SEF Mesy 3.0 User manual

Operation Manuell
Manufactureer:
SEF Eltronic GmbH
Kringelsburg
D-21379 Scharnebeck
Telefon: [phone]
Telefax: 0049 (0)4136-909-11
USB
Temperature measurement system
570.70
Mesy 3.0
Please keep this manual for later disposal
Year of manufacturing:
Seriennummer:

© SEF Eltronic GmbH, USB-Mesy® Version 3.0 (Juni 2003)
Subject to technical change.

Table of contents
01.eng USB-Mesy 3.0
Chapter 1 preface
Introduction…………………………………………….……........1.1
Intended operation……...…..........……………………………...…..1.2
Rights of use…………......……………………………………..…....1.3
About this manual………......……………………………...………...1.5
Special hints and conventions……......…………………...……..…1.7
Technical data…………………........………………………..……….1.8
Chapter 2 safety instructions
General safety instructions ………....……………..…...…………2.1
Important instructions ………......………………………...…………2.2
This you should now for operating the measurement system..........2.3
Disposal advices…………………………………......……...…...…..2.4
Chapter 3 installation
Functional description……………...……….......………..………….3.1
Scope of delivery……………….......………………………………...3.3
Software installation…………….......………………………..………3.4
Creating subdirectories on your hard disk………........…….....…...3.5
Making a backup……………………………….......…………..…….3.5
Hardware installation…………………….......……………..………..3.6
Chapter 4 system conguration
Starting the software………….......……...………………..…………4.1
General layout of the measurement forms….....……..…...……...4.3
The conguration sheet …………..……........……………...………4.5
The diagram sheet...……………….......……………………..…….4.13
The value sheet…………………......………………………...…….4.21
The reference sheet……………......………..……………...……...4.27
Adjustment of measurement box and temperature sensor.........4.37

Table of contents
01.eng USB-Mesy 3.0
Chapter 5 Measurement assembly and measurement
Preparing the PCB……………………………………….……….5.1
Conguration for the measurement analysis…………….…….5.3
Starting the measurement…………………...…………………..5.5
Saving a graph…………………………………….……………...5.7
Stopping the measurement………………..…………………....5.7
Chapter 6 Measurement analysis
The display supports……………..………………………………6.1
The measurement graph…………………..…………………….6.3
The reference graph…………………...…………………………6.5
Time and temperature values……………….…………………..6.7
Stretching and compressing the time axis………..…………...6.9
Stretching and compressing the temperature axis……….....6.13
Chapter 7 Notes

1.0 Preface
Site 1.1
01.eng USB-Mesy 3.0
Introduction
Dear customer,
this operation manual is made for the authorized
user. Basic knowledge and the handling of a personal
computer and its operation system is presumed.
Please take care for the instructions about the
hardware and software installation in this manual.
Thereby you prevent damage at the hardware and
software.
The measurement system was developed state of the
art and was tested for proper function before delivery.
Anyway there could be danger for health and life
of the user or third persons and for damage at the
measurement system if it is not used according to this
manual.
Read this manual before working with the measurement
system. Use the measurement system only in good
order and condition and according to all regulations,
safety and danger instructions in this manual.
This operation manual contains rules and instructions
for a proper use of the measurement system. Only the
compliance of this rules and instructions is obtained as
a proper use. Risks due to other use are accounted for
the operator.
Please contact us if you have further questions to the
measurement system or if you like to order accessories
or spare parts.
You can get through to us under:
Phone: [phone] / 909-0
Fax: [phone] / 909-11

1.0 Preface
Site 1.2
1.0 Preface
Site 1.3
01.eng USB-Mesy 3.0
01.eng USB-Mesy 3.0
The MESY 3.0 is designed for a measurement of
temperatures from 0°C – 400°C.
Damages due to higher temperatures are accounted to
the operator.
Please take care for:
u An intended or proper use also contains the com-
pliance of the installation, operation and disposal
instructions..
u Only qualied and trained staff is allowed to work
with the measurement system.Each person who
is working with the measurement system must
have read and understood the important parts of
the manual, especially chapter 2 „ Safety instruc-
tions“. In addition the operator must inform the
staff about possible dangers.
u The operator must ensure that the operation man-
ual was understood by all person who are working
with the measurement system.
u One copy of the operation manual must be kept at
the place of installation of the measurement sys-
tem.
Intended operation

