Security Centres TS2000 Operation manual

TS2000
Installation & User Guide
Compatible Equipment
CPA6 OM - Output Module
9040 - Loudspeaker
DC54/58 - Digital Communicators
496529 Issue A 1 of 20 TS2000

OVERVIEW
Introduction
The Intruder Alarm Control System TS2000 is provided for
large domestic and general commercial intruder
systems conforming to BS 4737 part 1 1986. It is an
extremely versatile system with the following facilities:
1. Will monitor up to 128 zones using various types of
detector device;
2. Will provide up to 136 output signals whose
response may be programmed;
3. May be programmed to provide a large number
of operational options and facilities.
As the system is microprocessor controlled it must be
programmed initially to select the required user options
such as number of zones, type of alarm and time of
operation. The general principle of operation is to
monitor protected zones, each having a detection
circuit, to detect the circuit status, then to respond
accordingly. As each zone has a circuit the terms Zone
and Circuit may be considered as being synonymous
but the term Circuit is generally used. Circuits may also
be grouped into wards.
Equipment
The system consists of a number of units that are
interconnected by a Control Network:
1. ControlPanel(CP):Thisisthecontrollingpanelforthe
system which:
(a) provides power to the system;
(b) communicates with and monitors the state of
theunitsconnectedtotheControlNetworkand
responds to alarm conditions according to the
pre-programmed instructions;
(c) provides special outputs to a printer, a Digital
Communicator, a Modem and other devices if
required.
It has no front panel controls and may be sited at any
convenient internal location.
2. NodeUnit (NU):a unitthat isremote fromthe CPand
is connected to it via the Control Network. It will
monitor the status of up to four circuits and will also
provideuptofour programmableoutputswhichare
controlled by the CP;
3. Remote Keypad Node Unit (REM): has the same
functions as the NU and in addition has a Keyboard
and a 40 character display to allow operators to
control the system.
The system will consist of a CP connected, via the
Control Network, to up to 32 NU’s and or REM’s so
providing up to 128 circuits and programmable outputs
each of whose functioning and use are
pre-programmed.AtleastoneREMisrequiredtocontrol
the system.
CP Options
Additional boards may be fitted to the CP as follows:
1. SerialInterfaceBoard(SlB):Providesaserialoutput:
(a) RS232 format for a serial printer;
(b) RS232 format to any suitable equipment;
2. Parallel Interface Board (PIB): Provides up to eight
outputportswhichmaybeprogrammedtorespond
to system activity and which can also be used to
provide outputs to a separate Digital
Communicator. It also has a (telephone) Line Fault
input port.
3. Digital Communicator type DC3 (Digicom): Will
transfer status information from the CP to a
dedicated Central Station via PSTN lines. When
activated via any of its eight logic input channels it
will:
(a) Dial one or two telephone numbers;
(b) Transfer an account (identity) number to the
dialled station;
(c) Transfer channel status information.
ModemtypeDC3M(Digimodem):Willtransferdataover
PSTN lines to any suitable equipment such as a modem
for a computer terminal. When activated the system will
dial one or two telephone numbers and will be capable
of transferring all commissioning information, event log
data etc., to a remote maintenance centre. The
remote maintenance centre may also call the DC3M
and transfer data to it.
TS2000 2 of 20 496529 Issue A
TS2000

Additional Equipments
Ward Control Unit (WCU): When fitted the WCU will allow
a group of circuits, which are designated a Ward, to be
Set and Unset using Exit and Entry routes separate from
the system. The WCU is connected to the outputs and
circuits of a REM or a NU and will require a separate 12V
supply.
Printer: An Epson printer P40-S may be connected
temporarily to the CP or to the SlB to provide printout
records. Other printers that accept RS232 serial data
maybepermanentlyconnectedtotheSIBifpermanent
records are required.
Power Supply Unit: All power can be supplied from the
TS2000CPinternal PowerSupplyUnit butinlargesystems
it may be necessary to fit additional power supply units.
The PSU150 has been designed for use with the TS2000
system and consists of a PSU and battery (supplied
separately) and it may also have a Node Unit and a
Relay Unit fitted in its enclosure.
Output Modules (OM): If remote indicators or Mimic
Panels containing LEDs are required then Output
Modules type CPA6.OM may be connected to the CP.
EachOMunitwilldriveuptoeightLEDsandtheunitsmay
be interconnected for large displays. The system may
be programmed so that the LEDs indicate circuit
condition or alarms and ward status if wards are
programmed.
Extension loudspeakers: The REM contain a small
sounder unit to provide an indication of the system
status. If the volume of the sounder is insufficient (e.g. a
louder exit sound is required) then an extension speaker
may be fitted to the NU and this will require a
Loudspeaker Drive Unit type LSD1 to be connected
between the NU and the loudspeaker. A separate 12V
power supply will also be required.
Relay Unit: The NU and REM programmable outputs will
provide current limited drive for various facilities but in
many cases it will be necessary to isolate the system
from the external equipment by driving via relays. Relay
Units type RM3A provide two relays, which may be
energised by NU or REM programmable outputs, and
whichprovide twosetsof’clean’ changeovercontacts.
The unit may be fitted separately or in a PSU150 case.
Remote Data Transfer
When fitted with a Digimodem type DC3M the system
may be programmed from a remote location, and log
data transferred to it, using a dedicated program
installed in a Personal Computer at that location. The
use of this facility is protected by a series of passcodes
and user menus.
496529 Issue A 3 of 20 TS2000
TS2000

