Sencor SVC 6000BK User manual

01/2017
- 1 -
Copyright © 2017, Fast ČR, a.s.
EN Bagged Vacuum Cleaner
SVC 6000BK

01/2017
- 2 -
Copyright © 2017, Fast ČR, a.s.
EN Bagged Vacuum Cleaner
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
■This vacuum cleaner may be used by children 8 years of age and older
and by persons with physical or mental impairments or by inexperienced
persons, if they are properly supervised or have been informed about how
to use this vacuum cleaner in asafe manner and understand the potential
dangers. Children must not play with the vacuum cleaner. Cleaning
and maintenance performed by the user must not be performed by
unsupervised children. Keep the vacuum cleaner and its accessories out of
reach of children that are younger than 8 years of age.
■This vacuum cleaner is designed for use in households, offices and similar
types of areas. Do not use it in industrial surroundings or outdoors.
■Do not expose the vacuum cleaner to direct sunlight and do not place it
near an open fire or appliances that are asource of heat.
■Before connecting the power cord to a power socket, check that the
technical details on the vacuum cleaner’srating label match the electrical
voltage in the socket.
■Make sure the power cord is not touching ahot surface or sharp objects.
■Do not submerge the vacuum cleaner under water or any other liquid and
do not rinse it under running water.
■Before turning on the vacuum cleaner, make sure that the dust bag is
inserted inside and that the inflow micro-filter and the outflow HEPA filter
are installed in their place.
■When the vacuum cleaner is running, ensure that the air outlets and the
suction opening are not blocked.
■Do not use the vacuum cleaner to vacuum the following items:
– smouldering cigarettes, burning items, matches or embers;
– water and other liquids;
– flammable or volatile materials;
– sharp items, e.g. broken glass, needles, pins, etc.;
– flour, wall plaster, cement and other building materials;
– larger pieces of paper or plastic bags, which can easily block the suction
opening.

01/2017
- 3 -
Copyright © 2017, Fast ČR, a.s.
■Vacuuming of some types of floors or floor surfaces can create
anelectrostatic discharge, which presents no danger to the user.
■Do not place the suction nozzle or tube against any parts of the face.
■Always turn off the vacuum cleaner and disconnect it from the power
socket when leaving it without supervision, after finishing using it and
before cleaning it.
■Disconnect the power cord from the power socket by pulling on the plug,
never pulling on the cord. Otherwise, this could damage the power cord or
the socket. Hold the power cord in your hand when winding it up.
■If the power cord is damaged, have it replaced at aprofessional service
centre. It is forbidden to use the vacuum cleaner if it has adamaged power
cord.
■Do not use the vacuum cleaner if it is not working correctly, if it has been
damaged or has been submerged in water. Do not repair the vacuum
cleaner yourself or make any adjustments to it. Have all repairs or
adjustments performed at an authorised service centre. By tampering with
the appliance, you risk voiding your legal rights arising from unsatisfactory
performance or quality warranty.

01/2017
- 4 -
Copyright © 2017, Fast ČR, a.s.
1
2
4
3
A
5
6
7
8
11
12 13
14
15
16
17
9
10

