation.
1.8 Please transporting , using and storing the camera in allowable tempera-
ture and humidity.
1.9 If the camera was broken, for example power cord or plug dam-
aged ,splash liquid or foreign matter fall into camera, rain-
ing ,wetting ,etc can’t work situation ,please contact manufacturer or
maintenance center (modify and maintenance without permission ,you
must be responsible for the problems)
2.Statement
2.1 All photos here are for reference only .Specifications are subject to
physical product.
2.2 This manual is subject to change without further notice.
2.3 Please contact with customer service for the newest procedures and
supplementary specification.
2.4 This manual list several model numbers for reference , please user ac-
cording actual product to operating.
2.5 We will do the best to keep this manual complete and accurate, but
some data may has deviation. If any doubt or dispute ,company retain
the final right of the product.
HD CCTV CAMERA
USER MANUAL
INTRODUCTION:
This camera which has 2.1M Pixes is specially designed for security monitoring. It
applies the latest 2.1M Pixes progressive scan CMOS. It is a heavyweight new-
designed HD camera which applied DC12V and support user customize the output
parameter settings.
Safety Instruction
Application method
1
3 4
NO. Name Model Number
1 Camera 1
2 Power line — 1
3 Warranty
Card — 1
Packing List
Specification
Imaging Sensor 1/3" 2.1Megapixel Panasonic CMOS
Scanning System Progressive Scan
S/N Ratio More than 50dB (AGC Off)
Video Output Mode 1080P(1920 X 1080)
Video Output Level HD-SDI /1.0 Vp-p (75Ω，Composite)
Lens 2.8-12mm Manual Zoom Lens
Min. Illumination 1.0Lux(Color),0.5Lux(BW)
IR Distance 30M(with ￠5X36PCS LED)
OSD Built-in
Electronic Shutter Auto/FLK/1/25,30sec ~ 1/60000sec
AGC Level adjustable
DNR Low/Middle/High
Digital Zoom 1.0X-8.0X
D-DFFECT Mirror/Flip/D-Zoom/Defog
Back Light HLC/BLC/WDR
SENS-UP X2-X8
Voltage/Current DC12V+10% / 210mA(550mA with IR on)
Operating temperature -10°~ +50°C
Dimension (mm) ￠131x 93(H)
Weight (g) 800
2
HDIR7907VF

LENS
1.When the SETUP menu screen is displayed, select LENS
by
using the UP and Down buttons so that the arrow indi-
cates
LENS
* ELC/ALC: Select Fix iris and Auto Iris Lens.
EXPOSURE
1.Using this function, you can control screen brightness.
►BRIGHTNESS: You can control the brightness .
►SHUTTER: MANUAL/AUTO.
* MANUAL
NTSC: 1/30 ~ 1/60000,
PAL: 1/25 ~ 1/60000,
* FLICKER: Select this when you picture flicker.
* AUTO: Select this mode to control the shutter speed
automatically. Shutter speed is automatically controlled de-
pending on the brightness of the screen.
►SENS-UP: When it is night, the camera automatically
detects the light level and maintains a clear picture.
►AGC: You can adjust it . The higher the gain level, the
brighter the screen but the higher the noise.
BACKLIGHT
►HLC: To inhibit strong light and compensate bright-
ness of the area around it.
* LEVEL:0-20 * MODE :ALL DAY/NIGHT ONLY
►BACKLIGHT: This function allows you to get a clear
pictures of objects even the objects in strong backlight.
* H-POS/V-POS/H-SIZE/V-SIZE
►WDR: If there are bright area and dark area on the screen
at the same time, this function makes both areas to be in clear
image.
* LOW/MIDDLE/HIGH
WHITE BAL.
According to the color temperature of environment to
adjust the camera’s color.
* AUTO/AUTOext/PRESET/MANUAL
DNR
 This function reduces the background noise in a low lumi-
nance
environment.
* LOW/MIDDLE/HIGH
►SHARPNESS（0~10）: Adjust the sharpness of the im-
age.
►GAMMA: Set the GAMMA value of camera.
►COLOR GAIN: 0~20.
►MIRROR: you can flip the image horizontally.
►FLIP: you can flip the image vertically.
►D-ZOOM: 1.0X~8.0X.
►ACE: Adaptive Color Enhancement.
If there are bright area and dark area on the screen at the
same time, this function makes both areas to be in clear im-
age.
*OFF/LOW/MIDDLE/HIGH
►SHADING: Lens shading compensation.
►PRIVACY: Hide an area you want to hide on the screen.
* ZONE NUM : 0~15
* ZONE DISP : ON/OFF
* H-POS/V-POS/H-SIZE/V-SIZE
* Y-LEVEL/CR-LEVEL/CB-LVEL
MOTION
►SENSITIVITY: When the number is high, the detection is
increased to recognize even small movement.
►WINDOW TONE: 0~6.
►DET H-POS:0~60.
►DET V-POS:0~40.
►DET H-SIZE:0~60.
►DET V-SIZE:0~40.
►MOTION OSD: ON/OFF.
►ALARM: ON/OFF.
SYSTEM
►COM.: Communication settings.
* CAM ID/BAUDRATE
►IMAGE RANGE: USER/FULL/COMP.
►OUTPUT MODE: 1080P/720P.
►COLOR SPACE: HD-CbCr/YUV/SD-CbCr.
►FRAME RATE: 25FPS/30FPS.
►CVBS: PAL/NTSC.
►LANGUAGE: ENG/CHN/CHN(S)/JPN/KOR.
►COLORBAR: OFF/ON.
►RESET
5
6
7 8
Function Menu
LENS ■ELC ■ALC
EXPOSURE ■BRIGHTNESS ■AGC ■SENS-UP ■AGC
BACKLIGHT ■HLC ■BLC ■WDR
WHITE BAL ■AUTO ■AUTOext ■PRESET ■MANUAL
DNR ■LOW ■MIDDLE ■HIGH
■SHARPNESS
■FLIP
■SHADING
■GAMMA
■D-ZOOM
■PRIVACY
■COLOR GAIN
■AEC
■MIRROR
■DEFOG
MOTION
■SENSITIVITY
■DET H-SIZE
■WINDOW
TONE
■DET V-SIZE
■DET H-POS
■MOTION OSD
■DET V-POS
■ALARM
SYSTEM
■COM.
■FRAME RATE
■IMAGE
RANGE
■CVBS
■OUTPUT
MODE
■LANGUAGE
■COLOR
SPACE
■COLORBAR
EXIT
OSD MENU
How to use the camera