Schematic Block Diagram
TS2000 4 of 20 496529 Issue A
TS2000
WARD
CONTROL
UNIT*
REMOTE
POWER
SUPPLY
UNIT*
NODE OR
REMOTE KEYPAD
No 32 (MAX)
NODE OR
REMOTE KEYPAD
No X
NODE OR
REMOTE KEYPAD
No 2
CONTROL
PANEL
NODE OR
REMOTE KEYPAD
No 1
Programmable
Outputs
S001 - S004
Mains input
240V 50Hz
PSTN Lines*
Other Option Outputs
Programmable
Option Outputs
Detection
Circuits
C001 - C004
Control Network cable
Cable: 6 or 8 core 7/0.2mm min
.
Max length 100m between units
2
Detection Circuits
C005 - C008
Control Network Cable
4 Output Circuits
for WCU Exit/Entry
Circuits
12V l/p
Control Network Cable
Detection Circuits
C125 - C128
Programmable
Outputs
S125 - S128
12V Supply
M
ains Input
Programmable
Outputs
S005 -S008
Distance between Nodes/Keypads must be less than 100m.
Distance between Control Panel and last Node/Keypad must be less than 1km
*= Option
Control Network Cable
3 Detection
Circuits
for WCU
Figure 1. TS2000 Schematic Block Diagram

TS2000 System Options - Schematic
496529 Issue A 5 of 20 TS2000
TS2000
SIB* PIB* PSU
DC3(M)*
OR D 3*
CPMAINBOARD
8 Programmable
outputs DC 28
Digicom PSTN Line
Central
Station
Mains Input
To PSTN
To PSTN Approved
Modem
P. C.
To Serial Printer* 8Outputs*
8Outputs*
CPA6.OM Unit*
CPA6.OM Unit*
Other outputs:
Wlk Test, Tamp, Aux, Relay,
Sw12, Strobe
12V supply Loudspeaker
Drive LSD1*
Three Outputs
NODE
UNIT
F
our Circuits
Network
Cable
*NODE
UNIT PSU
Battery*Relay Unit
RM.3A
Two sets relay
clean contact
Four Circuits
Four Outputs
REM
Mains Input
Bell (SAB1)
Sounder (ES )
PSU Type 150*
Loudspeaker*
(Min impedance 8R
)
One Circuit**
Two Outputs**
Network
Cable
2000
CONTROL
PANEL
To Epson*
Printer
Network
Cable
*=Option
** = Other Circuits & Outputs
used for PSU monitoring
and relay drive.
Ward Control Unit option not shown
C
TS
1
Figure 2. TS2000 System Options - Schematic

