Sencor SRV 9550BK Repair manual

08/2020
- 1 -
Copyright © 2020, Fast ČR, a.s.
EN Robotic Vacuum Cleaner
Translation of the original manual
SRV 9550BK

08/2020
- 2 -
Copyright © 2020, Fast ČR, a.s.
EN Robotic vacuum cleaner
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
General warnings
■This appliance may be used by children 8years of age and older
and by persons with physical or mental impairments or by
inexperienced persons, if they are properly supervised or have
been informed about how to use the product in asafe manner
and understand the potential dangers.
■ Children must not play with the appliance. Cleaning and
maintenance performed by the user must not be performed by
unsupervised children.
■ In the event that the power cord is damaged, have it repaired
at aprofessional service centre to prevent causing adangerous
situation. It is forbidden to use the appliance if it has adamaged
power cord.
■The robotic vacuum cleaner must only be used with the original
power adapter that came with it. In order to avoid adangerous
situation from arising, never use adifferent type of power adapter.
■Prior to cleaning or maintenance, always disconnect the robotic
vacuum cleaner from the power socket and turn it off using the
power button.
■Adhere to the instructions contained in this user’smanual when
performing cleaning and maintenance tasks.
■ For charging the robotic vacuum cleaner, only use the original
charging station that was supplied with it.
■The appliance must only be powered using asmall safe voltage
corresponding to the markings on the appliance.

08/2020
- 3 -
Copyright © 2020, Fast ČR, a.s.
Laser
The laser sensor meets the laser safety class according to
standard EN 60825-1.
■When using, handling or performing maintenance tasks on the
robotic vacuum cleaner with alaser sensor, always adhere to the
following instructions:
- Prior to any handling, turn off the robotic vacuum cleaner using
the power button.
- Do not point the laser beam at people.
- Do not look into the direct or reflected beam of the laser.
- Modifications or repairs of the laser sensor not performed by an
authorised service centre are forbidden.
Warning:
Not following the instructions contained in this
user‘smanual may result in dangerous irradiation!
Electrical safety
■Before connecting the adapter to apower socket check that the
technical details on the rating label match the electrical voltage
in the socket.
■Connect the power adapter only to aproperly grounded power
socket. Do not use an extension cord.
■Do not disconnect the power adapter from the power socket by
pulling on the power cord. This could damage the power adapter
or the power socket. Disconnect the power adapter from the
power socket by pulling on the plug.
■ Do not place the power cord of the power adapter over sharp
objects. Make sure that the power cord does not hang over the
edge of atable and that it is not touching aheated or hot surface.

08/2020
- 4 -
Copyright © 2020, Fast ČR, a.s.
■ It is forbidden to use apower adapter with adamaged plug or
power cord. For areplacement power adapter, please contact an
authorised service centre.
■ Never use the power adapter supplied with this appliance for any
other purposes.
■Keep the power adapter and its power cord dry.
■If the power cord of the power adapter is damaged, it must be
replaced by the manufacturer, its service technician or by asimilarly
qualified person, as this will prevent adangerous situation from
arising.
■Do not connect and disconnect the power adapter cord to and
from the power socket with wet hands.
■ Do not uncover the electronic parts of the robotic vacuum cleaner
or its battery.They do not contain any components repairable by
the user. Have the appliance serviced by qualified persons.
■To charge the battery, only use the power adapter supplied with
this robotic vacuum cleaner.
■To avoid any injury by electrical shock, do not spray the robotic
vacuum cleaner with water and do not submerge it in water or
any other liquid.
■ If you will not be using the robotic vacuum cleaner for an extended
period of time, take out the battery. Prior to taking out the battery,
ensure that the robotic vacuum cleaner is disconnected from the
power socket and that it is turned off using the main switch.
■ Do not use the robotic vacuum cleaner when it is not working
correctly, if it has been damaged or has been submerged in water.
■ To avoid the danger of injury by electrical shock, do not repair
the robotic vacuum cleaner yourself or make any adjustments
to it. Have all repairs performed at an authorised service centre.
Tampering with the robotic vacuum cleaner during the warranty
period may void the warranty.

08/2020
- 5 -
Copyright © 2020, Fast ČR, a.s.
■Prior to cleaning or maintenance, always disconnect the robotic
vacuum cleaner from the power socket and turn it off using the
main switch.
Safety during use
■This robotic vacuum cleaner is designed for use in households,
offices and similar types of areas. Do not use it in industrial
surroundings or outdoors.
■ The robotic vacuum cleaner is not intended for vacuuming water
and therefore must not be used in damp or wet areas, for example
in laundries, bathrooms or around swimming pools. If it were
to come into contact with water, the internal electronics of the
vacuum cleaner would be destroyed.
■Do not use the robotic vacuum cleaner to vacuum the following
items:
–smouldering cigarettes, burning or flammable items, matches
or ash;
–water and other liquids;
–sharp items, e.g. splinters, needles, pins, etc.;
–flour, wall plaster and other building materials;
– larger pieces of paper or plastic bags, which can easily block the
suction hole.
■Do not expose the robotic vacuum cleaner to direct sunlight and
do not place it near an open fire or appliances that are asource
of heat.
■ Do not use the robotic vacuum cleaner on narrow raised surfaces
such as tables, wardrobes, etc. If the vacuum cleaner does not have
sufficient space for manoeuvring, it may fall and be damaged.
■ Only use the robotic vacuum cleaner with the original accessories
from the manufacturer.
■Ensure that the robotic vacuum cleaner has adust filter correctly

08/2020
- 6 -
Copyright © 2020, Fast ČR, a.s.
installed in the dust container before use.
■Before putting the robotic vacuum cleaner into operation, check
that the entry door into your apartment or house is closed. From
the floor surfaces, remove clothing, paper, toys, power or extension
cords and other items that the vacuum cleaner could suck in or
catch. Lift curtains and drapes that reach to the floor so that they
do not get caught in the vacuum cleaner.
■Do not place any items on to the robotic vacuum cleaner and do
not step or sit on it.
■If the robotic vacuum cleaner is running, watch out for children
and household pets.
■ When the robotic vacuum cleaner is running, ensure that the air vents
are not covered and that the suction hole is not blocked. Otherwise,
the robotic vacuum cleaner may be damaged.
■Do not push on the laser navigation module or attempt to lift its
cover. This could damage the module.

