Senix HTX5-M User manual

58V MAX LITHIUM ION
HEDGE TRIMMER
Operator’s manual
Model: HTX5-M
For customer support, please call 1-800-261-3981 or send email to:
[email protected]
SAVE THIS MANUAL FOR FUTURE REFERENCE.

1WWW.SENIXTOOLS.COM
TECHNICAL DATA
TABLE OF CONTENTS TECHNICAL DATA
Model Number: HTX5-M
Motor: 40V Motor
Speed: 2800 SPM
Cutting Capacity: 2/3 in.
Weight (w/ Battery): 8.2 lbs
Product Dimensions: 38 x 8.5 x 8.5 in.
Battery/Charger: B25X5/CHX5
Battery: 58V Max Lithium Ion, 2.5 Ah
TECHNICAL DATA���������������������������������������������������������������������������������������������1
WORK AREA SAFETY................................................................2
ELECTRICAL SAFETY ...............................................................2
PERSONAL SAFETY ����������������������������������������������������������������������������������������2
SPECIFIC RULES FOR HEDGE TRIMMERS��������������������������������������������������� 3
COMPONENT LOCATION
KNOW YOUR HEDGE TRIMMER���������������������������������������������������������������������4
OPERATION������������������������������������������������������������������������������������������������������5
ATTACH /REMOVE THE BATTERY������������������������������������������������������������������5
PREPARING THE HEDGE TRIMMER ��������������������������������������������������������������5
STARTING THE HEDGE TRIMMER �����������������������������������������������������������������5
TRIMMING HEDGES ���������������������������������������������������������������������������������������5
MAINTENANCE
CLEANING THE HEDGE TRIMMER�����������������������������������������������������������������6
CARBON BRUSHES�����������������������������������������������������������������������������������������6
LUBRICATION���������������������������������������������������������������������������������������������������6
SHARPENING THE BLADES����������������������������������������������������������������������������6
STORAGE AND TRANSPORTATION ���������������������������������������������������������������6
PARTS
EXPLODED VIEW���������������������������������������������������������������������������������������������7
WARRANTY
LIMITED TWO-YEAR WARRANTY�������������������������������������������������������������������9

2 WWW.SENIXTOOLS.COM
SAFETY
SAFETY
Safety is a combination of common sense, staying alert
and knowing how your item works. SAVE THESE
SAFETY INSTRUCTIONS.
WARNING — To reduce the risk of injury, user must
read and understand operator’s manual.
WARNING — To avoid mistakes and serious injury, do
not use this tool until the following steps
have been read and understood.
1. READ and become familiar with this entire instruction
manual. LEARN the tool’s applications, limitations, and
possible hazards.
2. AVOID DANGEROUS CONDITIONS. Do not use in wet
or damp areas or expose them to rain. Keep work areas
well lit.
3. DO NOT use in the presence of ammable liquids
or gases.
4. DO NOT direct the tool at any bystanders.
5. KEEP BYSTANDERS AT A SAFE DISTANCE from the
work area, especially when the tool is operating. NEVER
allow children or pets near the tool.
6. DO NOT FORCE THE TOOL to do a job for which it was
not designed.
7. DRESS FOR SAFETY. Do not wear loose clothing,
gloves, neckties, or jewelry (rings, watches, etc.) when
operating the tool. Inappropriate clothing and items can
get caught in moving parts and draw you in. ALWAYS
wear non-slip footwear and tie back long hair.
8. WEAR A FACE MASK OR DUST MASK if working in
dusty or dirty conditions.
9. ALWAYS remove the battery from the tool when making
adjustments, changing parts, cleaning, or working on
the tool.
10. AVOID ACCIDENTAL START-UPS. Make sure the
power switch is in the OFF position before inserting
the battery.
11. REMOVE ADJUSTMENT TOOLS. Always make sure
all adjustment tools are removed from the tool before
turning it on.
12. NEVER LEAVE A RUNNING TOOL UNATTENDED.
Turn the power switch OFF. Do not leave the tool until it
has come to a complete stop.
13. NEVER STAND ON A TOOL. Serious injury could
result if the tool tips or is accidentally hit. DO NOT store
anything above or near the tool.
14. DO NOT OVERREACH. Keep proper footing and
balance at all times. Wear oil-resistant rubber-soled
footwear. Keep the oor clear of oil, scrap, and
other debris.
15. WEAR NECESSARY hand and hearing protection.
Wear no-slip heavy duty work gloves and hearing
protection to prevent injury.
16. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools
clean and in good working order. Follow instructions for
lubricating and changing accessories.
17. CHECK FOR DAMAGED PARTS. Check for alignment
of moving parts, jamming, breakage, improper
mounting, or any other conditions that may a󰀨ect the
tool’s operation. Any part that is damaged should be
properly repaired or replaced before use.
18. DO NOT operate the tool if you are under the inuence
of drugs, alcohol, or medication that may a󰀨ect your
ability to properly use the tool.
19. USE SAFETY GOGGLES AT ALL TIMES that comply
with ANSI Z87.1. Normal safety glasses only have
impact resistant lenses and are not designed for safety.
Wear a face or dust mask when working in a
dusty environment.
20. Use ear protection such as plugs or mu󰀨s during
extended periods of operation.
!
!