Equipment
System Specification
Supply Voltage: 240V + or - 10% 30W 50 Hz
Battery: 12V 6Ah
Zones: 128 maximum
Outputs: 128 remote 8 local maximum
Unit Dimensions: CP L 395 x W 280 x D 100mm
(boxed) NU/WCU L 145 x W 85 x D 50mm
REM L 220 x W 145 x D 40mm
Unit Weights: CP 4 kg
NU/WCU 220 g
REM 430 g
Environment: 0 - 40°C 95% RH n.c.
Control Panel (CP)
The CP comprises electronic units inside a white
polycarbonate lid and a steel base which are factory
assembled to hinge on the left but which may be
reversed if required.
The Base Unit contains the mains input terminals and a
mains transformer. Space is provided for a battery and
also for a Digital Communicator. Cable entry points are
provided as follows:
1. Four 20mm knockouts top and bottom;
2. Two Holes for plastic trunking fitted with plastic inserts
top and bottom;
3. 13mm round knockouts fitted in the plastic inserts;
4. Four 20 mm round holes in the back.
The lid unit contains the Main Control printed circuit
board (pcb) and the Power Supply pcb which are
secured on posts and on which are fitted terminals for
external connections. Option Boards (SIB and PIB) may
also be fitted to the main board.
Under normal conditions the unit can be positioned at
any location as access will only be required for
maintenance.
Power Supply
The CP is fitted with the system combined Power Supply
andBatteryChargerUnitandabatterywhichwillprovide
power during a mains failure. Power arrangements are
as follows:
1Mains input 240V +/- 10%
2Battery 12V 6Ah Sealed Lead Acid rechargeable
type which is normally float charged at about 13.6V;
3. System regulated supply 12V with a maximum
output of 1.5A. The internal supply is load
protected and the external supply fused;
4. System internal 5V supply;
5. Standby operation during a mains failure depends
upon battery size and the size of the system.
Current consumption may be calculated as
follows:
(a) CP: normal 150mA; alarm 500mA;
(b) Each NU (with 4 circuits connected): normal
33mA;
(c) Each REM (with 4 circuits connected): normal
33mA;
(d) Each NU/REM in alarm - load depends upon
outputs used;
6Power supply fault monitoring is for loss of mains
supply, low system supply voltage and low battery
voltage;
7Fuses are fitted on the PSU as follows:
(a) F1: 1A QB for low voltage a.c. input;
(b) F2: 2A QB for 12V dc external output;
8In-line Fuseholder: 1A QB for Network 12V supply;
9A 1A fused terminal block is fitted for the mains
input.
TS2000 6 of 20 496529 Issue A
TS2000

Node Unit (NU)
The NU comprises a small two part polycarbonate case
containing a single pcb on which are terminal blocks.
The unit is connected to the control network and is a
control and connecting device for four circuits and four
programmable outputs. It also contains a sounder
output and a sounder mute output. It has no external
controls hence it may be positioned at any convenient
location as access is normally only required for
maintenance. The unit is surface mounted and has
cable entry points in the base top and bottom.
Remote Keypad Node Unit (REM)
The REM comprises a small two part polycarbonate
case containing a pcb and the system controls
consisting of:
1. A 15 key tactile keypad for entering data and
programmingthesystem.When inusethekeypadis
illuminated;
2. A liquid crystal display (LCD) of two lines of 20
characters each which provides system status
information and gives directions when
programming the system.
The unit is connected to the control network and is a
control and connecting device for four circuits and four
programmable outputs. The base contains a terminal
block for all external connections and the unit is fitted
with an internal sounder which provides local alarms
and system status sounds. The unit is surface mounted
andhascableentrypointsinthebaseonallfoursides.
The REM’s are used to control and programme the
system hence they must be positioned at suitable
control positions with easy access.
Ward Control Unit (WCU)
The WCU comprises the same case as the NU and
contains a single pcb on which are terminal blocks. If
fitted the unit acts as a control and interface device to
allow a designated Ward to be Set and Unset using its
own dedicated Exit and Entry route and units. The WCU
maybepositionedat anylocationnormallyadjacentto
its Exit/Entry devices and to its controlling REM or NU. The
unitissurfacemountedandhascableentrypointsinthe
basetopandbottom. Itcontainscontrols foritsWardfor
settingtheentrytime,exittimeandsettlingtimeandlinks
to select the type of exit procedure.
System Control Network
The CP supplies power to and monitors all the
connected NU and REM via a six or eight wire Control
Network. Each connected unit is ’daisy chained’ to the
Network and the maximum permitted distance
betweenunitsis100mbutthefurthestunitinafullsystem
is limited to a total cable length of 1 km from the CP.
496529 Issue A 7 of 20 TS2000
TS2000
Ward
Control
Unit
Loudspeaker
REM
or
NU
12V Supply Exit Terminate (ET Con)
Access (Acc Con)
Last Exit/Entry(LX Con)
Ward Control Outputs:
Ward Set Fail (A)
Ward Exit (B)
Ward Set (C)
Ward Alarm (D)
Ward Control Circuits
Ward Control (A)
Last Exit Out (B)
Access Out ( C)
Network
Network
Figure 3. Ward Control Unit Schematic

