SEMAK VitaJuice Pro Installation guide

OPERATIONS &WARRANTY MANUAL

Page | 2
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ...................................................... 4
VITAJUICE PRO WHATS IN THE BOX ....................................................... 6
ASSEMBLY INSTRUCTIONS...................................................................... 7
VITAJUICE PRO BREAKDOWN DIAGRAM ................................................ 8
OPERATING INSTRUCTIONS.................................................................. 10
CLEANING INSTRUCTIONS .................................................................... 11
TROUBLESHOOTING ............................................................................. 12
SERVICE & MAINTENANCE.................................................................... 13
SPARE PARTS ........................................................................................ 13
WARRANTY........................................................................................... 13
WARRANTY REGISTRATION .................................................................. 15
© Semak 2013

Page | 3

Page | 4
IMPORTANT SAFETY INSTRUCTIONS
Please read all of the instructions before using the Vitajuice Pro Juicer and ensure
that other operators also read and are made to understand all safety and operating
instructions. Save these instructions for Future reference. Thank you for purchasing
a Semak Vitajuice Pro Juicer.
1. Important notice: Ensure that the power supply is switched off before connecting
to the electric outlet.
2. Use only on AC 220-240V –50 Hz only.
3. Do not use an extension cord.
4. To avoid risk of electric shock, do not immerse cord, plug or motor end of the
appliance in water or any other liquid. Never put the VitajuicePro in a dishwasher.
5. Always switch off at the power outlet before removing the plug. Remove by
holding the plug - do not pull on the cord. When the appliance is not in use or
prior to cleaning, always switch off the power and remove the plug.
6. Disconnect the power cord from the electrical outlet when the VitajuicePro Juicer
is not in use.
7. The VitajuicePro Juicer should not be used by children or infirm persons and care
should be taken when used near these persons. The VitajuicePro should not be
used outdoors. Young children should be supervised to ensure that they do not
play with the appliance. Never leave the Juicer unattended.
8. Avoid physical contact with moving parts. The cutting blades are very sharp and
care is needed when handling cutting blades / disc, and only when the
VitajuicePro Juicer is disconnected from the power supply. Never attempt to touch
the cutting disc while the juicer is in operation.
9. Never operate the VitajuicePro without the pulp or juice containers securely in
place.
10.Do not use on the stove or let the cord come into contact with any hot surface.
11.Keep hands and utensils out of the pulp/juicing containers while using the Juicer
to prevent the possibility of severe injury to persons or damage to the unit. A
pusher is provided to press down the fruit/vegetables down the juicing chute,

Page | 5
never try to force anything down the juicing chute using your hands or any object
other than the pusher.
12.The Juicer features a safety mechanism that prevents the appliance from
operating if the handle is not securely locked into position. If you cannot lock the
handle into position, ensure the juicing cover is sitting on the unit correctly and
nothing is obstructing the juicing area.
13.Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, is dropped or damaged in any way. Return the appliance to Semak
Australia. (Manufacturer) or its Authorised Service Agent for repair.
Do not attempt to repair the machine.
14.For Safety reasons and to avoid maintenance by unskilled persons, the appliance
should always be returned to Semak Australia (Manufacturer) for adjustment or
repair if required.
WARNING
This appliance should be used according to the instructions.
MISUSE of this appliance will cause HAZARD.

