SEMPLICE SHV302 Series Instruction Manual

TECHNICAL DRAWING | MEASUREMENTS IN MM
SHEET - 1/8
TECHNICAL FILES
SHV302X | T1.16I.BAD
WALL MOUNTED WASHBASIN MIXER WITH 2 HOLES, INTERNAL PART
SHV302 | T1.16I.BAD

COMPONENTS LIST | COMPONENTS DRAWING
T1.16I
01
02
03
04
05
06
07
08
SHV302 | T1.16I.BAD SHEET - 2/8
COMPATIBLE WITH:
T1.675
1
2
3
4
5
6
7
8
Cold water inlet G1/2”
Water outlet
Hot water inlet G1/2”
FIXING PLATE
SCREW
SPIRIT LEVEL
MONOBLOCK
HALF INCH CAP
CARTRIDGE
TECAFORM FASTENING NUT
P26377
P38629
PLASTIC PROTECTION
T1.16BE.SB
TECHNICAL FILES
SHV302X | T1.16I.BAD
WALL MOUNTED WASHBASIN MIXER WITH 2 HOLES, INTERNAL PART

ASSEMBLY INSTRUCTIONS
PICTURE 1 Aenon!!!
Before starng the installaon, the pipes must be properly
cleaned, to eliminate any dirt that may cause permanent
damages to the cartridge.
MINIMUM PRESSURE 1 BAR
MAXIMUM PRESSURE 10 BAR
RECOMMENDED WORKING PRESSURE 2-5 BAR
MAXIMUM WATER TEMPERATURE 70º/176º
MAXIMUM WATER TEMPERATURE RECOMMENDED 65º/149º
MAXIMUM INLET PRESSURE DIFFERENCE (HOT-COLD) 1.5 BAR
SHV302 | T1.16I.BAD SHEET - 3/8
OK
OK
Cold water
inlet G1/2”
Hot water inlet G1/2”
TECHNICAL FILES
SHV302X | T1.16I.BAD

ASSEMBLY INSTRUCTIONS
PICTURE 2 Ensure the water supply is turned off before proceeding to
the mixer installaon.
1- Verify on the picture “A” the maximum and minimum
measurements for internal part installaon.
Minimum 50 mm | Maximum 55 mm
2- Please mark the wall where the internal part T1.16I will
be placed.
3- Aer marking four fixaon points, drill the wall.
4- Screw the fixing plate with compable bolts (not
included), leaving them unght enough for the following
step.
SHV302 | T1.16I.BAD SHEET - 4/8
TECHNICAL FILES
SHV302X | T1.16I.BAD
OK
Turn o water
MIN.50 MM
MAX.55 MM
Picture A

ASSEMBLY INSTRUCTIONS
PICTURE 3
PICTURE 4
SHV302 | T1.16I.BAD SHEET - 5/8
TECHNICAL FILES
SHV302X | T1.16I.BAD
Cold water
inlet G1/2”
Hot water inlet G1/2”
Picture A
MIN.Ø 30 MM
MAX.Ø 40 MM
MIN.Ø 45 MM
MAX.Ø 50 MM
100 MM
1- Drill the holes on the coang, for the mixer and spout.
Mixer diameter: minimum 45mm | maximum 50mm
Spout diameter: minimum 30mm | maximum 40mm
2- Aer compleng step 1 proceed with the applicaon of
the coang.
END OF INSTALLATION
1- Confirm on the spirit level (included on the mixer seat)
that the piece is levelled with the floor. Aer ensuring the
alignment is correct, conclude the ghtening of the bolts.
2- Proceed to the water connecons, connecng cold and
hot water to the corresponding tubes.
3- Please guarantee that these connecons are done
correctly before placing the coang on the wall.
4- Ensure there is access to the cartridge for future
maintenance.

SHV302 | T1.16I.BAD SHEET - 6/8
1- Unscrew the handle with the help of the allen key.
2- Remove the handle from the top of the cartridge.
3- Unscrew the cartridge concealer from the tecaform locknut, then remove the hood from the
tecaform piece.
4- Unscrew the tecaform locknut with the help of a wrench. Aer this, you can remove the
cartridge.
To apply a new cartridge, please consider the reverse procedure.
12
3 4
CARTRIDGE REPLACEMENT
TECHNICAL FILES
SHV302X | T1.16I.BAD

We recommend regular maintenance of the tap, in order to assure its permanent good funcon. To clean the tap, please
use a smooth cloth with water and neutral soap. Never use products with abrasives substances, such as chloride acid,
ammonia, acetone, vinegar, bleach or abrasive sponges. The use of non-recommended products might damage
permanently the surfaces, which will annul the warranty.
WARRANTY
Waterevoluon guarantees all its products in case of manufacturing defects, as follows:
5 Year Warranty:
- Machining or casng faults and porosity defects;
- Cartridge and valve defects (the wear of this component depends on water quality);
- Chrome plang or PVD defects. Defects caused by improper use are excluded, please refer to the maintenance
instrucons.
2 year warranty:
- Powder Coang finishes. Defects caused by improper use are excluded, please refer to the maintenance instrucons.
Our responsibility is exclusively subject to defects originated on the producon process.
The warranty does not cover components subject to wear and tear, such as O-rings, gaskets, flexible hoses and joints for
connecons.
ATTENTION:
Natural finishes, such as brass or stainless steel, depend enrely on the exposure to the environment and maintenance.
Therefore, any stain that may appear cannot be considered a product defect.
The warranty gives the customer the right to have all the parts which due to a manufacturing fault do not work correctly,
replaced free of charge.
The following are excluded from the warranty:
- Items or parts which are damaged or do not work properly due to negligence in the use or wrong maintenance;
- Wrong installaon;
- Intervenon by unqualified people or circumstances beyond one’s control.
In order to use this warranty, please keep the invoice and aach it to this document. Defecve products must be sent to
Waterevoluon with shipping expenses borne by the sender. This warranty document and a copy of the purchase invoice
must be aached to the package. The products will be promptly replaced and sent back with shipping expenses borne by
Waterevoluon.
MAINTENANCE AND WARRANTY
SHV302 | T1.16I.BAD SHEET - 7/8
