SELF Electronics FLEX User manual

FLEX / FLEXIP

1
www.self-electronics.com
2
www.self-electronics.com
INSTRUCTION MANUAL
SERIES: FLEX / FLEXIP
ATTENTIONS
Read these instructions completely and carefully.
To reduce the risk of fire, do not install in a compartment smaller than L+1/2 inches by
9/16 inches by 9/16 inches.
Afin d’éviter tout risques d’incendie, ne pas installer dans un compartiment plus petit que
L+1/2 inch, par 9/16 inch, par 9/16 inch.
(L see formForm ①
Use only with SELV power supply or Class 2 power supply (For USA market)
CAUTION:
AVERTISSEMENT:
Dimensions: (mm/inches)
FLEX-LX-24V-K
* X: The quantity of LEDs, will be multiples of six.
24VDC
24VDC
0.06×X
0.06×X
-4~95°F
(-20~35°C)
-4~95°F
(-20~35°C)
(L+1/2”)×9/16”×9/16”)
(L+12)×15×15mm
(L+1/2”)×9/16”×9/16”)
(L+12)×15×15mm
Minimum mounting space
(L1xWxH)
Length(L) ta
Form ①
Model Rated input Power(w)
custom design
3-15/16"×X/6
(100×X/6)
custom design
3-15/16"×X/6
(100×X/6)
LAMP x1
Components:
Hard connector
x1
Mounting Channel
x1
Cover
x1
Optional
Input cable
x1
Soft connector
x1
Install LED fixtures directly:
21
3 4
LED POWER SUPPLY
Read the instruction carefully before installation，non-observance of this instruction may cause damage
to the fixture or hurt to human body. The installation must be carried out by a qualified electrician in
accordance with local or national codes.
Cut off the power supply before installation and maintenance !
Regularly check the light source , the LED power supply, the cord and other accessories.
If any part is damaged, the product should not be used.
Keep this instruction manual handy for future use
The light source of these product are non-changeable light diodes(LED).
Do not disassemble the product, as the light diode can cause damage to the eyes.
The production is indoor use only , suitable for damp locations.
0° magnetic mounting clip
X3
0° mounting clip
X3
+-
+-
FLEX-LX-24V-K FLEXIP-LX-24V-K
8(5/16”) 10(3/8”)
2.2(1/16”) 3.5(1/8”)
LL
FLEXIP-LX-24V-K
IP
IP20
IP43
or

Install LED fixtures with mounting channel :
(Only suitable for FLEX-LX-24V-K)
1
2
3
Cover
End Cut
1
2
1
2
LED POWER SUPPLY
3
www.self-electronics.com
4
www.self-electronics.com
4
≥1”
≥1”
5
6

!
R 1-3/8”(35mm)
R 1-3/8”(35mm)
R 9/16”(15mm)
R 9/16”(15mm)
5
www.self-electronics.com
6
www.self-electronics.com
or
3
Wiring diagram:
or
1
or
2!The cutted strip can still be used.
or
4
SELF Electronics Co.,Ltd.
No. 1345 JuXian Road, Ningbo Hi Tech Park, Ningbo, China 315103
15/9/2017
