SENSIT Technologies GAS-TRAC LZ-30 User manual

851 Transport Drive
Valparaiso, IN 46383-8432
SENSIT Technologies
is in compliance with
ISO 9001:2008
Phone: 888 4SENSIT
888 473 6748
219 465 2700
Fax: [phone]
www.gasleaksensors.com
INSTRUCTION MANUAL

2
FOR YOUR SAFETY
NOTICE: This safety symbol is used to indicate a potentially
hazardous situation which, if not avoided, may result in
minor or moderate injury.
WARNING: Read and understand this manual fully before use.
WARNING: Disassembly and maintenance is forbidden in explosive
atmosphere.
WARNING: Any disassembly or repair of the instrument must be done by
a factory certified technician.
WARNING: Follow the manual instructions and testing methods.
WARNING: Continuously low calibration check results may indicate
sensor end of life or failure. Consult SENSIT Technologies
with any questions.
CAUTION: Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
CAUTION: Do not point the instrument towards the sun, or other extreme
sources of light/heat. Damage may occur.
DANGER: Do not use the device in an explosive environment.
DANGER: Avoid direct eye exposure to the laser and do not point in the
direction of others. Visible and Invisible Lasers are deployed
by this instrument.

3
FOR YOUR SAFETY
CAUTION: Laser radiation. Avoid direct eye exposure. Class 3R
laser product.
LASER WARNING LABEL LOCATION
The laser warning label is located on the back of the instrument. Refer to the
label pictured in the lower right for details.
LASER
APERTURES

4
CONTENTS
For Your Safety ...............................................................................................2
Laser Warning Label Location.................................................................................3
Contents..........................................................................................................4
Parts And Accessories....................................................................................6
Standard Accessories (Included).............................................................................6
Accessories And Replacement Parts ......................................................................6
General Description.........................................................................................7
Specifications ..................................................................................................8
Product Features...........................................................................................10
Beam Dimensions .................................................................................................11
Smart-Link Live (Paid Option).......................................................................12
Sensor Technology .......................................................................................13
Gas Detection........................................................................................................13
Distance Detection ................................................................................................13
Explanation Of PPM•M..................................................................................14
Battery Charging ...........................................................................................15
Operation And Use........................................................................................16
Operation and Use Tips ................................................................................18
Investigating Through Windows ............................................................................18
Shape of the Detection Beam and Line of Sight....................................................19
Shape of the Detection Beam and Line of Sight....................................................20
Wind Conditions and Plume Size..........................................................................21
Locating Targeting Laser.......................................................................................22
Calibration Check (Bump Test).....................................................................23
Calibration .....................................................................................................24
User Menu.....................................................................................................25
Calibration.............................................................................................................26
Bluetooth ID...........................................................................................................26
Set Alarm...............................................................................................................26

5
Set Red Laser .......................................................................................................27
Set Green Laser....................................................................................................27
Set Unit..................................................................................................................27
Distance Units.......................................................................................................28
3 Tier Alarm...........................................................................................................28
Language ..............................................................................................................29
Reset.....................................................................................................................29
Smart-Link Live Setup (Firmware 4.1 or newer) ...........................................30
Maintenance and Care..................................................................................32
Notes.............................................................................................................33
Requirements Under WEEE Regulations .....................................................35
Warranty........................................................................................................36

6
PARTS AND ACCESSORIES
STANDARD ACCESSORIES (INCLUDED)
330-00049 D-ring
331-00155 D-ring screw
360-00040 Wrist Strap
750-00080 Instruction Manual (English)
-01 French
-02 German
-03 Italian
-04 Polish
-05 Spanish
870-00098 Shock Protective Boot
871-00074 Charging Kit (charging base + power supply, for units
with shock protective boot)
872-00035 Hard Carrying Case (for units with shock protective boot)
882-00150-SN Calibration/Bump Test Cell
ACCESSORIES AND REPLACEMENT PARTS
871-00062 Charging Base (for units without shock protective boot)
871-00063 Multi-Blade Power Supply for Charging Base
871-00072 Charging Base (for units with shock protective boot)
871-00064 Charging Kit (charging base + power supply, for units
without shock protective boot)
882-00157 Shock Protective Boot Upgrade Kit

7
GENERAL DESCRIPTION
The GAS•TRAC LZ-30 is a methane selective, laser-based gas detector. The
device is based on world-leading photonic technology and is designed using
the effect that methane gas absorbs a certain laser wavelength, and the
absorbing strength is related to the concentration of the methane.
The device is a handheld gas detector, for the remote detection of methane
and gases containing methane (natural gas and naturally occurring sources of
methane). By pointing its beam of laser light to the testing target, a
concentration result can be read immediately within a distance of 0.5 to 30
meters. By sending the beam of the laser to the target destination, the device
measures the laser signal returned from the target destination. The methane
concentration along the reflected beam path will be calculated and displayed.
In addition, the GAS•TRAC LZ-30 measures the total distance to the target and
displays the result in real-time along with the gas reading.
The laser modules specifications are Class IIIR, with a power output of less
than 5mW for the distance detection laser and spotter laser, and a power
output of less than 50mW for the IR (gas detection) laser.

