SEEK Reveal User manual

Reveal Series User Manual
Menu
Fast Frame (FF)
Reveal and
RevealXR Fast
Frame devices
operate at 15Hz for
smooth scanning on
the go.
Welcome to the Reveal Series. Let's take a few minutes to quickly
walk through the basics and learn how to use your device.
View captured images.
Set date, time, language,
and auto power off settings.
Control high and low
flashlight intensity.
Access device serial# and
firmware version.
Power off your device.
Exit the menu.
View time, date and battery
Status.
To fully reset back to factory settings,
choose Device then Restore.
Change the current
display palette.
Navigation
Capture an image to be
stored in the gallery
Use the reticle to
measure a specific
temperature.
Temperature
display
At a Glance:
- 36º Field Of View
- 400ft detection distance
- 206x156 professional sensor
- 330 Lumen flashlight
Reveal
Great For:
Accurately and safely inspecting any job site.
Available with
9Hz frame rate
or ≥15Hz (FF).
Reveal XR
At a Glance:
- 20º Field Of View
- 900ft detection distance
- 206x156 professional sensor
- 300 Lumen flashlight
Great For:
Hunters, safety and security professionals.
Available Colors:
-Pure Black
-TrueTimber©
Kanati Camouflage
Available with
9Hz frame rate
or ≥15Hz (FF).
Charge battery and
access integrated
microSD
Power On/Off
Change reticle and
temperature units
by navigating to
Device àGeneral
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Benefits of Registration:
By sharing your name,
email, and serial number,
you enable us to send you
product updates and tips
and techniques. We can
also expedite your warranty
inquiries by knowing when
and where you purchased.
Country information helps
us to provide better local
product support.
Welcome to RevealPRO. Let's take a few minutes to quickly
walk through the basics and learn how to use your device.
RevealPRO User Manual
Registration
Changing your Registration:
Go to thermal.com and login
to make changes to your user
account.
Menu
Quickly access common settings from the dropdown menu.
View captured images.
Change the thermal imaging mode.
Zoom in up to 4x.
Toggle reticle on or off.
Adjust emissivity.
Access more settings and features.
Press the
Up
button to
capture images. Hold to
capture multiple images.
Capture
Filters
Explore the various
filters– from standard
grayscale to spectra
high contrast.
Set Date and Time:
Set date, time and language
on first startup.
Use buttons to navigate through menus.
Turn on the 300 Lumen
LED flashlight.
Up
Down
Select
Zoom
While imaging, press
and hold the left button
to continuously zoom
up to 4X. You can also
set the zoom factor
manually in settings.
Navigation
The left two buttons have a
quick navigation dropdown
when selected.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Settings
Emissivity is a material property that defines how
much IR light is emitted from a particular surface.
Calibrate for emissivity through four pre-defined
settings to ensure accurate temperature readings
and reporting.
Thermal Span and Level
Individually adjust Span
and Level range to meet
your requirements. Choose
reset to return to the
default range.
Modes
Default mode that maximizes
thermal image consistency using
auto exposure control.
Displays all temperature data for
maximum clarity.
Allows you to set and lock a
temperature range to display the
maximum thermal information of
any object or scene.
Change the thermal imaging mode.
View captured images.
Control zoom, watermark and banner
settings.
Adjust units (°C,°F,K), emissivity and reticle.
Set date and time, language,
auto power off, and flashlight settings.
Access device serial#, firmware version
and registration information.
Reticle
Enable the reticle for
precise spot temperature
readings.
Emissivity Control
Optional, more advanced modes, that display all temperature data for maximum clarity.
Current emissivity (ε)
setting is visible in the
lower banner.
To fully reset back to factory settings,
choose Device then Restore.
