Securitytronix ST-HDoC User manual

ST-HDoC / ST-HDoC-MM
CVI/TVI/AHD & ANALOG TEST METER
WITH OPTIONAL SDI & DIGITAL MULTIMETER
(Optional Features: ST-HDoC-MM)
User Manual V 1.2
www.nacebrands.com www.securitytronix.com

Thank you for purchasing the ST-HDoC Analog and HD camera test monitor!
To use the ST-HDoC safely, please read the Safety Information Carefully.
The manual should be kept with the ST-HDoC for reference.
Keep the serial number label for after-sale service within the warranty period. Please see the last page of the
manual for warranty information.
Batteries come disconnected to ensure they do not drain during shipment. Please connect the battery prior to
powering on the ST-HDoC
If there is any question or problem while using the ST-HDoC HD tester, please contact our SecurityTronix
technical support department at 1-800-688-9282, option 3, and then option 2.
Visit our website http://www.securitytronix.com for additional information.

Table of Contents
1.Safety information ...............................................................................Error! Bookmark not defined.
2.Introduction.......................................................................................................................................... 1
2.1 General................................................................................................................................... 1
2.2 Features.................................................................................................................................. 2
2.3 Function..................................................................................................................................3
2.4 Packing List............................................................................................................................ 7
2.5 Front Panel ............................................................................................................................. 8
3.Operation...........................................................................................Error! Bookmark not defined.3
3.1 Installing the Battery.............................................................................................................12
3.2 Instrument connection ..........................................................................................................13
3.3 OSD Menu............................................................................................................................ 13
3.3.1 PTZ controller.........................................................................................................14
3.3.2 Color bar generator.................................................................................................. 17
3.3.3 Video level meter (Optional) *................................................................................18
3.3.4 Video setting........................................................................................................... 18
3.3.5 PTZ address search.................................................................................................. 19
3.3.6 CVI camera test (Optional) * ................................................................................20
3.3.7 TVI camera test (Optional) *................................................................................. 21
3.3.8 AHD camera test (Optional) *...............................................................................21
3.3.9 SDI camera test (Optional) *.....................................................................................25
3.3.10 Cable tracer（Optional）*........................................................................................22
3.3.11 Cable test（Optional）*.............................................................................................22
3.3.12 Digital multimeter （Optional）*........................................................................ 23
3.3.13 Optical power meter（Optional）*.......................................................................31
3.3.14 Visual fault locator（Optional）*......................................................................... 31
3.3.15 TDR tester（Optional）*......................................................................................31
3.3.16 Data monitor..........................................................................................................31
3.3.17Time setting............................................................................................................31
3.3.18 Device setting........................................................................................................ 32
3.4 DC12V 1A power output......................................................................................................33
3.5 Audio input test .................................................................................................................... 34

3.6 LED lamp............................................................................................................................. 34
4.Specifications..................................................................................................................................... 34
4.1 General Specifications..........................................................................................................34
4.2 Multimeter specifications ..................................................................................................... 37

ST-HDoC / ST-HDoC-MM
1
1. Safety information
◆The ST-HDoC/ ST-HDoC-MM is intended for use in compliance with applicable codes and
laws.
◆Do not expose to moisture.
◆Do not drop.
◆The tester should not be charged over 8 hours.
◆The tester should not be used in an environment with any flammable gas or chemicals.
◆Do not disassemble the tester except to change the battery.
◆Don’t use any chemical cleaning products to clean the test meter. Use a dry cloth.
1.1 Digital Multi-meter Safety
◆Prior to taking any measurements, be sure you are using the correct range, function and input
jack. Red is positive, black is negative.
◆Never exceed the protection limit value for each range of measurement.
◆While measuring a live circuit, do not touch any unused terminals.
◆If the value to be measured is unknown while using the manual range, set the range selector to
the highest position.
◆Always be careful when working with AC or DC voltages since you could be injured or killed
by voltage going through your body. Keep your fingers behind the probe barriers while
measuring. Do not touch the metal probes while taking any measurements.
◆Never perform any capacitance measurements unless the capacitor has been fully discharged.
2. Introduction
2.1 General
The 3.5 inch touch screen HD camera monitor and tester, is designed for maintenance and installation
of HD over Coax and analog cameras as well as other security equipment. The 480X320 resolution
enables it to display HD cameras and analog cameras in high resolution. The unit supports many HD
over Coax technologies including HDCVI, TVI, and AHD.

