Sencor SPR 4000BK Operation instructions

- 1 - 06/2019 Copyright © 2019, Fast ČR, a.s.
EN Pressure cooker
Translation of the original manual
SPR 4000BK

- 2 - 06/2019 Copyright © 2019, Fast ČR, a.s.
EN Pressure cooker
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
GENERAL WARNINGS
■
This appliance may not be used by children. Keep the appliance and its power cord
away from children.
■The appliance may be used by persons with reduced physical, sensory or mental
capabilities or with alack of experience and knowledge, if they are supervised or
have been instructed to use the appliance in asafe manner and understand the
potential dangers.
■Children must not play with the appliance.
■ In the event that the power cord is damaged, have it repaired at aprofessional
service centre to prevent causing adangerous situation. It is forbidden to use the
appliance if it has adamaged power cord.
■This appliance is designed for domestic use and similar locations such as:
– kitchens in stores; offices and other workplaces;
– in agriculture;
– for guests of hotels, motels and other similar locations;
– in bed and breakfast establishments.
■ Never open the pressure cooker by force. Never open the pressure cooker until you
have ascertained that its inner pressure has fallen completely. See“User’smanual”.
■ This pressure cooker must be used only in accordance with the instructions contained
in this user’smanual. Please read and follow these instructions.
■ The pressure cooker must not be left without supervision while in operation. In
particular, do not leave children in the vicinity of the pressure cooker while it is in
operation.
■Do not place the pressure cooker into ahot oven.
■When the pressure cooker is under pressure, handle it extremely carefully.
■ Do not use pressure cookers for any other purposes than those for which they have
been designed.
■ This cooker cooks under pressure. The incorrect use of this pressure cooker may
cause scalding. Check that the pressure cooker is properly closed before heating.
See chapter CORRECTLY HANDLING THE LID
■Never use the pressure cooker for frying food under pressure. Never use apressure
cooker without water. This could seriously damage it.
■ Do not overfill the removable inner pot above the maximum ingredients mark. When
cooking foods that expand during the cooking process such as rice or dehydrated
vegetables, do not fill the inner pot past half its volume.

- 3 - 06/2019 Copyright © 2019, Fast ČR, a.s.
■After cooking meat with skin, e.g. beef tongue, which may increase in volume, do
not puncture the meat if the skin is swollen as this could result in scalding.
■ When cooking pasta, gently shake the pressure cooker before opening it to prevent
ejecting food out of it.
■Before every use, check that the valves are not clogged or soiled.
■
Do not tamper with any of the pressure cooker’ssafety systems beyond the
instructions specified in this user’smanual.
■
Only use spare parts from the manufacturer for the corresponding model. Always use
the inner pot and lid from the same manufacturer, which is designated as compatible.
ELECTRICAL SAFETY
■ Before connecting this appliance to apower socket, make sure that the voltage stated on its rating label corresponds to the voltage in your
power socket
■ Connect the appliance only to aproperly grounded socket. Do not use an extension cord.
■ Never connect the appliance to apower socket until it is properly assembled.
■ Fully unwind the power cord before using it.
■ Do not connect and disconnect the power cord to and from the power socket with wet hands.
■ Ensure that the power plug contacts do not come into contact with water or moisture.
■ To prevent the risk of injury by electrical shock, never submerge the pressure cooker unit, the power cord or the power plug in water or any
other liquid.
■
Make sure that no water or any other liquid splashes on the power plug or the power socket, and that the hot steam emitted from the appliance
is also kept away.
■ Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket.
Disconnect the cord from the power socket by gently pulling on the plug of the power cord.
■ Do not place heavy items on the power cord. Make sure the power cord does not hang over the edge of atable or that it is not touching ahot
surface or sharp objects.
■
To avoid the danger of injury by electrical shock, do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments
of the appliance performed at an authorised service centre. Tampering with the appliance during the warranty period may void the warranty.
■ Always turn off the appliance and disconnect it from the power socket when you have finished using it.
SAFETY DURING USE
■
This pressure cooker is intended for cooking meals such as soups, rice, stewed meals, goulash and all other meals that can be cooked in standard
pressure cookers or in stew pots. Do not use it for purposes other than those for which it was designed.
■ This pressure cooker is designed for use in indoor areas only. Never use it in an outdoor or industrial environment.
■ Only use the pressure cooker on an even, dry, clean, stable and heat-resistant surface. Do not use the pressure cooker on the drainboard of
the kitchen sink.
■ Do not place the pressure cooker on the edge of atable, on unstable, inclining or uneven surfaces, on an electric or gas stove and other sources
of heat, or in their vicinity.
■ When cooking, do not place the pressure cooker directly on surfaces that are sensitive to heat, for example stone countertops. This type of
countertop is sensitive to uneven heat, and when heated in asingle point it may crack. In the event that you wish to use this pressure cooker
on aheat sensitive countertop, place acutting board or asimilar heat resistant material underneath it.
