SENSIT Technologies ULTRA-TRAC APL User manual

MADE IN USA
ULTRA-TRAC® APL nds unmarked
underground pipe fast and accurately!
Innovative Detection Solutions
Locates
Plastic Pipe!
Locates
Plastic Pipe!
www.rjmcompany.com

ULTRA-TRAC® APL is the perfect choice for accurately locating
unmarked buried piping systems. APL nds plastic pipe systems and
other pipelines with broken or missing tracer wire. Natural gas, water
and sewer laterals are easily traced with no system access required!
The APL Tablet application processes and converts acoustic data into a
graphical format to determine pipe location.
Acoustic Pipe Locator (APL) nds unmarked underground pipe, reducing potential third party damages.
ULTRA-TRAC® APL
Standard Features:
• Large Graphic Display
• 25 Hour Recharge Battery Life
• Compact Storage
Types of Materials Located:
• Gas Piping • Plastic Pipe
• Gathering Lines • Metallic Pipe
• Sewer Laterals • Concrete Pipe
• Water Lines • Cast Iron
• Drainage Lines • Ductile Iron
• Electrical Conduit • Clay Tile
• Fiber Optic Conduit • And more
Soil Types & Coverings:
• Grass • Concrete
• Asphalt • And more
• Gravel
ULTRA-TRAC®APL is
• Rugged
• Easy to Use
• Easy to Interpret
• Made in USA
Locate Plastic Gas Pipe!

STANDARD KIT
ULTRA-TRAC APL
Carrying Case
Recharge Adapter
Measuring Tape
Instruction Manual
Quick Start Guide
SPECIFICATIONS
Size (inches): Handle 48; Base 20” X 10” X 10” (L x W x H)
Weight: 26 LBS
Operational Temp: - 4°F to 122°F (-20°C to 50°C)
Storage Temp: -20°F to 140°F (-29°C to 60°C)
Battery life: Base: 25 hours
Tablet: 6 hours
Battery Type: Base: 16vdc Lithium-ion
Tablet: 7.4vdc Lithium-ion
Recharge Time: Base: 10 hours
Tablet: 3 hour
Time Per Slice: <2 seconds
Time Per 20 Slice Scan: <2 minutes
DETECTION SPECIFICATIONS
Optimal Detection Range
Locates 1/2” pipe at a depth of 12” to 30.”
Locates 2” pipe at a depth of 12” to 48.”
Locates 4” pipe at a depth of 12” to 96.”
The APL will not detect objects less than 12” deep.
Accuracy is within ±18” plus the selected slice distance from pipe location
Detects any pipe material (Does not indicate type of pipe or size of pipe)
CHARGING
INDICATOR
DISPLAY
POWER
BUTTONSCAN
BUTTON
SPEAKER

Distributed by:
© SENSIT TECHNOLOGIES ISSUED: 10-24-2016 REV: 10-25-2016
MADE IN USA
SENSIT Technologies
is in compliance with ISO 9001:2008
ULTRA-TRAC®APL Replacement Part Numbers
Carrying Case Part # 872-00016
Recharge Wall Adapter Part # 871-00029
Measuring Tape Part # 360-00342
APL Instruction Manual Part # 750-00072
APL Quick Start Guide Part # 750-00073
APL Tablet PC Part # 360-00487
Tablet Support Bracket Assembly Pasrt #870-00087
USB Cable Part # 360-00500
APL Dampening Pads Part # 320-00061
Actuator Plate Part # 360-00326
Acceleromter Housing Part # 360-00320
ULTRA-TRAC®APL - Quick Start Instructions
1. Press and Hold the APL power button until the light begins to
ash. Once initialized, the APL power button will glow solid
green.
2. Power on the tablet by pressing the tablet power button.
3. The APL application will automatically start. When loading,
the SENSIT logo will be displayed.
4. Click the grey “Connect to APL” button. Once connected,
the button will turn green.
5. On the bottom right hand corner of the screen, select job
settings based on site conditions.
6. Select surface type; Hard or Soft. Site conditions will
determine the proper setting. If unsure, consult the manual.
7. Select the suspected depth of the target line, based on
system knowledge. If between 12” and 5’ deep, select
Normal mode. If the line is suspected to be greater than 5’
in depth, select Deep.
8. Select scan direction. If stepping to the left, click the left
arrow. If stepping to the right, click the right arrow.
9. Select step distance; either 6” or 12”. If no known surface
structures are present, select 12”. If scanning at a surface
structure, select 6” for a high resolution scan. (6” interval is
used for a higher resolution scan and is recommended for
most applications.)
10. When the menu displays “Ready for reading,” the APL is
ready to collect data. User settings will be displayed at the
top of the screen. The APL is now ready to begin a scan.
Instruction Videos available at www.gasleaksensors.com
RJM Equipment Sales, Inc
www.rjmcompany.com
800-620-4773
[email protected]