TS2000
TS2000 8 of 20 496529 Issue A
Connect to Control Network
See Fig 6
.
For Mimic. Connect to
CPA6.OM module.
For SAB Tamper.
Link to 0V if not used
Relay contacts are
shown in the
de-energised state.
Alarm relay is normally
energised and is
de-energised at alarm.
Connect
to PIR if
required.
12V supply
present when
system is set
Connect to 3W strobe.
Output will sink up to 250mA
Connect other side to +12V
Connect J3 to JP6 on
Main Board
Fused (F2)
Auxiliary Output From Internal
SLA Battery
Fuseholder fitted with
1A QB fuse for Network
Power Figure 5. Control Panel Power Supply Unit - Connections
(to the right of the main panel terminals)
Power Supply to
Network ONLY
Fuse F1 on the main board
is not fitted.
INT
+5V
Do not use
INT
0V INT
+12V EXT
0V EXT
12V BAT
-ve BAT
+ve
+12V
0V
STRB
WLK TST
NC
C
RELAY
NO
DAT
CLK
LAT
TAMP
DOWN
+DOWN
-DIR
+
DIR
-
SW 12
POWER
INPUT
0V
+12V
Figure 4. Control Panel Main Board - Connections
+12V OV

TS2000
496529 Issue A 9 of 20 TS2000
Use for Network
power to NU and
REM only
Cable 6 or 8 core 7/0.2mm
Maximum length 100m between each unit.
Using 8 core cable will allow the Network
power supplies to be kept separate.
NOTE
It is essential that the connectors shown are
correct and that no cross-overs occur.
Incorrect connections may damage the equipment
and or cause intermittent malfunctions.
Control
Panel +12V
0V
Down +
Down -
Dir +
Dir -
+12V
0v
MAINS
Node or REM
Up+
UP -
Dir +
Dir-
+12V
0V
Dn +
Dn -
Node or REM
Up+
UP -
Dir +
Dir-
+12V
0V
Up+
UP -
Dir +
Dir-
+12V
0V
Dn +
Dn -
Dn +
Dn -
Continue to next unit
Connect PSU where
required
Node or REM
When using 8 core cable use
the two spare cores for non
network power supplies
If required extra PSU should
be connected like this to
ensure that the supplies are
not paralleled
Power Supply Unit
with standby battery.
12V 1.5A o/p
MAINS
NOTE:AllPSUsmusthavethesamesizebattery
+12V 0V
0V
+12V
Figure 6. TS2000 Network Connections

TS2000
TS2000 10 of 20 496529 Issue A
OUT D
OUT C
OUT B
OUT A
I/P C
+
I/P A
+
I/P B
+
I/P D
+
0V
+12V
DIRECTION -
DIRECTION +
DATA UP -
DATA UP +
DATA DOWN -
DATA DOWN +
Connect to CP (Fig 4)
or to previous unit (Down)
Connect to next unit (Up)
Connect to CP (Fig 4)
or previous unit and to
next unit
OutputsD&Csink100mA
Outputs A & B source 100 mA
Circuit C
Circuit A
Circuit B
Circuit D
MUTE
SOUND
C+
I/P C
D+
I/P D
O/P A
O/P B
UP -
UP +
DOWN -
DOWN +
B+
I/P B
A+
I/P A
O/P D
O/P C
+DIR
-DIR
0v
+12V
SPARE 1
SPARE 2
CONNECT TO
NEXT UNIT (Up)
CONNECTTOCP(FIG4)
OR TO PREVIOUS UNIT (DOWN
)
OUTPUT A
OUTPUT B
SOURCE
12V 100mA
CIRCUIT D
CIRCUIT C
TO LSD1 FOR SPEAKER DEVICE
NOT USED
CIRCUIT B
CIRCUIT A
OUTPUT D SINK 100mA
OUTPUT C SINK 100mA
C
ONNECT TO CP (FIG 4)
O
R PREVIOUS UNIT AND TO NEXT UNIT SPARES ARE NOT CONNECTED INTERNALLY
Connector JP
Ribbon cable to
REM pcb
1
Figure 8. TS2000 Remote Keypad Node - Connections
Figure 7 TS2000 Node Unit - Connections

TS2000
496529 Issue A 11 of 20 TS2000
Settle
RV
SPKR
ACCESS
OUT
LX
OUT
WARD
CONTROL
0V
+12V
WARD SET
WARD EXIT
SET FAIL
WARD ALARM
To nc contacts of
Access device*
To nc contacts of
Last Exit device
To nc contacts of
Exit Terminator*
To NU/REM o/p C
To NU/REM o/p B
To NU/REM o/p A
To NU/REM o/p D
* = options Power supply must be sufficient
topowertheLoudspeaker(1A).
Do not use Network power.
Connect 0V to Network 0V.
12V power
supply input
To NU/REM Cct A.
A+ and I/P A
To NU/REM Cct B.
B+ and I/P B
To NU/REM Cct C.
C+ and I/P C
To Loudspeaker
Connect other side to 0V
Programme Outputs as Ward X Outputs:
A=SetFail C=Set
B=Exit D=Alarm
Programme circuits in ward X
A = Ward Control
B&C=Night
Terminals
WCU
LK LK
Exit Mode Exit
RV Entry RV
Link 1
Link 2 Timed Set
Last Exit Set* Last Exit Set
Exit Terminator Set*
Open Closed
* Only if link 1 is closed
Timers:
RV =EntryTime0-255secs
RV = Exit Time 0 - 255 secs
RV = Exit Settling Time 0 - 40 secs
W.C.U
EXIT
TERMINATE
LAST
EXIT
ACCESS
321
21
1
2
3
Figure 9 TS2000 Ward Control Unit - Connections
Figure 10. Ward Control Unit - Layout and Settings