■ Never carry the pressure cooker by the swivel handle, always carry it using the carry handle on the pressure cooker.
■ Only use the removable inner pot that is supplied with this pressure cooker. Never use any other pot.
■
Do not use acracked, dented or otherwise damaged removable inner pot. Adamaged inner pot must be replaced with new pot of the original type.
■ Before inserting the removable inner pot into the built-in outer pot, check that the outer surface and the inside of the built-in outer pot is
completely clean and dry. To prevent damaging the built-in outer pot, there must be no dried on food remains, etc. on the outer surface of the
pot and the surface of the heating element.
■ Do not use the pressure cooker with an empty removable inner pot. This could seriously damage it.
■ Always open the lid according to the instructions in chapter CORRECTLY HANDLING THE LID.
■ Do not use the pressure cooker when it is not functioning correctly or after it has fallen on the floor, been submerged in water or is damaged
in any other way. Hand it over to an authorised service centre for inspection or repair.
■ Before connecting the pressure cooker to apower socket, make sure that the removable inner pot is properly seated in the built-in outer pot
and that it is filled with water and ingredients and that the lid is correctly positioned in place.
■ Do not connect the pressure cooker to apower socket or turn it on without the removable inner pot located inside the built-in outer pot.
Warning:
Do not pour water or place any food into the built-in outer pot. Food and water are to be put only into the removable inner pot.
■ Only use the pressure cooker with the original accessories that came with it.

- 4 - 06/2019 Copyright © 2019, Fast ČR, a.s.
Attention:
Using non-original accessories may result in adangerous situation arising.
■ When operating the pressure cooker, the lid must be tilted down and properly closed. Do not place any items on to the lid.
■ During operation, there needs to be sufficient area for air circulation above the pressure cooker and around it.
■ Do not use the pressure cooker in the vicinity of heat sensitive materials. Do not cover the pressure cooker or block its vents.
■
Ensure that the current of steam escaping through the pressure control valve and the safety float valve is not directed at heat sensitive materials
or at you or other people. Hot steam may cause serious scalding.
■ When using the KEEP WARM function, do not leave any spoons or ladles or any other kitchen utensils inside the removable inner pot.
■ When handling the pressure cooker after finishing cooking, it is necessary to be very careful not to touch the outer surface of the pressure
cooker or any other parts of the pressure cooker because they may still be hot as aresult of residual heat.
■ Do not touch the hot surfaces of the pressure cooker. After turning off and disconnecting the pressure cooker from the power socket, use the
carry handle to lift and carry the appliance. For reasons of increased safety, we recommend using kitchen gloves.
■ Use kitchen gloves when removing the inner pot after you have finished cooking.
■ Water from the lid may only drip into the removable inner pot, it must not drip into the built-in outer pot.
■ Do not place the hot lid on heat sensitive surfaces.
■
Always turn off and disconnect the pressure cooker from the mains power socket when not using it, when leaving it without supervision, before
removing the inner pot, steamer insert or metal insert, before cleaning, before performing maintenance or moving it. Never move the pressure
cooker during operation.
■ It is necessary to pay exceptional care when moving the pressure cooker filled with hot food or liquids.
■ Always allow the pressure cooker to fully cool down before removing the inner pot and before cleaning.
■
Regularly clean the pressure cooker after each use according to the instructions in chapter Maintenance and cleaning. Do not perform any
maintenance on the pressure cooker apart from the maintenance procedure described in chapter Maintenance and cleaning.
■ Only clean surfaces that are intended for coming into contact with food according to the instructions in this user’smanual.
Warning:
Incorrect use may lead to injuries.
■
The temperature of accessible surfaces on the pressure cooker is high when the pressure cooker is in operation and for acertain time afterwards.
Likewise, also the surface of the heating element retains residual heat after use.
■ To prevent scratching the non-stick surface inside the removable inner pot when cleaning it, always use wooden, silicone or plastic utensils.
■ Apart from the removable inner pot, no part of this pressure cooker is intended for washing in adishwasher.

- 5 - 06/2019 Copyright © 2019, Fast ČR, a.s.
DESCRIPTION OF THE APPLIANCE
2
2
1
3 L
Max
CUP
10
8
6
4
2
3
4
5
6
1
9
7
12
8
10
11
13
14
15
19
18
16
17
A
A

- 6 - 06/2019 Copyright © 2019, Fast ČR, a.s.
Manual
Preset
Count down
B
2
3
4
5
7
6
1
15
16
17
18
19
9
8
10
Preset
Count down
Manual
12
13
14
11
2
3
1
C
B

- 7 - 06/2019 Copyright © 2019, Fast ČR, a.s.
Manual
Preset
Count down
B
2
3
4
5
7
6
1
15
16
17
18
19
9
8
10
Preset
Count down
Manual
12
13
14
11
2
3
1
C
C
Pomocná čára
Pomocná čára
3
2
3
4
1
D
E
1
1
1
2
F
G
D

- 8 - 06/2019 Copyright © 2019, Fast ČR, a.s.