1.0 Preface
Site 1.2
1.0 Preface
Site 1.3
01.eng USB-Mesy 3.0
01.eng USB-Mesy 3.0
Rights of use
The SEF Eltronic GmbH allows the customer the not exclusive
and not negotiable use of the delivered harware and software
(further named „product“) subject to the following regualations:
u The rights of use authorises the customer to use
the product and the necessary documentation.
u The SEF Eltronic GmbH is owner of all rights at
product. The customer is allowed to make a safety
backup. The SEF Eltronic GmbH reserves all rights
of publication, editing and utilisation at the product
and the documentation.
u The warranty is effective ex works SEF Eltronic
GmbH, D-21379 Scharnebeck and is valid incon-
sideration of our general terms and conditions. The
warranty claim expires if the assembly / board is
opened or changed by unauthorized persons, if
the type label was removed or changed or if the
inscriptions of the warranty paper were changed
ormade irrecognisable.
u The SEF Eltronic GmbH does not assume any li-
ability for a faultless function of the productor the
accuracy of the parameters.
u The SEF Eltronic GmbH is authorised to effect
changes and upgrades of the product in its sole
discretion. The SEF Eltronic GmbH is not boundto
provide these changes and upgrades unasked
free of charge. The SEF Eltronic GmbH is always
anxious to update the software. You can ask for a
software update for a nominal fee before the war-
ranty time expires.
Subject of the
contract
Protection of the
product
Warranty
Changes and
upgrades of the
product
Liability

1.0 Preface
Site 1.4
1.0 Preface
Site 1.5
01.eng USB-Mesy 3.0
01.eng USB-Mesy 3.0
u It is forbidden to copy the product or the written
documentation complete or in parts. It is forbidden
to change the product, especially to translate,
to redevelop, to decompile or to disassemble the
enclosed software.
u For perfective maintenance reasons it is necessary
to inform the manufacturer in case of donation or
hire of the product, otherwise the warranty claim
would expire.
u The general terms and conditions of the SEF
Eltronic GmbH are valid. These rights of use
succumb the right of the Federal Republic of Ger-
many. Court of jurisdiction and place of fullment is
Lüneburg.
(c) SEF Eltronic GmbH
USB-MESY® 3.0, June 2003
Special restric-
tions
Assignment of
the rights off use
General regula-
tions

1.0 Preface
Site 1.4
1.0 Preface
Site 1.5
01.eng USB-Mesy 3.0
01.eng USB-Mesy 3.0
About this manual
This operation manual shall explain the handling of the
measurement system and shall help you with the work with
the MESY 3.0.
Therefore we divided this manual in different chapters.
u Chapter 1, preface
In this chapter you get knowledge about the intended
use and the rights of use.
u Chapter 2, safety instructions
Safety must be. Here we give you important
instructions for the handling of the measurement
system and about what you should take care for in
the environment.In addition you get advices about the
disposal of the measurement system.
u Chapter 3, function description
In this chapter you will get knowledge about the
general function. We will show you, how you can
install the software and how to prepare the system for
measurement.
u Chapter 4, system conguration
In this chapter we describe how you can start the
software and which general Adjustments you can
make.
u Chapter 5, measurement assembly and measure-
ment
How to x temperature sensors to a PCB and how to
operate the measurement system will be described in
this chapter.
u Chapter 6, measurement analysis
In this chapter you will learn how to change the
diagram after recording a temperature prole.
u Chapter 7, notes
In this chapter you will nd free space for your own
notes.

1.0 Preface
Site 1.6
1.0 Preface
Site 1.7
01.eng USB-Mesy 3.0
01.eng USB-Mesy 3.0
Special hints and conventions
For an easier reading and consulting in this manual we
marked some parts of the text.
Marks descriptions, advices for a better
handling of the system or cross references
corresponding with other text passages.
Aufzählungen mit vorausgehender Raute sind
allgemeine Aufzählungen.
u Listings with a previous rectangle are work
or operation steps which must be done in the
mentioned order.
y Listings with protrusive rhombus are general list-
ings.
<Enter> These parts mark enters with the PC keyboard
and text inscriptions for operation and pro-
gramming.
At the beginning of this operation manual you will nd
a table of contents, which helps you to nd the single
topics.

