Segway Ninebot KickScooter F25 User manual

Ninebot KickScooter
F25 / F30 / F30S / F40
Product Manual EN
CE.00.0050.91-B
The manufacturer reserves the right to make changes to the product, release firmware updates, and update this manual at any
time. Visit www.segway.com or check the Segway-Ninebot app to download the latest user materials. You must install the app,
activate your KickScooter, and obtain the latest updates and safety instructions.
EN
EN The pictures shown are for illustration purposes only. The actual product may vary.
www.segway.com

Diagram
1
EN
Bell
Handlebar Electric Throttle
Snap Hook
Dashboard & Power Button
Safety Hook
Brake Lever
Headlight
Stem
Folding Mechanism
Quick-release lever
Front Fork
Front Fender
Hub Motor
Charge Port
Footboard
Buckle
Rear Fender
Rear Light
Disc Brake
Kickstand
Battery Compartment
01

Dashboard & Power Button
Power Button: Press the button to turn on; press and hold the button for 3 seconds to turn off. When the KickScooter is on, press the button
to turn on/off the headlight and the rear light, and press twice to switch between the speed modes.
Speedometer: It displays the current speed of the scooter, as well as error codes.
Please switch between metric and imperial units via the Segway-Ninebot app. How to switch: Tap the slide menu > Settings.
Speed Mode: There are three modes available. The top speed is as follows:
Error Notification: It indicates that the scooter has detected an error.
Temperature Warning: If the temperature warning is on, it indicates that the battery temperature has reached 131°F (55°C) or is below
32°F (0°C).
* At this point, the vehicle cannot accelerate normally and may not be charged. Do not use until the temperature has reverted to the
normal range.
Bluetooth: It indicates that the scooter has been successfully connected to the mobile device.
Battery Level: When the battery is at its full capacity, it will show 5 bars.
* The battery power is very low when the first battery bar is red. Please charge your KickScooter immediately.
Speedometer
Bluetooth
Headlight
Temperature Warning
Speed Mode
Error Notification
Battery Level
Power Button
Model
Mode F25 F30 F30S F40
9.3 mph (15 km/h)
15.5 mph (25 km/h)
15.5 mph (25 km/h)
9.3 mph (15 km/h)
15.5 mph (25 km/h)
15.5 mph (25 km/h)
9.3 mph (15 km/h)
18.6 mph (30 km/h)
18.6 mph (30 km/h)
ECO (Energy-saving mode)
D (Standard mode)
S (Sport mode)
Approx. 45 × 18.9 × 45.7 in (1143 × 480 × 1160 mm)
Approx. 45 × 18.9 × 19.5 in (1143 × 480 × 495 mm)
Approx. 32.4 lbs (14.7 kg)
Specifications
2
Product
Rider
Machine
Battery
Motor
Charger
Ninebot KickScooter
F25
Item Parameter
Name
Model
Length × Width × Height
Folded: Length × Width × Height
Net Weight
Payload
Recommended Age
Required Height
Max. Speed
Typical Range[1]
Max. Slope
Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Nominal Energy
Battery Management System
Output Power
Input Voltage
Max. Output Voltage
Rated Output
Brake Light
Riding Modes
Tire Pressure
Tires
40–45 psi
10-inch pneumatic tires.
LED Rear Light
Energy-saving mode, Standard mode and Sport mode
0.07 kW, 70 W
100–240 V~
42 V 41 V , 1.7 A
Nominal Power 0.3 kW, 300 W
36 V
42 V 32–104°F (0–40°C)
5100 mAh
183 Wh
Over-heating, short circuit, over-current, over-discharge and
over-charge protection
Approx. 15.5 mph (25 km/h)
Approx. 12.4 miles (20 km)
Approx. 12%
Asphalt/flat pavement; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
14–104°F (-10–40°C)
14–122°F (-10–50°C)
IPX5
Approx. 3.5 h
66–220 lbs (30–100 kg)
14+ years
3’11”–6’6” (120–200 cm)
[1] Typical Range: tested while riding under full power, 165 lbs (75 kg) load, 77°F (25°C), 60% of max. speed on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
Features
Tire
02 03

Approx. 15.5 mph (25 km/h)
Approx. 18.6 miles (30 km)
Approx. 15%
Asphalt/flat pavement; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
14–104°F (-10–40°C)
14–122°F (-10–50°C)
IPX5
Approx. 5 h
Approx. 45 × 18.9 × 45.7 in (1143 × 480 × 1160 mm)
Approx. 45 × 18.9 × 19.5 in (1143 × 480 × 495 mm)
Approx. 33.3 lbs (15.1 kg)
Product
Rider
Machine
Battery
Motor
Charger
Features
Tire
Ninebot KickScooter
F30
Item Parameter
Name
Model
Length × Width × Height
Folded: Length × Width × Height
Net Weight
Payload
Recommended Age
Required Height
Max. Speed
Typical Range[1]
Max. Slope
Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Nominal Energy
Battery Management System
Output Power
Input Voltage
Max. Output Voltage
Rated Output
Brake Light
Riding Modes
Tire Pressure
Tires
40–45 psi
10-inch pneumatic tires.
LED Rear Light
Energy-saving mode, Standard mode and Sport mode
0.07 kW, 70 W
100–240 V~
42 V 41 V , 1.7 A
Nominal Power 0.3 kW, 300 W
36 V
42 V 32–104°F (0–40°C)
7650 mAh
275 Wh
Over-heating, short circuit, over-current, over-discharge and
over-charge protection
66–265 lbs (30–120 kg)
14+ years
3’11”–6’6” (120–200 cm)
Approx. 34.8 lbs (15.8 kg)
Approx. 18.6 mph (30 km/h)
Approx. 24.9 miles (40 km)
Approx. 20%
Approx. 6.5 h
0.35 kW, 350 W
10200 mAh
367 Wh
F40F30S
[1] Typical Range: tested while riding under full power, 165 lbs (75 kg) load, 77°F (25°C), 60% of max. speed on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
This product is certified to ANSI/CAN/UL-2272 by TUV Rheinland.
The battery complies with UN/DOT 38.3.
The battery complies with ANSI/CAN/UL-2271.
Federal Communications Commission (FCC) Compliance Statement for USA
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolledenvironment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Cet équipement est conforme aux limites d'exposition aux radiations de la IC définies pour un environnement non contrôlé.
Cet équipement doit être installé et utilisé à une distance minimale de 20 cm entre le radiateur et votre corps.
Industry Canada (IC) Compliance Statement for Canada
This device complies with Industry Canada license-exempt RSS standard (s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
CAN ICES-3 (B)/NMB-3(B)
Neither Segway Inc. nor Ninebot is responsible for any changes or modifications not expressly approved by Segway Inc. or
Ninebot. Such modifications could void the user's authority to operate the equipment.
Certifications
3
Model: F25 / F30 / F30S / F40
FCC ID: 2ALS8-KS0005
IC: 22636-KS0005
04 05