Pomocná čára
Pomocná čára
3
2
3
4
1
D
E
1
1
1
2
F
G
E
Pomocná čá
ra
Pomocná čára
3
2
3
4
1
D
E
1
1
1
2
F
G
F
Pomocná čára
Pomocná čára
3
2
3
4
1
D
E
1
1
1
2
F
G
G

- 9 - 06/2019 Copyright © 2019, Fast ČR, a.s.
EN Pressure cooker
User’smanual
■ Prior to using this appliance, please read the user’s manual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user’smanual. Keep this
user’smanual in asafe place where it can be easily retrieved for future
use. In the event that you hand this appliance over to somebody else,
make sure to also include this user’smanual.
■ Carefully unpack the appliance and take care not to throw away any
part of the packaging before you find all its parts. We recommend
saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty
card for at least the duration of the legal liability for unsatisfactory
performance or quality. In the event of transportation, we recommend
that you pack the appliance in the original box from the manufacturer.
DESCRIPTION OF THE PRESSURE COOKER
A1 Pressure cooker unit lid
A2 Inner pot lid
A3 Open lid button
A4 Pressure cooker unit
A5 Control panel with display
A6 Pressure cooker socket
A7 Steam release valve cover
A8 Safety float valve indicator
When the temperature and
pressure inside the pressure
cooker reaches acertain
level, the steam will push
the valve into ahole in the
lid, which will subsequently
push out the indicator. At the
same time, the mechanism
that locks the lid in place is
activated and prevents the
lid from being opened.
A9 Swivel handle
A10 Removable inner pot
A11 Built-in outer pot
A12 Carry handle
A13 Temperature sensor (inside
the built-in outer pot)
It monitors the internal
temperature and based on
it automatically regulates
heating intensity.
A14 Hotplate (inside the built-in
outer pot)
A15 Power cord
A16 Steamer insert
A17 Measuring cup
A18 Ladle
A19 Spoon
B1 Display
B2 Cancel / Keep Warm
Cancels the last performed
action / keeps food at an
ideal temperature for up to
24 hours to be served later
B3 Manual (Custom setting)
Enables custom cooking
time and temperature
settings.
B4 Add ingredient
Serves to release all steam to
enable the lid to be opened
safely during the cooking
process and the food inside
the inner pot to be handled.
B5 Cooking programs menu
B6 Minus (–) button
Serves to lower the time or
temperature value and to
scroll through the cooking
programs.
B7 Temperature
In the manual setting mode,
it enables the required
cooking time to be set in the
range from 30 to 160°Cin
5°Cincrements.
B8 Manual cooking mode
indicator
B9 Delayed cooking function
indicator
B10 Countdown indicator
B11 Locked lid indicator
B12 Unlocked lid indicator
B13 Pressure inside cooker
indicator
Indicates pressure inside the
cooker, which prevents the
lid from being opened.
B14 Heating element activity
indicator
B15 Start
It serves to start the cooking
process.
B16 Preset
Serves to activate the
delayed cooking function.
B17 Cooking program selection
button
Press this button to select
apreset cooking program.
B18 Plus (+) button
Serves to increase the time
or temperature value and to
scroll through the cooking
programs.
B19 Cooking time
Serves to set acustom
cooking time.
C1 Lid body
C2 Gasket seal
C3 Steam valve cover
D1 Magnetic float valve
D2 Float valve
D3 Steam release valve, inner part
D4 Temperature sensor
E1 Steam release valve cover
E2 Steam release valve, outer
part
E3 Float valve hole
F1 Steam release valve cover
latch
G1 Water condensate tank
PURPOSE OF USE
■ The electric pressure cooker is intended for cooking meals at high
pressure, which enables the cooking time to be reduced by more
than half, whilst retaining flavours and aromas of the cooked meal.
■ The pressure cooker can be used for cooking meals such as soups,
rice, stewed meals, goulash and all other meals that can be cooked
in standard pressure cookers or in stew pots. Furthermore, it enables
the cooking of legumes (beans, chickpeas, etc.) without pre-soaking
and it is also suitable for cooking healthier meals.
■ The pressure cooker can be used either in automatic mode by
selecting one of 15preset programs without having to perform
any other settings or in manual mode where the cooking time and
temperature can be set based on your needs and experience.
■
Afurther function of the cooker is delayed cooking; an automatic or
manually set function for keeping ameal warm after it has finished
cooking; or cooking with the lid open.
Attention:
This appliance is not intended to be operated using
an external timer switch or aremote control system.
BEFORE FIRST USE
■ Open the lid A1 as described in chapter OPENING THE LID OF ACOLD
PRESSURE COOKER. Take out the inner pot A10 and, together with
accessories A16 to A19, thoroughly wash in warm water using
neutral kitchen detergent.Then rinse them with clean water and dry
them thoroughly with afine wiping cloth.The inner pot can also be
washed in adishwasher.
