Seneca ST4000 User manual
SLOT0
SLOT4
SLOT8
SLOT1
SLOT5
SLOT9
SLOT2
SLOT6
SLOT10
SLOT3
SLOT7
SLOT11
DRIVE SLOT LOCATIONS
Online
Setting Alarms
Install Guide page 32
MIPO
Install Guide page 28
Connection to Server
Install Guide page 27
Hosts
Install Guide page 23
Volumes
Install Guide page 22
RAID Set or Pools
Install Guide page 16
Setting up the Network
Install Guide page 11
Login to GUI
Install Guide page 10
Mounting and Cabling
Install Guide page 5
*ST4000DQS*
ST4000DQS
ST4000DQS.0417
STORAGE QUICK START GUIDE
PLEASE STOP AND READ THIS DOCUMENT
CRITICAL INFORMATION:
DEFAULT LOG IN INFORMATION
Username: administrator
Password: P@ssw0rd
Note: This user has administrative privileges.
STOP
AND READ
SENECA ST4000 DUAL CONTROLLER
CONTENTS OF PACKAGE
Quantity Item
1 ST4000 Storage Appliance - Rackmount Enclosure
1 Set of Slide Rails Including Mounting Hardware1
2 AC Power Cords
1 USB “A” to “Micro” Cable
INSTALLATION STEPS
Download Resources
Install Guide page 3
Download the Installation Guide:
http://products.senecadata.com/PDF/support/storage/ST4000IG.PDF
MOUNTING SLIDER RAIL SET1
RAIL INSTALLATION - Rail suits square hole and round hole racks only
2436"
1
2
Repeat steps 1 and 2 for the front and back then tighten the screw. Repeat all
the steps for the second rail.
REAR CONTROLLER PANEL VIEW
1 Slide kit does not work with pre-threaded holes 2 Assumes SFP RJ45 transceivers installed 3 Assumes SFP+ slot empty for 10GbE DA Copper Cable or 10GbE SR transceiver installed 4 Transceivers available in four packs only
1GbE Mgmt Port
Port A0Port A1Port A2Port A3
12G SAS
Expansion
USB
Maint
To Disk
Expansion
Chassis “A”
To IP SAN “A” Switch
Controller “A”
To
Management LAN
Controller “B”
1GbE Mgmt Port
Port B0 Port B1 Port B2 Port B3
12G SAS
Expansion
USB
Maint
To Disk
Expansion
Chassis “B”
To
Management LAN
To IP SAN “B”Switch
See other side for connections and support information.
MAIN BACK PANEL CONNECTIONS
LOWER CONTROLLER “B”
I/O Port Connection Port Usage
Port B0 SFP+ Host Port 0
Port B1 SFP+ Host Port 1
Port B2 SFP+ Host Port 2
Port B3 SFP+ Host Port 3
12G SAS Expansion Disk chassis expansion port
MAIN BACK PANEL CONNECTIONS
UPPER CONTROLLER “A”
I/O Port Connection Port Usage
Port A0 SFP+ Host Port 0
Port A1 SFP+ Host Port 1
Port A2 SFP+ Host Port 2
Port A3 SFP+ Host Port 3
12G SAS Expansion Disk chassis expansion port
HOST PORT TRANSCEIVERS AVAILABLE4
Form Speed Cable & Connector Protocol
SFP+ 10GbE DA Copper, SFP+ iSCSI
SFP+ 10GbE Multi Mode, LCLC iSCSI
SFP 1GbE CAT6, RJ45 iSCSI
SFP+ 16GbE Multi Mode, LCLC Fibre Channel
NOTE: No transceiver required when using SFP+ Copper Cable
SMB/CIFS & NFS protocols are NOT supported
CUSTOMER SUPPORT
Arrow customer care group stands ready to assist with any hardware and operating system assistance.
Contact Seneca Digital Security and Surveillance Support:
Normal Business Hours Outside Business Hours
800.227.3432 option 5 888.227.9994
Available Monday–Friday 8am–6pm EST
First level of data protection and integrity begins with AC power protection.
Please consult your Seneca Account Manager for properly sized, uninterruptable power supply (UPS).
1 Slide kit does not work with pre-threaded holes 2 Assumes SFP RJ45 transceivers installed 3 Assumes SFP+ slot empty for 10GbE DA Copper Cable or 10GbE SR transceiver installed 4 Transceivers available in four packs only
WARNING: ALL EIGHT PORTS MUST BE CONFIGURED IN DUAL CONTROLLER MODE & OS MPIO MUST BE INSTALLED
DEFAULT 1GBE FIXED IP ADDRESSES2
LOWER CONTROLLER “B”
Port IP Address Mask Gateway
Management LAN 172.16.6.15 255.255.255.0 172.16.6.1
B0 10.0.10.34 255.255.255.0
B1 10.0.10.35 255.255.255.0
B2 10.0.10.36 255.255.255.0
B3 10.0.10.37 255.255.255.0
DEFAULT 1GBE FIXED IP ADDRESSES2
UPPER CONTROLLER “A”
Port IP Address Mask Gateway
Management LAN 172.16.6.14 255.255.255.0 172.16.6.1
A0 10.0.10.30 255.255.255.0
A1 10.0.10.31 255.255.255.0
A2 10.0.10.32 255.255.255.0
A3 10.0.10.33 255.255.255.0
WARNING: ALL EIGHT PORTS MUST BE CONFIGURED IN DUAL CONTROLLER MODE & OS MPIO MUST BE INSTALLED
DEFAULT 10GBE FIXED IP ADDRESSES3
LOWER CONTROLLER “B”
Port IP Address Mask Gateway
Management LAN 172.16.6.15 255.255.255.0 172.16.6.1
B0 10.10.10.7 255.255.255.0
B1 10.10.10.8 255.255.255.0
B2 10.10.10.9 255.255.255.0
B3 10.10.10.10 255.255.255.0
DEFAULT 10GBE FIXED IP ADDRESSES3
UPPER CONTROLLER “A”
Port IP Address Mask Gateway
Management LAN 172.16.6.14 255.255.255.0 172.16.6.1
A0 10.10.10.3 255.255.255.0
A1 10.10.10.4 255.255.255.0
A2 10.10.10.5 255.255.255.0
A3 10.10.10.6 255.255.255.0