08/2020
- 7 -
Copyright © 2020, Fast ČR, a.s.
SRV 9550BK
9
7
12
13
14
8
15
16
17
10
11
2
3
4
5
6
1
18
19
A

08/2020
- 8 -
Copyright © 2020, Fast ČR, a.s.
>0,5 m >0,5 m
>1,5 m
2
3
4
5
7
6
1
9
8
B

08/2020
- 9 -
Copyright © 2020, Fast ČR, a.s.
2
3
4
5
1
6
C

08/2020
- 10 -
Copyright © 2020, Fast ČR, a.s.
6
2
1
3
4
5
7
D

08/2020
- 11 -
Copyright © 2020, Fast ČR, a.s.
2
3
4
5
1
E

08/2020
- 12 -
Copyright © 2020, Fast ČR, a.s.
+
+
9
2
34
5
7
6
8
10
11
1
12
13
14
F
2
3
4
5
1
6
G

08/2020
- 13 -
Copyright © 2020, Fast ČR, a.s.
2
1
H
2
3
1
I
EN: Link to the application for controlling the vacuum cleaner APP Store Google Play

- 14 - 08/2020 Copyright © 2020, Fast ČR, a.s.
EN Robotic vacuum cleaner
User'smanual
■ Prior to using this appliance, please read the user'smanual thoroughly, even in cases,
when one has already familiarised themselves with previous use of similar types of
appliances. Only use the appliance in the manner described in this user’smanual.
Keep this user'smanual in asafe place where it can be easily retrieved for future use.
In the event that you hand this appliance over to somebody else, make sure to also
include this user'smanual.
■ We recommend saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for at least the
duration of the legal liability for unsatisfactory performance or quality. In the event
of transportation, we recommend that you pack the appliance in the original box
from the manufacturer.
■ Carefully unpack the appliance and take care not to throw away any part of the
packaging before you find all the parts of the appliance.
DESCRIPTION OF THE APPLIANCE AND ACCESSORIES
A1 Infrared signal sensor
A2 Anti-collision sensors (in the
bumper bar)
A3 Lidar-type laser sensor
A4 Inspection window
Enables one to check the amount of
debris inside the dust container
A5 Button for turning the automatic
cleaning mode on/off and for
turning off automatic cleaning
A6 Return to the charging station
button
A7 Side sensor
A8 Vents (on both sides of the vacuum
cleaner)
A9 Charging contacts
A10 Anti-fall sensor, central
A11 Side rotary brush
A12 Bottom anti-fall sensor, left
A13 Left motorised rubber wheel
A14 Central rotary brush
A15 Dust container / water tank with
dust container
A16 Front swivel wheel
A17 Bottom anti-fall sensor, right
A18 Top battery cover
A19 Right motorised rubber wheel
B1 Power indicator
B2 Charging station
B3 Charging contacts
B4 Cut-out for power adapter cable
B5 Storage compartment
B6 Power adapter plug socket
B7 Bottom cover
B8 Power adapter
B9 Power adapter plug
C1 Dust container with capacity of 480
ml
C2 Filter holder
C3 Fine filter
C4 HEPA filter
Highly effective air-borne particle
filter able to capture even the finest
dust particles.
C5 HEPA filter holder
C6 Latch for releasing the container
from the vacuum cleaner
D1 Water tank with capacity of 260 ml
D2 Rubber cap of the filling hole
D3 Filling hole
D4 HEPA filter
Highly effective air-borne particle
filter able to capture even the finest
dust particles.
D5 Dust container with capacity of
240ml
D6 Latch for releasing the dust
container
D7 Latch for releasing the water tank
from the vacuum cleaner
E1 Mop holder
E2 Latch for releasing the holder from
the vacuum cleaner
E3 Mop fastening velcro strips
E4 Mop fabric
E5 Mop attachment fastening groove
F1 Remote control
F2 Display
F3 Scheduled cleaning setting button
F4 System time setting button
F5 Forward direction button / increase
time value
F6 Left direction button / switch to
minutes
F7 Right direction button / switch to
hours
F8 Backwards direction button /
decrease time value
F9 Button for turning the automatic
cleaning mode on/off and for
turning off automatic cleaning
F10 Suction power adjustment button
F11 Start the along-the-walls cleaning
mode button
F12 Return to the charging station
button
F13 Battery compartment cover
F14 Battery compartment (2pcs AAA ×
1.5V)
G1 Rotary brush cover
G2 Latches
G3 Brushes
G4 Brush bearings
G5 Central rotary brush compartment
G6 Replacement rubber brush, suitable
for floating floors
H1 Cleaning brush H2 Blade
Serves to cut hair that is wound on
to the central brush
I1 Battery
I2 Connector
I3 Battery compartment
PURPOSE OF USE AND FEATURES OF THE ROBOTIC VACUUM
CLEANER
■ The robotic vacuum cleaner is intended for cleaning various types of hard floors
such as wooden or laminate floating floors, tiles, vinyl, etc. and carpets with alow
pile height. While vacuuming, it effectively combines various routes to optimally
clean the entire floor area.
■ The suction hole effectively removes hair, animal fur, etc. The side rotary brush
brushes dirt out of hard-to-reach places along walls and furniture and out of corners.
The motorised rubber wheels protect sensitive floors against scratching and can