■ Wipe the inside of the built-in outer pot A11 with alightly dampened,
soft wiping cloth and then wipe dry using adry, clean wiping cloth.
CORRECTLY HANDLING THE LID
OPENING THE LID OF ACOLD PRESSURE COOKER
■ Rotate the handle A9 anticlockwise all the way to the symbol and
then press button A3. If the pressure cooker is connected to the
mains power supply and in stand-by mode, the melody for “OPEN”
is played and the open lid indicator B12 is lit.
OPENING THE LID DURING AND AFTER COOKING
■
When cooking and after finishing cooking, it is only possible to open
the lid once the steam is released from inside the pressure cooker.
When it is not possible to rotate the handle A9 (the steam symbol
B13 is lit or flashing), it means that there is still steam inside the
pressure cooker, the temperature of which still presents adanger to
you. If this happens, hold down button B4 (Add ingredients). Steam
will be continuously emitted from the steam valve A7 and indicator
B13 will flash. When indicator B13 turns off, four dashes will be
shown on the display. The lid can now be opened.

- 10 - 06/2019 Copyright © 2019, Fast ČR, a.s.
Warning:
When releasing steam, keep away from the escaping
steam to avoid being scalded. Never place your hands,
arms or face in the vicinity of the steam release valve
A7 when it is releasing steam.
Attention:
When cooking food such as porridge or edible
seaweed, never release the steam by pressing button
B4 (Add ingredients), but rather allow the pressure
cooker to automatically release the pressure itself.
■
When all the steam has been released, first visually check the position
of the safety float valve indicator A8, see chapter FUNCTION OF
THE SAFETY FLOAT VALVE. If the safety float valve indicator A8 is
level with the hole in the cover, open the lid in the same way as on
acold pressure cooker.
CLOSING THE LID
■
Before closing the lid A1 always first check whether the lid A2 of the
inner pot is seated in position including the gasket C2 and the steam
valve cover C3. All these parts must be clean.
■ Push the lid down. Aproperly closed lid is indicated by an audible
click sound. Rotate the handle A9 clockwise all the way to the symbol
. If the pressure cooker is connected to the mains power supply
and in stand-by mode, the melody for“closed”is played, four dashes
appear on the display and the closed lid indicator B11 is lit.
FUNCTION OF THE SAFETY FLOAT VALVE
■ When the temperature and pressure inside the pressure cooker
reaches acertain value during the cooking process, the steam will
push the safety float valve D2 out the hole in the lid E3. The valve
will then push the indicator A8 out of the hole in the cover A7. At
the same time, the mechanism that locks the lid in place is activated
and prevents the lid from being opened. Thereby, the valve serves as
asafety mechanism that prevents the lid from being opened during
the cooking process and the indicator serves as avisual guide that
there is pressure inside the closed pressure cooker.
■ Before opening the lid A1, always first visually check the position of
the indicator A8. If the indicator is extended out of the hole in the
lid, then there is still pressure inside the pressure cooker. Wait until
the indicator retracts into the hole of the valve cover A7. Only then
may the lid be opened.
Warning:
When the indicator A8 is extended out of the hole in
the lid, never handle the pressure cooker or move it
around, rather always wait until
Note:
In the event that the indicator and thereby the safety float
valve does not retract into the hole in the lid even after
avery long time. (e.g. an hour or more) from the time
that the pressure cooker is turned off and steam has been
released and the pressure cooker unit is already cold, then
it is possible that the valve may have jammed, e.g. by the
effect of jammed food or due to the valve sticking to the lid
with food. If this occurs, then carefully open the lid in the
same way as with acold pressure cooker. When opening
the lid, as aprecaution, stand in such away that no part of
your body may be scalded.
OTHER SAFETY ELEMENTS OF THE PRESSURE COOKER
■ As soon as the pressure inside exceeds 110kPa, the pressure cooker
will automatically release steam through the valve D3. At the same
time, the valve is protected against being soiled by food by means
of the cover C3.
■ If the pressure inside the pressure cooker is high and is unsafe for
the user, it will not be possible to open the lid.
■ If the lid is not properly closed, the pressure cooker will not permit
the cooking process to start. The only exception are programs Fry
or Pasta, which enable cooking with the lid open.
■
If the removable inner pot A10 is not inserted, it will not be possible
to start the cooking process.
■
The temperature sensor D4 monitors the temperature inside the
pressure cooker and automatically adjusts the temperature of
the cooking process. If for any reason the temperature inside the
pressure cooker were to exceed acertain limit, the pressure cooker
will automatically disconnect the power supply and will not permit
cooking to continue.
■ In the event of overvoltage from the mains power supply, afuse will
disengage the circuit and thereby protect the electrical system of
the pressure cooker against damage.
PREPARING FOR COOKING
■ Place the pressure cooker on an even, rigid surface. Do not place the
pressure cooker on metal underlays.
■ Open the lid A1 as described in chapter CORRECT HANDLING OF
THE LID.