TS2000
TS2000 12 of 20 496529 Issue A
4k7
Tamper Sw
Detector Sw
Next PIR or Det
EOL Res
2k2
Exit Terminator
n.c. (Or n.o.) Contacts
For n.o contacts set
Inverted Attribute
4k7
2k2
E.O.L. Res
X+
I/P X
To Node/REM
Passive Infra Red
(PIR) Detector
X+
I/P X
To Node/REM
Tamper Sw
Detector Sw
EOL
Res
2k2
Tamper Sw
Detector Sw
Tamper Sw
Detector Sw
+
I/P
To Node/REM
Detection Circuit Connections
D
e
t
ec
t
or
N
o
1
Detector No2
For PSU monitor circuits connect monitor
lines directly to I/P A or B or C or D and leave
the relevant +ve connection open
Output Device
Maximum load
100mA
Output Device
Maximum load
100mA
Switched positive
Switched negative
+12V
Sink O/P
CorD
Source O/P
AorB
To Node/REM
To Node/REM
0V
Red Red Red
2k2 Resistor
Yellow Violet Red
4k7 Resistor
Resistor Colours
Tamper
Switch (nc)
0V
Tamp
Box Tamper Connections
Pro
g
rammable Outputs Connections
4k7 4k7 4k7
Detector No n (<11)
Figure 11. TS2000 Circuit and Output Connections

TS2000
Key Functions
Engineer Reset
1. Enter your engineer’s code default 1234, you are
now in Engineer’s Mode
2. Press 0in quit to unset.
Loading Defaults
1. Power down panel battery and mains, close LK2
2. Power up panel battery and mains
3. Enter 1234 and open LK2
4. The panel is back to Factory Default Programming.
Bell Test/Walk Test
Please refer to page 19
Memory Default Values
WhenaCPisshippedfromthefactorythememorydata
default parameters are set to:
1. Circuits: The Type and Attributes Parameters set will
depend upon the number of circuits detected;
2. Passcodes: Engineer 1234: Master 5678: Others
unspecified;
3. Timers: Exit 25 secs: Exit Settling 5 secs: First Entry 30
secs: Second entry 30 seconds: Bell delay 5 mins:
Bell Duration 20 mins: Comms Delay 1.5 mins: Lights
Off5secs:MainsOff10secs:MenuTimeout30secs:
Double Knock 10 secs.
These values will also be restored if a Factory Restart
occurs.
Control Panel Links
Fuses
496529 Issue A 13 of 20 TS2000
Link Functions
LK1 Open: Printer to monitor Network
activity
Closed: Normal; Printer normal
and responds to keypad
commands
LK2 Open: Normal; On-site restart at
power up
Closed:Factory restart at power
up
LK3 DC3 Monitor; Leave closed
JP5 Normally fitted with links
Remove and fit Engineer’s REM if
required.
JP9 Open: Novram battery isolated
Closed: Normal; Novram battery
connected
JP13 Open: Normal
Closed: Soft reset
Fuse Value Use
PSU F1 1AQB Low voltage
ac input
PSU F2 2A QB 12V external
(auxiliary)
supply
Fuseholder 1A QB Network 12V
supply
Fused terminal
Block 1A Mains input

Define Circuit Text
TS2000
TS2000 14 of 20 496529 Issue A
STEP ACTION DISPLAY REMARKS
1 NO* Press < YES > to
DEFINE CIRCUIT TEXT Press YES to Define Circuit Text from the dictionary. Press NO to go to to Install DC3 menu. Press 0 to quit
2 YES CCT > 001 000 000 000 Press YES to accept displayed data. Press NO to change
it. Enter figures or use arrow keys to enter a new circuit
3 NO CCT 001 > 000 000 000 Text is to be changed. Enter number of the first word of
text (see dictionary) then press YES to accept it
4 123 CCT 001>123 000 000
TEXT First word of text entered. Press YES to accept it
5 YES CCT 001 123 > 000 000
TEXT First word accepted and displayed. Repeat the procedure tor the other two words
6 YES CCT >001 123 456 789
TEXT TEXT TEXT All words entered and accepted. Press YES to go to next circuit or use figures or arrows to select another circuit.
Enter 000 to quit
7000 CCT > 000 NOT VALID
YES to continue Press YES to go to step 1
8YES Press YES to
DEFINE CIRCUIT TEXT Press NO to go to Install DC3 menu. Press YES to repeat this menu. Use arrow keys to step through menus. Press 0
to quit
*from last step of previous Menu