Page | 6
VITAJUICE PRO WHATS IN THE BOX
Juice Jug Plate
Juice Jug
Pulp Container
Motor
Unit
Locking Handle
Juice collector
with spout
Filter with blades disc
Lid
Pusher

Page | 7
ASSEMBLY INSTRUCTIONS
1. Assemble the Juice Collector:
- Ensure the spout on the juice collector
aligns with the spout slot in the motor base.
- Push down to connect the juice collector
with the motor base.
2. Fitting the Cutting Blade Disc:
- Hold the outside of the Cutting Disc and
lightly push into Juice Collector until disc
locks into place. Turn to ensure smooth
operation.
3. Assemble the Lid:
- Place the Lid onto of the Juice Collector /
Base, ensuring that the locking points match.
The lid should sit into the pulp container.
4. Lock the Safety Handle into place:
- Pull the handle into the lid locking grooves
completely, otherwise the machine will not
start.
DISSASEMBLY INSTRUCTIONS
5. Dissable the blades disc:
- With one hand grasping the spout, and the
other on the blade disc, separate the blade
disc from the drive socket

Page | 8
VITAJUICE PRO BREAKDOWN DIAGRAM

Page | 9
Item No.
Description
1
Pusher
2
Polycarbonate Lid
3
Disc Blade Assembly
4
Juice Collector Assembly
5
Drive Socket
6
Juice Collector Rubber Buffer
7
Upper Base
8
Motor
9
Middle Base
10
Lower Base
11
Locking Arm
12
Roller
13
Locking Arm Cover
14
Front Touch Rod
15
Touch Spring
16
Touch Rod Track Rail
17
Locking Arm Fixer Cover
18
Touch Plate
19
Safety Switch
20
Locking Arm Fixer
21
Spring Block Slice
22
Power Indicating Switch
23
Circuit Board
24
Knob Switch
25
Juice Container Lid
26
Juice Filter Plate
27
Juice Container
28
Stainless Steel Housing
29
Pulp Container
30
Rubber Foot

Page | 10
OPERATING INSTRUCTIONS
1. Please save the operating instructions for future reference.
2. Make sure all of the detachable parts are assembled correctly before use.
3. Wash the fresh fruit and/or vegetable and cut them into small enough pieces (less
than 75mm diameter) to fit down the feeding tube. Ensure that the relevant
fruits/vegetables are skinned and cored if required.
4. Place the juicing jug under the spout.
5. Start the juicer by moving the power switch to the ON position.
6. Select the relevant juicing speed using the speed control as below:
Speed 1: Ideal for juicing apple, pineapple, carrot, cucumber, grape juice, etc.
Speed 2: Ideal for juicing pears, lemons, tomato
Speed 3: Ideal for juicing oranges and similar
Speed 4: Ideal for juicing mango, watermelon, and other melons
Speed 5: Ideal for juicing kiwifruit and similar.
7. Slowly put the prepared ingredients into the feeding tube and gently press them
downwards using the pusher towards the rotating filter. For maximum flavour and
freshness, consume juice immediately after preparation.
8. NEVER use utensils to push fruit or vegetables into the juicer.

Page | 11
CLEANING INSTRUCTIONS
Always unplug the VitajuicePro from the power source before cleaning.
1. Disassemble all detachable parts referring to instructions
2. Clean all detachable parts by rinsing with hot water. All detachable parts may
be cleaned excluding the motor unit or machine base parts. Wash with a HACCP
safe detergent and rinse clean for more stubborn soiling. A HACCAP sanitizer
may be used to minimize bacterial contamination. Repeat with fresh water until
the water runs clear.
3. Rinse the filter under the tap or wipe out residual with a soft brush (do not use
a hard brush to ensure you do not damage the fine micromesh filter)
4. Clean the motor unit with a damp cloth
5. Make sure the machine is clean and dry before you store it away.
Do not place any of the components in a dishwasher.
Clean motor base by wiping with a barely damp cloth only.
Never immerse the motor end, plug or cord in water or any other liquid.