■ Make sure that the inside of the built-in outer pot A11 including the
hotplate A13 is clean and free of any food remains.
■ Place the removable pot A10 into the built-in outer pot A11 and
gently turn it to both sides to ensure that it is seated on the hotplate.
■ Place the ingredients and water if necessary into the removable pot
A10 so that the entire contents do not go over the MAX mark shown
on the inside of the pot. To ensure its proper operation and prevent
its damage, the pot must be filled up to at least the bottom mark on
the scale. In the event that the edges or the outer parts of the built-in
outer pot A11 or the inner pot A10 are soiled, clean them thoroughly.
■ Close the lid as described in chapter CLOSING THE LID.
TURNING ON THE PRESSURE COOKER
■ Insert the plug of the power cord A15 all the way into the connection
socket A6 on the side of the pressure cooker. Connect the power cord
plug to apower socket.The pressure cooker will play amelody and
switch to stand-by mode.
STAND-BY MODE
■ The stand-by mode means that the pressure cooker is ready for use.
If the lid is locked, the display will show four dashes and the locked
lid indicator B11 will be lit. If the lid is unlocked, the display will
show the text“OPEN”and the unlocked lid indicator B12 will be lit.
■ Set the pressure cooker to stand-by mode after connecting it to the
power supply or by pressing button B2 (Cancel/Keep Warm) at any
time while the pressure cooker is running.
COOKING
Attention:
Before and during cooking, always check that the
steam valve cover A7 is not covered, e.g. by awiping
cloth.
AUTOMATIC COOKING USING PRESET PROGRAMS
■ The electric pressure cooker has 15smart cooking programs. Each
of them has its predefined cooking time, temperature and pressure
level to enable you to easily achieve the best possible results.
Overview of the programs:
PROGRAM TITLE APPLICATION COOKING
TIME*
Fry FRYING
This program substitutes
for afrying pan. You can fry
with the lid closed or without
using the lid. It is also used
for adding colour, sautéing
and even gently cooking
ingredients.
0:30
Stew STEWING
This program is used for
cooking juicy meals similar to
those cooked in a standard
pressure cooker. It is not
necessary to add water. The
program is ideal for stewing
meat, livers, fish or vegetables.
0:15

- 11 - 06/2019 Copyright © 2019, Fast ČR, a.s.
Meat MEAT It is used for cooking all types
of meat. 0:15
Fish FISH It is used to cook fish. 0:10
Rice RICE It is used for cooking standard
or pre-cooked rice. 0:12
Bread BREAD It is used for baking bread. 1:45
Pasta PASTA It is used for cooking all types
of pasta. 0:05
Vegetables VEGETABLES It is used for cooking
vegetables. 0:05
Slow cook SLOW
COOKING
This program is suitable for
cooking foods that require
alonger cooking time.
1:00
Yoghurt YOGHURT
This program is suitable
for making yoghurt. Before
selecting it, first heat the milk
in steam for two minutes or
use pasteurised milk. Then add
the yoghurt culture into the
milk and select the YOGHURT
program. The program has
apreset ideal temperature
and time for making perfect
yoghurt and therefore does
not enable adjustment. After
the yoghurt making process
is finished and it has cooled
down, place the yoghurt into
arefrigerator to help it thicken
further.) Note:The yoghurt
culture can be commercial
unflavoured yoghurt, yoghurt
made earlier, yoghurt
powder mixture available in
supermarkets or ayoghurt
culture from ahealth food
store.
8:00
Desserts DESSERTS It is used for making desserts. 0:15
Bake BAKING
This program is suitable for
baking pies, cupcakes, biscuits
and other sweet foods as
well as baked meats, fish and
vegetables.
0:15
Cake CAKE
This program is used for
baking various types of cakes
or pies, including sponge cake.
0:45
Steam STEAM
COOKING
This program is for cooking
meals in steam, whereby
vitamins and the natural
flavour of the food is retained.
This program can also be used
for heating up cold or frozen
foods. The program utilises
the full power of the pressure
cooker, therefore, always use
it with the steamer insert A16,
which will ensure that the food
is not touching the bottom
of the removable inner pot
A10. When the program has
finished, we recommend that
the steam is manually released
as soon as possible using
button B4 so as to prevent
the food inside the pressure
cooker from overcooking.
0:10
Soup SOUPS This program is suitable for
making soups. 0:15
* The cooking time does not include the automatic preheating time, which
always differs depending on the type and amount of ingredients in the
pot A10.
■ Select the individual programs by pressing button B17 (Menu). The
first program to be activated is always Fry (frying), the other programs
follow cyclically in rows from left to right. You can also use buttons B6
(minus) and B18 (plus) to select programs. Each time that button B6
(minus) is pressed you will go back one program, and pressing button
B18 (plus) will move you forward by one program. The activation of
the individual programs is accompanied by abeep and the flashing
name of the respective program.
■ Once you have selected aprogram, press button B15 (Start). The
pressure cooker will play amelody and the cooking process will start.
