Knight Cubit Caddy User manual

knightgroup.co.nz
Tools Required: Powered Screwdriver
Assembly Instructions
Cubit Caddy

Page 1
Assembly Instructions
knightgroup.co.nz
Cubit Caddy
• To prevent possible scratches or damage, assemble the product
on a soft surface such as a blanket, carpet or packaging.
Recommended
2-person Step

Page 2
Assembly Instructions
knightgroup.co.nz
Cubit Caddy
Item Description Qty Item Description Qty
A Top Panel 1 5/8” Cam Cover 18
X Left Side Panel 1 Threaded Dowel Pin 16
Z Right Side Panel 1 ST5*16 Screw 18
D Back Panel 1 4*25 Screw 8
G Bottom Panel 1 Castor 4
E Moveable Shelf 1
Y Vertical Panel 1
Cam
c5
Pre-installed Parts
p1
s2
t3
c2
s1
5 x Threaded Dowel Pin 24 x 5/8” Cam Cover 20 x ST5*16 Screw
p1 c2 s1
5 x Castor
t3 4 x 4*25 ScrewS2
Parts

Page 3
Assembly Instructions
knightgroup.co.nz
Step 1
Page 3
Assembly Instructions
Cubit Caddy
Step 2
Connect Cam bolts and dowels on panel D to the holes on panel X and Z and tighten in a clockwise direction.
Assemble castor (t3) with screws (s1) on bottom of panel G.
Cams/holes on the panel
Y to face to panel X.

Page 4
Assembly Instructions
knightgroup.co.nz
Page 4
Assembly Instructions
Step 3
Cubit Caddy
Step 4
Connect cam bolts and dowels on panel X, Z, Y and D to the holes on panel A and G and tighten in a clockwise
direction.
Insert threaded dowel pins (p1) into panels X, D, Y and Z. Put the TWO panels E on the top of threaded dowel pins
(p1). Insert the pedestal into the caddy.

Page 5
Assembly Instructions
knightgroup.co.nz
Page 5
Assembly Instructions
Complete
Cubit Caddy
