SeeEyes SC-IPT07P User manual
Release Version 1.1
1Channel IP Over Coaxial Transmission Solution
SC-IPT07P, SC-IPR07P
User’s Manual
SC-IPR07P
(1CH Receiver)
SC-IPT07P
(1CH Transmitter)
Release Version 1.1
1
Precaution and Safety Guidelines
The content of this guideline is to protect the safety of users and prevent property damage.
Be sure to read this user’s manual thoroughly and use the device correctly.
Warning (If you do not keep any of the below guidelines, you may get seriously injured or
cause somebody’s death.)
■Be sure to install the product after unplugging power cord. Also, do not use several
power plugs at the same time.
- It may cause abnormal heat, fire and electric shock.
■Do not leave the device at any place that water falls or splashes. Also, do not put anything
full of water such as a flower vase on the device.
- It may cause malfunction or fire if liquid goes into the device.
■Do not bend the power cord by excessive force. Make sure the power cord is not crushed by
heavy things.
- It may cause fire.
■Do not open the lid arbitrarily as this device has high voltage part inside. Never disassemble,
repair or modify it.
- By abnormal working, it may cause fire, electric shock and personal injury.
■Do not install this product in places with high humidity, dust, or soot.
- It may cause electric shock and fire.
■Do not tug at the power cord section or unplug the power plug with wet hands. If the power
cord is loose, do not plug in.
- There may be a risk of fire and electric shock.
■Always keep the location of the appliance clean during or after installation to prevent dust.
Especially when cleaning the device, wipe it with dry towel and do not use water, thinner or
organic solvent.
- It may damage the case of this device, and cause malfunction or electric shock.
■Keep the device in a cool place where doesn’t let direct sunlight. Keep it at a proper
temperature and avoid heating appliances like candle or heater. Also, keep the equipment or
tools away from places where people come and go.
- It may cause fire.
■Pay attention to possible hazards in the workplace, such as wet floor, ungrounded power
extension cables, old power cords and a lack of safety earth. Consult your place of purchase or
professional if problems arise.
- It may cause fire and electric shock.
■Concerning the input voltage for operating this device, a voltage range must be within 10%
of rated voltage, and the power outlet must be grounded. Also, do not use a heat source such
as a hair dryer, iron and refrigerator to the same power unit.
- It may cause abnormal heat, fire and electric shock.
Release Version 1.1
2
Caution (If you do not keep any of the below guidelines, you may get injured or suffer
property loss.)
■Proper ambient temperature and humidity are recommended.
- Avoid extremely high temperatures(over 50°C) or low(below -10°C), and humid conditions.
■Install in well ventilated place, and avoid direct sunlight or heat appliance.
■Be sure to plug the power cord with grounded outlet.
- There is a risk of electrical shock and personal injury.
■Do not use this device in close proximity to a device that produces strong waves such as
radio set(TRANCEIVER, Walkie-talkie, etc.) or repeater. It may affect the video signal, or cause
disorders such as noise or crack on the screen.
■Transmission distance may vary depending on the type of coaxial and UTP cable.
■Disconnect the power plug with care during thunder and lightning.
■When connecting cables, install as “U” shape in order to prevent rainwater/dew/fog from
getting into the product.
■Refer to the user’s manual for problems or questions besides the above. Contact our service
center if you need assistance from a professional technician.
■When you extend or terminate coaxial cable, it should be connected in the following way.
- BNC-M(Male) - BNC-JJ - BNC-M(Male): BNC Connector connection example(for HD-SDI)
■Make the joint part of the cables insulated completely not to expose the metal parts.
■When using the product in outdoor, we recommend to use STP(Shield Twisted Pair) because
UTP(Unshielded Twisted Pair) Cable is for indoor use.
- Use UTP cable above than standard CAT.5e.
■Make sure to read this user’s manual thoroughly since this product has PoC function that
might generate a problem such as malfunction when connected with other products.
■Configure in separate for general network use (Internet, indoor, etc.) and CCTV usage.
- It might be the cause of problem.
■Be careful not to change the Network cable connection.
- Refer to the Cable Connection way below.
Network Cable Diagram
TIA / EIA 568B Type
Pin No.
Color
Func.
1
White
Orange
TX+
2
Orange
TX-
3
White
Green
RX+
4
Blue
PWR+
5
White
Blue
PWR+
6
Green
RX-
7
White
Brown
PWR-
8
Brown
PWR-
Release Version 1.1
3
1. Introduction
1-1. Overview
SC-IPC07P is a 1CH IP PoC transmission unit composed of SC-IPT07P (Transmitter) and
SC-IPR07P (Receiver). With PoC function, this product supplies power to Transmitter and camera and
power construction is unnecessary. In addition, since only coaxial cable construction is needed,
construction period is shortened and installation cost is reduced.
Also, coaxial cable laid between the transmitter and receiver enables long-distance transmission of
Ethernet data, which compensates for the disadvantage of short network transmission distance.
1-2. Features
•Supply power to IP camera (supports PoE Type B / Max. 30W)
•Transmission bandwidth: Up to 100 Mbps
•Transmit power + Ethernet data Max. 1,000m over RG-6 coax. cable (10Mbps)
•Auto MDI/MDIX function
•Supply stable power by auto cable checking function.