Note:
If you do not press button B15 (Start) within 10seconds of
selecting acooking program, the pressure cooker will start
cooking automatically.
■
First, the pressure cooker is automatically preheated to the required
temperature and pressure, which is signalled by the heating element
activity indicator B14 and adashed rectangle running on the display.
Once the correct temperature is reached, the countdown indicator
B10 will be lit on the display and the actual cooking program will
start, during which the time will start counting down on the display.
Note:
The automatic cooking process can be interrupted at any
time by pressing button B2 (Cancel/Keep Warm).
■
When the timer reaches zero, the cooking process will end. The
pressure cooker will play the end of cooking melody and will switch
to the keep warm mode. This is the end of the program.
MODIFYING THE COOKING PROGRAMS
■
The cooking time can be arbitrarily changed on all the preset
programs. Select aprogram, press button B19 (Cooking Time) and
use buttons B6 (minus) or B18 (plus) to adjust the time as required.
■ After making this adjustment, start the cooking process by pressing
button B15 (Start). The cooking process will run in the same way as
with automatic cooking.
MANUAL COOKING
■
The electric pressure cooker also enables custom cooking parameters
to be set based on recipes, amounts of ingredients and your
personal preferences. Thus, you can set both the cooking time and
temperature.
■ Press button B3 (Manual).
- To set acustom cooking time, press button B19 (Cooking Time).
The hours indicator will start flashing. Use buttons B6 (minus) or
B18 (plus) to adjust the value. After pressing button B19 (Cooking
Time) again, the minutes value will start flashing; set this value
using buttons B6 (minus) or B18 (plus). The time can be set in the
range from 00:01 to 24:00.
- To set acustom temperature, press button B7 (Temperature).
The temperature indicator will start flashing. Use buttons B6
(minus) or B18 (plus) to adjust the temperature value as required.
The temperature can be set in the range from 30 to 160°Cin
5°Cincrements.
■ To start cooking, press button B15 (Start). The cooking process will
run in the same way as with automatic cooking.
Attention:
When using custom settings and cooking without
the lid A1, do not fill the inner pot A10 up to the
MAX mark and under no condition leave the pressure
cooker without supervision. Never use alid from
adifferent pot, always use only the supplied lid and
accessories.
ADJUSTING INGREDIENTS DURING THE COOKING PROCESS
■
If you wish to adjust the amounts of ingredients during the cooking
process, hold down button B4 (Add ingredient).The button’sindicator
will be lit, the display will show the letter “P”, the internal pressure
indicator B13 will start flashing and the pressure cooker will start
to automatically release steam. Once the steam is released and the
internal pressure is reduced, indicator B13 and button B4 will turn

- 12 - 06/2019 Copyright © 2019, Fast ČR, a.s.
off and four dashes will be shown on the display. Now it is possible
to open the lid and add or remove ingredients, etc.
Note:
This function is available for the Stew, Meat and Soup
programs.
COOKING WITH AN OPEN LID
■ Rotate the handle A9 to symbol and open the lid using button
A3. The display will show “OPEN” and the unlocked lid indicator
B12 will be lit.
■ On the open lid, rotate the handle A9 towards the symbol . The
display will show four dashes and the unlocked lid indicator B12
will be lit.
■ Select acooking program using button B17 (Menu).
■ To set the temperature, press button B3 (Manual), then B7
(Temperature) and use buttons B6 (minus) and B18 (plus) to set
the desired value.
■ To set the time, press button B19 (Cooking Time) and use buttons
B6 (minus) and B18 (plus) to set the desired value.
■ Press button B15 (Start). The cooking process will start even with
the lid open.
DELAYED COOKING FUNCTION
■
The delayed cooking function enables you to start cooking at atime
of your choosing. The minimum delay time is 10 minutes and the
maximum delay time is 24 hours.
Note:
This function is not available for the programs FRY,
YOGHURT, DESSERTS and CAKE.
■
Select acooking program and press button B16 (Preset). The minutes
indicator will start flashing. Using buttons B6 (minus) and B18 (plus)
set the minute value for delayed cooking.
■ To set the hours, again press button B16 (Preset) and use buttons
B6 (minus) and B18 (plus) to set the hours value.
■ Press button B15 (Start) to start the countdown. Indicators B8
(Manual), B9 (Preset) and B10 (Countdown) will be lit. As soon as
the time you set elapses, the pressure cooker will start the cooking
process.
KEEP WARM FUNCTION
■
The Keep warm function will keep food warm at apreset temperature
for up to 24 hours.
■ The function will start automatically when the pressure cooker
finishes the cooking process. The display will show the time 00:00
and the timer will start counting up in minutes.
■ The function can be started at any time by pressing button B2
(Cancel/Keep warm).
TURNING OFF THE PRESSURE COOKER
■ To completely turn off the pressure cooker, disconnect the power
cord A15 from the power socket.
