senses akustik MIDI User manual

INSTALLATION MANUAL|MIDI

Senses Akustik I Installation manual IMidi
Assembly Guide - Important Information
This assembly guide is specifically for the right-hand opening door of the
Kolo Midi unit without furniture.
1.
2. The packaged Kolo Duo unit weighs 406 kg and should be installed by 2-3
individuals. The installation process typically takes an average of 30 to
45 minutes.
3. Exercise caution during assembly and ensure that the installation site is
protected to prevent any injuries or damage to the product or its
surroundings.
4. Position and assemble the Kolo Midi unit as close as possible to its final
placement. If necessary, the fully assembled unit can be repositioned by
retracting the four levelling feet and moving it using the bottom rollers.
However, be cautious not to push the unit against the direction of the
rollers to avoid tipping or damaging them.
5. Ensure that you have all the required tools & parts listed from page
03 to 07 before starting the assembly process.
6. We recommend maintaining a minimum of 30 cm of space between the
wall or between multiple units of the Kolo Midi.
7. Verify that the power source for the Kolo Midi can safely handle a load of 10
amps. When the ventilation is active, the LED light is at its full illumination,
and the power charging station is not in use, the wattage usage is 14W.
The power cord fuse is set at 7 amps to prevent overloading.
8. The Kolo Duo unit includes 2 AC power outlets and 2 USB charging outlets.
Do not connect any electronic devices that require more than 5 amps.

Senses Akustik I Installation manual IMidi
Required Tools
Drill
Ratchet Wrench - Metric Socket Phillips Screw Driver
90 Degree Drill Adaptor Rubber Mallet
Allen Key Set

Senses Akustik I Installation manual IMidi
Part Last
Tool Kit: Screw Pack Tool Kit: Power Cord
Floor Corner
Nº1-1 Nº1-2
Nº2-1
x1
x1
x1
M4x40mmL x2
Dowel Pin
Nº1-3
x8
Exterior Handle
Nº1-4
x1 Mounting Plate
Nº1-5
x2 Rose
Nº1-6
x2
Interior Handle
Nº1-7
x1
Nº1-8
Bottom Socket Cover Tile x2
Nº6
Screw Cover Double
Nº1-10
x9
Nº1-11
Screw Cover Single
Nº1-9
x2

Senses Akustik I Installation manual IMidi
Frame Corners
Nº10
x8
Horizontal Frame Covers
Nº8-2
x4
Horizontal Frames
Nº8-1
x4
Roof
Nº7
x1
Floor
Nº6
x1Side Wall
Nº5
x1Side Wall + Electric
Nº4
x1
Roof Corner
Nº3-1
x1 Roof Corner + E lectric
Nº3-2
x1
Vertical Frame Covers
Nº9-2
x4
Vertical Frames
Nº9-1
x4
Floor Corner + Electric
Nº2-2
x1

Senses Akustik I Installation manual IMidi
Side Floor PET Tiles x2
Nº15
Glass Door
Nº13
x1
Center Floor PET Tile
Nº14
x1
Nº17
Bottom Side Panels x2
Nº16
Top Side Panels x2
Side Glass
Nº11
x4 Back Glass
Nº12
x1

Senses Akustik I Installation manual IMidi
Tool Kit: Screw Pack List
M8 x 50 M8 x 25 Spring Washer
A / B C D
E
x48
x24 x48
M4 x 25 x11
F
M4 x 25 x4

Senses Akustik I Installation manual IMidi
Step 1.
Nº2-1
Floor Corner
Nº2-2
Floor Corner + Electric
Nº6
Floor
M8 x 50
Bx4
Dowel Pin
Nº1-3 x4
Handle with care! Parts are NOT fully assembled
out of the packaging. Please disjoint the parts
before proceeding with the following step
HEADS UP

Senses Akustik I Installation manual IMidi
Step 2.
Yellow
Green
Internet
(Yellow)
Montior
(Green)
Yellow Green
Internet
(Yellow)
Montior
(Green)
M8 x 50
Ax4
M8 x 50
Ax4
Nº4
Side Wall + Electric
Nº5
Side Wall

Senses Akustik I Installation manual IMidi
Handle with care! Parts are NOT fully assembled
out of the packaging. Please disjoint the parts
before proceeding with the following step.
HEADS UP
Step 3.
M8 x 50
Bx4
Nº3-1
Roof Corner + Electric
Nº3-2
Roof Corner
Dowel Pin
Nº1-3 x4
Nº7
Roof

Senses Akustik I Installation manual ISenses Akustik I Installation manual IMidi Senses Akustik I Installation manual IMidiMidi Senses Akustik I Installation manual IMidi
Step 4.
M8 x 50
Ax4
M8 x 50
Ax4

Senses Akustik I Installation manual IMidi Senses Akustik I Installation manual IMidi
Step 5.
Nº8-1
Horizontal Frame
Spring Washer
Dx7
M8 x 25
Cx7

Senses Akustik I Installation manual ISenses Akustik I Installation manual IMidi Senses Akustik I Installation manual IMidiMidi Senses Akustik I Installation manual IMidi
Step 6.
Nº9-1
Vertical Frame
Nº10
Frame Corner
Spring Washer
Dx5
M8 x 25
Cx5

Senses Akustik I Installation manual IMidi
Step 7.
Nº11
Side Glass
Nº12
Back Glass

Senses Akustik I Installation manual IMidi
Step 8.
Nº8-2
Horizontal Frame Cover
Nº9-1
Vertical Frame
Nº10
Frame Corner

Senses Akustik I Installation manual IMidi
Step 9.
Nº9-1
Vertical Frame
Spring Washer
Dx5
M8 x 25
Cx5

Senses Akustik I Installation manual IMidi
Step 10.
Nº9-2
Vertical Frame Cover
Nº9-2
Vertical Frame Cover
Nº8-2
Horizontal Frame Cover
Nº8-1
Horizontal Frame Nº10
Frame Corner
Nº10
Frame Corner
Nº10
Frame Corner

Senses Akustik I Installation manual IMidi
Step 11.
Spring Washer
Dx5
M8 x 25
Cx5

Senses Akustik I Installation manual IMidi
Step 12.
FRONT
Spring Washer
Dx5
M8 x 25
Cx5
Nº8-1
Horizontal Frame

Senses Akustik I Installation manual IMidi
Step 13.
FRONT
Nº9-1
Vertical Frame
Spring Washer
Dx5
M8 x 25
Cx5
Nº10
Frame Corner