travel over threshold strips up to aheight of 1.5 cm and ride on to a2 cm high carpet.
■ The suspended bumper enables the vacuum cleaner to dampen the approach to an
obstacle and to efficiently clean around it. The infrared sensors in the front bumper
prevent the robotic vacuum cleaner from colliding with obstacles. Safe operation in
rooms with stairs is made possible by the bottom anti-stair-fall sensors.
■ Another advantage of the robotic vacuum cleaner is the mop function, which
enables dry and wet wiping of smooth hard floor surfaces. While wiping, the vacuum
cleaner vacuums small bits of dirt and dust from the floor to prevent the mop fabric
from being excessively soiled during the cleaning cycle. When the vacuum cleaner
finishes cleaning, it will automatically shut off the supply of water and thereby limit
it leaking on to the floor.
■ For easy operating status identification, there is abutton on the cover fitted with an
indicator light, the colour of which indicates various operating states, see chapter
GUIDE TO LIGHT INDICATORS. Apart from the indicator lights, the vacuum cleaner
also has audio signals and voice messages that accompany certain functions or error
states of the vacuum cleaner.
■ Comfortable control is made possible by asmart device application that enables the
vacuum cleaner to be turned on and off, to be set to the automatic cleaning mode,
to select an operating mode, to send the robotic vacuum cleaner to the charging
station or to set scheduled cleaning.
■ The vacuum cleaner navigates within an area by means of aLidar-type laser sensor
and aGYRO MAPPING function, which can identify the space geometry of aroom in
which it is cleaning, and thereby the vacuum cleaner is able to better clean the floor.
This is abuilt-in function and cannot be affected in any way.
PREPARING FOR OPERATION
INSTALLING AND USING THE SIDE ROTARY BRUSH
■ The side rotary brush A11 is intended for smooth floor surfaces and ensures
effective cleaning in corners, along walls and furniture.
■ If the robotic vacuum cleaner is not supplied with the rotary brush already installed,
it is necessary to attach it. Turn the robotic vacuum cleaner upside down and push
the brush with force on to the pin.
Attention:
When turning the vacuum cleaner upside down for maintenance
tasks, ensure that it does not fall out of your hands on to the
floor or that you do not damage its laser sensor A3 when putting
it down. We recommend placing the vacuum cleaner on to
asuitable soft surface.
■ When using the robotic vacuum cleaner to clean rooms with carpets, remove
the side rotary brush. When removing it, proceed in the reverse sequence to its
installation.
LOCATION OF THE CHARGING STATION
■ The charging station B2 serves to automatically recharge the battery and the
vacuum cleaner must have good access to it.
■ Select alocation for the charging station that is hard, horizontal and dry, and that
is within reach of apower socket. Make sure that there are no stairs or obstacles
within adistance of at least 0.5m on the left and right of the charging station and
within adistance of at least 1.5m in front of the charging station, that would prevent
the vacuum cleaner from finding the charging station and docking successfully. It is
appropriate to position the rear part of the charging station against awall or apiece
of furniture.
■ Remove cover B7 from the underside of the charging station. Connect the power
adapter cable plug into the socket B6 in the body of the charging station and lead
the power cord through the cut-out B4 in the body of the charging station. Based
on the distance of the charging station from the power socket, the unneeded part
of the power cord can be wound up in the power cord compartment. Then put the
bottom cover back on.
■ Place the charging station in the selected location and insert the power cord plug
into apower socket. Place the remainder of the power cord in such away that it does
not tangle into the cleaning brushes of the vacuum cleaner.
■ In the event that the vacuum cleaner is not used for an extended period of time,
disconnect the charging station from the power socket and store it in adry, clean
and cool place.
CHARGING THE BATTERY FOR THE FIRST TIME
■ Before using the vacuum cleaner for the first time, it is necessary to fully charge the
battery for at least 5 hours.
■ Check that the charging station is correctly positioned and connected to apower
socket according to chapter LOCATION OF THE CHARGING STATION.
■ Hold down button A5 ( ) for more than 3 seconds. The indicator in buttons A5
( ) andA6 ( ) will start to flash slowly in blue colour and amelody will be
played. When the indicator is lit blue, the vacuum cleaner is ready for operation.

