Sennheiser IE 800 S User manual

DE Bedienungsanleitung
EN Instruction manual
JA 取扱説明書
FR Notice d’emploi
ES Instrucciones de manejo
PT Manual de instruções
NL Gebruiksaanwijzing
IT Istruzioni per l’uso
DA Betjeningsvejledning
SV Bruksanvisning
FI Käyttöohje
EL ȅįȘȖȓİȢȜİȚIJȠȣȡȖȓĮȢ
PL Instrukcja obsługi
TR Kullanma kılavuzu
RU ɂɧɫɬɪɭɤɰɢɹɩɨɷɤɫɩɥɭɚɬɚɰɢɢ
ZH 使用说明
TW 使用說明書
KO 斲殯橎喺昢
ID Buku Petunjuk
EE Kasutusjuhend
LV Lietošanas instrukcija
LT Naudojimo instrukcija
CS Návod k použití
SK Návod na obsluhu
HU Kezelési útmutató
RO Instruciuni de utilizare
BG Ɋɴɤɨɜɨɞɫɬɜɨɡɚɨɛɫɥɭɠɜɚɧɟ
SL Navodila za uporabo
HR Upute za upotrebu
IE 800 S
High-end in-ear headphones
IE 800
S
Hi
gh
-end in-ear he
a

1
3
45
A
2
For more information on Comply™Foam Tips: www.complyfoam.com/sennheiser
Comply is a registered trademark of Hearing Components.
Left
Right
M
M
S
L
Silicone
ComplyTM
15 s

B
Y-Divider
2.5 mm
BALANCED
• HiRes Player
• Mobile
Headphone
Amplifier
3.5 mm
UNBALANCED
• Music Player
• Smartphone
4.4 mm
BALANCED • Headphone Amplifier
• Music Player

C
D
E
Silicone
12 h

R–
R+
L+
L–
L+
L–
R+
R–
GND nc
L+
L–
R+
R–
L+
R+
L/R–
Y-Divider
Pinbelegung | Pin assignment | ピン割り当て | Brochage |
Asignación de pines | Esquema dos pinos | Pinbezetting |
Piedinatura | Stikbenskonfiguration | Kontaktschema |
Nastajärjestys | ǹȞIJȚıIJȠȓȤȚıȘĮțȡȠįİțIJȫȞ | Układ pinów |
Pin ataması | Ɋɚɫɩɚɣɤɚɤɨɧɬɚɤɬɨɜ| 引脚分配 | 插䳾ٯᕍ| 䂅䂥Ḿ |
Penetapan pin | Pistikutikkude määrangud | Kontaktu piešķire |
Kojelių išdėstymas | Zapojení pinů | Obsadenie pinov |
Tüskekiosztás | Alocare pini | Разположение на изводи |
Konfiguracija pin | Raspored pinova
2.5 mm
3.5 mm
4.4 mm

1
IE 800 S | English
ENJAFRESPTNLITDASVFIELPLTRRUZHTWKOIDEELVLTCSSKHUROBGSLHR DE
Important safety instructions
ǑRead the instruction manual carefully and completely before using
the product.
ǑAlways include the instruction manual when passing the product on to
third parties.
ǑDo not use an obviously defective product.
Preventing damage to health and accidents
ǑProtect your hearing from high volume levels. Permanent hearing
damage may occur when headphones are used at high volume
levels for long periods of time. Sennheiser headphones sound
exceptionally good at low and medium volume levels.
ǑDo not insert the ear canal phones too deep into your ears and never insert
them without ear adapters. Always extract the ear canal phones from your
ears very slowly and carefully.
ǑAlways maintain a distance of at least 10 cm/3.94” between a cardiac
pacemaker, implanted defibrillator (ICD) or other implants and the ear
pieces or the carrying case since the product and the clasp of the carrying
case generate permanent magnetic fields.
ǑKeep the product, accessories and packaging parts out of reach of children
and pets to prevent accidents and choking hazards.
ǑDo not use the product in an environment that requires your special
attention (e.g. in traffic).
Preventing damage to the product and malfunctions
ǑAlways keep the product dry and do not expose it to extreme temperatures
(hairdryer, heater, extended exposure to sunlight, etc.) to avoid corrosion or
deformation.
ǑDo not drop the product. The ceramic housing is brittle and may shatter
when hitting hard surfaces.
ǑUse only attachments/accessories/spare parts supplied or recommended
by Sennheiser.
ǑClean the product only with a soft, dry cloth.
Intended use / Liability
These dynamic, closed in-ear headphones have been designed for use with
portable music players and hi-fi systems.
It is considered improper use when the product is used for any application not
named in the corresponding product documentation.
Sennheiser does not accept liability for damage arising from improper use or
misuse of this product and its attachments/accessories.