ST-HDoC / ST-HDoC-MM
2
The tester is a great compact tool for performing routine maintenance as well as new HD installations.
Test LAN cables for proper connection termination. Other functions include, LED Flashlight, 12VDC
2A power output and much more. Its portability, user-friendly design and many other functions make
the ST-HDoC an essential tool for all installers or technicians.
2.2 Features
Easy to operate 3.5” 480X320 TFT-LCD.
LED Flashlight.
User-defined shortcut keys（F1 and F2）
LCD screen with adjustable brightness/contrast/color saturation.
Automatically adapting NTSC/PAL input.
Enhanced color bar generator, new added gray-scale image test. PAL/NTSC multi-system
color bar video generator (Eight-system switchable, transmit/receive eight-system color
bar).
HD CVI camera image display, coaxial PTZ control and call up the camera OSD menu.
HD TVI camera image display, coaxial PTZ control and call up the camera OSD menu.
AHD camera image display, coaxial PTZ control and call up the camera OSD menu.
TDR cable test, test cable’s open circuit (breakpoint) and short circuit location.
PTZ address scanning for locating PTZ camera Address, Baud and Protocol.
Network cable tester: Tests LAN cable sequence of wires.
Support RS485, Baud Rate adjustable from 600 ～115200bps.
Supports more than thirty PTZ protocols, Such as PELCO-P, PELCO-D, SAMSUNG.
PTZ protocol analysis: Control commands are displayed to check RS485 Transmission.

ST-HDoC / ST-HDoC-MM
3
PTZ control: Pan, tilt & zoom, focus adjustment, IRIS Open/Close and set preset
positions.
12VDC 1A output power for cameras.
Audio input and output tests. Outputs an audio signal.
Digital multimeter (ST-HDoC-MM)
Lithium Ion Polymer Battery. Remaining battery charge indicator, Lithium Ion Polymer
battery can last up to 11 hours of normal use after charging for 4 -5 hours.
2.3 Function
2.3.1 Video signal test
The new ST-HDoC tester with 3.5 inch LCD-TFT, 480（RGB）x320 resolution, allows the user to view
the images from sufficient angles. The display is suitable for outdoor installation and maintenance
work.
2.3.2 Video level meter (CVBS)
Performs NTSC and PAL video amplitude signal measurements for PEAK to PEAK, SYNC level,
COLOR BURST, and CHROMA level
Video signal PEAK to PEAK level:
For NTSC format, the video signal level is 140±15IRE
For PAL format, the video signal level is 1000±200mV
If the level is too low, it will cause the image to lose quality and limit the distance it will travel over a
coaxial cable. If the level is too high, it will lead to a washed out image.
SYNC level: Testing the amplitude of the video sync pulse to verify if the video level is correct.
For NTSC format, the SYNC level is 40 ± 5IRE
For PAL format, the SYNC level is 300 ± 35mV
If the level is too low, it will cause the image to not frame out properly. If the level is too high, it will
lead to poor video quality.