- 15 - 08/2020 Copyright © 2020, Fast ČR, a.s.
Note:
If the indicator is flashing or its colour is other than blue, please refer to
chapter GUIDE TO LIGHT INDICATORS.
If the indicator does not light up at all, the battery is completely flat.
In this case, pick up the vacuum cleaner and manually put it into the
charging station so that the charging contacts A9 on the underside of the
vacuum cleaner and the charging contacts B3 on the charging station are
connected. When the contacts are connected, the charging process will
start. When the battery is charged to agiven level, the vacuum cleaner
will turn on automatically.
■ Press button A6 ( ). The indicator light in buttons A5 ( ) andA6 ( ) will start
to slowly pulse in yellow colour. Avoice message will be sounded and the vacuum
cleaner will automatically start to seek out the charging station. After docking in the
charging station, the charging cycle will commence.
■ During the charging process, the indicator light in buttons A5 ( ) andA6 ( )
will slowly pulse in yellow colour.
■ When the battery is fully charged, the indicator light in buttons A5 ( ) andA6 (
) will be permanently lit blue and the charging process will stop automatically.
The vacuum cleaner is now ready for use.
Note:
Further details about automatic or manual charging of the robotic
vacuum cleaner are found in chapter CHARGING THE ROBOTIC VACUUM
CLEANER
INSERTING AND REPLACING BATTERIES IN THE REMOTE
CONTROL
■ Push down the latch of cover F13 on the rear side of the remote control F1 to release
it and remove the cover.
■ Insert two type AAA (1.5 V) batteries into the remote control. When inserting the
batteries, ensure the correct polarity as shown inside the battery compartment F14.
Put the cover F13 back on and click it into place.
■ In the event that the batteries are flat, replace them with new ones. Do not combine
various types of batteries or new and old batteries.
■ The signal range of the remote control is approximately 6 m.
SETTING SYSTEM TIME
■ The system time of the vacuum cleaner is the actual time according to your time
zone. It must be correctly set if you wish to use the scheduled cleaning function.
■ In the stand-by mode, hold down button F4 ( ) until the hour setting information
starts flashing on the display F2.
■ Using buttons F5 ( ) or F8 ( ) set the time value.Toggle between the hour and
minute numbers using buttons F6 ( ) or F7 ( ).
■ Confirm the set time by pressing button F4 ( ). The appliance will beep 2x and
the set time will be saved to memory as the system time.
■ In the event that no change is made within 10 seconds, the appliance will beep 2x
and the system time setting mode will automatically be cancelled. Time will not be
stored in memory.
OPERATION
Note:
Before starting the vacuum cleaner, always make sure that either the
water tank with the dust container, or just the dust container with the
respective HEPA dust filters, is inserted inside.
TURNING ON THE ROBOTIC VACUUM CLEANER
■ Hold down the On/Off button A5 ( ) on the vacuum cleaner for more than 3
seconds. The indicator in buttons A5 andA6 will start to flash slowly in blue colour
and amelody will be played. When the indicator is permanently lit blue, the vacuum
cleaner is in stand-by mode and ready for operation.
STAND-BY MODE
■ The stand-by mode means that the vacuum cleaner is idle but ready for operation.
Buttons A5 ( ) andA6 (  ) are backlit with ablue colour and the vacuum
cleaner awaits acommand.
■ Set the vacuum cleaner to the stand-by mode by pressing button A5 ( ) on the
vacuum cleaner or button F9 ( ) on the remote control at any time during its
operation.
SLEEP MODE
■ The sleep mode serves to save the battery'scapacity. The vacuum cleaner enters
sleep mode either automatically after five minutes of inactivity or when it is unable
to dock in the charging station. The backlight on buttons A5 ( ) andA6 ( )
will turn off and the vacuum cleaner will automatically switch to the sleep mode.
■ To wake the vacuum cleaner from the sleep mode to the stand-by mode, press
button A5 ( ) on the vacuum cleaner or button F9 ( ) on the remote control.
Note:
When the vacuum cleaner is in sleep mode, it is not possible to wake it
up using the mobile phone application. In sleep mode, it reacts only to
buttons A5 ( ) or F9 ( ) on the remote control.
Attention:
The battery is gradually discharged also in the sleep mode,
though slowly. If the vacuum cleaner is left in the sleep mode
for an extended period of time (several days), the battery may
become fully discharged. If this happens, the vacuum cleaner will
not react to any button that is pressed and it will be necessary
to place it into the charging station so that it can recharge itself.
GUIDE TO LIGHT INDICATORS
Colour of indicator in
buttons A5 ( )
andA6 ( )
Meaning
Blue – permanently lit Ready for operation
Blue – flashing slowly Active network configuration mode
Blue – pulsing slowly Vacuum cleaner system start-up / firmware upgrade
Yellow – flashing slowly Return to the charging station
Yellow – pulsing slowly Charging
Red – flashing quickly Problem
TURNING OFF THE ROBOTIC VACUUM CLEANER
■ If you wish to turn the vacuum cleaner completely off, hold down the On/Off button
A5 ( ) for more than 3 seconds. The indicator in button A5 ( ) andA6 ( ) will
turn off and power supply will be shut off. In the turned off state, the vacuum cleaner
does not react to any button other than again holding down button A5 ( ).
SELECTING THE CLEANING MODE
■ Before starting the cleaning process, check that the entry door into your apartment
or house is closed. From the floor surfaces, remove clothing, paper, plastic bags,
toys, power or extension cords and other items that the vacuum cleaner could
suck in or catch. Lift curtains and drapes that reach to the floor so that the vacuum
cleaner does not catch them.
Tip:
When vacuuming in a new environment for the first time, carefully
observe the movement of the vacuum cleaner. You can thereby recognise
problematic obstacles and remove them for the next cleaning session.
AUTOMATIC CLEANING MODE
■ Press button A5 ( ) or button F9 ( ) on the remote control.The vacuum cleaner
will enter the automatic cleaning mode, in which it first vacuums along the walls of
the selected area and then vacuums the inner areas using Z-shape movements. As
soon as the vacuum cleaner finishes cleaning, avoice message will be made and
the vacuum cleaner will seek out the charging station and dock there to recharge.
ALONG-THE-WALLS CLEANING MODE
■ Press button F11 ( ) on the remote control. The vacuum cleaner will enter the
along-the-walls cleaning mode, in which it moves along the perimeter of the room
and the motorised side rotary brush sweeps out the dirt along the walls, furniture
corners to achieve aperfect clean. As soon as the vacuum cleaner finishes cleaning,
it will seek out the charging station and dock there to recharge.
Note:
Other cleaning modes are available via the smart device application,
see chapter CONTROLLING THE VACUUM CLEANER USING THE MOBILE
APPLICATION
SELECTING SUCTION POWER
■ The vacuum cleaner has three suction power levels.
■ The suction power of the vacuum cleaner can be cyclically increased or decreased
by pressing button F10 ( ) during the cleaning process. The strongest level 3
is set as default.
- When pressed for the first time, it will beep 2x and the display will quickly show
MODE1 and the power will be set to the lowest level.
- When pressed for the second time, it will beep 2x and the display will quickly show
MODE2 and the power will be set to the middle level.
- When pressed for the third time, it will beep 2x and the display will quickly show
MODE3 and the power will be set to the highest level.
MANUALLY CONTROLLING THE MOVEMENT OF THE VACUUM
CLEANER
■ The direction buttons F5, F6, F7 andF8 ( , , , ) can be used to manually
control the movement of the robotic vacuum cleaner on the floor.When the vacuum
cleaner is moved on the floor, the operation of the side rotary brush is synchronised
with the movement of the motorised wheels. The vacuuming function is disabled
during this time.
■ When the direction button F5 or F8 is pressed, the robotic vacuum cleaner will move
in the respective direction. For continuous movement forward, hold down button
F5 or F8. Releasing the button will stop the movement of the vacuum cleaner.