8
SPECIFICATIONS
Detection Technology: Tunable Diode Laser Absorption Spectroscopy
(TDLAS)
Methane Detection Range: 0-50,000ppm•m in 1ppm•m increments
Sensitivity: 5ppm•m ≤15m (50ft)/10ppm•m ≤30m (100ft)
@ ≥ 300ppm•m
Response Time: ≤0.1 seconds
Detection Distance: 0.5m to 30m (1.5’ to 100’)
Distance may vary slightly depending on reflection
Distance Indicator: 0.2m to 30m (6” to 100’)
Range may vary slightly depending on reflection
Beam Dimension: Conical, 20cm diameter at 30m (8” at 100’)
Alarms: Adjustable threshold alarm with baseline:
Visual, audible, and tactile (vibrating motor)
Default: 100ppm•m
Warnings: Low Reflection, High Reflection,
Low Battery, High Methane
Calibration/Self check: Built-in self-test/bump test and calibration
with test cell incorporated in carrying case
Laser classifications: IR laser (methane detection) Class IIIR
Target laser (green) Class IIIR
Distance laser (red) Class IIIR
Communication: Bluetooth, supported by Android
Display: OLED

9
SPECIFICATIONS
Operational Temp: -20C to 50C (-4F to 122F)
Storage Temp: -40C to 60C (-40F to 140F)
Humidity: ≤98% non-condensing
Enclosure: Designed to meet IP54
Intrinsic Safety: Designed to meet US and ATEX
Weight: 300g (0.7lbs)
Size: 164mm (6.5”) x 78mm (3.0”) x 36mm (1.5”)
Power Source: Internal Lithium Ion, 2000mAh
Battery Life: 6 Hours Continuous
Recharge Time: 3 to 4 Hours

10
DETECTION LASER (IR, NOT
VISIBLE)
DISTANCE LASER (RED)
TARGETING LASER (GREEN)
BACKLIT OLED DISPLAY
DURABLE, FLAME-RETARDANT
POLYCARBONATE HOUSING
OPERATION BUTTONS
CHARGING PINS FOR INTERNAL
RECHARGEABLE BATTERY
PRODUCT FEATURES
GAS•TRAC LZ-30 instruments are constructed of durable flame-retardant
polycarbonate plastic to withstand the rigors of field use.
The housing contains a rechargeable Lithium Ion battery, which is charged by
inserting the instrument into the charging base.
Open-path TDLAS technology ensures that gas detection is instantaneous,
accurate, and methane specific –up to a distance of 30m (100ft).
The operator will be given real-time gas readings on an easy to read OLED
display, displayed in ppm•m by default, along with a distance measurement
for the current target.
The alarm comes in the form of an audible tone, a visual indication via a red
backlight on the measure button, as well as a vibrating motor. There is 1
adjustable alarm threshold, and 2 varying types of alarms at 50% and 100%
of this threshold (low and high). When the high alarm is reached, the
frequency of the audible tone will increase and the vibrating motor will turn on.

11
PRODUCT FEATURES
BEAM DIMENSIONS
The GAS•TRAC LZ-30 produces a conical beam of laser light, that starts from
the front of the instrument and gradually spreads as the distance increases.
At the maximum detection distance, 30m, this beam is 8” in diameter. This is
depicted in the image below (not to scale).
4” at 15m (50ft)
8” at 30m (100ft)
Point Source

12
SMART-LINK LIVE (PAID OPTION)
TRY IT FREE FOR 30 DAYS
SENSIT Technologies offers an app (currently Android only) called SMART-
LINK LIVE that can be used in conjunction with the GAS•TRAC LZ-30. This
app allows the user to continuously capture live readings from the LZ-30,
along with date/time stamps and GPS coordinates. This data can then be
viewed on a map or exported and transferred to a PC.
NOTE: To be compatible with Smart-Link Live, the LZ-30 must have firmware
version 4.1 or newer (displayed on startup).
Access to licensing for the SMART-LINK LIVE app can be purchased along
with the GAS•TRAC LZ-30 when an order is made for a new instrument. If
you already own a GAS•TRAC LZ-30 and want access to the app, contact
SENSIT Technologies to obtain licensing for your instrument. Then, search
“Smart-Link Live” on the Google Play store, select the app, and hit “Install”.
The app is free to install but will not work with your instrument unless you
obtain licensing from SENSIT Technologies, after the 30 day free trial.