CLEANING AND MAINTENANCE
Attention:
Apart from the removable pot A10, no part of
the pressure cooker is intended to be washed in
adishwasher.
The pressure cooker unit A4 is not intended to be
washed under awater tap. Do not spray the pressure
cooker unit or the power cord with water or any
another liquid, or submerge it in water or another
liquid.
Attention:
Never use chemicals, cookware scrubbers, steel wool,
or abrasive cleaning agents to clean the outside of the
pressure cooker unit A4 or the inside of the inner pot
A11 as this could damage the surface of the pressure
cooker unit or the inner pot.
■ Before cleaning, always disconnect the power cord A15 of the
pressure cooker from the mains power supply and pull it out of
the socket of the pressure cooker. Before removing the lid A1 and
taking out the inner pot A10, always leave the pressure cooker to
cool down completely.
REMOVABLE INNER POT AND ACCESSORIES
■ Wash the removable inner pot A10 in hot water with detergent, rinse
it and dry it thoroughly. If there are baked on food remains inside the
inner pot, then first allow it to soak for 20-30minutes in hot water
with detergent.The food remains can then be easily removed using
asoft kitchen brush. The pot can also be washed in adishwasher.
Note:
The colour of the inside surface of the inner pot A10 may
change during use. This is normal and in no way changes
the properties of the surface.
■ Wash the accessories A16 to A19 in hot water with detergent, rinse
them and dry them thoroughly.
PRESSURE COOKER UNIT AND THE BUILT-IN OUTER POT
■ Clean the outer surface of the pressure cooker unit A4 using asoft,
damp cloth and wipe it dry using adry wiping cloth.
■
Wipe the inside of the built-in outer pot A11 with alightly dampened,
soft wiping cloth and then wipe it dry using adry, clean wiping cloth.
■ Wipe the display using asoft sponge lightly dampened in warm
water. Adry sponge or cleaning agents could scratch the surface.
■ Carefully pull out the water condensate tank G1. Wash it in warm
water with asmall amount of kitchen detergent. Rinse it with clean
water, wipe it dry and put it back in its place.
LID OF THE REMOVABLE POT
■
Pull on the steam valve cover C3 to remove the lid of the removable
pot out of the pressure cooker unit. Push the cover out of the hole
of the lid body C1.
■ Gently pull the gasket C2 around the entire perimeter to remove
it from the lid body.
■ Wash the lid body in hot water with standard detergent, remove any
food remains using afine brush, rinse with clean water and wipe it
dry. Carefully wash the gasket and the cover in warm water with
asmall amount of kitchen detergent. Rinse with clean water and
wipe thoroughly until dry. Return the gasket and the cover back in
their place in reverse sequence.
■ If the gasket or the cover are worn out or damaged, contact the
supplier, who will order the respective part for you.
INNER PARTS OF THE PRESSURE COOKER LID
■ After removing the lid of the removable pot, also clean the bottom
(inner) part of the pressure cooker lid. Clean the surfaces of the lid
using asoft damp cloth or suitable soft brush.
■ Check the valves D1, D2 and D3 and the temperature sensor D4 for
soiling and if necessary carefully clean these parts using asoft brush.
Carefully pull the gaskets off the valves D1 and D2 and wash them
in hot water with detergent, rinse and dry them thoroughly. Return
both gaskets to their place.
Attention:
Never use the pressure cooker without the float valve
gaskets or if the gaskets are damaged.
OUTER PARTS OF THE PRESSURE COOKER LID
■ Clean the outer parts of the pressure cooker lid using asoft, damp
cloth and wipe it dry using adry wiping cloth.
■ Pull upwards to remove the cover A8 and cover E1 of the outer part
of the steam release valve E2.
■ Use adamp wiping cloth to clean the contact surfaces of the cover
A8 including the hole E3. Use asoft brush to clean the outer parts of
the steam release valve E2 and dry it using adry wiping cloth. Slide
the cover E1 back on to the outer part of the valve.

- 13 - 06/2019 Copyright © 2019, Fast ČR, a.s.
■ Press the latch F1 of the steam release valve cover and open up
the cover. Wash both parts of the cover, including the safety float
valve indicator A8 in warm water with detergent, rinse and dry
them thoroughly. Assemble the cover and return it back into the
pressure cooker lid.
Attention:
Before connecting the power cord into apower socket
and into the pressure cooker and before turning the
pressure cooker on again, allow all surfaces to cool
down completely.
PROBLEM POSSIBLE CAUSE REMEDY
The pressure
cooker cannot be
turned on.
The power is not
connected
Check the connection of
the power cord, plug and
the power socket.
The pressure
cooker lid cannot
be closed and
locked
The gasket of the
inner pot lid is not
seated correctly.
Check the correct position
of the gasket.
The safety float valve
indicator or the safety
valve itself is in the up
position.
Using asuitable tool
(e.g.skewer) push the
indicator and/or the valve
into the down position.
The lid of the
pressure cooker
cannot be
opened.
There is still pressure
inside the pressure
cooker.