TS2000 Dictionary
TS2000
496529 Issue A 15 of 20 TS2000
001 A 056 CEILING 111 ENTRANCE
002 ABOVE 057 CELL 112 ENTRY
003 ACCESS 058 CELLAR 113 EQUIPMENT
004 ACCOUNTS 059 CENTRAL 114 ESCAPE
005 ADMIN 060 CENTRE 115 EXIT
006 ALARM 061 CHAIR 116 EXPORT
007 ALERT 062 CHANGING 117 EXTERNAL
008 ANNEXE 063 CLASSROOM
009 AREA 064 CLEANERS 118 F
010 ART 065 CLERK 119 FACTORY
011 ASSEMBLY 066 CLERKS 120 FAILURE
012 ASSISTANT 067 COIN 121 FAR
013 AT 068 COLD 122 FEMALE
014 ATTACK 069 COLLECTION 123 FENCE
015 ATTIC 070 COMMUNICATOR 124 FILING
016 AUTOMATIC 071 COMPUTER 125 FIRE
017 AUXILIARY 072 CONFERENCE 126 FIRST
073 CONTAINER 127 FIRST-AID
018 B 074 CONTACT 128 FLAT
019 BACK 075 CONSERVATORY 129 FLOOR
020 BAGGAGE 076 CORNER 130 FOR
021 BAKERY 077 CORRIDOR 131 FOREIGN
022 BALCONY 078 COUNTER 132 FREEZER
023 BALLROOM 079 CUPBOARD 133 FROM
024 BANKING 134 FRONT
025 BAR 080 D
026 BARN 081 DARK-ROOM 135 G
027 BASEMENT 082 DATA 136 GAMES
028 BATHROOM 083 DAY 137 GARAGE
029 BAY 084 DEPARTURE 138 GARDEN
030 BEAM 085 DEPUTY 139 GATE
031 BEDROOM 086 DEPT. 140 GENTS
032 BELL 087 DESIGN 141 GIRLS
033 BELOW 088 DESK 142 GLASS
034 BESIDE 089 DETECTOR 143 GOLD
035 BLOCK 090 DEVELOPMENT 144 GOODS
036 BLUE 091 DEVICE 145 GREEN
037 BOARD 092 DINING 146 GROUND
038 BODY 093 DIRECTOR 147 GROUP
039 BOILER 094 DISPATCH 148 GUARD
040 BOTTOM 095 DOOR 149 GUN
041 BOX 096 DOUBLE 150 GYM
042 BOYS 097 DOWNSTAIRS
043 BRANCH 098 DRAWER 151 H
044 BROWN 099 DRAWING 152 HALL
045 BUILDING 100 DRINKS 153 HANGER
046 BUNKER 101 DRIVE 154 HEAD
047 BY 102 DRUGS 155 HEAT
156 HIGH
048 C 103 E 157 HOME
049 CABINET 104 EAST 158 HOT
050 CALL 105 ELECTRIC 159 HOUSE
051 CANTEEN 106 ELECTRONICS
052 CAR 107 EMERGENCY 160 I
053 CARGO 108 END 161 IN
054 CASH 109 ENGINE 162 INDUSTRIAL
055 CASHIER 110 ENGINEERS 163 INFORMATION