•PoE ON/OFF function for Transmitter connected to camera
•Built-in surge protection circuit
2. Components
2-1. SC-IPT07P (Transmitter)
SC-IPT07P
Bracket
RJ-45 Cable
Manual
2-2. SC-IPR07P (Receiver)
SC-IPR07P
DC 48V Adapter
Power Cord
Bracket
Manual
Release Version 1.1
4
3. Product Parts and Functions
3-1. SC-IPT07P (Transmitter)
①CAMERA PoE: Switch to set power supply to PoE IP camera.
※In case of connecting PoE IP camera, set CAMERA PoE switch as ON.
※The factory setting for the PoE switch is ON.
※In case of connecting non-PoE IP camera, set CAMERA PoE switch as OFF.
②LED Indicator
Name
Color
Status
PWR
Red
On: Power input
Off: No power input
ETH
Green
Flashing: Ethernet connected
Off: Ethernet Not connected
LINK
Green
On: Connected to Receiver
Off: Not connected to Receiver
PoE
Red
On: PoE Input to IP camera
Off: No Poe input to IP camera
Flashing: IP camera overcurrent (short / open circuit)
※When turning the product on, the LED turns on sequentially first and the product is operated.
③RECEIVER SIDE: Port to connect Receiver and output video.
④CAMERA SIDE: Port to connect IP camera.
①
③
④
②
Release Version 1.1
5
3-2. SC-IPR07P (Receiver)
①NVR SIDE: Port to connect NVR or PoE Hub.
②DC 48-57V IN: Port to input DC adapter (48V or 56V) power.
③TRANSMITTER SIDE: Port to connect Transmitter and input video.
④LED Indicator
Name
Color
Status
PWR
Red
On: Power input
Off: No power input
ETH
Green
Flashing: Ethernet connected
Off: Ethernet Not connected
LINK
Green
On: Connected to Transmitter
Off: Not connected to Transmitter
PoC
Red
On: PoC power output to Transmitter
Flashing: Transmitter or cable overcurrent (short / open circuit)
⑤Bandwidth Select Switch: Support 100Mbps, 10Mbps setting
※10M : Transmit by 10Mbps (10Mbps over RG-6 : 1km).
※100M : Transmit by 100Mbps (100Mbps over RG-6 : 500m, 50Mbps : 600m).
※When turning the product on, the LED turns on sequentially first and the product is operated.
.
④
④
①
③
②
⑤
④
Release Version 1.1
6
4. Connection Diagram
4-1. In case of connecting PoE IP Camera (PoE Switch ON)
<Installation Guide>
①Set CAMERA PoE switch as ON from SC-IPT07P (Transmitter). (PoE LED On)
※In case of connecting non PoE camera, set CAMERA PoE switch as OFF from Transmitter.
②After connecting IP CAMERA to Transmitter, connect coaxial cable connected to SC-IPR07P (Receiver).
③Connect coaxial cable connected to Transmitter to Receiver. Connect Receiver to NVR or PoE Hub.
④Check the transmission distance and set the Bandwidth switch of SC-IPR07P to the corresponding
transmission speed.
※10M : Transmit by 10Mbps (10Mbps over RG-6 : 1km).
※100M : Transmit by 100Mbps (100Mbps over RG-6 : 500m, 50Mbps : 600m).
⑤Supply power by connecting DC Adapter (48V or 56V) to the DC Jack of the receiver.
⑥Check the camera’s video from the monitor connected to NVR.
※If connected properly, LINK LED on Tx and Rx is ON and ETH LED is flashing.
Set CAMERA PoE switch on
Transmitter as OFF
Transmission Distance over RG-6]
10Mbps : 1km, 100Mbps : 500m, 50Mbps : 600m
RG-6
Release Version 1.1
7
5. Specifications
MODEL
SC-IPT07P
Power Input
PoC (PoC power input from SC-IPR07P)
Power Output
Midspan PoE (Type B Only, PoE SW On/Off available)
Transmission Speed
100Mbps
Connection Port
RECEIVER SIDE
BNC-F, 75Ω
CAMERA SIDE
RJ-45 (TIA/EIA568B Type)
LED Indicator
PWR
RED LED
ETH
GREEN LED
LINK
GREEN LED
PoE
RED LED
CAMERA PoE SW
Slide Switch
Temperature / Humidity
-10℃~ 50℃/ 0 ~ 80%
Case Body / Weight
ABS / 60g
Dimensions
90(W) x 55(H) x 24(D)
MODEL
SC-IPR07P
Power Input
DC 48V-56V/1A adapter or PoE Hub (IEEE 802.3at)
Power Output
PoC (DC 48V)
Power Consumption
DC 48V~56V/900mA
Max. Transmission Distance
RG-6 100Mbps: 500m, 50Mbps: 600m
RG-6 10Mbps: 1,000m
Transmission Speed
100Mbps
Connection
Port
TRANSMITTER SIDE
BNC-F, 75Ω
NVR SIDE
RJ-45 (TIA/EIA568B Type)
DC 48V-56V IN
DC-JACK
LED
Indicator
PWR
RED LED
ETH
GREEN LED
LINK
GREEN LED
PoE
RED LED
Bandwidth Select Switch
10M: 10Mbps, 100M: 100Mbps
Temperature / Humidity
-10℃~ 50℃/ 0 ~ 80%
Case Body / Weight
ABS / 62g
Dimensions
90(W) x 55(H) x 24(D)
Release Version 1.1
8
6. Transmission Distance by Coax. Cable Type (unit: m)
※The transmission distance may vary depending on the coaxial cable and connector construction
quality.