2
English | IE 800 S
Package contents
1 IE 800 S ear canal phones, cable length approx. 0.25 m
Connection cable
1 2.5mm stereo jack plug, balanced, length approx. 1 m
1 3.5mm stereo jack plug, length approx. 1 m
1 4.4mm Pentaconn stereo jack plug, balanced, length approx. 1.1 m
Ear adapters (in pairs):
3 silicone ear adapters, size S, M (pre-mounted to the IE 800 S) and L
3 Comply™ ear adapters, size S, M, L
1 instruction manual
1 carrying case
1 microfiber cloth
Your IE 800 S
• High-fidelity ear canal phones for natural, balanced sound and high
noise isolation
• Improved acoustics with refined bass reproduction
• Sennheiser proprietary wide-band transducers of only 7 mm in diameter
• Patented dampened two-chamber absorber (D2CA)
• Ergonomically designed ear pads from Comply™
• Two protection meshes – one in the silicone ear adapter and one in the
nozzle – for easy cleaning
• Matte black ceramic housing
• Premium leather carrying case
• Engineered and handcrafted in Germany
ASelecting the ear adapters and inserting the ear canal
phones into the ears*
The perceived sound quality and bass performance of the ear canal phones
depends to a large extent on the correct fit of the ear canal phones in the ear.
Figure out which ear adapter type and size suits you best in terms of both
sound quality and wearing comfort.
Silicone
ǑInsert the ear canal phones into the ears. Select ear adapters of the correct
size (S, M or L) so that the ear canal phones sit comfortably and securely in
your ears.
* Illustrations can be found on the fold-out pages.

3
IE 800 S | English
ENJAFRESPTNLITDASVFIELPLTRRUZHTWKOIDEELVLTCSSKHUROBGSLHR DE
Comply™
ǑRoll the Comply™ ear adapters between your fingers and insert the ear canal
phones into the ears. Hold the ear canal phones for at least 15 seconds so
that the compressed Comply™ ear adapters can expand and sit snuggly in
your ear.
BSelecting and connecting the connection cable*
• 2.5mm stereo jack plug, balanced signal transmission, 4-pin
• 3.5mm stereo jack plug, unbalanced signal transmission, 3-pin
• 4.4mm Pentaconn stereo jack plug, balanced signal transmission, 5-pin
COptimum cable routing*
DCleaning*
For reasons of hygiene, the ear adapters should be replaced from time to
time. (The Comply™ ear adapters only have a durability of a few months
due to their material properties.) Spare ear adapters are available from your
Sennheiser partner. To find a Sennheiser partner in your country, search at
www.sennheiser.com.
ǑClean the product only with a soft, dry cloth (supplied).
ǑYou can clean the silicone ear adapters under lukewarm running water.
Let the ear adapters air dry at room temperature for at least 12 hours before
re-attaching them to the ear canal phones.
ETransporting and storing the IE 800 S*
Specifications
Transducer principle dynamic, closed
Frequency response 5 to 46,500 Hz
Frequency response diffuse-field equalized
Ear coupling in-ear
Impedance 16 Ω
Sound pressure level
125 dB at 1 kHz, 1 Vrms
compliant to IEC/EN 62368-1 (tested accor-
ding to EN 50332-2)
Total harmonic distortion (THD) < 0.06% (1 kHz, 94 dB)
Attenuation 26 dB
Cable oxygen-free copper cable (OFC)

4
English | IE 800 S
Connector
(see pin assignment on
inside cover)
stereo jack plug, gold-plated
3.5 mm, unbalanced, 3-pin
2.5 mm, balanced, 4-pin
4.4 mm, balanced, 5-pin
Weight approx. 8 g (without cable)
Operating temperature 10°C to +55°C
Manufacturer Declarations
Warranty
Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on
this product. For the current warranty conditions, please visit our website at
www.sennheiser.com or contact your Sennheiser partner.
In compliance with the following requirements
• General Product Safety Directive (2001/95/EC)
Compliant to Sound Pressure Limits according to country specific
requirements.
EU declaration of conformity
• RoHS Directive (2011/65/EU)
The full text of the EU declaration of conformity is available at the
following internet address: www.sennheiser.com/download.
Notes on disposal
• WEEE Directive (2012/19/EU)
The symbol of the crossed-out wheeled bin on the product, the
battery/rechargeable battery (if applicable) and/or the packaging
indicates that these products must not be disposed of with
normal household waste, but must be disposed of separately at the end of
their operational lifetime. For packaging disposal, please observe the legal
regulations on waste segregation applicable in your country.
Further information on the recycling of theses products can be obtained from
your municipal administration, from the municipal collection points, or from
your Sennheiser partner.
The separate collection of waste electrical and electronic equipment, batte-
ries/rechargeable batteries (if applicable) and packagings is used to promote
the reuse and recycling and to prevent negative effects caused by e.g. potenti-
ally hazardous substances contained in these products. Herewith you make an
important contribution to the protection of the environment and public health.

5
IE 800 S | English
ENJAFRESPTNLITDASVFIELPLTRRUZHTWKOIDEELVLTCSSKHUROBGSLHR DE
FOR AUSTRALIA ONLY
Sennheiser’s goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a
major failure. This warranty is in addition to other rights or remedies under law.
Nothing in this warranty excludes, limits or modifies any liability of Sennheiser
which is imposed by law, or limits or modifies any remedy available to the
consumer which is granted by law.
To make a claim under this warranty, contact Sennheiser Australia Pty Ltd,
Unit 3, 31 Gibbes Street, Chatswood NSW 2067, AUSTRALIA
Phone: [phone], email: [e-mail].
All expenses of claiming the warranty will be borne by the person making
the claim.
The Sennheiser International Warranty is provided by
Sennheiser Australia Pty Ltd (ABN 68 165 388 312), Unit 3, 31 Gibbes Street,
Chatswood NSW 2067 Australia.

Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany
www.sennheiser.com
Publ. 09/17, 576002/A02
