Motorola SCOUT2300/2 User manual

QUICK START GUIDE
For a full explanation of all features and instructions, please refer to the User’s Guide.
1. Setting up your Digital Video Pet Monitor
MODELS:
SCOUT2300,
SCOUT2300/2,
SCOUT2300/3,
SCOUT2300/4
Connect the small plug of
the power adapter to the
pet unit and the other end to
the electrical outlet.
Only use the enclosed
adapter (5.9V DC/1000mA).
A. Connecting power supply for the Pet unit
B. Installing the battery pack for the Owner unit
Insert the wire tab of the
rechargeable battery pack into
the contact slot as shown above
and fit the battery pack into the
compartment.
RedBlack
D. Connecting power supply for the Owner unit
Connect the small plug of the
power adapter to the owner
unit and the other end to the
electrical outlet.
Only use the enclosed adapter
(6V DC/500mA).
C. Fastening the cover for the Owner unit
Small cross head or
Flat end screwdriver
WARNING:
STRANGULATION HAZARD - In case this unit is being to monitor infants or children, keep the unit and adapter cord more than 3 feet from the crib and out
of their reach. Never place camera or cords within a crib or near a bed. Secure the cord away from children's reach. Never use extension cords with AC
Adapters. Only use the AC Adapters provided.
As with any electrical device, supervision of your pet's usage should be exercised until your pet is acclimated to the product. If your pet is prone to chewing,
we strongly recommend you keep this and all other electrical devices out of its reach.

2. Basic operation of the keys
3. General Information
If your product is not working properly...
1. Read this Quick Start Guide or the User’s Guide.
2. Contact Customer Service:
Owner unit
PON/OFF button Press and hold to switch on/off the unit.
+-,. UP/DOWN buttons Press to tilt the camera upward or downward. Press to adjust menu settings.
<> LEFT/RIGHT buttons Press to pan the camera left or right. Press to access the different menu options.
MMENU button Press to open menu options or exit.
OOK button Press to confirm a selection.
>> Quick Scan button Press to double the video pan and tilt speed. Press again to return to normal speed.
TTALK button Press and hold to talk to your pet.
Pet Unit
ON/OFF switch Push power switch to the right to switch on the unit.
Push power switch to the left to switch off the unit.
US and Canada 1-888-331-3383
Email: motoro[email protected]om
Manufactured, distributed or sold by Binatone Electronics International LTD., official licensee for this
product. MOTOROLA and the Stylized M Logo, are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. and are used under license. All other trademarks are the property of their
respective owners. © 2013 Motorola Mobility LLC. All rights reserved.
Printed in China
Version 5.0