- 16 - 08/2020 Copyright © 2020, Fast ČR, a.s.
■ When the direction button F6 or F7 is pressed, the robotic vacuum cleaner will turn
in the respective direction. To continuously turn the vacuum cleaner, hold down
button F6 or F7. Releasing the button will stop the turning of the vacuum cleaner.
■ In the manual movement control mode, the robotic vacuum cleaner moves
according to the direction buttons and the front sensors in the bumper bar and
the sensors on the underside of the vacuum cleaner that prevent collisions with
obstacles and falling from stairs.
PAUSING THE CLEANING PROCESS
■ Press button A5 ( ) or F9 ( ) on the remote control at any time during the
cleaning process to stop the vacuum cleaner in the place where it is cleaning. Press
one of the above-mentioned buttons again to continue with the commenced
cleaning process. Pausing and restarting the cleaning process is accompanied by
avoice message.
USING THE MOP
Assembly
■ The mop is used for dry and wet wiping of hard floor surfaces combined with
vacuuming. It consists of the holder E1 and amopping fabric E4. However, the mop
is not intended for cleaning carpets.
■ Attach the mopping fabric to the holder E1 using the Velcro zip E3 on the holder.
■ Insert the holder with the fabric into the groove E5 located on the underside of the
water tank D1.Then insert the water tank D1 assembled in this way into the vacuum
cleaner. For wet wiping (mopping) it is necessary to first pour water into the water
tank, see description below.
Attention:
The mop holder can only be attached to the water tank D1.
Therefore, only use the holder and the water tank that is intended
for this robotic vacuum cleaner model.
Always attach the mop holder on to the water tank away from
from the vacuum cleaner, and only thereafter insert the tank with
the holder into the vacuum cleaner. To attach the holder with the
mop to the tank when it is inserted in the vacuum cleaner would
require one to turn the vacuum cleaner upside down. This could
result in damage to the laser sensor A3 or other parts of the
vacuum cleaner, e.g. by being dropped on the floor or the sensor
being excessively pushed in against the floor.
Dry wiping of floors
■ Dry wiping is used for removing fine dust and floor polishing.
■ Insert the assembled water tank D1 with the mop holder into the vacuum cleaner.
There must be no water poured into the water tank D1.
■ Start the vacuum cleaner.
Wet wiping of floors
■ Wet wiping (mopping) is used for wiping away minor dirt and floor polishing. It will
not, however, remove resistant stains such as dry stains from coffee, etc.
■ Assemble the water tank D1 with the mop holder. Tilt open the rubber cap D2 on
the water tank and fill it up with clean water through the filling hole D3. Properly
push the cap back on and wipe away any water remaining on the water tank.
■ Insert the water tank D1 into the vacuum cleaner.
■ Start the vacuum cleaner.
Note:
The vacuum cleaner is equipped with an electronically-controlled water
pump that automatically doses the water on to the fabric and also stops
dosing water at the end of the cleaning process to prevent water from
leaking on to the floor or the charging station.
For wiping, we recommend using clean water. If you use acleaning agent,
it may foam up and thereby worsen the dripping of the water on to the
fabric, or potentially cause smudges on the floor after it dries.
Removing the mop from the water tank
■ If you wish to remove the holder with the mop from the water tank, first take the
water tank out of the vacuum cleaner and turn it upside down.
■ Pressing latches D7 will release the holder with the mop, which can then be easily
pulled out of the groove in the water tank.
SCHEDULED CLEANING
Note:
The scheduled cleaning time setting is based on the system time of the
vacuum cleaner. Therefore, before setting the scheduled cleaning time,
it is necessary to correctly set the system time as described in chapter
SETTING THE SYSTEM TIME.
■ This function enables scheduling the vacuum cleaner to automatically start cleaning
at acertain time once per day.
■ When the smart device application is used to control the vacuum cleaner, it is
possible to schedule adifferent cleaning time for each individual day of the week.
Please follow the instructions in the application.
Setting scheduled cleaning:
■ In the stand-by mode or in the charging in the charging station mode, hold down
button F3 ( ) until the hours setting value starts flashing on the display F2.
■ Using buttons F5 ( ) or F8 ( ) set the time value. Toggle between the hour and