13
SENSOR TECHNOLOGY
GAS DETECTION
The GAS•TRAC LZ-30 uses open path TDLAS (tunable diode laser absorption
spectroscopy) technology. The laser generates a specific wavelength of light
that is sent through the gas monitoring area, partially absorbed by any
methane source, and reflected back to the instrument by the reflection surface.
The higher the methane concentration, the larger the absorption will be,
resulting in a higher reading. Using this technology in an open path allows for
the instrument to detect gas remotely, simply by pointing at the target
anywhere from 0.5 to 30 meters away from the operator.
DISTANCE DETECTION
There is a separate laser that is used specifically for distance detection. It
sends a laser pulse to the target in a narrow beam and measures the time
taken from when it leaves the instrument to when it returns, from the reflection
surface. Using this time measurement, the distance is determined based on
the speed of light.
Both the distance and gas detection rely on a surface that is reflective enough
to return the signal to the instrument. Most solid surfaces will work. Changes
in reflectivity can cause variance in both the gas and distance measurements.

14
EXPLANATION OF PPM•M
The GAS•TRAC LZ-30 displays its readings in parts per million meter (ppm•m).
This is a representation of the average gas concentration over 1 meter, or
roughly 3.3 feet.
The detection laser of the GAS•TRAC LZ-30 measures the amount of light
absorbed by a concentration of gas. However, there is no way of knowing the
size of the plume. Because of this, higher concentrations over a small area or
smaller concentrations over a large area can give the same reading on the
screen. While point and shoot technology of this nature is a great indication
tool, and can be used to pinpoint the source of a leak by comparing readings,
it cannot be used to quantify a gas leak.
See the diagram to the right.
On the top, there is a gas
plume 0.5 meter in length with
a concentration of 2,000 ppm
methane. On the bottom,
there is a gas plume 1 meter in
length with a concentration of
1,000 ppm methane. The
GAS•TRAC LZ-30 will see the
same amount of absorption in
both scenarios, and therefore
give the same reading of 1,000
ppm•m.
In addition, in a real-world
scenario there will be some
small amount of background
methane in ambient air. This
is generally about 2 ppm•m.
So for a reading at 30m (100ft),
the reading on the screen
would be about 60 ppm•m
higher.

15
BATTERY CHARGING
The GAS•TRAC LZ-30 has an internal, rechargeable lithium-ion battery pack,
and includes a recharging base. This battery is not user replaceable.
To recharge the internal battery, ensure that the charging base is plugged in
and insert the instrument into the base, bottom first. Contacts on the bottom
of the instrument touch spring loaded pins in the bottom of the charging base
to make an electrical connection.
The LED on the front of the charging base indicates the charging status:
Solid Green & Red flicker: No connection
Solid Red: Instrument charging
Solid Green: Instrument fully charged
Charging takes approximately 3 to 4 hours if the battery is fully depleted.
CHARGING
INDICATION LED

16
OPERATION AND USE
WARNING: When the GAS•TRAC LZ-30 is powered on, the laser
module(s) will be energized.
1. Press and hold the ON/MENU button until the
screen illuminates. The software version will
be displayed during a brief warmup period
(~15 seconds).
2. If the displays fails to illuminate or a low
battery indication is show, place the
instrument in the charging base to charge
the battery.
3. After warmup, the instrument will show the
following on what is called the work display:
a. (Upper left)
Distance measurement
b. (Upper right)
Fuel gauge
c. (Center)
Current methane reading
d. (Lower left)
Peak methane reading
e. (Lower right)
Measurement unit/scale
4. A bump test can be performed before each use. See the “Calibration
Check (Bump Test)” section on page 22 of this manual for more
information.
5. To begin an investigation, press and release the MEASURE button.
During measurement, the targeting laser (green) will flash on and off
continuously, as well as an audible beeping to alert the operator that
a measurement is active. A distance measurement and the current
and peak methane readings will be displayed on the screen.

