Segway-Ninebot Gokart Pro Lamborghini User manual

Model: Gokart Pro Lamborghini
Product Overview
100kg
Peak Load
Hollow
Non-Inflatable
Tyre s
51.2kg Unit
Weight
450w *2
Motor
Max Speed
37KM / H
IPX4
Splash Proof
KG
15%
Hill Grade
25 km
Range
New wind-cooled
hub motor
Two new wind-cooled high-
power wheel hub motors
realize an astonishing 10
km/h maximum speed. Dual
heat dissipation structure of
the motor provides longer
peak performance, 1.02 G
acceleration, and smooth
experience with ample back
push.
Fine-tuned body balance
The front-to-rear weight
ratio of body is 40:60,
having flexible acceleration
of kart rear end. You
can enjoy the exciting
experience of recovering
kart state by turning the
wheel in the opposite
direction when coming
around a corner at high
speed.
Exclusive power vector
distribution system
Adjustable difficulty for
drifting
Select “Dynamic Swerve”
in Segway-Ninebot Travel
APP, and adjust the power of
the inner and outer wheels
to make the vehicle more
“drifty” or “pushy”, so as to
change the corner coming
characteristics.
Four driving modes
Customized driving for fun
Four driving modes can be
selected after connecting to
the APP. No matter a green
hand who has just started
from scratch or a dab hand
who easily maneuvers along a
race course, their own driving
pleasure is guaranteed.
Gokart Pro Lamborghini

Model:Model: Gokart Pro Lamborghini
Product Specifications
N2C432
1420 ×852 ×600 mm
1040 ×852 ×459 mm
100 kg
51.2 kg
14+ years old
130–190 cm
Approx. 37 km/h
Approx. 3 km/h
Approx. 25 km
2.1:1
Approx. 45 mm
Approx. 15 °
14–104°F (-10–40°C)
-4–122°F (-20–50°C)
IPX4
Approx. 4 hour
8 Specifications
[2] Front compartment battery: The battery compartment inside the frame that is used to power the frame indicator/
head-light. When the battery is low, the blue indicator light turns yellow and blinks. You need to replace the batteries
yourself.
[3] Braking distance: Under the circumstances of full power, 70kg load, and measured on a flat hard road at an average
speed of 20 km/h.
Nominal Voltage
Nominal Energy
Nominal Power
Max. Power
55.5 V DC
Max. Charging Voltage 59.5 V DC
432 Wh
Over-voltage, under-voltage, short circuit, and over-heating protection.
Auto-sleep and auto-wake.
500 W ×2
2400 W ×2
Speed modes
Status indicator
Taillights
Rull-colour RGB taillight/brake light
ECO mode—max. speed: 8 km/h; STRADA mode—max. speed: 18 km/h; SPORT mode—max.
speed: 28 km/h; CORSA mode—max. speed: 37 km/h.
Flat surface, paved road; obstacles < 1 cm;
gaps < 3 cm; slopes < 15 °
The indicator comes in three colors: blue, yellow, and red. Blue means that the vehicle
is in normal condition. Yellow means that the batteries in the front compartment need
to be replaced. Red means that the vehicle has a performance failure, and you need to
open the app to check the cause of the failure and contact the after-sales service.
Product
Size
Weight
Driving
Main
parameters
Battery
Motors
Charger
Front
compartment
battery
[2]
Brake
Tyres
Light
Model
Vehicle size
Package size
Max payload
Net weight
Age
Height
Speed limit
Reversing speed limit
Steering ratio
Ground clearance
Maximum slope
Traversable
Terrain
Operating temperature
Storage temperature
IP rating
Charging time
Input Voltage
Output Voltage
Nominal Power
Output Current
Model/Quantity
Braking method
Braking distance
[3]
Front tyre
Rear tyre
Headlight
100-240 V ～50/60 Hz
59.5 V DC
120 W
2 A
6 AA Batteries
Electronic brake + mechanical handbrake
6 m
Tyre width: 80 mm; flatness ratio: 60%; hub diameter: 127 mm
Tyre width: 68 mm; 10 ×6.8mm, hollow solid tyre
0.2 Watt white LED light bar
[1] Typical Range: tested while riding under full power, 75 kgload, 77°F (25°C), 60% of max. speed on average on pavement. * Some of
the factors that affect range include: speed, number of starts and stops, ambient temperature, etc.
Typical Range
[1]
Charging Temperature 32–104°F (0–40°C)
Battery Management
System
16 17