Release the pressure from
inside the pressure cooker
using button B4 (Add
ingredients).
The pressure
cooker lid cannot
be opened
after the steam
has been fully
released.
The safety float
valve is still in the up
position.
Using asuitable tool (e.g.
skewer) push the valve
into the down position.
Alarge amount
of steam is
escaping around
the edge of the
pressure cooker.
The pressure cooker
lid is not properly
closed.
Check the correct
installation of the gasket
in the lid.
The inner pot lid
gasket is not in its
place or is soiled by
food remains.
Position the gasket
correctly on the lid or
clean it.
The inner pot lid
gasket is worn out or
damaged
Replace the damaged
gasket with anew one of
the same type.
The inner pot lid is
damaged or deformed
(e.g. by falling on the
floor).
Contact the service
department.
Alarge amount
of steam is
escaping from
the safety float
valve A5.
There are food
remains on the inner
pot lid gasket.
Remove the gasket from
the lid and clean it
The inner pot lid
gasket is worn out or
damaged
Replace the damaged
gasket with anew one of
the same type.
Steam is
continuously
escaping from
the steam valve.
Steam valve fault. Contact the service
department.
The hotplate is
not heating.
The pressure cooker
lid is not properly
closed.
Close the lid in the proper
manner.
The hotplate is faulty
or the power circuit is
defective.
Contact the service
department.
Code E1 is lit on
the display. Faulty bottom sensor. Contact the service department.
Code E2 is lit on
the display.
The temperature of
the bottom sensor is
too high.
Disconnect the power
supply and after the
pressure cooker cools
down, reconnect it. If
the fault does not go
away, contact the service
department.
Code E2 is lit on
the display.
Interrupted circuit of
the bottom sensor.
Contact the service
department.
Code E6 is lit on
the display.
Interrupted circuit of
the pressure cooker lid
sensor.
Contact the service
department.
Code C1 is lit on
the display.
Overheating
protection was
engaged.
Check whether there is
asufficient amount of
food and water inside
the pot and fill it up if
necessary. Then press B2
(Cancel/Keep warm). If the
code does not disappear
even after this, disconnect
the power supply and
after the pressure cooker
cools down, turn it on
again. If the malfunction
persists, contact the
service department.
Code E8 is lit on
the display.
The pressure switch
circuit is interrupted.
Contact the service
department.
Rice or food is
half cooked or
too hard.
Not enough water. Add water.
The pressure cooker
lid was opened
prematurely.
When the cooking cycle
has finished, leave the
lid closed for 5 minutes
or more.
Frozen food was
placed into the inner
pot.
Allow frozen food to
defrost before cooking it.
Rice is too soft. Too much water. Reduce the amount of
water.
There is water
behind the
pressure cooker.
The condensate tank
is full or condensate
water is dripping
down the surface of
the pressure cooker
unit.
Empty out the condensate
tank or select adifferent
location for the pressure
cooker so that steam has
more space above itself.
Wipe away the water.
The pressure
cooker is
emitting an
unpleasant
odour.
There are food
remains or other
materials on the outer
surface of the inner
pot or on the hotplate.
Check and if necessary
clean the contact surfaces
of the inner pot and the
hotplate.
STORAGE
■ Before storing it, the pressure cooker must be completely cool,
clean and dry.
■ Disconnect the plug of the power cord from the socket of the
pressure cooker.
■ Insert the removable inner pot A10 into the built-in outer pot A11.
The accessories A16 to A19 can be placed inside the inner pot A10.
■ If your storage space permits, it is recommended to keep the lid
A1 open to enable the inside of the pressure cooker to ventilate.
■ Place the pressure cooker in aclean, dry place out of reach of children.
Attention:
Keep the stored pressure cooker away from extreme
temperatures, direct sunlight and excessive humidity
and do not store it in an overly dusty environment. Do
not place anything on to the pressure cooker.
TECHNICAL SPECIFICATIONS
Rated voltage range...................................................................... 220−240 VAC
Rated frequency ........................................................................................50/60 Hz
Power output................................................................................................1 100 W
Capacity of the pressure cooker .......................................................................4 l
Pot dimensions.................................................................... 310 x 285 x 450 mm
Operating pressure....................................................................................... 70 kPa
Temperature range.................................................................................30-160 °C
Weight................................................................................................................ 6.7 kg
Protection class.................................................................................................. IPX0

- 14 - 06/2019 Copyright © 2019, Fast ČR, a.s.
EXPLANATION OF TECHNICAL TERMINOLOGY
Safety class for electrical shock protection:
IPX0 – The appliance is not protected against dangerous contact or
against the damaging effects of water, which could enter inside the
appliance.
Amendments to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in
your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling hand over these appliances to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance. Correct disposal of this product helps save valuable
natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details.
In accordance with national regulations penalties may be imposed for
the incorrect disposal of this type of waste.
This product meets all the basic requirements of EU directives
related to it.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer
or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