TS2000 Dictionary Cont’d
TS2000
TS2000 16 of 20 496529 Issue A
164 INFRA-RED 217 METER 271 PORCH
165 INSIDE 218 MEZZANINE 272 POST
166 INSTRUCTORS 219 MICROWAVE 273 POWER
167 INTERIOR 220 MIDDLE 274 PRESSURE
168 INTO 221 MILK 275 PRIMARY
169 IRON 222 MINOR 276 PRIME
170 IT 223 MOBILE 277 PRINT
224 MODEL 278 PROCESSING
171 J 225 MONITOR 279 PRODUCTION
172 JANITOR 226 MOULDING 280 PUBLIC
173 JUNIOR 227 MOVEMENT 281 PURCHASING
282 PURPLE
174 K 228 N
175 KEEP 229 NEAR 283 Q
176 KEYPAD 230 NEW 284 QUALITY
177 KITCHEN 231 NEXT 285 QUIET
232 NIGHT
178 L 233 NODE 286 R
179 LAB 234 NURSE 287 RANGE
180 LADIES 235 NURSERY 288 READING
181 LANDING 236 NORTH 289 REAR
182 LAST 290 RECEPTION
183 LAUNDRY 237 O 291 RECORDS
184 LAVATORY 238 OF 292 RED
185 LAWN 239 OFFICE 293 REFECTORY
186 LECTURE 240 OFFICER 294 REPAIR
187 LEFT 241 OIL 295 RESEARCH
188 LEVEL 242 ON 296 REST
189 L.H.S. 243 OPEN 297 RESTAURANT
190 LIBRARY 244 ORANGE 298 REVOLVING
191 LIFT 245 OUT 299 RIGHT
192 LIGHT 246 OUTER 300 R.H.S.
193 LINE 247 OUTSIDE 301 ROLLER
194 LITTLE 302 ROOF
195 LOADING 248 P 303 ROOM
196 LOBBY 249 P.A. BUTTON 304 ROUND
197 LOCK 250 PACKING
198 LOFT 251 PAINT 305 S
199 LORRY 252 PANEL 306 SAFE
200 LOUNGE 253 PANIC 307 SALES
201 LOW 254 PARCEL 308 SCREEN
255 PARK 309 SEA
202 M 256 PARTITION 310 SECURE
203 MACHINE 257 PASSIVE 311 SECRETARIES
204 MAGNETIC 258 PATH 312 SECRETARY
205 MAIN 259 PATIO 313 SECTION
206 MAJOR 260 PENTHOUSE 314 SECURITY
207 MALE 261 PERIMETER 315 SENSOR
208 MAN 262 PERSONNEL 316 SHAFT
209 MANAGER 263 PIR 317 SHED
210 MANAGERS 264 PIR BY 318 SHOP
211 MASTER 265 PIR IN 319 SHOW-ROOM
212 MAT 266 PIR ON 320 SHORT
213 MEDICAL 267 PLANT 321 SHUTTER
214 MEN 268 PLAY 322 SIDE
215 MESS 269 POINT 323 SILENT
216 METAL 270 POOL 324 SILVER

TS2000 Dictionary Cont’d
TS2000
496529 Issue A 17 of 20 TS2000
325 SITE 381 TRAP 431 11
326 SITTING 382 T.V. 432 12
327 SLIDING 383 TWIN 433 13
328 SMOKE 384 TYPE 434 14
329 SOFTWARE 385 TYPING 435 15
330 SOUND 386 TYRE 436 16
331 SOUTH 437 17
332 SPRAY 387 U 438 18
333 SPRING 388 ULTRA-SONIC 439 19
334 SQUARE 389 UNDER 440 2
335 SQUASH 390 UNIT 441 2ND
336 STABLE 391 UP 442 20
337 STAFF 392 UPPER 443 3
338 STAIRS 393 UPSTAIRS 444 3RD
339 STAIRWELL 394 USER 445 4
340 STALLS 395 UTILITY 446 4TH
341 STAND 447 5
342 START 396 V 448 5TH
343 STATION 397 VAN 449 6
344 STOP 398 VAULT 450 6TH
345 STORE 399 VISUAL 451 7
346 STORES 400 VOLTAGE 452 7TH
347 STROBE 453 8
348 STRONG 401 W 454 8TH
349 STUDY 402 WAITING 455 9
350 SUITE 403 WALK 456 9TH
351 SUMMER 404 WALL 457 0
352 SUNDAY 405 WARD 458 !
353 SUPPLY 406 WAREHOUSE 459 &
354 SURGERY 407 WASH 460 .
355 SWIMMING 408 WATER
356 SWITCH 409 WAY
357 SYSTEM 410 W.C.
411 WEAPON
358 T 412 WEEKEND
359 TABLE 413 WEST
360 TALL 414 WINDOW
361 TAMPER 415 WINTER
362 TEA 416 WITH
363 TEACHER 417 WOOD
364 TECHNICAL 418 WORK
365 TECHNICIAN 419 WORKS
366 TELLER 420 WORKSHOP
367 TEN
368 TEST 421 X
369 THE
370 THEATRE 422 Y
371 TICKET 423 YARD
372 TILL 424 YEAR
373 TO 425 YELLOW
374 TOILET
375 TOOL 426 Z
376 TOP 427 ZONE
377 TRACK
378 TRADE 428 1
379 TRAINING 429 IST
380 TRANSPORT 430 10