minute numbers using buttons F6 ( ) or F7 ( ).
■ Confirm the set time by pressing button F3 ( ). Two beeps will be made and
the set time will be saved to memory as the automatic cleaning time. The vacuum
cleaner will clean at this time every day.
■ In the event that no change is made within 10 seconds, the appliance will beep 2x
and the scheduled cleaning time setting mode will automatically be cancelled.Time
will not be stored in memory.
Note:
If you wish to use automatic cleaning, then it is appropriate to leave the
vacuum cleaner in the charging station.
Cancelling scheduled cleaning
■ Hold down button F3 ( ). The set automatic cleaning time will start flashing on
the display.
■ Using the arrows F5 to F7 set the value 00:00.
■ Hold down button F3 (  ). Two audible beeps will be heard. Thereby the set
cleaning time has been cancelled.
CONTROLLING THE VACUUM CLEANER USING THE MOBILE
APPLICATION
■ The vacuum cleaner can also be controlled using a smartphone or tablet. The
application enables you to select the cleaning mode, stop the cleaning process or
send the vacuum cleaner to the charging station; it provides an overview of how
much time was spent cleaning and about the condition of the vacuum cleaner.
■ The application is freely available in the Apple App Store or Google Play Store. This
link for this application is found in the picture part of this user'smanual.
Note:
The robotic vacuum cleaner supports Wi-Fi in the 2.4 GHz frequency band.
If unsure about which standards are used by your Wi-Fi network and your
router, please contact your internet service provider or the manufacturer
of the router.
■ After downloading and installing the application on the smart device, set the
vacuum cleaner to the network configuration mode by simultaneously holding
down buttons A5 ( ) and A6 (  ) for more than 3 seconds. Two beeps and
a voice message about network configuration will be made. The indicator on
buttons A5 and A6 will start flashing blue. If you wish to cancel the network
configuration mode, press any button on the remote control or one of the buttons
A5 and A6 on the vacuum cleaner.
■ Launch the application. After registration, the application will guide you through
the process for connecting the vacuum cleaner to your Wi-Fi network.
CHARGING THE ROBOTIC VACUUM CLEANER
AUTOMATIC CHARGING
■ When the vacuum cleaner finishes cleaning or when it detects alow battery voltage
during operation, the indicator on button A5 ( ) andA6 ( ) will start slowly
pulsing yellow. A voice message will be sounded and the vacuum cleaner will
automatically start to seek out the charging station.
■ In order for it to find it and dock, it needs to find the infrared signal transmitted
by the charging station. For this reason, we recommend leaving the charging
station constantly connected to the power grid and located in accordance with the
instructions provided in chapter LOCATION OF THE CHARGING STATION.
■ In the event that the vacuum cleaner is for some reason unable to find the charging
station (too many obstacles, incorrect location, etc.) avoice message will be made
requesting the vacuum cleaner to be placed in the vicinity of the charging station.
■ After docking in the charging station, the charging cycle will commence. A full
charge takes approximately 5 hours. The actual charging time depends on the
power level of the battery. Afully charged battery will provide up to 200 minutes
of operation.
■ During the charging process, the indicator light in buttons A5 ( ) andA6 ( )
will continue to slowly pulse in yellow colour. When the battery is fully charged, the
indicator lights on both buttons will remain permanently lit blue and the process
will end automatically.
■ In the event that the charging contacts are disconnected during the charging cycle,
the vacuum cleaner will move away from the charging station and then re-dock
itself to resume the charging process, unless it is prevented from doing so by an
obstacle. In the event of apower outage, the charging cycle will be interrupted and
will continue after the power supply is renewed. In the event that the maximum
charging current is exceeded, the charging station will automatically interrupt the
charging cycle.
Note:
When the vacuum cleaner is docked in the charging station, it is not
possible to turn it off completely by pressing button A5 ( ) on the
vacuum cleaner or button F9 ( ) on the remote control. If this is
attempted, avoice message will inform you that the vacuum cleaner must
first be removed from the charging station.