3WWW.SENIXTOOLS.COM
SAFETY
SPECIFIC RULES FOR HEDGE TRIMMERS
WARNING — Do not let comfort or familiarity with
product (gained from repeated use)
replace strict adherence to product
safety rules. If you use this tool
incorrectly, you can su󰀨er serious
personal injury!
1. Keep all parts of the body away from the cutter blade.
Do not remove cut material or hold material to be cut
when blades are moving. Make sure the switch is o󰀨
when clearing jammed material. Blades coast after turn
o󰀨. A moment of inattention while operating the hedge
trimmer may result in serious personal injury.
2. Carry the hedge trimmer by the handle with the cutter
blade stopped. Proper handling of the hedge trimmer will
reduce possible personal injury from the cutter blades.
WARNING — Keep hands away from blade. Use
both hands when operating the hedge
trimmer. Using one hand could cause
loss of control and result in serious
personal injury.
3. Hold the hedge trimmer by insulated gripping surfaces
only, because the cutter blade may contact hidden
wiring. Cutter blades contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
4. When using the hedge trimmer, always use caution and
stand in a rm, well-balanced position. Avoid working on
wet and slippery ground or uneven terrain.
5. Never run with the hedge trimmer. Keep your eyes open,
paying full attention to your surroundings.
6. Do not use the hedge trimmer if you are unable to hold
it with both hands. Do not overreach in an attempt to
get hard-to-reach branches. Always hold the trimmer
properly with two hands during operation.
7. Never allow children to operate the hedge trimmer. Make
sure anyone that operates the hedge trimmer has fully
read and understood these instructions.
8. Do not use the machine with children or pets in the
vicinity. Do not use if you’ve ingested drugs, alcohol, or
any medications that may slow your reaction time.
9. Do not use the hedge trimmer if the guards or parts have
been damaged.
10. Always wait until the cutting device has come to a
complete stop before removing the battery from the
hedge trimmer.
11. Remove the battery before transporting the unit or
performing any kind of maintenance. Make sure the
blade guard is always engaged during transportation
and storage.
12. Make sure the tool is o󰀨 before inserting the battery.
13. Check for foreign objects in the hedges such as wire
fences before operation.
!
!

4 WWW.SENIXTOOLS.COM
COMPONENT LOCATION
COMPONENT LOCATION
KNOW YOUR HEDGE TRIMMER
3
6
7
4
1
2
5
1 — Blade
2 — Front Guard
3 — Front Handle
4 — Safety Switch
5 — Battery1
6 — Trigger
7 — Rear Handle
8 — Blade Guard (Not pictured)
1 Battery sold separately

5WWW.SENIXTOOLS.COM
OPERATION
OPERATION
ATTACH /REMOVE THE BATTERY
CAUTION: Only use a Senix-approved battery
and charger.
Note: The battery is not fully charged at the time of
purchase. Charge it fully before using it for the
rst time.
To insert the battery, slide it into the back of the unit until a
“click” is heard. Make sure the battery is fully inserted and
latched into position.
To remove the battery, press the release button and slide
the battery out.
WARNING — Do not insert or remove the battery while
the trigger is pressed or while the unit is
in motion.
PREPARING THE HEDGE TRIMMER
Before starting the hedge trimmer, check that the trigger
switches and safety switches are moving freely, returning
automatically and quickly upon release. Also check that the
cooling air vents are not obstructed and that both the front
and rear handles are clean and dry.
STARTING THE HEDGE TRIMMER
The hedge trimmer is equipped with a two-handed safety
switch. In order to power the machine on, you must press
both the front handle’s safety switch and the rear handle’s
trigger switch simultaneously. Always hold the hedge
trimmer with both hands during operation.
TRIMMING HEDGES
A hedge trimmer is primarily used to cut hedges, but can
also be used on shrubs and bushes as well. For the best
results, angle the blade of the hedge trimmer 15° from the
targeted hedge.
A string or tie can be used as a guideline in order to create
a level hedge. Position the string at the preferred height
and cut everything that protrudes past it.
The unit can be used in either direction. Use a sweeping
motion back and forth for even cuts. Avoid cutting limbs
and branches larger than 2/3 of an inch.
Do not force the hedge trimmer through heavy shrubbery.
If the blades become jammed, immediately release the
trigger and remove the battery pack.
Always be careful of ying debris during operation. Wear
gloves when trimming thorny or prickly foliage.
!
!