Page | 12
TROUBLESHOOTING
Problem
Possible Cause
Solution
The Juicer does not
work
No power connection
Plug in unit to 220-
240V AC outlet
Parts have not been
assembled correctly
Check whether the
handle has been
slipped into the lock
groove
Increased vibration
and noise
The juicer is not on a
level surface
Place the juicer on a
level surface
The filter has not been
assembled in the right
way
Make sure the filter is
securely attached to
the motor base
Coarse or granulated
Juice
Check if the filter or
spout is blocked
Disconnect from
power and remove
any obstructions
The filter has been
placed incorrectly
Remove the filter and
place into motor base
securely

Page | 13
SERVICE & MAINTENANCE
For Service and Repair, contact Semak for your nearest Authorised Service Agent.
The Foodservice Industry is deemed a hostile environment within the scope of
AS/NZS 3760:2003. Semak VitajuicePro MUST be routinely electrically tested for
compliance with this standard if used commercially.
It is recommended that a Food Safety program such as HACCP be employed and that
routine service and repair be undertaken at the time of electrical testing to ensure
the correct operation and function of all parts. The equipment MUST be serviced
annually or sooner depending of the hostility of the environment in which it is
operated.
SPARE PARTS
Spare Parts, exploded views and wiring diagrams are available from our webpage. Go
to www.semak.com.au and locate the appliance in the product section for the above
information.
WARRANTY
Model VJP2013 is a Commercial Grade Juicer suitable for commercial use. This
product is guaranteed for 12 months from the date of purchase against mechanical &
electrical defects. If the fault is deemed caused by MISUSE/ABUSE the terms of the
warranty are invalidated. If the product has been opened or tampered with (ie. In an
attempt to repair it) the warranty is invalidated.
It is against company policy to authorize warranty repairs over the phone. Service
Agents will require a work order number from Semak to conduct warranty repairs.

Page | 14
SEMAKWARRANTY
THIS WARRANTY APPLIES ONLY TO PRODUCTS MANUFACTURED AND SOLD IN AUSTRALIA
The benefits conferred by this warranty are an alternative to all other rights and remedies
in respect of the product which the consumer has under the Trade Practices Act and similar
State and Territory Laws.
Semak Australia Warrant each new SEMAK appliance manufactured by SEMAK to be free
from defects in materials or manufacturing process for a period of 12 Months from the date
of original purchase.
Should defects due to faulty materials or manufacturing process develop within the
warranty period, the appliance will be repaired without charge providing all conditions of
this warranty are observed.
1. Proof of Purchase and Warranty card must be retained and available on request.
2. This Warranty is void if the equipment has been damaged due to misuses neglect or is
used for a purpose for which it was not suited; and no repairs, alterations or
modifications have been attempted by other than Semak or its authorised Service
Agent.
3. Semak Australia. Reserves the right to reject a claim for warranty if service is required
due to misapplication, improper installation, inadequate wiring, and incorrect voltage
conditions. Under no circumstances shall SEMAK or its agents bear responsibility for
consequential damages of any kind.
4. Where required by Statute or local authority, equipment must be installed by qualified
person in accordance with all relevant regulations. Failure to do this will void product
warranty.
5. Cost of transport of any appliance or part to and from SEMAK or its Service Agent is to
be paid by the owner.
6. A charge will be made where failure is due to neglect, abuse or accidental damage on
the part of the operator, or when no fault can be found or the fault is due to causes
outside the control of Semak Australia.
7. The above does not preclude the purchaser from their Statutory rights as a consumer.
Semak Australia
Factory 18
87-91 Hallam South Road
HALLAM VIC 3803
Ph [phone]
Fax [phone]
Email techn[email protected]

Page | 15
WARRANTY REGISTRATION
Retain for Future Reference
DO NOT SEND
Please complete one registration for each Semak appliance.
You may be required to provide this information when requesting after sales service. Please
staple your proof of purchase to this page.
Company Name: ________________________________________________
Company Address: ________________________________________________
Business Type: ________________________________________________
Contact: ________________________________________________
Phone: ________________________________________________
Fax: ________________________________________________
Email: ________________________________________________
Product: ________________________________________________
Serial Number: ________________________________________________
Date of Purchase: ________________________________________________
Place of Purchase: ________________________________________________

© 2013 Semak Australia