1.0 Preface
Site 1.6
1.0 Preface
Site 1.7
01.eng USB-Mesy 3.0
01.eng USB-Mesy 3.0
Technische Daten
Size of the measurement box (lxwxh): 120 x70 x 23 mm
Weight of the measurement box: 180 g
Voltage supply: via USB-connector
Data transfer: via USB-connector
Operation temperature: 0°C – 50°C
Number of temperature sensors: 3
Type of temperature sensors: thermocouple type K
Measurement- (temperature-) range: 0°C – 400°C
Measurement accuracy: +/-1°C (after
adjustment)

1.0 Preface
Site 1.8
01.eng USB-Mesy 3.0

2.0 Safety instruction
Site 2.1
02.DE USB-Mesy 3.0
This measurement system is manufactured state of the
art. Anyway the system can cause danger if it is not
used in compliance with the instructions. The operation
manual serves for an intended and safety work with
the measurement system.
Each person who is working with this measurement
system must have read and understood the complete
operation manual, especially this chapter. Safety
instructions serve for occupational safety and health
and for accident protection.
Safety instructions must be observed.
Keep this operation manual next to the measurement
system, so that you have it always to your disposal. Your
attentive cooperation is necessary to prevent you and
your colleague from injuries. Work with care and safety
awareness.
The following warning and instruction symbols are used
to mark text passages with safety instructions. Keep this
symbols and their meaning in mind.
Warning sign: This safety symbol warns of a pos-
sible danger. Non-observance can cause injury or
damage of the system.
Commandment sign: that rules a special behav-
iour. Non-observance can cause heavy injuries.
Remain dangers are not obvious risks given to the use
of the measurement system. Although the measurement
system is developed state of the art and is constructed
and manufactured according to the generally accepted
safety regulations, even with intended use remain
dangers cannot be eliminated. Therefore use the
measurement system only in unobjectionable condition
and take care for all possible dangers and for the rules
for the prevention of accidents.
General safety instructions
Important symbols
Remain dangers

2.0 Safety instructions
Site 2.2
2.0 Safety instruction
Site 2.3
02.DE USB-Mesy 3.0
02.DE USB-Mesy 3.0
Owner is every individual and legal person who has
bought the measurement system.
Operator is every individual and legal person who uses
the measurement system gives the order to use it.
Only competent, qualied and briefed persons are
allowed to operate the measurement system. These
persons must have sufcient knowledge of the special
subject area and of the relevant working safety and
accident prevention regulations.
Accident prevention regulations must be followed.
Please inform yourself about the accident prevention
rules which are relevant for your company and for the
work with the measurement system.
We want to refer to the following accident prevention
rules (valid in Germany):
UVV “First Aid” (BGV A59)
UVV “General regulations” (BGV A1)
Please take also care for the following regulations:
u Safety regulations VDE,
u Safety regulations IEC,
u Safety instructions of the chip glue and solder
pastemanufacturer
Accident
prevention
regulations
Competent and
qualied persons
Owner
Operator
Wichtige Hinweise

2.0 Safety instructions
Site 2.2
2.0 Safety instruction
Site 2.3
02.DE USB-Mesy 3.0
02.DE USB-Mesy 3.0
Only assigned and instructed persons are allowed to use
the measurement system. The state of health of these
persons must be okay so that they are in a position to operate
the system and these persons must not come under the
inuence of pharmaceuticals which reduce the reaction time.
The operator is obliged to make sure that the measurement
system is used only in a safety and operable state.
The measurement system is inapplicable for the
operation inside the temperature zone you want to
measure. Make sure that the operation tempera-
ture of the system is not higher than 50°C.
The operation staff must also take care that only
assigned persons work with the measurement
system. Every procedure which affects the safety
of the measurement system is not allowed. If a fault
appears which may cause danger for persons, for the
measurement system and / or for the environment,
the system must put out of operation immediately. It is
allowed to put the system on stream again only if the
fault was eliminated before and if there is no danger
any longer. The operation staff is obliged to inform the
operator or the owner about any changes at the system
which may take effect to the safety.
Only original spare parts are allowed for repair.
Take care for the safety and operation instructions
of the chip glue and solder paste manufacturer.
Read also the operation manual of the soldering
system
This you should now for operating the measurement system
General safety
instructions
Reference to other
manufacturer.

