SECURITY HUB STARTER KIT User manual

STARTER KIT
Quick Start Guide
1. Take the devices out of the box and check the package contents according to the data
sheet.
2. Open the controller cover
9. Download and install «Security Hub»
application on your mobile device
a
b
* . The controller has 2 Internet communication channels: primary LAN and backup GSM
One communication channel is enough for operation.
Connecting Controller
A
Close
Open
7. Connect the
controller to the
Internet using a patch
cord*
8. Plug the controller into
220V/AC outlet using
5V/DC power adaptor
(included)
4. Insert one or two SIM
cards
5V
1A
OPEN
3. Write down controller's serial number (a set of numbers placed under the bar code
on the PCB).
5. Install and connect
backup battery to the
PCB
Revision SH-komplekt_v2_1_instr
1
карта microSIM
карта microSIM
6. Close the
cover

+
Registration. Controller Setup
Run the application. To register an account, click the REGISTRATION button and follow
the instructions on the mobile application screen.
After successful registration, set up the controller, following the instructions of the
controller's setup wizard.**
Adding And Installing Sensors
1. Unpack the sensor.
In additional sensors, purchased separately from the Security Hub kit, put the jumper on the Rmod
plug .
In the Astra-361 RK water leakage sensor and the Astra-RI-M RPDK remote control keyfob (not
included), set the mode of radio Mode 2 and frequency Letter 1 using DIP switches in accordance
with the sensor's instruction manual
B
C
2. Open the sensor housing, ensure that jumpers and switches are set correctly (highlighted in
black in the figure)*
To add more controllers, use the button in the OBJECTS tab of the
MAIN page. +
*
*
2
Rmod
Lit
Lit
Rmod
12
DIP switch

3. Click the ADD SENSOR button and follow the instructions in the setup wizard.*
(certain atWhen adding a sensor, select a partition area the protected facility) to which the
sensor will be assigned, or create a new using the ADD command. For partition PARTITION
sensors of different types , fire, temperature, water leakage) create the appropriate intrusion
partitions.
After completing the setup wizard, adding new sensors is performed by
pressing button in the PARITIONS tab of the Partitions window or in
the SENSORS tab of the selected partition window.
+
*
3
Door opening sensor Astra-3321 Motion sensor Astra-5121
Not recommended places for the Astra-5121 motion sensor installation
4. :Mount sensors observing the following rules
Sensor
Door
Control magnet
Side view
2,4-2,5 m
5. Bring the sensor to selected place, press the tamper spring, make sure that the sensor status
signal is displayed in the mobile application.

Made in Russia, Kazan, [email protected]
9. Reinstall sensor PCB. Close the cover, check the system operation
(test pass, door opening).
Additional sensors can be purchased on the
website www.security-hub.ru/en
6. .Remove sensor PCB from its base by bending the catches off
7. Attach the door opening sensor
base to the door frame, and the
control magnet to the door leaf. Use a
dielectric gasket when installing the
sensor base on a metal surface
8. Attach the motion sensor bracket to the
wall. Attach the base of the sensor to
the bracket with a screw
Catch
40°
Ledges
Ball
Groove
Lock Screw
Screw 3х12
Connecting iVideon Video Cameras
D
5. Setup the camera
Enter Cameras
menu
4. Log in
1. Register your Wi-Fi camera on the iVideon cloud in accordance with its user manual.
2. Enable the Events function in your personal account
3.