ST-HDoC / ST-HDoC-MM
4
COLOR BURST level: Testing the color burst level will determine if the burst signal is sufficient to
trigger the displays color producing circuit. Burst will diminish in amplitude over longer cable runs and
can fall below the threshold for the video display to show a color image.
For NTSC format, the chroma standard level is 40 IRE
For PAL format, the chroma standard level is 280mV
If the chroma level is too low, the color will not be as deep, and some details of the image will get
washed out. If the chroma level is too high, there may be spots on the image. If the coaxial cable is too
long, it will reduce the chroma level.
2.3.3 PTZ controller
Displays and allows for analysis of analog video and controls pan/tilt/zoom functions of an analog PTZ
camera. For PTZ testing, setup the controlling parameters from the meter to match those of the camera:
e.g. PTZ protocol (PELCO-D, etc.), communication port (RS-485, etc.), baud rate, PTZ camera ID and
pan/tilt speed.
2.3.4 Enhanced Color bar generator
The newly added gray-scale image test, allows the tester to test the monitor for optimal gray-scale
performance. The tester sends out color bars via its BNC output to the monitor. This is used to test for a
problem in the cable going from the camera back to the monitoring area
2.3.5 DC12V 1A output power
The unit can power a camera with 12V DC (1A) power output from the tester. It is helpful for
determining powerline issues or if power supply box is malfunctioning.
2.3.6 Audio testing
Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable.
Consult your local laws and regulations on recording audio and using audio devices. In the
United States of America and all individual states thereof, there are federal and state laws that
limit your ability to monitor and / or record audio. These laws expose you to the risk of criminal
prosecution and potentially give an injured party a civil claim for money damages against you.
2.3.7 Cable tester
Connect a LAN cable from the ST-HDoC/MM unit to the included blue remote cable tester. The unit
will test for connection status, cable type and the status of each wires conductivity will be displayed.

ST-HDoC / ST-HDoC-MM
5
2.3.8 PTZ controller
Test the PTZ control command data to diagnose any errors or to ensure there is a sufficient
RS485/RS232 data transmission. The unit receives the control protocol code (PELCO-D, etc.) from a
PTZ keyboard or a DVR with a RS485/RS232 interface.
The unit will display 16 hexadecimal codes such as:
PELCO-P：A0 00（Add）xx xxxxxx AF xx
PELCO-D：FF 01（Add）xx xxxxxxxx
2.3.9 PTZ address scanning
Search the ID/ Protocol/ Baudrate of a PTZ camera being tested.
2.3.10 CVI camera test
This displays an HD CVI camera image. It supports 720p @ 25/30/50/60fps & 1080p @ 25/30fps. The
features are live video and coaxial PTZ control including calling up the camera’s OSD menu.
2.3.11 TVI camera test
This displays an HD TVI camera image. It supports 720p @ 25/30/50/60fps & 1080p @ 25/30fps. The
features are live video and coaxial PTZ control including calling up the camera’s OSD menu.
2.3.12 AHD camera test
This displays an HD TVI camera image. It supports 720p @ 25/30fps & 1080p @ 25/30fps. The
features are live video and coaxial PTZ control including calling up the camera’s OSD menu.
2.3.13 SDI camera test (ST-HDoC-MM only)
This displays an HD SDI camera image. It supports 720p @ 25/30fps & 1080p @ 25/30fps. The
features are live video and coaxial PTZ control including calling up the camera’s OSD menu.

ST-HDoC / ST-HDoC-MM
6
2.3.14 Cable tracer
Cable Tracing is not available with the ST-HDoC series testers.
2.3.15 Digital multimeter (ST-HDoC-MM only)
The ST-HDOC-MM has a highly accurate 33/4 digit (6600) built in digital multi-meter. It is used to
measure AC and DC voltages, current, resistance, continuity, capacitance and diode testing. It can
switch between auto and manual measuring ranges.
2.3.16 Optical Power Meter
Optical power testing is not available with the ST-HDoC series testers.
2.3.17 TDR open circuit
TDR testing is not available with the ST-HDoC series testers.
2.3.18 Visual fault locator
Visual Fault Locator is not available with the ST-HDoC series testers.
2.3.19 LED lamp
Press the LED On/Off button to use the LED flashlight.
2.3.20 F1, F2 User-defined shortcut keys
The user-defined shortcut key is designed for improving operator efficiency. Once configured, the F
keys can be used to quickly call up functions that are most commonly used.

