SEGUE MOD-1601 User manual

© 2021
Order #XXXXX
Locked layer contains
placeholder marks.
*
U-Channel
Transformer
1
1A
2
2A
3
3A
44A
Item
1,1A
2,2A
3,3A
4,4A
--
Qty.
1,1
1,1
1,1
2
1
Description
36” CEI152 Vertical Extrusion
36” CEI152 Vertical Extrusion
24” CEI152 Horizontal Extrusion
Base Plate
9” U-Channel
Steps:
1) Attach u-channel to horizontal [3].
See U-Channel Connection detail.
2) Assemble CEI152 extrusions together, flat on floor.
See CEI152 Frame Assembly sheet for instruction.
3) Attach base plates to [3], using bolts, washers, and
wing nuts then lift assembled frame upright.
4) Connect lighting cords and attach transformers then
set transformers into u-channels. See Light to Light
Connection & Light to Transformer Connection details.
5) Install SEG graphics to front and back of assembled frame.
Completed Assembly
++
+
-
-
-
to power
Lights
Male
Male
Female
Female
Transformer
96W / 4A / 24V
Light to Light Connection
Light to Transformer Connection
Maximum of 7 lights per transformer.
U-Channel
Bolt
Bolt
Horizontal Extrusion
V2 V2
Slide V2 connectors into top groove of horizontal
extrusion. Tighten set-screws to secure. Attach
U-Channel to connectors, using bolts.
U-Channel Attachment
Note: V2 connectors stay attached when packing.
*
SEG Graphic Installation
Corner A
Corner D
Corner B
Corner C
It is important to first insert
graphic into each alternate
corner, then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Graphic Removal
To remove the graphic from
the frame, locate the fabric
pull tab. Gently pull up on
the tab to remove the fabric.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
MOD-1601 Double-Sided Lightbox
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2021
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information

© 2021
Order #XXXXX
1) Slide TWO-PIECE TS RV 2 L-bracket into
Interior Center Slot of extrusion so that two
set screws are inside groove.
Tighten two set screws to secure.
2) Slide two A1 L-Brackets into outer interior
grooves of upper and lower horizontals.
Tighten set screws to secure.
4) Slide exposed ends of installed brackets of
upper horizontal into open ends of verticals.
Tighten set screws to secure.
3) Slide vertical extrusion over exposed ends
of brackets in lower horizontal.
Tighten set screws to secure.
Corner Bracket Installation
CEI-152 Profile
TS RV 4
Bracket
V4
V4
Insert two-piece
bracket into the
interior center slot
of extrusion.
Slide V4 Connectors
into front & back
interior grooves.
Secure inserted half of
bracket & connectors
using set screws.
Slide connecting
extrusion over
exposed ends
of bracket &
connectors.
Completed
Assembly
Secure extrusion,
using remaining
set screws.
Set
Screws
Straight Bracket Installation
TS RV 2
Upper
Horizontal
Lower
Horizontal
Upper
Horizontal
Lower
Horizontal
TS RV 2
Insert L-Brackets into the
Interior Center Slot & outer
interior grooves of extrusion.
Slide verticals over
brackets of lower
horizontal, then slide
upper horizontal &
brackets into grooves
& center slots
of verticals.
12 Brackets Total:
(4) - TS RV 2
(8) - A1 L-Brackets
A1
A1
A1
A1
Completed
Assembly
Corner Connection
1) Slide TWO-PIECE TS RV 4 straight bracket into
Interior Center Slot of extrusion, so that two of the
set screws are inside groove. Tighten two set screws
to secure.
3) Slide connecting extrusion over exposed ends of
bracket & connectors. Tighten all remaining set screws
to secure extrusions.
2) Slide two V4 Connectors into outer interior grooves
of extrusion, so that one set screw is inside groove.
Tighten set screw.
Straight Connection
Disassembly
1) Loosen set screws on brackets and slide
extrusions off of brackets.
CEI-152 Frame Assembly
CEI152 Frame Assembly

© 2021
Case 1 of 1
Order #XXXXX
Locked layer contains
placeholder marks.
Top View of Each Level
Level 1 (Bottom Level) Level 2
1
4
4
2 1A
3
2A
3A
Level 3
Setup Hardware
Case Packing