- 17 - 08/2020 Copyright © 2020, Fast ČR, a.s.
MANUAL CHARGING
■ When the vacuum cleaner is located away from the charging station and detects
alow battery voltage, the indicator on button A5 ( ) and A6 (  ) will start
slowly pulsing yellow. Press button A6 ( ) on the vacuum cleaner or button F12
( ) on the remote control The vacuum cleaner will automatically seek out the
charging station and start automatic charging as described in the previous chapter.
■ If the battery is so flat that the vacuum cleaner is unable to seek out the charging
station then it is necessary to dock the vacuum cleaner into the charging station
manually. Pick up the vacuum cleaner and manually place it into the charging
station so that the charging contacts on the underside of the vacuum cleaner and
the charging contacts on the charging station are connected. When the contacts are
connected, charging will start.
CARING FOR THE BATTERY
■ We recommend that you do not interrupt the charging cycle and maintain the
battery in acharged state.
■ Do not leave the vacuum cleaner completely flat for an unnecessarily long period
of time. Abattery that is allowed to remain flat for along time may self-discharge
below apermissible level and thereby cause irreparable damage to itself.
REPLACING THE BATTERY
■ Make sure that the vacuum cleaner is turned off. Turn the vacuum cleaner upside
down and remove the screws from the top part A18 of the battery.
■ Tilt the battery I1 out of the storage compartment I3 and pull the connector I2to
disconnect it from the control board of the vacuum cleaner. To disconnect the
connector it is necessary to use greater force to overcome the safety mechanism
against spontaneous disconnection. Remove the battery.
■ Insert the connector of the new battery into the control board and place the battery
into the storage compartment being careful not to damage the connector cables.
Screw the top part of the battery into place.
Attention:
Use only the original battery type.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE AND SOLUTION
The vacuum cleaner
cannot be turned on.
Battery is almost or completely flat. Charge the battery.
Manually place the vacuum cleaner on to the charging
station.
The ambient temperature is too low or too high (lower than
0°C or higher than 50°C). Locate the vacuum cleaner in
an environment with atemperature in the range from 0°C
to 40 °C.
The vacuum cleaner
is running but it is
vacuuming dust and dirt
poorly or not at all.
The dust container is full. Empty it out.
The dust filter in the container is not properly installed or
is excessively soiled. Check the position and cleanliness of
the filter.
The central rotary brush is clogged with material or hair is
tangled on it, and it is not turning. Clean out the brush and
the suction hole.
The vacuum cleaner
is making an unusual
noise while cleaning.
The central rotary brush, side rotary brush or one of the
motorised wheels is wrapped with material or tangled into
an obstacle (cables, etc.).
The vacuum cleaner
travels only backwards
when it is turned on.
The vacuum cleaner was placed on afloor that is too dark.
Move the vacuum cleaner to alighter-coloured floor and
start it again.
One of the bottom sensors is soiled. Clean the all the sensors.
The bristles on arotary
brush are deformed and
do not sweep up dust
and dirt.
The bristles are worn out. Dip them in warm water to renew
their original shape. Contact the vendor or service centre and
order anew brush.
Cleaning did not
occur at
the scheduled time.
The battery was not sufficiently charged. Scheduled cleaning
will only start when the battery is charged to at least 30%.
The vacuum cleaner was completely off. After performing
scheduled cleaning, it must be in the stand-by or sleep
mode.
The vacuum cleaner
did not travel on to the
charging station.
The charging station is not connected to mains power.
Connect it.
The vacuum cleaner is too far away from the charging
station. Carry the vacuum cleaner by hand to the vicinity of
the charging station.
The charging station is not located according to the
instructions in this user'smanual and the vacuum cleaner
has poor access to it.
The vacuum cleaner is in
the charging station but
is not charging.
Check that the charging station is connected to the power
grid. Clean the charging contacts on the charging station and
the vacuum cleaner.
The vacuum cleaner did
not connect to the Wi-Fi
network.
Weak Wi-Fi network signal or the vacuum cleaner is out of
its range.
Incorrectly entered password.
Your router transmits in the 5 GHz broadcast band but your
vacuum cleaner can only receive signals in the 2.4 GHz
broadcast band.
Indicator on buttons
A5 ( ) andA6 ( )
is rapidly flashing red.
The control system of the vacuum cleaner has detected
aproblem, that may include the vacuum cleaner being lifted
off the ground, the dust container / water tank sliding out of
the vacuum cleaner during the charging process, the wheels
or brushes becoming blocked during operation, etc. Attempt
to identify what has caused the problem and attempt to fix
it. If the red flashing of the indicators persists, try turning
the vacuum cleaner completely off and then on again
with button A5 ( ). If even this fails to help, contact an
authorised service centre.
CLEANING AND MAINTENANCE
■ Prior to cleaning, always turn off the vacuum cleaner by holding down button A5
( ).
■ For cleaning, never use abrasive cleaning products, solvents, etc.
■ Neglecting cleaning and maintenance may negatively affect the working order of
the vacuum cleaner and lead to its reduced performance.
Attention:
When turning the vacuum cleaner upside down for maintenance
tasks, ensure that it does not fall out of your hands on to the
floor or that you do not damage its laser sensor A3 when putting
it down. We recommend placing the vacuum cleaner on to
asuitable soft surface.
DUST CONTAINER AND DUST FILTER
■ Empty out the dust container after every use and clean it regularly. Push down
latch C6 to slide the dust container C1 out of the vacuum cleaner, slide out the filter
holder C2 atip the dust and dirt out of the container and filter.. For hygiene reasons,
we recommend doing this away from living areas.
■ Pull the holder C5 to remove it and then remove the dust filter C4 from it. Tap out
the dust filter and its holder or clean these parts using the brush H1. Check the
condition of the filter and if damaged, replace it with anew one.
■ Tilt out the fine filter C3 out of the holder C2 and clean carefully using abrush.
■ In the event of greater soiling, the dust container and the filter holder can be
completely washed under running water. After washing them, it is necessary to
allow all the components to dry completely.
Attention:
Do not wash the main container, the dust container or the dust
filter in adishwasher. The dust filter C4 must not be washed using
water.
Before putting the vacuum cleaner back into operation, check
that the dust filter is in its location. Otherwise the vacuum cleaner
may be damaged.
■ Assemble all the parts to the initial state and slide the main container back into the
vacuum cleaner.
WATER TANK WITH THE DUST CONTAINER
■ Empty out the dust container A5 contained inside the water tank D1 after every use
and clean it regularly. Push down the latch D7 to release the water tank from the
vacuum cleaner. Push down the latch D6 to slide the dust container out of the water
tank, open it and tip out the dirty material. For hygiene reasons, we recommend
doing this away from living areas.
■ Pull out the dust filter D4 and tap it out or clean it using the brush H1. Check the
condition of the filter and if damaged, replace it with anew one.
■ Use adamp cloth to also clean out the inside of the dust container. In the event of
greater soiling, the water tank and the dust container can be completely washed
under running water. After rinsing both containers, it is necessary to allow them
to dry completely.
Attention:
Do not wash the assembled water tank, the dust container or the
dust filter in adishwasher. The dust filter D4 must not be washed
using water.
Before putting the vacuum cleaner back into operation, check
that the dust filter is in its location. Otherwise the vacuum cleaner
may be damaged.
MOP
■ After every dry or wet wiping, remove the mop fabric from the holder, wash it by
hand in lukewarm water with the addition of asmall amount of gentle washing
powder and allow it to dry naturally.
■ Wipe the mop holder with alightly dampened cloth or wash it under running water
and then dry thoroughly.