Model:Model: Gokart Pro Lamborghini
Product Specifications
N2C432
1420 ×852 ×600 mm
1040 ×852 ×459 mm
100 kg
51.2 kg
14+ years old
130–190 cm
Approx. 37 km/h
Approx. 3 km/h
Approx. 25 km
2.1:1
Approx. 45 mm
Approx. 15 °
14–104°F (-10–40°C)
-4–122°F (-20–50°C)
IPX4
Approx. 4 hour
8 Specifications
[2] Front compartment battery: The battery compartment inside the frame that is used to power the frame indicator/
head-light. When the battery is low, the blue indicator light turns yellow and blinks. You need to replace the batteries
yourself.
[3] Braking distance: Under the circumstances of full power, 70kg load, and measured on a flat hard road at an average
speed of 20 km/h.
Nominal Voltage
Nominal Energy
Nominal Power
Max. Power
55.5 V DC
Max. Charging Voltage 59.5 V DC
432 Wh
Over-voltage, under-voltage, short circuit, and over-heating protection.
Auto-sleep and auto-wake.
500 W ×2
2400 W ×2
Speed modes
Status indicator
Taillights
Rull-colour RGB taillight/brake light
ECO mode—max. speed: 8 km/h; STRADA mode—max. speed: 18 km/h; SPORT mode—max.
speed: 28 km/h; CORSA mode—max. speed: 37 km/h.
Flat surface, paved road; obstacles < 1 cm;
gaps < 3 cm; slopes < 15 °
The indicator comes in three colors: blue, yellow, and red. Blue means that the vehicle
is in normal condition. Yellow means that the batteries in the front compartment need
to be replaced. Red means that the vehicle has a performance failure, and you need to
open the app to check the cause of the failure and contact the after-sales service.
Product
Size
Weight
Driving
Main
parameters
Battery
Motors
Charger
Front
compartment
battery
[2]
Brake
Tyres
Light
Model
Vehicle size
Package size
Max payload
Net weight
Age
Height
Speed limit
Reversing speed limit
Steering ratio
Ground clearance
Maximum slope
Traversable
Terrain
Operating temperature
Storage temperature
IP rating
Charging time
Input Voltage
Output Voltage
Nominal Power
Output Current
Model/Quantity
Braking method
Braking distance
[3]
Front tyre
Rear tyre
Headlight
100-240 V ～50/60 Hz
59.5 V DC
120 W
2 A
6 AA Batteries
Electronic brake + mechanical handbrake
6 m
Tyre width: 80 mm; flatness ratio: 60%; hub diameter: 127 mm
Tyre width: 68 mm; 10 ×6.8mm, hollow solid tyre
0.2 Watt white LED light bar
[1] Typical Range: tested while riding under full power, 75 kgload, 77°F (25°C), 60% of max. speed on average on pavement. * Some of
the factors that affect range include: speed, number of starts and stops, ambient temperature, etc.
Typical Range
[1]
Charging Temperature 32–104°F (0–40°C)
Battery Management
System
16 17

Model:Model: Gokart Pro Lamborghini
Product FAQ’s
Q: How is the Waterproof Performance of Segway-Ninebot Gokart Pro Automobili
Lamborghini Edition, could it ride in the rain?
A: Segway-Ninebot Gokart Pro Automobili Lamborghini Edition complete protection class is
IPX4, outdoor riding is prohibited in rainy weather. For your personal safety, outdoor riding is
not recommended in other severe weather.
Q: What are the main material quality of Segway-Ninebot Gokart Pro Automobili
Lamborghini Edition have slightly used marks? Is it a refurbished vehicle?
A: The exterior plastic parts of Segway-Ninebot Gokart Pro Automobili Lamborghini Edition are
mainly made of PC materials, and also included PC + ABS, PP, PA6 + GF and other materials;
the frame is made of steel.
Q: How to judge the braking distance of Segway-Ninebot Gokart Pro Automobili
Lamborghini Edition?
A: Segway-Ninebot Gokart Pro Automobili Lamborghini Edition brake standard is 75kg for test
riders, 20km / h, and asphalt road. It is normal for the left foot brake to be braked at a distance
of about 6 meters, and the manual brake handle is emergency braking. Pulling the brake handle
can immediately achieve the braking effect. If the braking distance is too long and fails in this
condition, it can be judged as abnormal, and you may need to contact the after-sales service.
Q: Why does the frame chassis so low that it can cross a standard road bumps?
A: The top speed of the Segway-Ninebot Gokart Pro Automobili Lamborghini Edition reaches
about 37km / h. In order to prevent overturns from causing sharp turning, the chassis is
designed to be low, with a minimum ground height of 45mm. If you need a speed reduction
belt, it is recommended that the driver get off the vehicle and push the vehicle over the speed
reduction belt to avoid hitting the chassis to damage the vehicle.