17
OPERATION AND USE
6. Using the visible targeting laser, survey the area according to federal,
state, municipal, and/or company procedures. Observe the readings
on the display and any alarm conditions that should occur. In general,
it is good practice to conduct investigations using an ‘S’ or ‘Z’ pattern
to maximize the area that is scanned.
7. If at any time the instrument gives a low or high reflection warning,
indicated by REF/L or REF/H on the display as well as an audible tone,
try a different angle, position, or distance in order to increase or
decrease the amount of reflected light. These messages indicate that
the instrument is not getting an appropriate amount of reflected light.
Be aware that not all surfaces may be suitable for reflection.
NOTE: The relative signal strength of the reflected
signal is indicated on the display next to the fuel
gauge.
8. If at any time the instrument displays HIGH METHANE, this is an
overload message indicating that you are detecting gas greater than
the upper detection limit of the instrument (50,000 ppm•m).
9. To stop a measurement, press and release the MEASURE button
again.
10. To access the user menu, press and release the ON/MENU button.
The user menu cannot be accessed if a measurement is currently
active. See the User Menu section of this manual for more details.
11. To power off the instrument, press and hold the OFF/BACK button. A
brief animation will show. Keep the button held down until the screen
goes blank.

18
OPERATION AND USE TIPS
Factors such as line of sight, wind, and sunlight conditions are not something
that most operators have had to take into account in the past. This section
gives a few tips and tricks for getting the most out of the GAS•TRAC LZ-30.
NOTE:Federal, state, municipal, and/or company procedures supersede
what is outlined in this section.
INVESTIGATING THROUGH WINDOWS
The laser technology used in the GAS•TRAC LZ-30 allows the instrument to
detect through standard window glass. This is a big advantage as it allows
the user to investigate the inside of a building (for example) when he/she
otherwise might not have been able to gain access.
In order to get the best results in this type of a scenario, follow these steps:
1. Maintain an angle of attack that is less than 90˚
to your target, and ideally between 45˚and 75˚.
This is depicted in the image to the right.
This greatly reduces the chance of what is
known as “specular reflections”, which is when
a portion of the laser reflects off of the surface
of the window. It is also especially helpful for
double-pane windows where the laser might
reflect/bounce multiple times between the
panes.
2. Use the distance measurement on-screen to
help determine if the lasers are actually
passing through the window. For example, if
the distance measurement on a wall next to
the window reads 15m and on the window
reads 20m, you can be reasonably sure you
are detecting through the window.
If instead they are the same distance, the
laser is just reflecting off of the window. An
anti-reflective coating on the glass may
cause this.
90˚
45˚- 75˚

19
OPERATION AND USE TIPS
SHAPE OF THE DETECTION BEAM AND LINE OF SIGHT
Due to the GAS•TRAC LZ-30 using a point of light for targeting, it can be easy
to forget that the actual detection path is in the shape of a cone, which starts
from a point (the instrument) and gets wider on the path to the target. At a
distance of 30m (100ft.), this width is 20cm (8in.).The operator will get the most
consistent results if he/she keeps as much of this path in/over the target as
possible.
Because of this, some situations can present a challenge, such as if part of
the beam is reflecting off of a different surface than another. This is known as
“beam skipping”. The operator will get the most consistent results if he/she
keeps as much of this beam in/over the target as possible.
In the picture to the right (beam not
to scale), part of the beam is partially
blocked by the fence, potentially
causing reduced sensitivity, or in
some cases, false positives. The
operator should simply move slightly
to the left, ensuring that the full width
of the beam will make it to the target.
If the operator were surveying the
ground behind the fence, this
wouldn’t be too great of a mismatch,
but if the target was the face of the
building in the background, there
would be a very large difference in
return signal between the portion of
the beam that is hitting the building
and the portion that is hitting the
fence.

20
OPERATION AND USE TIPS
SHAPE OF THE DETECTION BEAM AND LINE OF SIGHT
Another thing to consider is that the size of the beam can affect the reading
that the instrument gives, depending on the size of the plume.
Consider the picture to the right: the
green colored beam is roughly the
same size as the plume of gas, which
means that the instrument will be
reading only that plume. In the case
of the red beam, only half of it is
traveling through the plume, meaning
that the result on-screen is going to be
lower because part of what is being
analyzed is gas-free air.
What this means is that the distance
between the operator and the plume
can potentially affect the reading,
because the beam expands with
distance. Realistically, though, it is
unlikely to cause a noticeable effect
due to the gas plume naturally
dispersing over a (relatively) large
area. Where this might be more
noticeable is if the operator is far away
from a very small pinpoint leak. Most
of the beam will not be hitting the
plume, and will lower the reading.
In a real-world scenario, a gas plume doesn’t have strictly defined edges like
this, and the operator obviously won’t be aware of where it is to begin with.
However, what this illustrates is that technology of this nature makes it near-
impossible to get true quantitative results. There are simply too many
variables. Qualitative investigation and pinpointing is where it shines.
800
PPM
~400
PPM•M
800
PPM•M
1 METER