6 WWW.SENIXTOOLS.COM
MAINTENANCE
MAINTENANCE
WARNING — Remove the battery before inspecting,
adjusting, performing maintenance, or
cleaning the unit.
CLEANING
Keep all safety devices, air vents, and motor housing free
of debris and dirt.
Wipe o󰀨 the housing and the plastic components using a
moist, soft cloth. Do not use strong solvents or detergents
on the plastic housing or plastic components. Certain
household cleaners may cause damage or cause a shock
hazard.
CARBON BRUSHES
The carbon brushes need to be replaced by a
qualied service technician. Do not attempt to replace
them yourself.
LUBRICATION
For a long lifespan, make sure that the cutters are cleaned
and lubricated at regular intervals in order to ensure the
best possible performance. Routinely apply a thin lm of
lubricating oil.
SHARPENING THE BLADES
Remove the battery then clamp the blade assembly into
a vise. Make sure the main body of the hedge trimmer is
adequately supported to avoid damage.
File down the exposed cutting surface of each blade with
an 8 inch smooth round le with a diameter of 1/4 to 7/32 of
an inch. Make sure to retain the original angle of the cutter
teeth when ling.
In order to le both sides of each cutter tooth, you may
need to momentarily run the hedge trimmer until the
opposing side of the cutter teeth are exposed.
Do not run the hedge while it is locked into the vise. Make
sure all tools for sharpening have been removed before
installing the battery. Remove the battery pack and repeat
the sharpening process for the newly exposed teeth.
STORAGE
Examine the unit thoroughly for worn, loose or damaged
parts. If you need to repair or replace a part, contact Senix
customer service at 1-800-261-3981.
• Clean the unit before storing or transporting. Be sure to
secure the unit while transporting.
• Remove the battery from before storing.
WARNING — Shorting the battery terminals together
may cause burns or a re.
• When battery pack is not in use, keep it away from other
metal objects like paper clips, coins, keys, nails, screws,
or other small metal objects that can make a connection
from one terminal to another.
• Store the unit in a clean, dry place. Cover it in order to
provide added protection.
!
!

7WWW.SENIXTOOLS.COM
PARTS
PARTS
EXPLODED VIEW

8 WWW.SENIXTOOLS.COM
PARTS
No. Part # Description Qty. No. Part # Description Qty.
1 Battery Housing 113.4 Screw 2
2 Switch 113.5 626 Bearing 1
3Switch Spring 2 13.6 Spindle Bushing 1
4 Trigger 113.7 Gear 1
5 PCB Board 113.8 Output Shaft 1
6 PCB Guard 113.9 608Z Bearing 2
7 Battery Spring 113.10 Output Shaft Assembly 1
8 Left Housing 113.10.1 Output Shaft 1
9Handle Assembly 113.10.2 Drive Gear 1
9.1 Countersunk Screws 4 13.10.3 Wobbler 2
9.2 Left Plate 113.10.4 Blade Assembly 1
9.3 Right Plate 113.10.5 Blade Spacer 1
9.4 Front Handle 113.10.6 Base Plate 1
9.5 Spring 113.10.7 Pin 2
9.6 Handle Support 113.11 Bushing 1
9.7 Hand Guard 113.12 607 Bearing 1
9.8 Screws 213.13 End Cover 1
10 Switch 113.14 Screw 4
11 Insulator 214 Guide Bar Sheath 1
12 Screw 215 Battery Latch 1
13 Gear Box Assembly 116 Insulator 2
13.1 Motor Assembly 117 Screw 2
13.1.1 Stator/Rotor 118 Right Housing 1
13.1.2 Motor Gear 119 Screws 15
13.2 Hex Nuts 220 Battery 1
13.3 Gear Box 121 Charger 1
For replacement parts, email: [email protected].

9WWW.SENIXTOOLS.COM
WARRANTY
WARRANTY
LIMITED TWO-YEAR WARRANTY
