Sensio SE10615C0 User manual

IMPORTANT: please read these instructions before commencing installation and retain for future reference.
INSTALLATION
INSTRUCTIONS
1 x VIVA MULTI LED
FLEXIBLE STRIP
CODE: SE10615C0/W0, SE10625C0/W0, SE10645C0/W0
Safety instructions
1. Before commencing installation or maintenance, isolate
the main electrical supply for the appropriate circuit at the
fuse board.
2. This product is only suitable for connecting to a 240V 50Hz
supply with use of a 24V driver.
3. The light should be mounted onto a secure surface.
4. Never exceed the total output of the LED Driver you are using.
5. Suitable for furniture lighting.
6. When the lamp expires the tting must be replaced.
7. Class III safety extra low voltage (SELV).
Waste Electrical & Electronic Equipment (WEEE)
The symbol on the product, or on the document accompanying the product, the crossed out wheelie bin
symbol, indicates that this product may not be treated as household waste. Instead it shall be handed over to
the applicable collection point for the recycling of electrical and electronic waste.
Please read these instructions carefully before attempting to
install this product. It is advisable to keep these instructions in a
safe place for further reference.
We recommend that you consult a qualied electrician.
All electrical installations must be carried out in accordance
with current IEE wiring regulations (BS7671).
These products must not be modified, if any modifications are
made it may invalidate the warranty and may render the
product unsafe. These LED lights operate low voltage (24V).
•Do not wire the individual LED light fittings directly to the
mains. This product is for indoor use only. The silicone
coated part of the fitting is IP54 rated so is protected
against dust and splashing water.
• Install on smooth flat surface(s) only
• Make sure that the appropriate LED driver is used with this
flexible strip.
• The SE10314 driver connection lead is required to use this
product.
Components Tools Required
Important safety information
Scissors 6mm Drill Bit Power DrillFitting Instructions1x Flexible Strip
1 x End cap

1 x VIVA MULTI LED FLEXIBLE STRIP
Maintenance & Care
• Ensure that the power is disconnected prior to cleaning.
• Wipe over with a dry or slightly damp cloth only.
• Do not use harsh chemical solvents, it may dis-colour or damage the nish.
Sensio, Unit 7, Speedwell Road, Whitwood, Castleford, West Yorkshire, WF10 5PY
www.sensio.co.uk
Installation
1 2
Measure the length of each area to which the strip is
to be installed.
Fittings can be directly interlinked via the male &
female connectors on each tting. Interlink ttings
to achieve the required length before beginning
installation.
The exible strip can be cut once. Cut points are
every 50mm along the strip. Re-use a cut section
of the strip ONCE using the mini-cut connector
(SE10318MCC).
3
Connect the last strip in the run to the driver
connection cable (SE10314). Replace the end cap on
the other end of the strip to protect the tting.
4
Ensure the surface to which the strip is being applied
is clean. Remove the paper protecting the adhesive
on the back of the strip. Position the strip carefully
ensuring it is straight, and only when you are happy
with the position rmly press into place. We suggest
that the strip is not removed and re-applied.
Plug the connector on the end of the cable into the
24V LED driver distribution block. Ensure the wattage
of the LED driver is not exceeded. Finally, connect the
driver to the mains supply.
If hiding driver in cabinet a 6mm hole cut is
required to feed the cable through.
5 6
Accessories
SE10314
2.5M Driver Connection
*This item is required to
run the exible strip
SE10316
50mm Corner
Connection Lead
Get around 90 degree bend
without breaking the run
of strips running from one
driver connection lead.
Technical drawings are for illustrative purposes only. Sensio has the right to change any information without prior notice.
Make sure you check all hole cut outs before work commences.
The driver connection lead is an essential accessory to power EACH RUN of the exible LED strip light.
SE10317
1500mm Inter
Connecting Lead
Used to get around
appliances without
breaking the run of strips. 

SE10318MCC
Cut Joining
Connecting clip