01/2017
- 5 -
Copyright © 2017, Fast ČR, a.s.
18
19
20
21
A
B
1 2

01/2017
- 6 -
Copyright © 2017, Fast ČR, a.s.
EN Bagged Vacuum Cleaner
User'smanual
■ Prior to using this appliance, please read the user’smanual thoroughly,
even in cases, when one has already familiarised themselves with
previous use of similar types of appliances. Only use the appliance in
the manner described in this user’smanual. Keep this user’smanual in
asafe place where it can be easily retrieved for future use.
■ We recommend saving the original cardboard box, packaging material,
purchase receipt and responsibility statement of the vendor or warranty
card for at least the duration of the legal liability for unsatisfactory
performance or quality. In the event of transportation, we recommend
that you pack the appliance in the original box from the manufacturer.
DESCRIPTIONOFTHEVACUUMCLEANERANDITS ACCESSORIES
A1 Removable grill of the outflow
HEPA filter
A2 Washable outflow HEPA filter
is placed behind the grill.
A3 Automatic power cord
winding button
A4 Electronic suction power
control
A5 Full dust bag indicator
A6 Flexible hose connection hole
A7 Top cover locking and
releasing clip
A8 Integrated handle
A9 On/Off button of the vacuum
cleaner
A10 Rubber-coated rear travel
wheel
A11 Front swivel travel wheel
A12 Groove for the vertical
parking position
A13 Groove for the horizontal
parking position
A14 Dust bag*
A15 Dust bag holder
A16 Grill of the inflow micro-filter
A17 Washable inflow micro-filter
is placed in the grill.
A18 Flexible hose with mechanical
suction power control in the
handle
A19 Telescopic metal tube
A20 Floor nozzle with an
extensible brush
A21 2-in-1 brush and slot nozzle
Note*:
One disposable microfibre (nonwoven textile) bag is included.
PREPARING FOR USE
■ Make sure that the dust bag A14, inflow micro-filter A17 and outflow
HEPA filter A2 are properly installed.
■ Slide the end of the flexible hose A18 fully into the hole A6.
Note:
When disassembling, it is necessary to press both locking clips at
the end of the hose A18 while at the same time pulling the hose
A18 out of the hole A6.
■ On to the handle of the flexible hose A18, place the telescopic tube
A19 and set it to the required length as follows. Release the clip on the
telescopic tube A19 and slide it towards the extensible part of the tube
A19. After releasing the clip, set the length of the tube A19 by sliding
its extensible part in or out. When the clip is released, it will lock in at
the set length.
■ Connect the floor nozzle A20 to the free end of the telescopic tube A19.
The flap on the floor nozzle A20 serves to extend and retract the brush.
■ The 2-in-1 brush and slot nozzle A21 can be attached directly to the
handle of the flexible hose A18 or to the telescopic tube A19.
USING THE VACUUM CLEANER
■ Pull on the power plug to wind out the required length of the power
cord and connect it to apower socket.
Attention:
The yellow mark on the power cord indicates the approaching
end of its length, and the red mark indicates the complete end of
its length. Do not attempt to pull the power cord past this mark.
■ To start the vacuum cleaner, press button A9. When vacuuming smooth
hard floor surfaces, extend the brush on the floor nozzle A20, and
retract the brush when vacuuming carpets. The slot nozzle can be used
for vacuuming hard to reach places and the brush nozzle for vacuuming
various types of furniture.
■ Suction power can be set using the electronic control slider A4 or the
mechanical flap on the handle of the flexible hose A18.
■ When you have finished using the vacuum cleaner, turn it off by
pressing button A9 and disconnect the power cord from the power
socket. To wind the power cord back into the vacuum cleaner, press
and hold button A3 until its entire length is wound up. Gently hold the
power cord with one hand while winding it up.
Note:
If the power cord is not wound up completely, release button
A3, and pull the power cord out of the vacuum cleaner by
approximately 50 cm and then try again to wind it up.
PARKING POSITION OF THE VACUUM CLEANER
■ When not using the vacuum cleaner, you may put it in the parking
position. For the horizontal parking position, use the stopper on
the floor nozzle A20 and the groove A13, see fig. B1. For the vertical
parking position, first set the shortest length of the telescopic tube A19.
Then put the vacuum cleaner in avertical position, and slide the stopper
on the floor nozzle A20 into the groove A12, see fig. B2.
MAINTENANCE AND CLEANING
■ Before cleaning it, always make sure that the vacuum cleaner is turned
off and disconnected from the power socket.
Changing the dust bag
■ The need to replace the dust bag is signalled by the indicator A5.
■ Release the clip A7 and open the top cover of the vacuum cleaner.
Remove the used dust bag A14 from the holder A15 and insert anew
bag intended for this type of avacuum cleaner in its place. If the dust
bag is not replaced in time, the vacuum cleaner’s suction power will
be reduced.
Cleaning and replacing the inflow micro-filter and the outflow HEPA
filter
■ Release the clip A7 and open the top cover of the vacuum cleaner. Slide
the grill A16 out of the vacuum cleaner and take the micro-filter A17 out
of it. Rinse it under running lukewarm water and allow to dry naturally.
Then reinsert it and close the cover. In the event that the micro-filter A17
is showing signs of wear or it is heavily soiled, replace it with anew one.
■ Release and remove the grill A1. Remove the HEPA filter A2 from the
vacuum cleaner. In the case of light soiling, tap it out. We recommend
doing this away from living areas. In the event of greater soiling, wash
it under aweak current of running lukewarm water so that the water
washes the dirt out of the folds. Allow the HEPA filter A2 to dry naturally,
then reinsert it and secure it in place with the grill A1. It is recommended
to replace the HEPA filter with anew one after 6 months of use.
■ When filters are soiled, their effectiveness is reduced, so do not neglect
their cleaning.
Attention:
Before putting the filters back into the vacuum cleaner, make
sure that they are completely dry.
Cleaning the flexible hose, telescopic tube, floor nozzle and the
2-in-1 attachment
■ If the vacuum cleaner accessories are soiled, remove them from the
vacuum cleaner and clean all dirt off of them (dust, hair, animal fur, etc.).
Cleaning the outer surface of the vacuum cleaner
■ Clean the outer surface using adry or alightly dampened cloth. Then
wipe it thoroughly dry.
■ For cleaning the vacuum cleaner, do not use steel wool, abrasive
cleaning products, solvents etc.
■ Do not submerge the vacuum cleaner under water or any other liquid
and do not rinse it under running water.
TECHNICAL SPECIFICATIONS
Rated voltage range...................................................................................220−240 V
Rated frequency .............................................................................................50/60 Hz
Rated power input...........................................................................................1 400 W
Maximum power input...................................................................................1 600 W
Electrical shock protection class...............................................................................II
Noise level .........................................................................................................81 dB(A)
Dust bag capacity......................................................................................................... 3l
HEPA filter efficiency class......................................................................................E12
Length of the power cord .................................................................................... 7 m
Operational radius .................................................................................................10 m

01/2017
- 7 -
Copyright © 2017, Fast ČR, a.s.
The declared noise emission level is 81 dB(A), which represents alevel Aof
sound power with respect to areference sound power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-duty
insulation.
We reserve the right to change text and technical specifications.
PRODUCT INFORMATION SHEET
Name / trademark Sencor
Model identification number SVC 6000BK
Energy efficiency class* E
Annual power consumption (in kWh)** 52
Carpet cleaning efficiency class D
Hard floor cleaning efficiency class A
Vacuum cleaner dust emission class A
Level of acoustic power in dB(A) 81
Rated power input (W) 1 400
* Class A (highest efficiency class, low power consumption) to Class G
(lowest efficiency class, high power consumption).
**Approximate annual power consumption in kWh per year based on
50 cleaning cycles. Actual power consumption will depend on how the
appliance is used.
The values are determined pursuant to (EU) No. 665/2013.
INSTRUCTIONS AND INFORMATION REGARDING THE
DISPOSAL OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling hand over these appliances to determined collection
points. Alternatively, in some European Union states or other
European countries you may return your appliances to the
local retailer when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and human
health, which could result from improper waste disposal. Ask your local
authorities or collection facility for more details.
In accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer
or supplier for the necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU directives
related to it.