Model:Model: Gokart Pro Lamborghini
Product FAQ’s
Q: Why does Segway-Ninebot Gokart Pro Automobili Lamborghini Edition automatically
start moving Forward/Tilts backward after installation?
A: If the Segwau-Ninebot MAX does not switch to “Gokart PRO Mode”, it will cause the center
of gravity to move forward / back after the vehicle is turned on, and the Segway-Ninebot
Gokart Pro Automobili Lamborghini Edition cannot be upgraded. Please perform the following
operations on the Segway-Ninebot MAX before assembling the Segway-Ninebot Gokart Pro
Automobili Lamborghini Edition;
1. Download and install the Segway-Ninebot APP
2. Open the APP, search and connect your Segway-Ninebot MAX.
3. Click “Settings” - “Firmware Upgrade” in the upper right corner of the APP page. Click &
Open “Gokart PRO Mode” on the Segway-Ninebot MAX settings page.
Note: It is forbidden to sit on the Segway-Ninebot MAX without separate upgrading. Prevent
injury caused by excessive deviation of balance point and sudden acceleration of balance
vehicle
Q: Segway-Ninebot Gokart Pro Automobili Lamborghini Edition continuously beeping and
cannot move?
A: Please check whether the middle cabin panel of the Segway-Ninebot MAX displays the lock
sign. If it is displayed, first connect the Segway-Ninebot Gokart Pro Automobili Lamborghini
Edition Bluetooth with your mobile phone and click unlock. If it can’t be solved, you need to
separate the Segway-Ninebot Gokart Pro Automobili Lamborghini Edition kit and the Segway-
Ninebot MAX. After separately connecting the Segway-Ninebot MAX Bluetooth with the
Segway-Ninebot app, click unlock to resolve the problem.
Both the Gokart kit and the Segway-Ninebot MAX have a locking function, because of
compatibility issues, there might be two states after the lock, and both are normal.
1. The vehicle keep beeping when it is locked and motionless
2. There is no alarm when the vehicle is locked. Push/Step on the throttle or brake will have
alarm.
Q: How to clear the Bluetooth password?
A: In the start-up state, hold down the accelerator and brake for 15 seconds at the same
time, release it when you hear a beep sound, it means that Bluetooth password clearing is
completed.

Model:Model: Gokart Pro Lamborghini
Product FAQ’s
Q: Segway-Ninebot Gokart Pro Automobili Lamborghini Edition modes introduction,
how to choose the Mode that suits you?
A: Segway-Ninebot Gokart Pro Automobili Lamborghini Edition has five modes;
Safety mode: Max speed 8km / h;
New rider mode: Max speed 18km / h;
Sports mode: Max speed 28km / h;
Track mode: Max speed 38km / h;
Reverse mode: Max speed 3km / h;
Equipped with Ninebot MAX, full battery mileage is about 30km；
Please choose the appropriate speed mode according to yourself, family & friends driving
proficiency and age.
Q: What is the applicable product range of Segway-Ninebot Gokart Pro Automobili
Lamborghini Edition?
A: Segway-Ninebot Gokart Pro Automobili Lamborghini Edition KITs are suitable for the
following products:
1. Segway-Ninebot mini MAX
2. Segway-Ninebot miniPRO MAX
3. Segway-Ninebot MAX-PRO
4. Segwau-Ninebot miniPLUS, Segway miniPLUS, Segway miniLITE, products are not suitable
for the time being; Segway-Ninebot Gokart Pro Automobili Lamborghini Edition doesn’t sold
separately.
Q: Why does Segway-Ninebot Gokart Pro Automobili Lamborghini Edition failed to charge
after continuous use?
A: This battery is protected against overheating. If the battery / frame temperature exceeds
40 ° C, it cannot be charged, and it will return to normal when left to stand below 40 ° C. Do
not use the vehicle for a long time (you must turn off the battery to completely cool down after
using).
Q: How long does the dry batteries can be used continuously?
A: The 6 dry batteries can be theoretically use about 28 hours. Because the battery capacity of
different brands of dry batteries are different and the use time will also vary.

Model:Model: Gokart Pro Lamborghini
DOA:
Complete replacement
12 Month Warranty*:
All returns accepted excluding items that have received physical damage
by the owner/end-user
Warranty does not apply to any:
a) Damage caused by nature or acts of God, for example, lightning strikes, tornadoes
and the like;
b)Negligent or incorrect use of the Product;
c) Commercial use of the Product;
d)Modifications to any part of the Product;
e) Damage caused by use with non Segway-Ninebot products;
f) Damage caused by negligence, accident, abuse, misuse, flood, fire, earthquake or
other external causes;
g)Damage caused by operating the Product outside the permitted or intended uses
described by the manufacturer’s instructions provided by Segway-Ninebot or with
improper voltage or power supply;
h)Damage caused by servicing of the product (including upgrades and expansions)
performed by anyone who is not a representative of Panmi;
i) Damage caused by natural wear and tear.
Product Warranty