※There may be a difference between 20~30% of the available power values in above table
depending on the power status of camera.
※The transmission distance may vary depending on the specification of camera and NVR.
※In case of using PoE function of the Transmitter, the transmission distance may vary depending on
the type of camera. Especially, use exclusive adaptor for cameras with high power consumption
such as IP PTZ cameras and the cameras with many IR LEDs.
In addition, the length of NETWORK CABLE between camera and Transmitter is recommended to
be within 1m.
※In case of supplying power to Receiver by PoE Hub, the length of NETWORK CABLE is
recommended to be within 1m.
7. Installation Precautions
※Use exclusive power adapter separately for each product. It is not recommended to use single
adapter for supplying power to several products.
※It is not recommended to place products in close or tie each other.
※It is not recommended to connect adaptor to DC jack when powering the Receiver by PoE.
※When installing the product by supplying power by PoE, it is recommended to check the video
first and connect the ground of camera.
※When using a surge protector, the cable distance between camera and Receiver is recommended
to be within 50M.
※Use of LAN cable extension gender (coupler) may cause signal attenuation. It is not recommended
to use multiple extended gender connections.
5C-HFBT
5C-2V
3C-2V
RG-58
RG-59
200m
100Mbps / 12W
100Mbps / 12W
100Mbps / 12W
100Mbps / 12W
100Mbps / 12W
300m
100Mbps / 12W
100Mbps / 12W
100Mbps / 10W
100Mbps / 12W
100Mbps / 12W
400m
100Mbps / 12W
100Mbps / 12W
10Mbps / 7.7W
10Mbps / 12W
10Mbps / 10W
500m
100Mbps / 10.4W
100Mbps / 12W
10Mbps / 6W
10Mbps / 10W
10Mbps / 9.3W
600m
100Mbps / 9.8W
100Mbps / 12W
10Mbps / 5W
100Mbps / 8W
10Mbps / 7.8W
700m
10Mbps / 7.5W
10Mbps / 10W
10Mbps / 4.4W
10Mbps / 7.4W
10Mbps / 7W
800m
10Mbps / 6.5W
10Mbps / 9W
10Mbps / 3.8W
10Mbps / 6.6W
X
900m
10Mbps / 6W
10Mbps / 8W
X
X
X
1,000m
10Mbps / 5W
10Mbps / 7W
X
X
X
Release Version 1.1
9
8. Trouble Shooting
Symptom
Checking Method
There is
no power input.
<Transmitter>
•Check if PoC LED on Receiver and PWR LED on Transmitter is ON.
•Check the connection status of coaxial cable.
<Receiver>
•Check if the PWR LED is working properly.
•Check the input status of power adapter or PoE Hub.
•Check if the exclusive adapter (DC 48V/1A) is used.
The video
is not displayed.
•Please check if LINK LED is On and ETH LED is flashing.
•Check if the transmission distance is within the recommended
value or not.
•Check if the Network Cable arrangement is correct.
•In case of using PoE function on Transmitter, check if the PoE LED
is On. If LED is Off, set the PoE switch as ON.
Power supply
by PoE
does not work.
•Check the PoE switch status on Transmitter.
•Check if PoE LED on Transmitter is On.
•Check if the Network Cable arrangement is correct.
•Check if the IP CAMERA has PoE function.
NETWORK
connection
does not work.
•Check if the Network Cable arrangement is correct.
•Check if there is Walkie-Talkie or any device which has strong
waves near the product.
•Check if the Network configuration is installed properly.
The video status
is abnormal.
•Check the connection status of coaxial and Network cable.
•Check if the NVR is compatible with camera.
•Check the performance status of camera.
Release Version 1.1
10
9. Warranty Certificate
Product No.
Model No.
Date of Purchase
Place of Purchase
Purchaser
Name
Address &
Contact No.
Distributor
Name
Address &
Contact No.
Warranty Period
Two(2) years from the date of purchase
Any failure that occurs in the normal use for only two years after purchase will be
repaired free of charge.
Contact the phone number listed on the user’s manual for repair.
When reporting the failure, please inform the model name and condition of the
product accurately. It is convenient to know the name and department of the person
in charge.
Please check this user’s manual again before reporting the failure.
Product shapes and circuits are subject to change without notice to improve
performance.
Faults following will be treated as a charge:
Failure by user’s handling without care
Not connecting the rated power
Disassembled or repaired arbitrarily by user
Replacing consumables
Failure caused by natural disaster (lightning, fire, flood, tsunami, etc.)
This manual suits for next models
1
Table of contents
Other SeeEyes Receiver manuals