2.0 Safety instructions
Site 2.4
02.DE USB-Mesy 3.0
The system contains materials which can cause danger to the
environment when disposed. The operator is obliged that
these materials will be disposed conform to the law.
For Germany is valid:
It is mentioned in the federal law how to dispose these
materials. Not all of these materials will be disposed by the
communes. In this cases the operator is obliged to dispose
these materials by himself conform to the laws.
Ask the communes, the federation or the country
for information about the disposal.
u Keep the original packing for later return shipment
to the manufacturer.
u The electronic assemblies must be disposed con-
form to the law.
Disposal advices

3.0 Installation
Site 3.1
03.eng USB-Mesy 3.0
Functionel description
The measurement system 570.70 was especially designed
for the use at wave and reow soldering systems. The
measurement recording is taking place with a PC in an
Excel form. The measurement values are transferred from
the system to the PC. The temperatures are measured
via 3 thermocouple sensors of type K. These sensors
are connected with sockets at the rear side of the
measurement system. The duration of the measurement
recording acts in accordance with the adjustments in
the user software. All operation and indicator elements
are arranged at the front side. A LED shows the status
of the system. If it ashes green, the system is ready for
initialisation and for recording measurement data.
The demonstration of the measurement data occurs via the
measurement system software. This software can be installed
on any AT compatible personal computer which is equipped
with the operation systemsWindows 2000© or Windows XP©.
Microsoft Excel© from the software packages Ofce 2000© or
Ofce XP© is also needed. The hardware requirement is a PC
with a VGA graphics board, one free USB port 1.1 and 4,5
MB free hard disk space. The software can be installed with
the included setup le.
Indication and
connections
USB socket Staus LED
Rear view
Frontview
Measurement sockets 1 - 3
Intended
application
Software
Assembly

3.0 Installation
Site 3.2
3.0 Installation
Site 3.3
03.eng USB-Mesy 3.0
03.eng USB-Mesy 3.0
With the measurement system software the recorded
data can be displayed, analysed, organized and printed.
For the display of the measurement data in a graph,
the temperature and the time axis be adjusted, grid and
measurement graph symbols can be faded in and out.
The analysis functions allow to show information
about the peak temperature and peak duration of a
measurement graph according to a previous selected
melting point. A further function is the calculation of
the maximum increase rate of a temperature graph.
It is possible to save a graph together with positive
and negative tolerance values as a reference curve.
This reference curve can be compared with following
measurements to get an easy control about the process
accuracy.
A printout is possible via a printer which is connected to
the PC.
Functionel description
Measurement
data
Analysis
Print function

3.0 Installation
Site 3.2
3.0 Installation
Site 3.3
03.eng USB-Mesy 3.0
03.eng USB-Mesy 3.0
Lieferumfang
The measurement system will be shipped in a special
packing by post or another forwarder.
You have received a measurement system 570.70 including
the standard scope of delivery:
1 Measurement box 570.70
3 Thermocouple sensors type K, length 2,5 m
1 USB cable, length 3,0 m
1 Installation CD-ROM
1 Quick reference guide
1 operation manual
2 self-sealing magnetic stripes
You will nd all additional accessory deliveries on the delivery
note.
y Check immediately if there are any transport dam-
ages
y If there is a transport damage, please contact us
and the forwarder.
Attention, danger of life
Don’t operate the system if there are any
perceptible damages. The damage can cause
danger to your life.
y Check if the contents correspond with the details
on the delivery note. If the delivery and the de-
livery note don’t correspond please contact us at
once.
y After you have unpacked the measurement sys-
tem and checked the unobjectionable condition
and the correct delivery, you can start the begin-
ning of operation.
What was
delivered?
What can I do
in case of any
demage

3.0 Installation
Site 3.4
3.0 Installation
Site 3.5
03.eng USB-Mesy 3.0
03.eng USB-Mesy 3.0
Copy the software
on your hard disk
These are the computer requirements for an
unobjectionable measurement:
u Windows 2000© or Windows XP©
u VGA graphics board
u 1 USB interface 1.1 or higher
u 1 CD-ROM drive
u Microsoft Excel 2000© / XP© or Microsoft Ofce
2000© / XP©
The measurement system software will be started rectly
from the Microsoft Excel program.
For a correct installation Microsoft Windows
2000© or Microsoft Windows XP© and Microsoft
Excel 2000 XP© or Microsoft Excel XP© must
be installed to your computer.
Before connecting the measurement box with
the PC the measurement software must be in-
stalled.
y Insert the included CD-ROM in the CD-ROM
drive of your PC.
y Open the le “Setup.exe” on the CD-ROM.
y Follow the instructions which appear on the
screen.
y If necessary it is possible to create a new path.
y The software of the MESY 3.0 is installed on
your PC after the installation procedure is n-
ished.
Software installation
Computer require-
ments