TS2000
Programmable Ouputs
The programmable outputs from the NU and the REM,
arereferredtoastheNodeOutputsandareactivatedin
response to various conditions or events. They are
programmed to respond to System, Ward or Circuit
activation.
Panel outputs are from the CP and are programmed in
the same way as the Node outputs. Outputs 1 to 8 are
from the Parallel Interface Board, if fitted, and 9 to 16
are for the DC3 or DC3M Digicom if fitted.
The System activated outputs may be allocated to any
Node (NU or REM) output or the Panel (CP) outputs. They
are designated by their function and may be
programmed to be active if required. The following are
available:
(1) Alarm: A system alarm is present;
(2) P. A.: A Personal Attack circuit or a Duress Alarm
has been activated;
(3) Set: The system is Set;
(4) Fire: A Fire circuit has been activated;
(5) Medical: A Medical circuit has been activated;
(6) Tamper: A Tamper alarm is present;
(7) Aux: An Auxiliary circuit has been activated;
(8) Set Fail: An attempt to set the system has failed;
(9) Site Engr: The Engineer’s passcode has been
entered. The output will remain active until a
User passcode is entered;
(10) Lock-Alarm: The system has not been Set before
the start of the Time Lock period;
(11) Test-Fail: A test failure has occurred;
(12) AC Alarm: The mains supply to the PSU has not
been present for the mains fail time period;
(13) AC Off: The mains supply to the PSU is not
present or there is no 12V output;
(14) Batt Fault: During the PSU test or while the mains
is off the PSU Battery voltage is low.
(15) Bell: The CP bell output is activated;
(16) Strobe: The CP strobe output is activated;
(17) Switch +12: The system is Set and is not in
alarm;
(18) Walk Test +: A Walk Test is in progress (use output
A or B);
(19) Walk Test –: AWalk Test is in progress (use output
C or D);
(20) Line Fault: A Digicom telephone line fault is
present;
(21) Time Switch: The programmed Time Switch is
active;
(22) Time Locked: The system has been Time Locked
and cannot be unset;
(23) Entry Mode: Entry mode has been initiated;
(24) 2nd Entry: The first Entry time has timed out
before a passcode entry
(25) Exit Mode: System Exit procedure has been
initiated;
(26) Exit Setting: Final Exit setting is in progress
(27) Exit Error: An error occurred during the exit
procedure and the system cannot set
(28) Lock Alert: The programmed Time Lock period is
about to start;
(29) Fire/Viper: Will provide 12V (100mA source) to
devices which latch when activated and which
are unlatched when power is removed. The
output is removed for about 3 seconds when
unsetting the system after an alarm at the
second passcode entry;
(30) PSU Test: Connected to remote PSU to initiate a
battery test;
CAUTION: It is essential to ensure that the correct
outputs that will source (supply) or sink (accept) current
areselectedtomatch thefunctionrequired.
Menus Listing in Sequence
NOTES:
Users will enter menus at Menu 1
Engineer will enter menus at Menu 15
User Level 5 (Standard W) can only set and unset
designated wards
InstantaccesstoMenusfromakeyboardnumber
entry applies to Menus 1 to 9 only
Menu 2 is only available if a Ward is Set;
Menu 7 is only available if there are circuits with
attribute omit
Menu 9 is only available if a printer is connected
or the SIB is fitted
Menu 17 is only available if a Ward is defined
Menu 24 is only available if a DC3(M) is fitted
Menu 25 is only available if Engineer Reset is
programmed and a reset is required
(Passcode) Levels:
1 Engineer
2 Master
3 Manager
4 Standard S
5 Standard W
6 Restricted
TS2000 18 of 20 496529 Issue A

TS2000
496529 Issue A 19 of 20 TS2000
Menu No Menu Passcode Level
1 Start Set Sequence 1, 2, 3, 4, 5, 6
User 2 Unset Wards 1, 2, 3, 4, 5, 6
3 View Circuits 1, 2, 3, 4, 5, 6
4 View Event Log 1, 2, 3
5 Select Walk Test 1, 2, 3, 4, 5
6 Select Bell Test 1, 2, 3, 4, 5
7 Omit/Enable Circuit 1, 2, 3
8 Use Chime Facility 1, 2, 3
9 Use the Printer 1, 2, 3,
10 Alter Clock 1, 2
11 Alter Passcode 1, 3, 4, 5, 6
12 Define Users 2
13 Alter Time Switch 1, 2
14 Alter Time Lock 1, 2
Eng’r 15 Define Circuits 1
16 Define Outputs 1
17 Review Wards 1
18 Define Ward Alarms 1
19 Define Timers 1
20 Define Panel Modes 1
21 Use Test Options 1
22 User Network Options 1
23 Define Circuit Text 1, 2
24 Install DC3 1,
25 Reset by Remote 2
Menus Listing in Sequence

TS2000 20 of 20 496529 Issue A
TS2000
This page intentionally left blank