- 18 - 08/2020 Copyright © 2020, Fast ČR, a.s.
CENTRAL ROTARY BRUSH
■ Push on the latches G2 of the central rotary brush cover G1 and take the cover out
together with the brush.
■ Use adry wiping cloth to clean out the compartment G5 in which the rotary brush
is housed. Also clean the suction hole, the procedure is described later in this
user'smanual.
■ Remove any dirt and material (dust, wound on hair, animal fur, etc.) from the rotary
brush G3 and the bearings G4. You can cut heavily wound on hair using the blade
H2 of the cleaning brush.
■ Reinsert the rotary brush and its cover.
Attention:
In the event that an excessive amount of dirty material
accumulates on the central rotary brush and in its compartment,
there is a risk of permanently damaging the vacuum cleaner.
Regularly inspect the condition of the brush.
Do not use the vacuum cleaner without the central rotary brush.
■ When using the rubber rotary brush G6 instead of brush A14, proceed in the same
manner when cleaning it.
SUCTION HOLE
■ The suction hole is located underneath the central rotary brush, therefore, take it out
before cleaning the suction hole as described in the previous chapter. With repeat
use, dust and dirt may accumulate around the suction hole, which may manifest
itself through decreased suction efficiency. Remove the dirt and dust from the
suction hole using asoft brush. Regularly clean the suction hole to ensure maximum
suction power.
SIDE ROTARY BRUSH
■ Take out the rotary brush A11 by pulling it upwards. Remove any dust and dirt from
the location where the brush was mounted.
■ Remove all dust and dirt from the brush. If necessary you may wash the brush under
running water. If the bristles were deformed while the vacuum cleaner was running,
dip them in warm water to allow them to return to their original shape. Allow the
brush to dry before reattaching to the vacuum cleaner.
■ After cleaning it, reattach it.
Note:
The rotary brush wears out with use. After acertain time it is necessary to
replace the worn out brush with anew one. To order anew brush, contact
your vendor or an authorised service centre.
COMPLETE ROBOTIC VACUUM CLEANER
■ Regularly wipe the surface of the vacuum cleaner using asoft dry wiping cloth.
■ First remove any coarser dirty material from the front swivel wheel A16 and the
motorised wheels A13 and A19. Then clean them around their entire perimeter
using alightly dampened cloth and wipe them dry. Do not forget to also clean the
area around the wheels.
■ At least once per week, or more often, wipe the sensors A10, A12, A17 on the
underside of the vacuum cleaner and the side sensor A7 using asoft dry wiping
cloth or acotton bud.
■ Regularly clean the vents A8 along both sides of the vacuum cleaner.
CHARGING STATION
■ At least once per week, clean the surface of the charging station B2 including the
charging contacts B3 using asoft dry wiping cloth.
STORAGE
When not using the vacuum cleaner for an extended period of time, do the following:
■ Hold down button A5 ( ) to turn off the vacuum cleaner.
■ Clean the vacuum cleaner as described in chapter CLEANING AND MAINTENANCE.
■ Disconnect the charging station from the power socket.
■ Store the vacuum cleaner with all its accessories in adry, clean and cool place.
TECHNICAL SPECIFICATIONS
Robotic vacuum cleaner
Dimensions (diameter × height)................................................................................355 × 95 mm
Weight................................................................................................................................................3.8 kg
Motor power output .......................................................................................................................65 W
Operating time per single charge........................................................................... up to 200 min
Dust container capacity............................................................................................................ 480 ml
Water tank capacity.....................................................................................................................260 ml
Capacity of dust container inside the water tank.............................................................240 ml
Vacuuming system..................................................................................SUPER CYCLONE 8 000 Pa
Navigation system ....................................................................................................Sencor Nav. 18.0
Power adapter
Input.................................................................................................... 100–240 VAC, 50/60 Hz, 0.2 A
Output.................................................................................................................................5 V, 1,000 mA
Battery
Type............................................................................................................................. 6,200 mAh Li-Ion
Charging time.................................................................................................................................. 4–6 h
Input................................................................................................................................................. 5 V, 1 A
The declared noise emission level is lower than 69dB(A), which represents alevel Aof
sound power with respect to areference sound power of 1pW.
DISPOSAL OF USED BATTERIES
■ Prior to handing over the product at aspecialised collection facility, it is necessary
to ensure that the battery is removed. Prior to removing the battery, turn off the
vacuum cleaner using the main switch. Disconnect the battery according to the
procedure described in chapter REPLACINGTHE BATTERY.
This symbol indicates that used batteries do not belong in ordinary
municipal waste. Hand over used batteries to designated collection
points for proper disposal. Correct disposal of batteries will help
prevent negative impacts on the environment and human health.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of
used batteries, request the necessary information about the correct
disposal method from the local authorities or from your vendor.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC
EQUIPMENT
This symbol on products or original documents means that used
electric or electronic products must not be added to ordinary
municipal waste. For proper disposal, renewal and recycling, hand
these products over to determined collection points. Alternatively, in
some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent
new appliance.
Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and human health, which
could result from improper waste disposal. Ask your local authorities or collection
facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic devices, ask your retailer or supplier for
the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This product meets all the basic requirements of EU directives related to
it.
SENCOR hereby declares that radio device model number SRV 9550BK is in compliance
with directive 2014/53/EU. The full wording of the EU Declaration of Conformity is
available at the website: www.sencor.eu.