ST-HDoC / ST-HDoC-MM
7
2.4 Packing List
1) ST-HDoC video monitor
2) 5VDC 1.5A power adapter（with USB cable）
3) No.255 cable tester
4) Lithium Ion Polymer Battery（3.7V DC 3000mAh ）(typically not plugged in)
5) 3 foot BNC test cable
6) 18 inch RS485 test cable with alligator clips
7) Multi meter test leads (red and black) (only for the ST-HDoC-MM model)
8) 3 foot camera powering cable
9) 18 inch 3.5mm audio microphone or speaker cable with alligator clips
10) Carrying case and hanging strap with front accessory pouch
11) User’s manual

ST-HDoC / ST-HDoC-MM
8
2.5 Front Panel

ST-HDoC / ST-HDoC-MM
9
1
OSD menu
2
The charge indicator: it glows red while the battery is being charged. As the
charging is complete, the indicator turns off automatically
3
The data-transmission indicator: it glows red while data is being transmitted
4
The data-reception indicator: it glows red while data is being received
5
The power indicator: it glows green while the tester is powered on
6
Set key, press to enter sub-menu
7
Press for more than 2 seconds to turn off the device ,quick press to turn on or off the
menu display
8
Confirm/Open : Confirm the setting of a parameter; open or enlarge the aperture
9
Return/Close : Return or cancel while setting parameters, close or decrease the
aperture
10
Upward: Select the item which will be set or add the value of the parameter. Tilt the
PTZ upward
11
User-defined key（can be customized for quick access functions)
12
LED Lamp
13
Rightward, Enter the sub-menu or select the parameter whose value will be changed.
Add the value of the parameter. Pan the PTZ right
14
Digital multimeter: voltage, current, resistance and capacitance measuring,
continuity testing, diode testing (ST-HDoC-MM only)
15
Downward: Select the item which will be set or reduce the value of the parameter.
Tilt the PTZ downward
16
Leftward: Enter the sub-menu or select the parameter whose value will be changed.
Reduce the value of the parameter. Pan the PTZ left
17
Color bar generator shortcut key
18
PTZ control shortcut key
19
AHD,CVI or TVI shortcut key (Customizable) *

ST-HDoC / ST-HDoC-MM
10
20
WIDE: zoom out the image
21
Near focus: Focus the image near
22
Far focus: Focus the image far
23
Menu key
24
TELE: zoom in the image

ST-HDoC / ST-HDoC-MM
11
25
Analog / HD TVI/CVI/AHD signal input (BNC interface)
26
Video output (BNC output interface): CVBS output
27
Optical power meter interface (Optional) */Visual fault locator interface (Optional) *
28
TDR cable open circuit and short circuit test (Optional) *
29
12V DC 1A output
30
SDI test port (BNC interface) ( Optional) *
31
LED lamp
32
RS485Interface: RS485 communication for PTZ
33
Network cable /Telephone cable test port
34
Device charging port (Mini USB)
35
No function
36
No function
37
Audio input: for testing audio pickup equipment
38
Reset the device to factory original settings

ST-HDoC / ST-HDoC-MM
12
3. Operation
3.1 Installing the Battery
The tester has a built-in lithium ion polymer rechargeable battery. Prior to the use of the unit, the
battery cable connection behind the battery door needs to be connected and the unit fully
charged for no more than 8 hours prior to use.
Pressing key for 2 seconds can power on or off the tester.
Notice：Please use the original power adapter for the device!
At the first time of use, the batteries should be completely exhausted and then recharged for 4 or
5 hours.
The Charge Indicator lights red when charging the battery, and turns off automatically
when charging is complete.
Notice: When the Charge Indicator turns off, the battery is approximately 90%
charged. Do not charge for more than one hour after the indicator has turned off.
Press the RESET key at the left of the meter to restore the default settings if the tester
works abnormally.
Multi meter: the red and black multi meter pins must be inserted in the correct port.

ST-HDoC / ST-HDoC-MM
13
3.2 Instrument connection
⑴.The camera or speed dome to be tested should be connected to the “VIDEO IN” port.
⑵.The ST-HDoC “VIDEO OUT” interface is for connecting to an auxiliary BNC monitor.
⑶.Connect the camera or the speed dome’s RS485 controller cable to the tester’s RS485 interface
(Note positive and negative connection of the cable).
3.3 OSD Menu
Press the key to turn the tester on.
Press the key again to turn off, you can also set
the meter to automatically power off.
Enter the menu ,choose one function to enter , then short
press the key,
While in the main menu, pressing quickly switches to the different menu lists.
While in the main menu, continuously press the key to select different function. Once a
selection is made, press the key to enter.

ST-HDoC / ST-HDoC-MM
14
Press the key to switch between menu pages, the square icon at the bottom
of the screen indicates the different pages of apps available.
Press the key to select the different function icon, then press the key to enter
First page menu Second page menu
3.3.1 PTZ controller
Connect an analog PTZ camera to the tester, and open the PTZ controller app. From this menu, you
can view the video stream as well as control PTZ movements. From within the PTZ app, you can also
configure parameters such as: Protocol, Baud Rate, Address,
Pan/Tilt speed, Preset call and recall.
PTZ controller parameter settings
In the “PTZ CONTROLLER ”app（as shown in above photo）, press the key to enter the
parameter settings .
Press the key , to move the yellow cursor to select a parameter.
Press the key or , to change the parameter values. Then press the key to save and
return.

ST-HDoC / ST-HDoC-MM
15
A. Protocol
Use the up and down arrow keys to move the yellow cursor to
the “protocol ”function, from here, you can set the
corresponding Protocol. The tester supports more than 30
different protocols, including Pelco, Samsung, Bosch, etc.
B. Port
The default port for the ST-HDoC is set to RS485 for analog PTZ cameras, with UTC protocols being
embedded in the corresponding HDoC app.
C. Baud
Move the yellow cursor to “Baud” function, select the baud rate according to baud rate of the PTZ
camera.(600/1200/2400/4800/9600/19200/57600/115200bps)
D. Address
Set the ID according the ID of PTZ camera (0~254), the address settings must be consistent with that of
the PTZ camera being tested.
E. Pan speed: Set the pan speed of the PTZ camera (0~63)
F. Tilt speed: Set the tilt speed of PTZ the camera (0~63)
G. Set preset position (Set PS)
Move the yellow cursor to “SET PS”, to save the preset position number (1~128), Press the key
To accelerate the value change, then press the key to save.
H. Call the preset position (Go PS)
Move the yellow cursor to “Set PS”, then enter the desired preset position (1~128),
Press the key or to accelerate the value changing.
Press the key to complete preset position settings.
*Some PTZ cameras require special preset numbers to call specific menus/ functions.
Check and set the protocol, address, interface and baud rate, that they are the same as the dome camera,
then you can test and control the PTZ camera.

ST-HDoC / ST-HDoC-MM
16
Press the key to control the PTZ direction of rotation
Press the key or to switch on or turn off the aperture.
Press the key or , adjust the focus manually
Press the key or , manually adjust the zoom
1) Set and go PS
Set PS:
A. Use the PTZ controls to move the camera to the desired position.
B. Press the key to enter the PTZ controller submenu. Press the key to move the
yellow cursor to “Set PS”, Press the key to select the desired preset position number.
Then Press the key to save the preset position.
Go PS:
Call the preset position. (1~128) The PTZ camera will go to the desired preset position.
In “PTZ Controller”, Press the key to enter the PTZ controller submenu. Press the
key, to move the yellow cursor to “GO PS”. Press the key to select the desired preset number.
Then press the key to call the preset position.
The camera moves to the preset position immediately, Lens zoom, focus and iris is will automatically
change to the preset parameters provided the camera is equipped with these features.
Tips：Preset position setting is saved in the PTZ camera’s built in memory.
2) Menu of dome
The PTZ camera manufacturers may have different procedures for accessing the PTZ camera menu.
Please refer to the camera manual for specific instructions to access the PTZ menu. For example if the
camera menu is accessed by CALLING PRESET 64, use the steps below.
a. Press the key to enter PTZ controller submenu
b. Press the key , select preset position 64
c. Press the key to enter the main menu of the PTZ camera’s OSD.
